MJ LED LIGHTNING MJ-1027A User manual

LED MATRIX MOVING HEAD LIGHT
MJ-1027A
User Manual
======PROFESSIONAL STAGE LIGHTING ========
Thank you for choosing our LED matrix moving head light. For the sake of your safety, Please
read and follow these instructions carefully and keep this manual in a safe place for future
reference.

2
Catalogue
Chapter Page
Safe Usage Of The Product -----------------------------------------------------------------------------------------3
Install The Equipment ------------------------------------------------------------------------------------------------4
Power Code Connection ---------------------------------------------------------------------------------------------4
DMX Connection ------------------------------------------------------------------------------------------------------5
DMX Terminator -------------------------------------------------------------------------------------------------------5
Function Set --------------------------------------------------------------------------------------------------------------6
Operation Menu ---------------------------------------------------------------------------------------------------------6
Maintenance --------------------------------------------------------------------------------------------------------------7
Keeping The Product Clean ------------------------------------------------------------------------------------------7
Trouble Shooting---------------------------------------------------------------------------------------------------------7
Equipment and Appendix----------------------------------------------------------------------------------------------7
Channel List---------------------------------------------------------------------------------------------------------------8
Technical Parameters---------------------------------------------------------------------------------------------------11
☆Important notice:
·In this instruction for use contains about the installment and the use aspect important information of the LED moving
head. When installing and using, you need to look this usage instruction strictly.
·Before open the LED moving head and if you want to do the repair work, please make sure the power source is at the
separation condition.
·Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and the unit are
in good condition before installation and use. Should there be any damage caused by transportation, consult your dealer
and do not use the unit. Any damage caused by improper use will not be assumed by the manufacturer or dealer.
Attention: Unceasingly carries on the product improvement about our company the policy, in this instruction booklet
carries the data will have the possibility to be able to change in the future, when no longer separate notice change matters
concerned. Our company retains when the product improvement changes the related specification the authority. This
instruction booklet publisher cannot be responsible regarding this instruction booklet in information accuracy, also cannot
the related consequence which causes regarding these information be responsible.

3
SAFE USAGE OFTHE PRODUCT
When unpacking and before disposing of the carton, check there is no transportation damage before
using the product. Should there be any damage caused by transportation, consult your dealer and do
not use the apparatus.
The product is for indoor use only, IP20. Use only in dry locations. Keep this device away from rain
and moisture, excessive heat, humidity and dust. Do not allow contact with water or any other
liquids.
The product is not designed or intended to be mounted directly on to inflammable surfaces
The product is only intended for installation, operation and maintenance by professional person.
The product must be installed in a location with adequate ventilation, at least 50cm from adjacent
wall surfaces. Be sure that no ventilation slots are blocked.
Do not product the beam onto inflammable surfaces, minimum distance is 5m.
Avoid direct exposure to the light from the lamp. The light is harmful to the eye.
Do not attempt to dismantle or modify the projector in any way.
Electrical connection must only be carried out by qualified personnel.
Before installation, ensure that the voltage and frequency of power supply match the power
requirements of the projector.
It is essential that each projector is correctly earthed and that electrical installation conforms to all
relevant standards.
Do not connect this device to any other types of dimmer apparatus.
Make sure that the power-cord is never crimped or damaged by sharp edges. Never let the
power-cord come into contact with other cables. Only handle the power-cord by the plug. Never pull
out the plug by tugging the power-cord.
Keep the optical system clean. Do not touch the LED lens with bare hands.
The product should always be installed with a secondary safety fixing. On the projector base brink,
there is a hole for the safety cord provided. It should be attached as shown in “installing the projector”
section.
LED lens shall be changed if they have become visibly damaged to such an extent that their
effectiveness is impaired, for example by cracks or deep scratches.
Exterior surface temperatures of the luminaire after 5 minutes operation is 40°C，when steady state is
achieved 50°C.
There is no user serviceable parts inside the projector, do not open the housing and never operate the
product with the covers removed.
If you have any questions, don’t hesitate to consult your dealer or manufacturer.
★Always disconnect from the mains, when the device is not in use or before cleaning it or
before attempting any maintenance work !

4
Install The Equipment:
Use 2pcs clamp and safety cord(need to purchase).Use clamp fix with light hook which in the
packing box with light, then use screw install to the bottom of lamp. Hang the fixture on the structure
and fasten the screws attached to each clamp. Make sure the light is installed reliable, and confirm
the light which you fixed is strong enough for hanging the light. Base on safety reason, please
according to the above picture using safety wire cross the light to make it strong enough again.
Warning!
1．Hook and clamp only use for hanging the light. Do not use clamp as a tool to move fixtures.
2．Base on safety reason, please use the safety cord which can afford the weight ten times of lamp
through Insurance hole for auxiliary hanging.
3．Don't use the handle of the moving head light to fixed or lift!
Power Code Connection:
Connect the power cord as follows:
L (live) =brown
E (earth) =yellow/green
N (neutral) =blue
Use the plug provided to connect the mains power to the projector paying attention to the voltage and
frequency marked on the panel of the projector. It is recommended that each projector be supplied
separately so that they may be individually switched on and off.
★It is essential that each projector is correctly earthed and the electrical installation conforms
to all relevant standards.

5
DMX Connection:
Connection between the controller and a projector and between one projector and another must be
made with a 2 core-screened cable, with each core having at least a 0.5mm diameter. Connection to
and from the projector is via cannon 3 pin (which are included with the projector) XLR plugs and
sockets. The XLR's are connected as shown in the figure above.
Note: Care should be taken to ensure that none of the pins touch the metallic body of the plug or each
other. The body of the plug is not connected in any way. The XLED 590 accepts digital control
signals in protocol DMX512 (1990).
Connect the controller’s output to the first fixture’s input, and connect the first fixture’s output to the
second fixture’s input and connect the rest fixtures in the same way. Eventually connect the last
fixture’s output to a DMX terminator.
DMX Terminator:
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a
DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control
signals.
The DMX terminator is simply an XLR connector with a 120Ω (ohm) resistor connected across pins
2 and 3, which is then plugged into the output socket on the last projector in the chain. The
connections are illustrated below.

6
Function Set:
A．MENUs
B．UP
C．DOWN
D．ENTER
A B C D
Instructions: Press the function key A will cycle out of different functional effects, digital tube in
which the first two digits represent the current function (see Menu). After two figures represent the
kinds of functions are located. Address code. Or speed parameters. Press B or C keys to modify its
parameters. Press D to confirm.
Operation Menu:（All the functions are according to the selected and then press the D key to confirm）

7
Maintenance:
To prolong the life of the projector, some maintenance work has to be done to ensure the LED
optical system in good condition. If the projector does not function, check the fuses on the power
socket of the projector, they should only be replaced by fuses of the same specification. Should
these be damaged, call a qualified technician before replacement. The projector has thermal
protection device that will switch off the projector in case of overheating. Should either of these
operate, check that the fans are not blocked, and if they are dirty, clean them before switching on the
projector again. Check that the fans are operational, if not, call a qualified technician.
☆Any maintenance work should only be carried out by qualified technicians.
Keeping The Product Clean:
To ensure the reliability of the projector, it should be kept clean. It is recommended that the fans
should be cleaned every 15 days. LED lens should also be regularly cleaned to maintain an optimum
light output.
Cleaning frequency depends on the environment in which the fixture operates: damp, smoke or
particularly dirty surroundings can cause greater accumulation of dirt on the unit's optics. Asoft cloth
and typical glass cleaning products should be used for cleaning. It is recommended to clean the
external optics at least once every 15 days.
☆Do not use any organic solvent, e.g. alcohol, to clean housing of the apparatus.
Trouble Shooting:
Problem
Answer
The LED moving head light doesn’t switch on.
Check the fuse the power socket
Although shines, but the LED moving head
lamp doesn’t accept the instruction of the
controller.
Check the digital start address and also check the
connection situation of the communication control
line
LED moving head lamp only can work
intermittently.
Inspect the power supply and voltage is whether
normal.
Do not receive the DMX512 signal.
Whether the signal lines do contact well or broken.
The light beam appears gloomily.
Check that the heat dissipation system is running
normally or Inspect the optics part is whether clean.
☆Other maintain work should by the specialist which has the experience to carry on.
Equipment and Appendix:
The packing list of this light as follows:
☆Led moving head light 1pcs
☆Power Cable 1pcs
☆XLR connector 1unit
☆Light Hook 2pcs
☆The Product of Instruction 1pcs

8
Channel List:
19CH MODE
Channel Function value Details
CH1
Pan movement
0-255
0-540 degree
CH2 Unlimited Pan
movement
0-55
Pan non movement
56-155
Pan unlimited clockwise rotate slow to fast
156-255
Pan unlimited reversely rotate slow to fast
CH3
Tilt movement
0-255
0-270 degree
CH4 Unlimited Tilt
movement
0-55
Tilt non movement
56-155
Tilt unlimited clockwise rotate slow to fast
156-255
Tilt unlimited reversely rotate slow to fast
CH5
Pan/Tilt speed
0-255
From fast to slow
CH6
Dimmer
0-255
Linear dimmer from dark to bright
CH7 Strobe
0-3
No function
4-95
Strobe with the same step from slow to fast
96-176
Random strobe
177-255
Thunder strobe
CH8
R dimmer
0-255
Red dimmer from dark to bright
CH9
G dimmer
0-255
Green dimmer from dark to bright
CH10
B dimmer
0-255
Blue dimmer from dark to bright
CH11
W dimmer
0-255
white dimmer from dark to brigh
CH12 Effect show of
numbers and
punctuations
0-89
Effect show of numbers from 0 to 9
90-233
Effect show of punctuations
234-235
Running water effect
CH13 Effect show of letters
0-234
Effect show of letters fromAto Z
234-235
Running water effect
CH14 Effect show of static
gobos
0-234
Effect show of static gobos
234-235
Running water effect
CH15
Color of letters
0-255
Color choice for the letters
CH16 Dynamic gobos show
0-234
Effect show of dynamic gobos
234-235
Running water effect
CH17
Speed of effects
0-255
From fast to slow
CH18 Macro Function
0-49
No function
50-74
Numbers and punctuations show(Against CH12)
75-99
Letters show(Operate against CH 13)
100-124
Static gobos show(Operate against CH 14)
125-149
Dynamic gobos show(Operate against CH 16)
150-199
Auto Run
200-255
Sound activated
CH19 Reset
0-250
No function
251-255
Reset within 3 seconds

9
29CH MODE
Channel Function value Details
CH1 Pan movement 0-255 0-540 degree
CH2 Unlimited Pan
movement
0-55 Pan non movement
56-155 Pan unlimited clockwise rotate slow to fast
156-255 Pan unlimited reversely rotate slow to fast
CH3 Pan fine 0-255 16 bit Pan fine adjustment
CH4 Tilt 0-255 0-270 degree
CH5 Unlimited Tilt
movement
0-55 Tilt non movement
56-155 Tilt unlimited clockwise rotate slow to fast
156-255 Tilt unlimited reversely rotate slow to fast
CH6 Tilt fine 0-255 16 bit Till fine adjustment
CH7 Pan/Tilt s peed 0-255 From fast to slow
CH8 Dimmer 0-255 Linear dimmer from dark to bright
CH9 Strobe
0-3 No function
4-95 Strobe with the same step from slow to fast
96-176 Random strobe
177-255 Thunder strobe
CH10 R1 dimmer 0-255 Circle 1 Red dimm er from dark to brigh
CH11 G1 dimmer 0-255 Circle 1 Green dimmer from dark lo bright
CH12 B1 dimmer 0-255 Circle 1 Blue dimmer from dark to bright
CH13 W1 dimmer 0-255 Circle 1 white dimmer from dark to brigh
CH14 R2 dimmer 0-255 Circle 2 Red dimm er from dark to bright
CH15 G2 dimmer 0-255 Circle 2 Green dimmer from dark lo bright
CH16 B2 dimmer 0-255 Circle 2 Blue dimmer from dark to bright
CH17 W2 dimmer 0-255 Area 2 white dimmer from dark to brigh
CH18 R3 dimmer 0-255 Circle 3 Red dimm er from dark to bright
CH19 G3 dimmer 0-255 Circle 3 Green dimmer from dark lo bright
CH20 B3 dimmer 0-255 Circle 3 Blue dimmer from dark to bright
CH21 W3 dimmer 0-255 Circle 3 white dimmer from dark to brigh
CH22 Effect show of
numbers and
punctuations
0-89
Effect show of numbers from 0 to 9
90-233
Effect show of punctuations
234-235
Running water effect
CH23 Effect show of letters
0-234
Effect show of letters fromAto Z
234-235
Running water effect
CH24 Effect show of static
gobos
0-234
Effect show of static gobos
234-235
Running water effect
CH25 Color of letters 0-255 Color choice for the letters
CH26 Dynamic gobos show
0-234
Effect show of dynamic gobos
234-235
Running water effect
CH27
Speed of effects
0-255
From fast to slow

10
CH28 Macro Function
0-49 No function
50-74 Numbers and punctuations show(Against CH22)
75-99 Letters show(Operate against CH 23)
100-124 Static gobos show(Operate against CH 24)
125-149 Dynamic gobos show(Operate against CH 26)
150-199 Auto Run
200-255 Sound activated
CH29 Reset 0-250 No function
251-255 Reset within 3 seconds
117CH MODE
Channel Function value Details
CH1
Pan movement
0-255
0-540 degree
CH2
Unlimited Pan movement
0-55
Pan non movement
56-155
Pan unlimited clockwise rotate slow to
fast
156-255
Pan unlimited reversely rotate slow to fast
CH3
Pan fine
0-255
16 bit Pan fine adjustment
CH4
Tilt
0-255
0-270 degree
CH5
Unlimited Tilt movement
0-55
Tilt non movement
56-155
Tilt unlimited clockwise rotate slow to fast
156-255
Tilt unlimited reversely rotate slow to fast
CH6
Tilt fine
0-255
16 bitTill fine adjustment
CH7
Pan/Tilt s peed
0-255
From fast to slow
CH8
Dimmer
0-255
Linear dimmer from dark to bright
CH9 Strobe
0-3
No function
4-95
Strobe with the same step from slow to fast
96-176
Random strobe
177-255
Thunder strobe
CH10
R1 dimmer
0-255
LED 1 Red dimm er from dark to bright
CH11
G1 dimmer
0-255
LED 1 Green dimmer from dark lo bright
CH12
B1 dimmer
0-255
LED 1 Blue dimmer from dark to bright
CH13
W1 dimmer
0-255
LED 2 white dimmer from dark to brigh
...
......
...
......
...
......
...
......
CH106
R25 dimmer
0-255
LED 25 Red dimmer from dark to bright
CH107
G25 dimmer
0-255
LED 25 Green dimmer from dark to bright
CH108
B25 dimmer
0-255
LED 25 Blue dimmer from dark to bright
CH109
W25 dimmer
0-255
LED 25 white dimmer from dark to bright
CH110
Effect show of numbers
and punctuations
0-89
Effect show of numbers from 0 to 9
90-233
Effect show of punctuations
234-235
Running water effect
CH111 Effect show of letters
0-234
Effect show of letters fromAto Z
234-235
Running water effect

11
CH112 Effect show of static
gobos
0-234
Effect show of static gobos
234-235
Running water effect
CH113
Color of letters
0-255
Color choice for the letters
CH114 Dynamic gobos show
0-234
Effect show of dynamic gobos
234-235
Running water effect
CH115
Speed of effects
0-255
From fast to slow
CH116 Macro Function
0-49
No function
50-74
Numbers and punctuations show(Against CH110)
75-99
Letters show(Operate against CH 111)
100-124
Static gobos show(Operate against CH 112)
125-149
Dynamic gobos show(Operate against CH 114)
150-199
Auto Run
200-255
Sound activated
CH117 Reset
0-250
No function
251-255
Reset within 3 seconds
Technical Parameters:
Construction: Composite plastic, die-casting aluminum,
Voltage: AC100V-240V; 50/60Hz
Power Consumption:300W (220V)
LED Bulbs: 25pcs 12W CREE RGBW 4IN1 LEDs
BeamAngle: 7°
LED Current: 650mA
LED Lifetime: 50000Hours
Colors: RGBW color mixing
Adjusts the light: 0-100 electron adjusts the light, various colors may alone move also may mix the
color tone
Strobe: 1-25/second high speed strobe, but single color Mixes the color strobe
Head Movement: Pan and Tilt endless rotation, Pan 540°, Tilt 270°, with auto position correction
and electronic replacement function.
Control mode: DMX 512, Stand –alone mode, Sound, Master/slave
DMX Channel: 19CH, 29CH,117CH
Control Panel: LCD display panel
IP Grade: IP20
Work Environment Temperature:-20°C~40°C
Net weight:18KG
Gross Weight: 20 kg
Package Size: 420 x 330x 460cm
