MJ LED LIGHTNING MJ-3432A User manual

LED STUDIO LIGHT
MJ-3432A
User Manual
======PROFESSIONAL LED LIGHTING ========
Thank you for choosing our LED studio light. For the sake of your safety, Please
read and follow these instructions carefully and keep this manual in a safe place
for future reference.
6.TECHNICAL PARAMETERS
Voltage: AC100-240V, 50Hz/60Hz
Power Consumption: 216Watts
LED: 432pcs 0.5W SMD LED (WW:216pcs,CW:216pcs)
LED Current: 150mA / 1 pc
LED Beam Angle: 120°
LED Lifetime: 80,000-100,000 hours
Color: Warm white and cool white color mixing
Dimming: 0-100% smooth dimmer
Strobe: 25 Flashes per second
Operation Modes: DMX512, Master-slave, Sound, Internal Program
DMX Control: 4 Channels
Control Panel: Digital 4 Character Alphanumeric
Aluminum heat dissipation system without fan.
Maximum Ambient Temperature: 40° C
Net Weight: 9.6 Kg
Gross Weight:10.8Kg
Package Size: 650×390x150mm
Important notice:
Before open the LED studio light and if you want to do the repair work,
please make sure the power source is at the separation condition.
Unceasingly carries on the product improvement about our company
the policy, in this instruction booklet carries the data will have the
possibility to be able to change in the future, when no longer separate
notice change matters concerned. Our company retains when the
product improvement changes the related specification the authority.
This instruction booklet publisher cannot be responsible regarding this
instruction booklet in information accuracy, also cannot the related
consequence which causes regarding these information be
responsible.

table
）。
LED Top row on behalf of the function in the address code
、
or speed
and other parameters。Press Bor Ckey can modify the parameter value。
Press Dto confirm。
4.MENU DISPLAY FUNCTION TABLE
Please press “A” button to choose function , and press “D” button to confirm.
No. Display Function
1 d001
A001—A512 press “UP” and “Down” button
change the DMX address
2 L255
L000—L255 (Warm white dimming by hand),
press “UP” and “Down” button change the brightness
3 H255 H000—H255 (Cool white dimming by hand)
press “UP” and “Down” button change the brightness
4 P255 P000—P255 (Strobe by hand)
press “UP” and “Down” button change the speed
5 EP00/EP001
EP00 DMX signal keep
EP01 DMX clear
6
NT00
Temperature display
7
DISP
Display inverse
5.DMX FUNCTION
4CH Mode
Channel Value Function
CH1
0-255
Main dimming from dark to bright
CH2
0-255
Control strobe from slowly to quickly
CH3
0-255
Warm white dimming from dark to bright
CH4 0-255 Cool white dimming from dark to bright
2
1.INSTALLATION
1. In order to secure the safe installation of the light, always use it in the
well-ventilated environment.
2. Always keep this light with a safe distance from any flammable materials.
3. Never install, dismantle and maintain this light when it is powered; and all
work aforesaid must be conducted by professionals.
4. The packing list of this light is as follows:
1) LED studio light ---------------------------------------------1pcs
2) Power cable---------------------------------------------------1pcs
3) User manual------------------------------------------------1pcs
2.EFFECT
1. This light operation is very simple, Attractive appearance, Humanized
design, Dim without flicker and shake, Energy-efficient, Durable. It is suitable
for photography, television stations, stage, dance hall, KTV, bar, evening
show.
2. The program of this light can accept manual, DMX512 signal control and
be connected for use.
3.GRAPHIC PART
Operation description
：
Press “A” will cycle out 12pcs different functional
effect, LED Top row in represent the current function（Reference function
1
