MJ LED LIGHTNING MJ-3372 User manual

LED Studio Light-723
MJ-3372
User Manual
======PROFESSIONAL LED LIGHTING ========
Thank you for choosing our LED studio light. For the sake of your safety, Please
read and follow these instructions carefully and keep this manual in a safe place for
future reference.
Important notice:
Before open the LED studio light and if you want to do the repair
work, please make sure the power source is at the separation
condition.
Unceasingly carries on the product improvement about our company
the policy, in this instruction booklet carries the data will have the
possibility to be able to change in the future, when no longer separate
notice change matters concerned. Our company retains when the
product improvement changes the related specification the authority.
This instruction booklet publisher cannot be responsible regarding
this instruction booklet in information accuracy, also cannot the
related consequence which causes regarding these information be
responsible.

IV. Technical Parameters
Voltage: AC100-240V, 50Hz/60Hz
Power Consumption: 216Watts
LED: 3W*72pcs white LED
LED Current: 700mA / 1 pc
LED Beam Angle: 45°
LED Lifetime: 80,000-100,000 hours
Color: white color
Dimming: 0-100% smooth dimmer
Strobe: 10 Flashes per second
Operation Modes: DMX512, Master-slave, Internal Program
DMX Control: 2 Channels
Control Panel: Digital 4 Character Alphanumeric
Maximum Ambient Temperature: 40° C
Net Weight: 7.5 Kg
Gross Weight:8.8Kg
Package Size: 49×40×23.5CM
V. DMX function
2CH mode
Channel Value Function
CH1 0-255 Main dimming from dark to bright
CH2 0-255 Control strobe from slowly to quickly
Warning:
Please do NOT connect the power cable hand by hand over 4pcs.
2
I. Installation
1. In order to secure the safe installation of the light, always use it in the
well-ventilated environment.
2. Always keep this light with a safe distance from any flammable
materials.
3. Never install, dismantle and maintain this light when it is powered; and
all work aforesaid must be conducted by professionals.
4. The packing list of this light is as follows:
1) LED studio light --------------------------------------1pcs
2) Power cable---------------------------------------------1pcs
2) User manual------------------------------------------1pcs
II. Effect
1. This light operation is very simple, Attractive appearance, Humanized
design, Dim without flicker and shake, Energy-efficient, Durable. It is
suitable for photography, television stations, stage, dance hall, KTV, bar,
evening show.
2. The program of this light can automatically operate, sound, accept
DMX512 signal control and be connected for use.
III. Menu display function table
Please press “Menu” button to choose function , and press
“Enter” button to confirm.
No. Display Function
1 A001 A001—A512 (2 channel) press “UP” and “Down”
button change the DMX address
2 DE00 DE01—DE99 (Color change by Pulse), press
“UP” and “Down” button change the Pulse speed
3 U000 U000—U255 (white dimming by hand)
