MJ LED LIGHTNING MJ-2007 User manual

LED WALL WASHER-323
MJ-2007
(32P3W45DRGBW)
User Manual
=======PROFESSIONAL LED LIGHTING ========
Thank you for choosing our LED wall washer light. For the sake of your safety,
Please read and follow these instructions carefully and keep this manual in a safe place for
future reference.

WARNING
Please do NOT connect the power supply before open the light.
Please do NOT use any object to cover the lamp.
Please do NOT use the lamp under the close environment.
Please do NOT use the lamp under the water.
Please do NOT connect the power cable hand by hand over 5pcs.
Important notice:
Before open the LED wall washer and if you want to do the repair
work, please make sure the power source is at the separation
condition.

Unceasingly carries on the product improvement about our
company the policy, in this instruction booklet carries the data will
have the possibility to be able to change in the future, when no
longer separate notice change matters concerned. Our company
retains when the product improvement changes the related
specification the authority. This instruction booklet publisher cannot
be responsible regarding this instruction booklet in information
accuracy, also cannot the related consequence which causes
regarding these information be responsible.
4
1. Installation:
1. In order to secure the safe installation of the light, always use it in the
well-ventilated environment.
2. Always keep this light with a safe distance from any flammable materials.
3. Never install, dismantle and maintain this light when it is powered; and all
work aforesaid must be conducted by professionals.
4. The packing list of this light is as follows:
1) Light----------------------------------------------1pcs
2) Power Cable-----------------------------------1pcs
3) User Manual-----------------------------------1pcs
2. Effect:
This product is widely use to light the large building, garden, landscape or
other project illumination. The distance of the light beam can
up to
5-9meters.It can be controlled by itself, can connect all the lamps and DMX
control. It has 7colors change slow and fast, strobe synchronizatly.DMX256
grade dimmer, DMX programming.
7 colors change gradually,7 colors change skipply,7 colors strobe, connect
lamps change synchronizatly.
3. Control Mode:
Autocephaly mode: use the button to choose the inside program change.
DMX mode: DMX 512 signal control(3XLR)
4. Menu Display Function:
Operation description
：
Operation description: Press function button A
will cycle 7 different functional effects, Digital tube before a number which
represents the current function（refer the function sheet）。 The last two
1

digits represent the functions in which the address code or speed
parameters. Press the Bbutton to modify the parameter values,will save
automatically after 10 seconds.
No. Display Function
1 001 001—512 (8
channel) press “UP” and “Down”
button change the DMX address (Slave mode)
2 0.01
0.01—5.12 (4 channel) press “UP” and “Down”
button change the DMX address
3 C00
C01—C99 (Color change by Snapping), press “UP”
and “Down” button change the snapping speed
4 P00
P01—P99 (Color change by Fade), press “UP” and
“Down” button change the Fade speed
5 E00 E01—E99 (Color change by Pulse), press “UP” and
“Down” button change the pulse speed
6
R25
R00—R25 (Red dimming by hand)
7
G25
G00—G25 (Green dimming by hand)
8
B25
B00—B25 (Blue dimming by hand)
9
025
000—025 (white dimming by hand)
5. DMX Channel:
4CH Mode
CH1 0-255 Red dimming from dark to bright
CH2 0-255 Green dimming from dark to bright
CH3 0-255 Blue dimming from dark to bright
CH4
0-255
White dimming from dark to bright
2
8CH Mode
Channel Value Function
CH1 0-255 Main dimming from dark to bright
CH2 0-255 Control strobe from slowly to quickly
CH3
0-50
No function
51-100
Color change by Snapping
101-150
Color change by Fade
151-200
Color change by pulse
200-255
No function
CH4
0-255
The speed of function from slowly to quickly
CH5 0-255 Red dimming from dark to bright
CH6 0-255 Green dimming from dark to bright
CH7 0-255 Blue dimming from dark to bright
CH8 0-255 White dimming from dark to bright
6. Technical Parameters:
Voltage: AC 100-240V, 50Hz/60Hz
LED: 3W*32 LED (Red: 8pcs, Green: 8pcs, Blue: 8pcs, White: 8pcs)
Power Consumption: 32Watts
LED Current: 650 mA / 1 pc
LED Beam Angle: 45°
LED Lifetime: 80,000-100,000 hours
Possible Color Combinations: 16.7 million
DMX Control: 4/8 Channels
Operation Modes: DMX512, Internal Program, Master/slave
Control Panel: Digital 3 Character Alphanumeric
Maximum Ambient Temperature: 50° C
Waterproof Rating: IP65
Rotation Angle: 180°
Gross Weight:4.5 kg
Package Size: 1080×130×150mm
3
