MJ LED LIGHTNING MJ-3400-W User manual

LED BLINDER 400
MJ-3400-W
User Manual
======PROFESSIONAL LED LIGHTING ========
Thank you for choosing our LED blinder light. For the sake of your safety, Please
read and follow these instructions carefully and keep this manual in a safe place for
future reference

4CH mode
Channel Value Function
CH1 0-255 W1 dimming from dark to bright
CH2 0-255 W2 dimming from dark to bright
CH3 0-255 W3 dimming from dark to bright
CH4 0-255 W4 dimming from dark to bright
2CH mode
Channel Value Function
CH1 0-255 Main dimming from dark to bright
CH2 0-255 Control strobe from slowly to quickly
1CH mode
Channel Value Function
CH1 0-255 Main dimming from dark to bright
Important notice:
Before open the LED blinder light and if you want to do the repair
work, please make sure the power source is at the separation
condition.
Unceasingly carries on the product improvement about our
company the policy, in this instruction booklet carries the data will
have the possibility to be able to change in the future, when no
longer separate notice change matters concerned. Our company
retains when the product improvement changes the related
specification the authority. This instruction booklet publisher cannot
be responsible regarding this instruction booklet in information
accuracy, also cannot the related consequence which causes
regarding these information be responsible.
4
I. Installation
1. In order to secure the safe installation of the light, always use it in the
well-ventilated environment.
2. Always keep this light with a safe distance from any flammable
materials.
3. Never install, dismantle and maintain this light when it is powered; and
all work aforesaid must be conducted by professionals.
4. The packing list of this light is as follows:
1) Blinder Light -------------------------------------------1pcs
2) Power cable---------------------------------------------1pcs
2) User Manual------------------------------------------1pcs
II. Effect
1. This light operation is very simple, Attractive appearance, Humanized
design, Dim without flicker and shake, Energy-efficient, Durable. It is
suitable for photography, television stations, stage, dance hall, KTV, bar,
evening show.
2. The program of this light can automatically operate, sound, accept
DMX512 signal control and be connected for use.
III. Menu display function table
Please press “Menu” button to choose function , and press
“Enter” button to confirm.
No. Display Function
1 A001 A001—A512 (8
channel) press “UP” and “Down”
button change the DMX address
2 d001 d001—d512 (4
channel) press “UP” and “Down”
button change the DMX address
3 H001 H001—H512 (2
channel) press “UP” and “Down”
button change the DMX address
1

4 h001 h001—h512 (1
channel) press “UP” and “Down”
button change the DMX address
5 CC00 CC01—CC99 (Color change by Runn
ing), press
“UP” and “Down” button change the running speed
6 LL00 LL01—LL99 (Color Running speed), press “UP” and
“Down” button change the Running speed
7 CP00 CP01—CP99 (Color change by Fade), press “UP”
and “Down” button change the Fade speed
8 DE00 DE01—DE99 (Color change by Pulse), press “UP”
and “Down” button change the Pulse speed
9 BEBE1 Sound mode
10 W000 W000—W255 (white dimming by hand)
11 N255 n001—n255 (strobe speed)
IV. Technical Parameters
Voltage:AC100-240V, 50Hz/60Hz
Power Consumption: 400W
LED: 4pcs 100W COB white LED
LED Beam Angle: 60°
LED Lifetime: 80,000-100,000 hours
Color: white or warm white color
Dimming: 0-100% smooth dimmer
Strobe: 10 Flashes per second (any color)
Operation Modes: DMX512, Manual, Sound, Internal Program
DMX Control: 1/2/4/8Channels
Control Panel: Digital 4 Character Alphanumeric
Maximum Ambient Temperature: 40° C
Gross Weight: 9.8 kg
Package Size: 545 x 185 x 485cm
2
V. DMX function
8CH mode
Channel Value Function
CH1 0-255 Main dimming from dark to bright
CH2 0-255 W1 dimming from dark to bright
CH3 0-255 W2 dimming from dark to bright
CH4 0-255 W3 dimming from dark to bright
CH5 0-255 W4 dimming from dark to bright
CH6 0-255 Control strobe from slowly to quickly
CH7 0-20 No function
21-35 Lighting change by jump running1
36-50 Lighting change by jump running 2
51-75 Lighting change by jump running 3
76-90 Lighting change by jump running 4
91-105 Lighting change by jump running 5
106-120 Lighting change by jump running 6
121-135 Lighting change by jump running 7
136-150 Lighting change by fade running 1
151-165 Lighting change by fade running 2
166-180 Lighting change by fade running 3
181-195 Lighting change by fade running 4
196-210 Lighting change by fade running 5
211-225 Lighting change by fade running 6
226-240 Lighting change by fade running 7
241-255 Sound control
CH8 0-255 The speed of function from slowly to quickly
3
