MJ LED LIGHTNING MJ-3337C-200W User manual

LED PROFILE LIGHT WITH ZOOM
MJ-3337C-200W
User Manual
======PROFESSIONAL LED LIGHTING ========
Thank you for choosing our LED profile light with zoom. For the sake of your
safety, Please read and follow these instructions carefully and keep this manual in a
safe place for future reference.

OVERVIEW
Thank you for using our product, this unit is designed for indoor using, it’s widely used
for stage, building, disco, etc. as high power led effects lighting, this unit can be
operated as a single unit or multiple units for large applications. Direct input of DMX512
signal to unit to allow it controlled by any DMX controller, powerful internal programs
and friendly and convenient operation interface allows customers to program freely to
any different lighting project requirements for installation or showing.
This high power par can has gotten the nice sculpt, efficient, save electricity and
durable 。
Technical Parameter:
• Power Supply: AC100V-240V, 50/60Hz
• Power Consumption: Max. 260W
• LED: 200W RGBW 4in1 COB LED
• Color Rendering Index(CRI): Ra≥90
• LED Life time: over 10,000 hours
• Dimmer :0~100% linearly adjustable
• Strobe :1-25times/sec
• Refresh Rate:>400 Video Flicker Free
• Focus: Can be adjusted by hand
• Technology: High-quality optical system , Glass reflector
• Beam Angel: Zoom from 15°to 28°or 20°to 45°
• High-quality optical system , Glass reflector
• Control Mode: DMX, Auto run and Master/Slave
• DMX Channels: 4 / 8CH
• Cooling System:Low noise fan(one fan)
• IP Rating: IP20
• N.W.: 10 kgs
• G.W.: 13kgs
• Dimensions :800x305x310mm 1
APPENDIX
Caution :
﹡Unqualified person involved with installation , operation and maintenance of this
device is prohibited .
﹡If any above mentioned problem happened , or unknown problem happened ,
please contact manufacturer or distributor for assistance
DISCLAIMER
1. The device is with one year warranty . The warranty period appear non-artificial
quality problem, this company is responsible for free maintenance
2. User violate operation caused the machine failure, this is user responsibility.
3. If due to the wrong operation or intense impact caused product destroy even safety
accidents, the manufacturer does not undertake any responsibility
4.
Prohibit replaced product components by any person, therefore caused any
consequences will be whose responsible
Please contact us freely when you need our related products or in formations...
10

SAFETY WARNING
1. Warning
﹡Every person involved with the installation , operation and maintenance of this
device has to be qualified .
﹡User must follow the instructions of this manual
﹡Unqualified person can not open the housing cover and operate the device , or the
dealer will not accept liability for any resulting defects or problems.
﹡The device against rain and moisture
2. Waring notes :
﹡Power supply : AC 100V-240V , 50/60Hz
﹡Make sure the power switch is off , the power plug , outlet and the earth connection
is in well condition before connecting the device with the mains.
﹡Please use qualified power plug and the outlet. Never connect the power cord of
this device with other electrical equipment.
﹡During move and installation , make sure the device not crashed with metal parts
and other tough materials.
﹡Always disconnect from the mains, when the device is on the installation and
dismantled
﹡The minimum distance between light-output and the illuminated surface must be
more than 50cm
﹡The device must only be installed on a non-flammable surface . In order to
safeguard sufficient ventilation , leave 50cm of free space around the device . Please
note that heat-sensitive objects may be deformed or damaged by the emitted heat .
﹡During the operation the housing becomes very hot ! Do not operate the device for
15 minutes after switching off .
﹡The maximum ambient temperature Ta = 45℃must never be exceeded , The
maximum housing temperature Tb = 80℃must never be exceeded .
﹡For indoor use
﹡Replace any visible cracked protective shield , filters and lens .
﹡The protective shiel, filters and lens will require weekly cleaning as smoke “Cfluid
tends to building up residues , reducing the light “Coutput very quickly.
9
1. Product Introduction
1.1 Product Feature
4 control mode
External control mode
DMX512 controller controller mode （2 kind of DMX Channel）
Master/slave
Auto mode
Built-in Program
Different kind of Gradual change& Random change
Different kind of strobe：speed (slow to fast)、fix color( Strobe +color、
Strobe +Gradual change)……
Setting Program
It can setting the program without the controller , it can setting Gradual
change、jump change、strobe ...(different effect)
And the program data can be down load from master light to slave light
Static model
It can fix the color without the controller ,also can be choose the color with
strobe
Sound model
Included 2 kinds of commonly used sound model
“Software cutting ”
In the STAR mode , working built-in program /setting program ,the light would be
turn off when the dimmer channel as "0"（procedure would keep working)
The difference with “BLACKOUT” key(controller keys) &"Software cutting" ：only
work this light , and do not clear up the controller data .
White color
Setting different color temperature of white color
Screen Protection
Without operate key in 30 seconds , it enter black screen. Press any keys then it
can quit screen protection.
Temperature Protection
It can set to protect the temperature .
2

3.2. 8CH Channel
Channel Data Function Mark
CH1 0~255 Dimmer
CH2 0~255 Red
CH3 0~255 Green
CH4 0~255 Blue
CH5 0~255 White
CH6
0~30 No effect
31~200 Color change
201~205 Color temperature 1 (3200K) Can be set via menu of
“WT.xx”
...... Color temperature 2~10 (each
5 data is a color temperature)
250~255 Color temperature 11 (10000K)
CH7
0~10 No strobe This channel can control
the speed when run the
inner program
11~255
The speed of strobe (255 is
fasterest)
CH8
0~20 Speed of dimmer 4 (slowest
and softest)
21~40 Speed of dimmer 3
41~60 Speed of dimmer 2
61~80 Speed of dimmer 1
81~99 Speed pf dimmer off (no delay)
100~109 Inner program 1
...... ......(each 10 data is a program)
190~199 Inner program 10
200~240
Change light led by sound
model
241~255 Strobe by sound model
8
Speed of the Fan
The fan will be worked when the working temperature reach 40 degree,
and the speed will get the faster as the temperature get high.
Can be showed reverse display
1.2.Multi-light working in the same time
When using controller to control several lights , and using strobe , auto mode, the
controller just send the channel data . Those effect( strobe ,auto running ,fix
color)would be showed by itself. And should be attention for the follow situation:
1. There will be many situation make the light become not synchronization in
the beginning. (For example: the different time of opening the light will make them
connect the controller in different time) . And you can change the controller table
puller data( from 20 to 0, and back to 20), then it can be synchronization.
2. Due to different lights crystal frequency are not exactly equal, so it will
become not synchronization after long time.
3. If need to be synchronization for long time, there is 2 approaches:
A. Using the controller to make program make the strobe, auto run effect to
be synchronization.
B. Using the Maser/Slave model
2. Operation
2.1 Key operation
3

With
menus
Wt: white UP/DOWN
Color
temperature
setting
ENTER
Enter the
vice menu
……
R、G、B、
W…… UP/DOWN
Change the
value of
led
Change the
value of
color
temperature
ENTER
Sace data
and change
to vice
menu
No vice
menu
diSP:
display ENTER
reverse the
display
set to show
reverse
display
No vice
menu
rESt: reset ENTER
enter the
interface
of key
the password
is “UP
DONW UP
DOWN”
return Initial
State
3. Channel data
3.1. 4CH Channel
Channel Data Function
CH1 0~255 Red Dimmer
CH2 0~255 Green Dimmer
CH3 0~255 Blue Dimmer
CH4 0~255 White Dimmer
7
Menu
：
The first list is the main menu (press MENU to exchange), the second list is submenu
(press ENTER to get in or exchange)
If the menu include the decimal point, that’s the data, and it can be set by the Key of
Up/Down.
Key operation
：
Key of “MENU” (Press it and can save the data)
If it’s the main menu, it will exchange to next main menu.
If it’s the submenu , it will back to main menu.
Key of “ENTER” (Press it and can save the data)
If it’s the main menu and it have submenu, it will enter the submenu.
If it’s the submenu, it will exchange to the next submenu
Key of “UP/DOWN”
It’s no function if the menu not include the decimal point.
If the menu include the decimal point, it can set the data after the decimal point. And it
need to press “ENTER” to save the data.
4

2.2. Menu Data
Menu
State Operation Remark
Main Menu Vice Menu
No vice
menu
A: advance UP/DOWN
adjust ID
address disconnect
the
controller
and connect
the master
light, then it
will follow
the master
light.
It will
flicker if no
signal.
External
control mode
(standard
channel model)
ENTER
save the
ID address
No vice
menu
d: dmx UP/DOWN
adjust ID
address
External
control mode
(Basic channel
model)
ENTER
Save the
ID address
One vice
menu
At: auto UP/DOWN Choose
program
Auto run ENTER
Enter vice
menu
SP: speed UP/DOWN
Adjust the
speed
select the
speed of auto
run
ENTER Save data
None Sod: sound UP/DOWN
change to
Sound
control
Sound mode ENTER Save data
5
With
multi-vice
menus
StAt: static ENTER
Enter vice
menu
Static model
……
r、G、b、
W……
UP/DOW
N
Change the
value of led
Led set ENTER
Save data
and change
to vice
menu
St: strobe UP/DOW
N
Change the
value of
strobe
Strobe and
the speed ENTER
Save data
and change
2 vice
menu
tEMp:
temperature ENTER
enter the
vice menu
temperature
control
current
temperature ENTER
change to
vice menu
t: top UP/DOW
N
change the
data of
temperature
protect
set the
protect
temperature
ENTER
save and
change
6
