MJ LED LIGHTNING MJ-2009B User manual

HIGH POWER LED WALLWASHER
MJ-2009B
3W25DRGB
User Manual
=======PROFESSIONAL LED LIGHTING ========
Thank you for choosing our LED wall washer light. For the sake of your
safety, Please read and follow these instructions carefully and keep this
manual in a safe place for future reference

Catalogue
Chapter Page
Safety instructions----------------------------------------------------------------------1
Installation--------------------------------------------------------------------------------2
Description -------------------------------------------------------------------------------2
DMX-512 control connection---------------------------------------------------------2
DMX-512 connection with DMX terminator---------------------------------------2
Graphic part ------------------------------------------------------------------------------3
Display menu ----------------------------------------------------------------------------3
Cleaning and maintenance -----------------------------------------------------------4
Installation---------------------------------------------------------------------------------4
DMX functions and values-------------------------------------------------------------5
Technical parameters -------------------------------------------------------------------5
Warning-------------------------------------------------------------------------------------6
Before open the LED wall washer light and if you want to do the repair
work, please make sure the power source is at the separation
condition.
Unceasingly carries on the product improvement about our company
the policy, in this instruction booklet carries the data will have the
possibility to be able to change in the future, when no longer separate
notice change matters concerned. Our company retains when the
product improvement changes the related specification the authority.
This instruction booklet publisher cannot be responsible regarding this
instruction booklet in information accuracy, also cannot the related
consequence which causes regarding these information be
responsible.

SAFETY INSTRUCTIONS
This device has left the factory in perfect condition. In order to maintain this
condition and to ensure a safe operation, it is absolutely necessary for the user
to follow the safety instructions and warning notes written in this user manual.
When unpacking and before disposing of the carton, check there is no transportation damage
before using the product. Should there be any damage caused by transportation, consult your
dealer and do not use the apparatus.
The device can be use indoors and outdoors, IP65.
The device is not designed or intended to be mounted directly on to inflammable surfaces
The device is only intended for installation, operation and maintenance by professional person.
Do not device the beam onto inflammable surfaces, minimum distance is 5m.
Avoid direct exposure to the light from the lamp. The light is harmful to the eye.
Do not attempt to dismantle or modify the projector in any way.
Electrical connection must only be carried out by qualified personnel.
Before installation, ensure that the voltage and frequency of power supply match the power
requirements of the projector.
It is essential that each device is correctly earthed
and that electrical installation conforms to all
relevant standards.
Do not connect this device to any other types of dimmer apparatus.
Make sure that the power-
cord is never crimped or damaged by sharp edges. Never let the
power-cord come into contact with other cables. Only handle the power-cord by the plug. Never
pull out the plug by tugging the power-cord.
LED lens shall be changed if they have become visibly damaged to such an extent that their
effectiveness is impaired, for example by cracks or deep scratches.
Exterior surface temperatures of the luminaire after 5 minutes operation is 50°C，when steady
state is achieved 65°C.
There is no user serviceable parts inside the projector, do not open the housing and never operate
the device with the covers removed.
If you have any questions, don’t hesitate to consult your dealer or manufacturer.
Always disconnect from the mains, when the device is not in use or before
cleaning it or before attempting any maintenance work !
1
WARNING
Please do not use the lamp under the water!
Please do not connect the power cable hand by hand
over 5 lights per time!
6

DMX FUNCTIONS AND VALUES
7 channel description
Channel
Function
Description
1CH
Main dimming
Main dimming from dark to bright
2CH
R dimming
R dimming from dark to bright
3CH
G dimming
G dimming from dark to bright
4CH
B dimming
B dimming from dark to bright
5CH
Main strobe
Main strobe from slow to quick
6CH
Function speed
Function speed from slow to quick
7CH Function
Selection
0-50:DMX512, 51-99:jump change；
100-150:fade, 151-200:running change；
201-250:Pulse, 251-255:sound control
TECHNICAL SPECIFICATIONS
Construction: Aluminum
Power supply: 100V~240V AC,50 Hz /60Hz
LED: 3W*48LEDs(R:16;G16;B:16;)
LED Current: 700mA
Power consumption: max. 150 W
LED Beam Angle: 25°
LED Lifetime: 80,000-100,000 hours
Colour: RGB Mixing colour
DMX Channel:3/7CH
Dimming: 0-100% with regulated constant color control
Strobing: 10 Flashes per second (any color)
Operation Modes: DMX512, Internal Program, Sound, Master/slave
Control Panel: Digital 4 Character Alphanumeric
Maximum Ambient Temperature:-10 -40° C
Waterproof grade: IP 65
Net weight:.8 KGS
Gross weight: 9.2KGS
Packing dimensions: 49x30x19CM
5
INTRODUCTION
Thank you for having chosen our LED lighting
Unpack the device ,inside the box you should find:
1)LED Wall Washer Light----------------------1pcs
2) Power Cable-----------------------------------1pcs
3) User Manual-----------------------------------1pcs
Please check carefully that there is no damage caused by transportation.
Should there be any ,consult your dealer and don’t install this device.
DESCRIPTION
Features
.3/7DMX channels
.DMX-controlled operation, Sound-
controlled operation or stand
alone operation with Master/Slave-function
. Automatic identify Master signal
. Stepless RGB colour changing
. Equipped with 48 x 3W LEDS:16 x red,16 x blue, 16x green,
. Switch-mode power supply, 100V-240V
.Operation very easy
，
human design
，
dimming no flicker
、
jitter
phenomena. Can be adapted to video, photogra
phy, television and
other demanding lighting occasions.
DMX-512 CONTROL CONNECTION
The product has a DMX 512 input fitted with 3-pin XLR connectors.
Screened cables in compliance with EIA RS-485 specifications and the
following characteristics must be used for connections:
- 2 conductors plus screen
- 120Ohm impedance
- max. transmission rate 250kBaud.
DMX-512 CONNECTION WITH DMX TERMINATOR
For installations where the DMX cable has to run a long distance or
electrically noisy environment, such as in a d
iscotheque, it is
recommended to use a DMX terminator. This helps in preventing
2

P
corruption of the digital control signal by electrical noise. The DMX
terminator is simply an XLR plug with a 120 OHM resistor connected
between pins 2 and 3,which is then plugged into the output XLR socket of
the last fixture in the chain.
GRAPHIC PART
Operation description
：
Press “A” will cycle out seven different functional
effect, LED Top row in represent the current function（Reference function
table）。 LED Top row on behalf of the function in the address code、or
speed and other parameters。Press Bor Ckey can modify the parameter
value。Press Dto confirm。
DISPLAY MENU（All the functions are selected, press D to confirm.）
No Display Function description
1 A001
7 channel address code
， （
001
—
512
）
B、C button plus or reduce address code value
2 d001 3 channel address code，（001—512）
B
、
C button plus or reduce address code value
3 CC00 Colorful jump，（00—99）
B
、
C button change jump speed
4 CP00
Colorful pulse variable
、
gradient
， （
00
—
99
）
B、C button change speed of pulse and gradient
3
5 DE00
Colorful running
， （
00
—
99
）
B
、
C button change speed of runnting
6
BEBE
Colorful sound control variable
7 R220
Red dimming
， （
000
—
255
）
B、C button change the DMX value of red color
8 G220 Green dimming，（000—255）
B、C button change the DMX value of red color
9 B220 Blue dimming，（000—255）
B
、
C button change the DMX value of red color
Attention: Setting DMX address by button
1. press ENTER button when show the A001/d001 menu, then
adjust the DMX address by pressing [UP] or [DOWN] button
2. A001/d001 are master/slave mode
Press [ENTER] to confirm or pressing [ESC] to return to main menu.
CLEANINGAND MAINTENANCE
We recommend a frequent cleaning of the device. Please use a soft
lint-free and moistened cloth. Never use alcohol or solvents!
CAUTION!
Disconnect from mains before starting maintenance operation.
There are no service parts inside the device. Maintenance and service
operations are only to be carried out by authorized dealers.
If you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be
replaced by authorized dealers only in order to avoid hazards.
If you have further questions, please contact your dealer.
INSTALLATION
The device must only be installed at a vibration-free, oscilation-free
and fire-resistant location.
