MJ LED LIGHTNING MJ-2037C User manual

LED OUTDOOR PAR-718
MJ-2037C
User Manual
=======PROFESSIONALLED LIGHTING ========
Thank you for choosing our outdoor LED Par light. For the sake of your safety,
Please read and follow these instructions carefully and keep this manual in a safe
place for future reference
WARNING
Please do not use the lamp under the water!
Please do not connect the power cable hand by hand
over 10 lights per time!
Important notice:
Before open the LED outdoor par light and if you want to do the
repair work, please make sure the power source is at the separation
condition.
Unceasingly carries on the product improvement about our
company the policy, in this instruction booklet carries the data will
have the possibility to be able to change in the future, when no
longer separate notice change matters concerned. Our company
retains when the product improvement changes the related
specification the authority. This instruction booklet publisher cannot
be responsible regarding this instruction booklet in information
accuracy, also cannot the related consequence which causes
regarding these information be responsible.

5. Channel List:
6CH Mode
Channel Value
Function
CH1 0-255 Red dimming from dark to bright
CH2 0-255 Green dimming from dark to bright
CH3 0-255 Blue dimming from dark to bright
CH4 0-255 White dimming from dark to bright
CH5 0-255 Amber dimming from dark to bright
CH6 0-255 Purple dimming from dark to bright
11CH Mode
Channel Value
Function
CH1 0-255 Main dimming from dark to bright
CH2 0-5 No function
6-255 Control strobe from slowly to quickly
CH3 0-255 Red dimming from dark to bright
CH4 0-255 Green dimming from dark to bright
CH5 0-255 Blue dimming from dark to bright
CH6 0-255 White dimming from dark to bright
CH7 0-255 Amber dimming from dark to bright
CH8 0-255 Purple dimming from dark to bright
CH9 0-5 No function
6-255 Color mixture
CH10 0-9 No function
6-255 Macro function
CH11 0-255 Macro speed of function from quickly to slowly
5

3. Technical Parameters:
Construction: Aluminum
Voltage: AC 100-240V, 50Hz/60Hz
LED: 7PCS 18W 6IN1 LED
Power Consumption: 126 Watts
LED Current: 500mA / 1 pc
LED Beam Angle: 25°(±5) degree
LED Lifetime: 80,000-100,000 hours
Color: RGBWAcolor mixing
DMX Control: 6/11 Channels
Operation Modes: DMX512, Internal Program, Master/slave, Sound/Auto
Control Panel: Digital 4 Character Alphanumeric
Maximum Ambient Temperature: 60° C
Waterproof Rating: IP65
Gross Weight: 3.8kg
Package Size: 24×24×28CM
4. Waterproof manage:
Signal joint(at most 30pcs)XL-3R,at first, use the high voltage and
waterproof adhesive tape with mucosity to enlace the joint one circle. After
stretch the adhesive tape, then you can enlace it, please reference the
operation describe.), then cover a 20mm cannula with pyrocondensation.
At last, envelop the joint to reach a waterproof effect.
Warning
If this joint can’t do the waterproof manage, then the lamp waterproof effect
will be invalid, then destroy the product.
4
1. Installation:
1.This light can work normally between the Voltage of
AC100~240V,50/60Hz.
2. In order to secure the safe installation of the light, always use it in the
well-ventilated environment.
3. Always keep this light with a safe distance from any flammable
materials.
4. Never install, dismantle and maintain this light when it is powered; and
all work aforesaid must be conducted by professionals.
5. The packing list of this light is as follows:
1) Light----------------------------------------------1pcs
2) Power Cable-----------------------------------1pcs
3) User Manual-----------------------------------1pcs
2. Modes of Operation
There are four modes of operation: DMX control (Slave), Sound,
Automatic, and Manual. In the Sound, Automatic, and Manual settings,
the unit will perform independently and will send DMX signal, so that
other fixtures may be linked. This is useful if you want every fixture
doing the same thing and do not wish to use an external DMX controller.
All menu settings will be retained even after the lights have been
powered off.
1. DMX Control – Fixture is remotely controlled via a DMX controller
(sold separately).
2. Sound Control – Fixture changes color in response to noise.
3. Manual Control – Color are manually set via the control pad.
4. Automatic Color Cycle – Unit cycles through colors automatically.
User sets whether fade is instant or slow, whether 3 or 7 colors
are used, and the length of time between fades.
1

No. Display Function
1 6CH/11CH/ Channel choose (6CH/11CH) Press “UP” and “Down”
button change the DMX Channel
2 d001 d001—d512 (DMX address setting) press “UP” and
“Down” button change the DMX address
3 R220 R000—R255 (R dimming by hand), press “UP” and
“Down” button change the red brightness,
4 G220 G000—G255 (G dimming by hand), press “UP” and
“Down” button change the green brightness,
5 B220 B000—B255 (B dimming by hand),
press “UP” and
“Down” button change the blue brightness,
6 H220 H000—H255 (W dimming by hand), press “UP” and
“Down” button change the white brightness,
7 P220 P000—P255 (A dimming by hand),
press “UP” and
“Down” button change the amber brightness,
8 U220 U000—UP255 (P dimming by hand), press “UP” and
“Down” button change the purple brightness,
9 Pr01 Pr01—Pr14 (Built-in program Settings), press “UP” and
“Down” button change the program,
10 SP01 SP01—SP16 (Built-in program speed), press “UP” and
“Down” button change the speed
11 AUTO/AUDI (Auto and Sound control choose), press ENTER button,
then press “UP” and “Down” button change model
12 DISP (Display inversion ) press ENTER button, then press
“UP” and “Down” button choose display inversion
13 T00 (Temperature display), this light no function)
NOTE：When you choose the function, please press ENTER to save .
2
1. DMX Control
1. If you wish to control the unit remotely via DMX, you will need a
DMX controller. Connect an XLR cable to the controller's DMX
output and the fixture's input.
2. Set the fixture to receive DMX signal
a) Press and hold 'MENU' button until display says d001.
b) Press 'ENTER', then the fixture will receive the DMX 512
signal.
c) Press UP or DOWN to select the desired address.
d) Press ENTER button to activate the selection..
2. Sound Activation (color changes in response to loud noises)
1. Press and hold 'MENU' button until the display panel says AUTO or
AUDI (short for sound).
2. Press 'ENTER' Then press “UP”and “Down” button change to
AUDI.
3. Press 'ENTER'
3. Manual Control(RGBWAP dimming by hand):
1. Press and hold 'MENU' button until display panel says R255 , G255,
B255, H255, P255, U255
2. Press UP or DOWN to select the address
3. Press 'ENTER'
RED (ROO0-R255) GREEN (G000-G255) BLUE (B000-B255)
WHITE(F000-H255) AMBER(P000-P255) PURPLE(U000-U255)
4. Automatic Color Cycle
1．Press MENU, the display panel says Pr01 – Pr14, press “UP” and
“Down” button change the different program .
2. Press MENU, the display panel says AUTO or AUDI,this way is
color changes by Auto Running. Press 'ENTER' ,then press “UP” and
“Down” button change to AUTO.
3
