MJ LED LIGHTNING MATRIX BAR 910 User manual

LED MATRIX BAR LIGHT
MATRIX BAR 910
MJ-3129-4IN1
User manual
======PROFESSIONAL LED LIGHTING ========
Thank you for choosing our LED matrix bar light. For the sake of your
safety, Please read and follow these instructions carefully and keep this
manual in a safe place for future reference.

MATRIX BAR 910 4IN1 MATRIX BAR 910 4IN1
Installation: .
1. In order to secure the safe installation of the light, always use it in the
well-ventilated environment.
2. Always keep this light with a safe distance from any flammable materials.
3. Never install, dismantle and maintain this light when it is powered; and all work
aforesaid must be conducted by professionals.
4. The packing list of this light is as follows:
1) Light ----------------------------------------------1pcs
2)Power Cable-------------------------------------1pcs
3) User Manual------------------------------------1pcs
Effect:
1. This light operation is very simple, Attractive appearance, Humanized design, Dim
without flicker and shake, Energy-efficient, Durable. It is suitable for photography,
television stations, stage, dance hall, KTV, bar, evening show.
2. The program of this light can automatically operate, sound, accept DMX512 signal
control and be connected for use.
Graphic Part
：
Operation description
：
Press “A” will cycle out 14pcs different functional effect, LED
Top row in represent the current function（Reference function table）。 LED Top row on
behalf of the function in the address code、or speed and other parameters。Press Bor
Ckey can modify the parameter value。Press Dto confirm。
1
WARNING
Please do NOT connect the power cable hand by hand over 5pcs
Important notice:
Before open the LED matrix bar light and if you want to do the repair
work, please make sure the power source is at the separation
condition.
Unceasingly carries on the product improvement about our company
the policy, in this instruction booklet carries the data will have the
possibility to be able to change in the future, when no longer
separate notice change matters concerned. Our company retains
when the product improvement changes the related specification the
authority. This instruction booklet publisher cannot be responsible
regarding this instruction booklet in information accuracy, also cannot
the related consequence which causes regarding these information
be responsible.
8

MATRIX BAR 910 4IN1 MATRIX BAR 910 4IN1
Display Menu:（All the functions are selected, press D to confirm.）
No. Display Function
1 A001 DMX address (001—512)
Press “UP” and “Down”
button change the DMX address
2 9CH/14CH/
36CH
Channel choose (09CH/14CH/36CH) Press “UP” and
“Down” button change the DMX Channel
3 CC00 Color change by Snapping (CC01—CC99), press “UP”
and “Down” button change the snapping speed
4 Ed00 Color change by Fading (Ed01—Ed99), press “UP” and
“Down” button change the Fade speed
5 Er00
Colorful Running 1 (Er01—Er99), press “UP” and “Down”
button change the running speed (If setting
ID code1 by 1, it can get running effect in one group)
6 Po00
Colorful Running 1 (Po01—Po99), press “UP” and “Down”
button change the running speed (If setting
ID code1 by 1, it can get running effect in one group)
7 tr00 Running effect (tr01—tr14), press “UP” and “Down”
button change the running effect
8 tU00 Running effect speed (tU01—tU99
), press “UP” and
“Down” button change the running effect speed
9 BE50 Sound control (BE01—BE99), press “UP” and “Down”
button change the sound sensitivity
10 R000 Red dimming by hand (R000—R255)
press “UP” and
“Down” button change the Red brightness
11 G000 Green dimming by hand (G000—G255) press “UP” and
“Down” button change the Green brightness
12 B000 Blue dimming by hand (B000—B255)
press “UP” and
“Down” button change the Blue brightness
2
76-85 Color change by Fading (It control by CH1,CH2,CH5.
The 5CH is change speed)
86-95 Color Snapping running 1 (It control by CH1,CH5 to
CH9. The 5CH is change speed)
96-105 Color Snapping running 2 (It control by CH1,CH5 to
CH9. The 5CH is change speed)
...... .......
136-145 Color Snapping running 6 (It control by CH1,CH5 to
CH9. The 5CH is change speed)
146-155 Color running 1 (It control by CH1,CH5 to CH9. The
5CH is change speed)
156-165 Color running 2 (It control by CH1,CH5 to CH9. The
5CH is change speed)
...... .......
236-245 Color running 10 (It control by CH1,CH5 to CH9.
The 5CH is change speed)
246-255 Sound control (It control by CH1,CH6 to CH9.)
CH4
Function 1
0-5 No function
6-255
Each one value is a effect (It control by CH1,
CH6 to CH9.)
0-127 Colorful running by Snapping and Fading left
running
128-255 Colorful running by Snapping and Fading
right running
CH5 0-255 Function speed
CH6 0-255 Red dimming
CH7 0-255 Green dimming
CH8 0-255 Blue dimming
CH9 0-255 White dimming
7

MATRIX BAR 910 4IN1 MATRIX BAR 910 4IN1
13 W000 White dimming by hand (W000—W255)
press “UP” and
“Down” button change the White brightness
14 Id01 Id code setting (Id01-Id14)
press “UP” and “Down” button
change the Id address (It use running effect within one group)
Attention:
1. Setting DMX address by button
1). press MODE button when show the A001 menu, then adjust the DMX address by
pressing UP or DOWN button
2).oPrt is slave mode
Press ENTER to confirm or pressing MODE to return to main menu.
2. Setting ID code.(only for Er00 and Po00 do master to use)
If you set ID code one by one. and connect the light together.
It will be get amazing running effect within one group light.
(e.g. :first light ID is Id01, second light ID is Id02, third light ID is Id03, fourth light ID is
Id04....... those light is a group., it will be running from first light to last light)
Technical Parameters:
Voltage: AC 100-240V, 50Hz/60Hz
Power Consumption: 90 Watts
LED: 9pcs 10W 4in1 RGBW LED
LED Current: 520mA / 1 pc
LED Beam Angle: 25°
Dimming: 0-100% with regulated constant color control
Strobe: 10 Flashes per second (any color)
Operation Modes: DMX512, Sound, Internal Program, Master-slave
DMX Control: 9/14/36 Channels
Maximum Ambient Temperature: 40° C
Gross Weight: 4.2 kg
Package Size: 690 x 180 x 155mm
3
CH4
Function 1
0-5 No function
6-255
Each one value is a effect (It control by CH1,
CH6 to CH14.)
0-127 Colorful running by Snapping and Fading left
running
128-255 Colorful running by Snapping and Fading
right running
CH5 0-255 Function speed
CH6 0-255 LED 1 color mixing
CH7 0-255 LED 2 color mixing
CH8 0-255 LED 3 color mixing
...... ...... .........
CH14 0-255 LED 9 color mixing
C. 9channel description
Channel Value Function
CH1 0-255 Main dimming from dark to bright
CH2 0-255 Control strobe from slowly to quickly
3CH
Function 1
0-25 No Function
26-35 No Function
36-45
Colorful running by Snapping, It control by 1CH,6CH
to 9CH (If ID code one by one, it can be control within
one group)
46-55
Colorful running by Fading, It control by 1CH,6CH to
9CH (If ID code one by one, it can be control within
one group)
56-65 Color choose (It control by CH1,CH2,
CH5. The 5CH is choose color)
66-75 Color change by Snapping (It control by
CH1,CH2,CH5. The 5CH is change speed)
6

MATRIX BAR 910 4IN1 MATRIX BAR 910 4IN1
Cleaning and Maintenance:
We recommend a frequent cleaning of the device. Please use a soft lint-free and
moistened cloth. Never use alcohol or solvents!
CAUTION!
Disconnect from mains before starting maintenance operation.
There are no serviceable parts inside the device. Maintenance and service
operations are only to be carried out by authorized dealers.
If you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by
authorized dealers only in order to avoid hazards.
If you have further questions, please contact your dealer.
DMX functions and values:
A. 36 channel description
Channel Value Function
CH1 0-255 R1 dimming
CH2 0-255 G1 dimming
CH3 0-255 B1 dimming
CH4 0-255 W1 dimming
...... ...... ......
CH33 0-255 R9 dimming
CH34 0-255 G9 dimming
CH35 0-255 B9 dimming
CH36 0-255 W9 dimming
B. 14channel description
Channel Value
Function
CH1 0-255 Main dimming from dark to bright
CH2 0-255 Control strobe from slowly to quickly
4
3CH
Function 1
0-25 No Function
26-35 No Function
36-45
Colorful running by Snapping, It control by 1CH,6CH
to 1CH (If ID code one by one, it can be control within
one group)
46-55
Colorful running by Fading, It control by 1CH,6CH to
14CH (If ID code one by one, it can be control within
one group)
56-65 Color choose (It control by CH1,CH2,
CH5. The 5CH is choose color)
66-75 Color change by Snapping (It control by
CH1,CH2,CH5. The 5CH is change speed)
76-85 Color change by Fading (It control by CH1,CH2,CH5.
The 5CH is change speed)
86-95 Color Snapping running 1 (It control by CH1,CH5
to CH14. The 5CH is change speed)
96-105 Color Snapping running 2 (It control by CH1,CH5
to CH14. The 5CH is change speed)
...... .......
136-145 Color Snapping running 6 (It control by CH1,CH5
to CH14. The 5CH is change speed)
146-155 Color running 1 (It control by CH1,CH5 to CH14.
The 5CH is change speed)
156-165 Color running 2 (It control by CH1,CH5 to CH14.
The 5CH is change speed)
...... .......
236-245 Color running 10 (It control by CH1,CH5 to CH14.
The 5CH is change speed)
246-255 Sound control (It control by CH1,CH6 to CH14.)
5
