MJ LED LIGHTNING MJ-1012A User manual

LED Beam Moving Head Light
MJ-1012A
User Manual
Thank you for choosing our LED moving head light. For the sake of your safety, Please read
and follow these instructions carefully and keep this manual in a safe place for future
reference.

2
Catalogue
Chapter Page
Safe Usage Of The Product ---------------------------------------------------------------------------------3
Product Characteristic ----------------------------------------------------------------------------------------4
Product Parameter ---------------------------------------------------------------------------------------------4
Menu Description ----------------------------------------------------------------------------------------------4
Channel List -----------------------------------------------------------------------------------------------------6
FAQ ----------------------------------------------------------------------------------------------------------------8
☆Important notice:
·In this instruction for use contains about the installment and the use aspect important information of the LED moving
head. When installing and using, you need to look this usage instruction strictly.
·Before open the LED moving head and if you want to do the repair work, please make sure the power source is at the
separation condition.
·Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and the unit are
in good condition before installation and use. Should there be any damage caused by transportation, consult your dealer
and do not use the unit. Any damage caused by improper use will not be assumed by the manufacturer or dealer.
Attention: Unceasingly carries on the product improvement about our company the policy, in this instruction booklet
carries the data will have the possibility to be able to change in the future, when no longer separate notice change matters
concerned. Our company retains when the product improvement changes the related specification the authority. This
instruction booklet publisher cannot be responsible regarding this instruction booklet in information accuracy, also cannot
the related consequence which causes regarding these information be responsible.

3
SAFE USAGE OF THE PRODUCT
When unpacking and before disposing of the carton, check there is no transportation damage before
using the product. Should there be any damage caused by transportation, consult your dealer and do
not use the apparatus.
The product is for indoor use only, IP20. Use only in dry locations. Keep this device away from rain
and moisture, excessive heat, humidity and dust. Do not allow contact with water or any other
liquids.
The product is not designed or intended to be mounted directly on to inflammable surfaces
The product is only intended for installation, operation and maintenance by professional person.
The product must be installed in a location with adequate ventilation, at least 50cm from adjacent
wall surfaces. Be sure that no ventilation slots are blocked.
Do not product the beam onto inflammable surfaces, minimum distance is 5m.
Avoid direct exposure to the light from the lamp. The light is harmful to the eye.
Do not attempt to dismantle or modify the projector in any way.
Electrical connection must only be carried out by qualified personnel.
Before installation, ensure that the voltage and frequency of power supply match the power
requirements of the projector.
It is essential that each projector is correctly earthed and that electrical installation conforms to all
relevant standards.
Do not connect this device to any other types of dimmer apparatus.
Make sure that the power-cord is never crimped or damaged by sharp edges. Never let the
power-cord come into contact with other cables. Only handle the power-cord by the plug. Never pull
out the plug by tugging the power-cord.
Keep the optical system clean. Do not touch the LED lens with bare hands.
The product should always be installed with a secondary safety fixing. On the projector base brink,
there is a hole for the safety cord provided. It should be attached as shown in “installing the
projector” section.
LED lens shall be changed if they have become visibly damaged to such an extent that their
effectiveness is impaired, for example by cracks or deep scratches.
Exterior surface temperatures of the luminaire after 5 minutes operation is 40°C，when steady state is
achieved 50°C.
There is no user serviceable parts inside the projector, do not open the housing and never operate the
product with the covers removed.
If you have any questions, don’t hesitate to consult your dealer or manufacturer.
★Always disconnect from the mains, when the device is not in use or before cleaning it or
before attempting any maintenance work !

4
I. Product Characteristic
Use TFT display, interface luxuriant, promote product’s level.
Menu language switch,can change to Chinese or English to kinds,fit for different customer needs.
655536pcs intensity grade, really achieve 16-bit dimming. Eliminated 8-bit dimming low brightness blink’s problem,
make the dimming effect much more smooth.
Master/slave mode, any light can be master light when switch off the control signal, drive other lights.
II. Product Parameter
Power supply: AC90-240V; 50/60Hz
Power consumption: 120W
DMX control channel:11CH,15CH
DMX 512 connection:3-pin XLR
Control mode: DMX 512,Master/slave,Auto,Sound
Maximum PAN 630
Maximum TILT 240
Number of LEDs: 7pcs 12W 4-in-1 OSRAM LEDs( LE RTDUW S2W)
Beam angle: 8°
Weight: 7kg
Dimensions: 320 * 230 *350mm
III. Menu Description
Menu Structure chart
Main menu Sub menu
Address(001-512)
Address
RunMode
DMX (15CH / 11CH)
Auto(Auto1 -Auto8)
TestMode
Sound
Pan（000-255）
Titl（000-255）
Green（000-255）
Red（000-255）
White（000-255）
Blue（000-255）

5
Main menu
Use button control cursor, press “ENTER” to confirm.
Sub menu
Submenu include Address,Runmode,Testmode,Language,Setup,Sysinfo, use soft button to do each set in interface.
1) Address，after setting press “Enter” to keep address code,then go back to main menu.
2) Runmode setting，“√”is mean to the currently run mode.At the same time, only
running one mode. When you select DMX mode and auto mode, press “ ENTER”, also can choose different DMX
mode and auto mode.
Language
中文(Chinese)
English
SetUp
IDCode（0-25）
PanReverse（ON/OFF）
TitlReverse（ON/OFF）
FaderDelay(ON / OFF)
Hand（开启/关闭）
SignellLink (ON / OFF)
CodeWheel（ON/OFF）
TempSwitchSet（ON/OFF）
PanOffSet（-128-+128）
ScreenSaver（OFF/Mode1/Mode2）
ScreenRot（ON/OFF）
TiltOffSit（-128-+128）
FactorySet（YES？）
Motor RESET（YES？）
OnTime（The running time of this time）
SysInfo
RunTime（Total use time）
Ver YJ-LM2C4 D301
RunningMode
DmxAddress
TemperatureSet（50°- 120°）
Temperature（The real temperature of this light）

6
When the light in the DMX mode, then also can be slave mode. If the light connect to the DMX control
signal, then it is DMX mode.If you connect the light is Master signal, then it is running slave mode.
Auto mode,auto mode also can be master mode.
When the light in sound mode, it can’t be master mode.
3) Test mode, test mode is a special mode,only can be used when it is in test mode interface,exit interface, then
return to previous running mode.In the test mode,you can adjust Pan,tilt and focus motor’s position,also can
adjust intensity of RGBW color.The RGBW color of test mode can be used by the 16th channel in the DMX
mode.
4) Language, menu language can setted to Chinese or English.
5) Setup,
ID code,ID code is using for DMX mode in the channel15th,when the value of channel 15th over number
9,only ID code corresponding to the front two value which in 16th channel,then other channel value are
available now.
Pan reverse set
Tilt reverse set
Fader delay,when switch on handspike delay,the controller handspike can achieve soft dimming effect.
Handspike delay can be chosen ON/OFF on the controller.
Sinal link: When turn on signal link,cut off control signal will be blackout.
Code wheel: If off,ID code will failure in reset and running mode,can’t record correct position of pan and
tilt.Will recover from wrong running operation.Reset can be max travel reset from code wheel reset.
Temp Switch: Temperature protect’s switch.
Temperature:Protect temperature, when start temp protect function,if test temperature over protect
temperature,then brightness will be reduce a half.
Screen protect:It can be set turn off,mode1 and mode 2.When it’s OFF,then won’t enter screen protect
condition.When in mode 1,it will clear the screen.When in mode 2,after you into screen protection,big letter
display current address code.
Screen Rot: this menu can let the screen inversion 180 degree.
Factory set: you can set all parameters to factory set.
Motor Reset:reset the motor by hand.
Pan Off Set:Pan adjustment
Tilt Off Sit: Tilt adjustment
6) Sys info : display related information on system
i. ON time: the current time when you power on it.
ii. Run time: Total time of using this light
iii. Ver: current verson of software
iv. Running mode: System running mode currently
v. DMX address
vi. Temperature: Display current temperature
IV. Channel List
15CH

7
Channel
Value
Control function
1
0-255
Main dimming ON
2
0-255
Red
3
0-255
Green
4
0-255
Blue
5
0-255
White
6
0-255
User customs color
7
0-255
Pan
8
0-255
Titl
9
0-255
Pan fine（16Bit）
10
0-255
Titl fine（16Bit）
11
0-255
XY motor speed from quick to slow
12
0
No strobe
1-255
Strobe from slow to quick
13
0
No marco funtion
1~25
Start controller handspike
26-50
Turn off controller handspike
51-90
Program color selection switch
91-130
Pulse change
131-170
Jump change
171-210
fade
211-250
Inside mode 1（can’t be controlled）
251-255
Sound mode（can’t be controlled）
14
0-255
pulse，jump，fade from slow to quick（CH14 is between 91-210）
0
Can’t use color selection function
1~20
R255 G↑ B0 W0
21~40
R↓ G255 B0 W0
41~60
R0 G255 B↑ W0
61-80
R0 G↓ B255 W0
81-100
R↑ G0 B255 W0
101-120
R255 G0 B↓ W0
121-140
R255 G↑ B↑ W0
141-160
R↓ G↓ B255 W0
161-170
R255 G255 B255 W255
171-200
R0 G0 B0 W0
201-205
R242 G204 B5 W227
206-210
R242 G215 B5 W227
211-215
R255 G255 B50 W255
216-220
R255 G255 B90 W255
221-225
R255 G255 B118 W255
226-230
R255 G255 B132 W255
231-235
R255 G255 B151 W255
236-240
R255 G255 B171 W255
241-245
R255 G255 B185 W255
246-250
R255 G255 B197 W255
251-255
R255 G255 B234 W255
0-9
IDcode fail
10-19
ID1
20-29
ID2

8
15
30-39
ID3
40-49
ID4
50-59
ID5
60-69
ID6
70-79
ID7
80-89
ID8
90-99
ID9
100-109
ID10
110-119
ID11
120-129
ID12
130-139
ID13
140-149
ID14
150-159
ID15
160-169
ID16
170-179
ID17
180-189
ID18
190-199
ID19
200-209
ID20
210-219
ID21
220-229
ID22
230-239
ID23
240-249
ID24
250-255
ID25
11CH
Channel
Value
Control function
1
0-255
Main dimming
2
0-255
Red
3
0-255
Green
4
0-255
Blue
5
0-255
White
6
0-255
User custom color
7
0-255
X motor
8
0-255
Y motor
9
0-255
Pan fine（16Bit）
10
0-255
Titl fine（16Bit）
11
0-255
XY motor speed from quick to slow
V. FAQ
When the motor can reset in correctly,Please check if XY motor or XY code wheel insert wrong postion.
When you reset it,need to corresponding to the XY motor and XY code wheel,then can reset correctly.You can
change the motor wire to test the direction.
If you want to change motor direction,please change the DMX cable of code wheel,otherwise can’t reset normal.
When it in master/slave mode,need cut off DMX signal,otherwise can’t accept master’s signal correctly.
If code wheel damaged,you can go to set up to turn off code wheel.The light still can use normal.
