MOBILE STAIRLIFT EZ LITE User manual

2

EZ LITE EVACUATION CHAIR
1
INDEX
Introduction
1.1 - Indication for Use
1.2 - General Description / Intended Use
1.3 - Disclaimer
1.4 - Unpacking the Device
Symbols and Definitions Used in the Manual
2.1 - Warning/Cautions/Note Definitions
2.2 - Safety Precautions
Diagram of Chair
3.1 - Side View of Stairlift
Device Label
Care and Cleaning Instructions
Maintenance
Troubleshooting
FAQs
Warranty
Operation Details
4.1 - Folding The EZ Lite Evacuation Chair For Storage or Transportation
1.0
2.0
6.0
3.0
4.0
9.0
7.0
5.0
10.0
8.0

EZ LITE EVACUATION CHAIR
2
1.0-1.1
1.0 Introduction
Thank you for purchasing the Mobile Stairlift EZ Lite Evacuation Chair! We aim to provide the
safest and most adaptable mobility equipment on the market. Please read this manual in its
entirety before operating or maintaining this product. To ensure safe use, all operators of this
device should be properly trained.
CAUTION
Improper usage of this device can cause injury to the rider or operator. The EZ Lite Evacuation
Chair must only be operated as described in this manual. Do not modify the EZ Lite Evacuation
Chair or any of its components unless you are a Certified Mobile Stairlift Technician, as
modifications can result in unpredictable performance and result in injury to the rider or operator.
NOTE: This manual should remain with the EZ Lite Evacuation Chair at all times.
For customer service or technical assistance,
please contact us via email [email protected]
1.1 Indications for Use
The Mobile Stairlift EZ Lite Evacuation Chair is a manual transport device that transports the
rider in a seated, upright position on the ground as well as down stairs in a safe and efficient
manner. The EZ Lite Evacuation Chair is capable of moving adult, adolescent, or child occupants
who are able to remain seated while secured by the safety belt. The EZ Lite Evacuation Chair
is for medical and rescue personnel with proper training to move individuals under 350lbs with
disabilities safely down staircases. The EZ Lite Evacuation Chair’s wheels also allow the operator
to transport the occupant on flat surfaces when the tracks are in an upright and locked position.
WARNING
DO NOT use this stair chair lift to transport occupants
who may have cervical, spinal, or fracture injuries.

EZ LITE EVACUATION CHAIR
3
1.2-1.4
1.2 General Description / Intended Use
The Mobile Stairlift EZ Lite Evacuation Chair is intended as a transport device for a human
occupant in a seated position to be taken down flights of stairs. The occupant should be 350lbs or
less, and besecured in the chair by restraints for their safety and the safety of the operator. The
operator must read this manual and be properly trained on this product before use. The operator
must practice with the Stairlift EZ Lite Evacuation Chair alone before using it to transport a rider.
1.3 Disclaimer
This user manual contains general instructions and guidelines for the use, operation, and care of
this product. These instructions are not all-inclusive. The safe and proper use of this product is
solely at the discretion of the user. Safety information is included as a service to the user. All other
safety measures taken by the user should be within and under consideration of applicable regu-
lations. It is recommended that a complete training on how to properly use this product should be
provided before actual use.
1.4 Unpacking the Device
You will receive your device in a large box with foam protection, as photographed below. Unpack
your brand new Mobile Stairlift EZ Lite Evacuation Chair, remove all the shipping and packing
materials, and check all the items for proper operation. If anything is missing or noted not to be
correct, or any type of damage is present due to shipping, please contact Mobile Stairlift.
Items Included:
• 1 x EZ Lite Evacuation Chair
• 1 x Detachable Headrest
• 1 x Dust Cover
• 1 x Wall Hook
• 1 x Instruction Manual

EZ LITE EVACUATION CHAIR
4
2.0-2.1
2.0 Symbols and Definitions Used in this Manual
Consult instructions for use.
General Warning of any possible damages, bodily injury, or even death resulting from
incorrect use or carelessness. (See Section 2.1 for more information)
Caution to alert the reader to hazardous situations and if instructions are not
properly followed could result in minor or moderate injury to the user or occupant.
(See Section 2.1 for more information)
Serial Number of the device.
Date of Manufacture
Product should not be disposed of with your other household waste.
Check sign explains the items that you should comply with upon operation, repair
and maintenance of this device.
Do not lubricate the belts or tracks of this device.
2.1 Warning / Caution / Note: Definitions
These words carry special meanings and should be carefully reviewed.
This symbol alerts the reader about a situation which, if not avoided, could result in
death or serious injury. It may also describe potential serious adverse reactions and
safety hazards.
This symbol alerts the reader of a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury to the user or patient or damage
the product or other property. This includes special care necessary for the safe and
effective use of the device and the care necessary to avoid damage to a device
that may occur as a result of use or misuse.
NOTE: This provides special information to make maintenance easier or important instructions
clearer.

EZ LITE EVACUATION CHAIR
5
2.2
2.2 Safety Precautions
1. Read this entire user manual before using the Mobile Stairlift EZ Lite Evacuation Chair, and
use the EZ Lite Evacuation Chair only as described in this manual.
2. Always make sure that the chair is locked in the unfolded position before use. An unlocked
chair may fold during use causing injury.
3. Do not use the chair with suspected cervical, spinal, or fracture injuries.
4. Do not leave an occupant unattended. Maintain a grip on the EZ Lite Evacuation Chair while
an occupant is seated on the EZ Lite Evacuation Chair.
5. Always use the restraint straps to secure the occupant in the chair. An unrestrained
occupant may fall from the chair.
6. Make sure the occupant keeps hands inside the chair when moving up or down a staircase.
7. Avoid getting dirt inside the tracks.
8. Do not attach any additional items to this chair unless certified by Mobile Stairlift.
9. The EZ Lite Evacuation Chair may not work the same on all stair surfaces and in all
environments and conditions.
10. Never lubricate the belts or tracks of this product. Lubricating the track system can result in
injury to the patient and /or operators.
11. Do not attempt to transport occupant loads greater than what you can safely lift, and never
over the 350lb weight limit capacity.
12. To clean the EZ Lite Evacuation Chair, wipe with a towel and clean water. Dry after cleaning.
Please note that cleaning products may cause corrosion and damage to the EZ Lite
Evacuation Chair.
13. Use only parts that are specifically made for this Stairlift. If replacement parts are needed,
please contact Mobile Stairlift for assistance.
14. Maintain and operate the Evacuation Chair only as described in this manual. Mobile Stairlift
can be reached for all service, maintenance and questions regarding this chair and its
operation.

EZ LITE EVACUATION CHAIR
6
3.0
3.0 Diagram of Chair
Footrest
Handlebar
Headrest / Restraint
Removable Seat Seatbelt

EZ LITE EVACUATION CHAIR
7
3.1
3.1 Side View of Mobile Stairlift EZ Lite Evacuation Chair
ANTI SLIP RUBBER TRACKSWHEEL LOCKS
Foot brakes are located behind the two back
wheels. When at rest, please engage the
brakes to prevent unwanted movement.
Tension controlled tracks make controlled
descents safer, and durable rubber ensures
safe evacuations for years to come.
Handlebar Lock
Wheel Locks
Tracks
Track Locks
Back Wheels
Front Wheels
Front Handles

EZ LITE EVACUATION CHAIR
8
4.0
4.0 Operation Details
NOTE:
It is recommended that the operator begin training by practicing using the EZ Lite Evacuation
Chair without a rider. This will help them get familiarized with the working mechanisms of the EZ
Lite Evacuation Chair and how to safely move on flat surfaces, as well as how to
descend staircases with a rider.
Before each use of the chair, make a visual check to see that all parts are in place and that there
are no loose or moving parts. If you see anything out of ordinary issues with the chair, do not use
it until you verify with our customer service rep that it is safe to use.
STEP 3
STEP 2
STEP 1
To extend the handbar, simply
pull up and then adjust the
headrest height.
Unfold the seat and make sure
it is locked into place.
Unbuckle the safety belt from
around the EZ Lite Evacuation
Chair.

EZ LITE EVACUATION CHAIR
9
4.0
STEP 5
STEP 4
Fasten the seatbelt around
the patient.
Guide the seat towards the
patient with one individual
securely holding the chair,
as another assists the
patient into the seat.
STEP 6 OPTIONAL: Fasten the
adjustable safety strap
located on the headrest
around the rider’s
forehead. This is especially
recommended if the rider is
unable to support their head.

EZ LITE EVACUATION CHAIR
10
8.4
4.0 Operation Details
STEP 8 Holding the handlebar firmly
with both hands, tilt the EZ Lite
Evacuation Chair backwards
onto its rear wheels while
pushing the bottom of the chair
forward with your foot. As the
chair goes over the top stair, the
rubber tracks will be engaged.
STEP 9 Slowly and carefully descend
the staircase, keeping a firm
hold on the handlebar while
pressing it down towards the
stairs to maximize friction.
STEP 7 Stand behind the chair and
move the EZ Lite Evacuation
Chair until the front wheels are
a few inches from the top stair
4.0

EZ LITE EVACUATION CHAIR
11
8.4
STEP 12 Use breaks before transfer-
ing to new device or when
stopped
STEP 11 When you reach the bottom of the stairs and are on level ground,
unhook the rear wheels, and roll the chair to the desired location.
STEP 10 When you reach the bottom
of the stairs and are on level
ground, tilt the EZ Lite Evac-
uation Chair into the upright
position and roll the chair to
the desired location.
4.0

EZ LITE EVACUATION CHAIR
12
STEP 2 Press in on the handle locks on
either side of the handlebar.
STEP 1 After the patient has been
transported, slide the head
rest to the top of the handle.
4.1 Folding Directions
4.1-5.0
STEP 3 While the handle locks are
pressed in, slide the handle
bar down as far as it will go.

EZ LITE EVACUATION CHAIR
13
STEP 3 Press the rear wheels in towards the unit until they lock, then fold
the bottom of the seat up.
8.4
STEP 4 Finally, use the seatbelt to
fasten the chair closed.
4.1-5.0
5.0 Care and Cleaning Instructions
• To clean the chair, use a clean cloth or soft brush with warm clean water.
• Dry completely before use.
• Do not use products that have bleach or phenolic cleaners.
• Avoid over-saturation or leaving the chair wet for any amount of time.
• To clean the track casing, use SD-20 All Purpose Cleaner and a cloth to remove any grease
or other substance.
• Thoroughly dry before use.
• In a medical setting, we recommend you disinfect the chair between riders with basic
disinfectant for patient and operator safety.

EZ LITE EVACUATION CHAIR
14
6.0-9.0
6.0 Maintenance
To obtain parts and service call Mobile Stairlift information in the front of this
manual.
Please contact your representative for prior approval before returning this product
7.0 Troubleshooting
If you have any questions about the Stairlift, please reach out to [email protected] for
customer service assistance. The device label will also show the serial number and the date
manufactured
8.0 FAQs
Q: Can the rider operate the Mobile Stairlift EZ Lite Evacuation Chair alone?
A: No.
Q: How much space do I need on staircase landings?
A: When going from one flight of stairs to another flight of stairs, we recommend a landing
minimum of 38” x 38” to adequate room to land and make the turn. When going up
or down a single flight of stairs we recommend 40” for the top landing, and 38” for
the bottom landing.
Q: Can the chair be used in more than one location?
A: Yes, the chair folds up small enough to fit in most car trunks, and it is meant to be
transported wherever it is needed!
Q: Will this work on carpeted stairs? How about Wood, Cement, etc.?
A: Yes, the EZ Lite Evacuation Chair is made to work on all surfaces. On carpeted stairs, the
carpet must be fully attached to the stairs. It will not work with unattached carpets: the
tracks will not be able to grip properly and may slip during use.
Q: So the EZ Lite Evacuation Chair will work on cement, wood, iron and all types of stair
surfaces, but what about different shaped staircases, like round staircases?
A: The Mobile Stairlift EZ Lite Evacuation Chair does not work on round staircases.

EZ LITE EVACUATION CHAIR
15
9.0
9.0 Warranty
Thank you for your interest in the products and services of Climbing Steps, Inc.
This Limited Warranty applies to physical goods, and only for physical goods, purchased from
www.MobileStairLift.com
What does this Limited Warranty cover?
This Limited Warranty covers any defects in material or workmanship under normal use during the Warranty
Period. During the Warranty Period, Climbing Steps, Inc will repair or replace, at no charge, products or parts of
a product that proves defective because of improper material or workmanship, under normal use and mainte-
nance.
What will we do to correct problems?
Climbing Steps, Inc will either repair or replace the Product at no charge, using new or refurbished replacement
parts or products.
How long does the coverage last?
The Warranty Period for products purchased from Climbing Steps, Inc is Lifetime on the Frame Welds and 180
days on all parts from the date of purchase. A replacement product or part assumes the remaining warranty of
the original product or 180 days from the date of replacement or repair, whichever is longer.
What does this Limited Warranty not cover?
This Limited Warranty does not cover any problem that is caused by:
- Conditions, malfunctions, misuse, accidents, physical damage, modifications, or damage not resulting from
defects in material or workmanship.
What do you have to do?
To obtain warranty service, you must contact us to determine the problem and the most appropriate solution for
you.
For further information regarding this limited warranty, please contact Climbing Steps, Inc by calling
[phone], emailing at Inf[email protected], or writing Climbing Steps, Inc at the following address:
Climbing Steps Inc.
Attn Mobile Stairlift Warranty Department
1661 N. Dixie Highway
Pompano Beach, DL 33060

EZ LITE EVACUATION CHAIR
16
10.0
10.0 Device Label
Indications for Use: The Mobile Stairlift EZ Lite Stairlift is a manual transport device.
The Stairlift transports the body in a seated, upright position down a set of stairs. The
chair holds adult, adolescent, or child occupants who can remain seated and secured
in the chair. The chair stair lift is for home use with proper training. This device can also
be used in hospital environment and emergency medical service and for medical first
responders. The front and rear wheels also allows the operator to transport the occu-
pant on flat surfaces.
Need UPC
Manufactured by: Mobile Stairlift, 1661 N. Dixie Highway, Bay 12, Pompano Beach, FL 33060
EZ LITE EVACUATION CHAIR
Distributed by:
Mobile Stairlift
1661 N. Dixie Highway, Bay 12, Pompano Beach, FL 33060 • [phone]

13.0
Have more questions? Contact us!
Mail:
Mobile Stair Lift
1661 N. Dixie Highway, Bay 12,
Pompano Beach, FL 33060
Email: [email protected]
Web: www.mobilestairlift.com
Phone: [phone]
Scan with your smartphone camera to view
the Mobile Stairlift EZ Lite Evacuation Chair Information and Product Video
or visit MobileStairLift.com/EZLite


EZ LITE EVACUATION CHAIR
WWW.MOBILESTAIRLIFT.COM
