Mocka Octavia Change Table User manual

Octavia Change Table
1
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
Hardware Supplied
bolt
x16
B
allen key
x1
Phillips & Flathead screwdrivers required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
WARNING: Any furniture that is not anchored to a wall has the potential to tip
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.
Wall attachment
C
screw
x1
G
wall strap
x1
E
washer
x2
F
wall plug
x2
D
screw
x1

12
Octavia Change Table
2
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach panels [1] to panels [2] and secure with 8 x bolts (A). Tighten
with an Allen Key (B).
Attach panels [3] and [6] to assembled frame and secure with 4 x bolts
(A). Tighten with an Allen Key (B).
A
A
A
A
A
A
A
A
A
A
A
A
2
2
1
2
2
1
6
3
B
A
A
B

3
3
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Slide panels [4] and [5] into position as shown. Attach assembled frames together as shown and secure with 4 x bolts
(A). Tighten with an Allen Key (B).
Octavia Change Table
4
A
A
A
A
4
4
5
A
B

5
4
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Once assembled lift furniture into place, do not drag.
Attach wall strap (G) to unit with 1x washer (E) and 1x screw (C).
Use a drill to create a small hole lining up with the safety strap (G).
Fasten to wall using 1x wall anchor (F), 1x washer (E) and 1x wall
screw (D).
Ensure unit is balanced and steady before use. You’re done, enjoy!
Octavia Change Table
CD
EF
G
E
