Mocka Porto User manual

Porto Dining Table
1
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Phillips screwdriver required
Hardware Supplied
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
A
50mm
screw x22
B
30mm
screw x20
C
12mm
screw x8
Thank you for your purchase.
Please follow the instructions below for correct assembly.

12
Porto Dining Table
2
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Attach 2 x legs [5] to the frame [4] and secure with 8 x 30mm screws
(B) and 8 x 12mm screws (C). Tighten with a screwdriver.
Attach 3 x support panels [3] to panels [4] and secure with 12 x 30mm
screws (B). Tighten with a screwdriver.
B
B
B
B
C
C
C
C
3
5
5
4
4
3
3
C
B
B
B
B
B
B

3
3
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
Flip unit on its side as shown and attach panels [1] and [2] to panels [3],
[4] and [5] and secure with 22 x 50mm screws (A). Tighten with a
screwdriver.
Lift the completed unit into place, do not drag. You’re done, enjoy!
