Modena PI 1315 Owner's manual

User
Manual Book
Portable Induction Cooker
Essente Series
PI 1315, PI 0316, PI 1316, PI 2316

English 2
TABLE OF CONTENT
Part 1: Important Safety Information 3
Part 2: Name of Parts 6
PI 1315 6
PI 0316, PI 1316, PI 2316 6
Part 3: Pre-Installation Steps 7
Part 4: How to Use 7
Functions and Operation Guide of the Control Panel 7
Usable and Non-usable Cookware 14
Part 5: Maintenance 16
Part 6: Preventive Action 17
Part 7: Troubleshooting 18
Part 8: Specification 19
This manual book explains everything you need to know about your new
product. Please contact our Customer Care should you need further
assistance through www.modena.com.

English 3
Disposal: Do not dispose this product as common waste (garbage)
without being separated. Separate the garbage to have a special
needed treatment. Please read this manual carefully before using this
portable induction cooker.
The following symbols are used in this manual book:
The possibility of causing death or danger to
persons.
The possibility of causing a physical or appliance
damage.
Warning or Caution.
Prohibition.
Must be in accordance with the instructions.
WARNING!
The cooker repair should only be performed by trained and registered
service technicians.
Unplug the power cord before cleaning. Do not unplug the power cord with
wet hands.
Do not use the cooker if the power cord is damaged. The cord may only be
replaced by MODENA technicians or MODENA authorized call center.
Do not touch the surface of the cooker shortly after cooking because of a
burn risk from a residual heat. After cooking, the surface of the cooker takes
time to become cold.
Do not damage, bend, strongly pull or suppress on the power cord.
Make sure the voltage matches the product specification label.
This cooker is made for household use or other similar uses and is not
intended for the commercial use/ business.
In case of any problems on the cooker or damage (such as cracks,
scratches, or sides) to the black crystal glass, the cooker must be turned
off, and the power plug must be removed from the power socket to prevent
the possible electric shock.
PART 1: IMPORTANT SAFETY INFORMATION

English 4
CAUTION!
During the use, always keep an eye on the cooker. If the cooker is not used
in a long time, unplug the power cord.
Do not use the cooker that is surrounding by the flammable gases.
Do not place or store the flammable liquids or flammable materials on or near
the cooker.
The over-hot fat and oil can be burnt quickly. Do not leave the cooker when
you are cooking with fat or oil.
Do not heat the wrapped food before opening the lid.
Do not use the cooker in an environment with high humidity levels.
The addition or modification on the cooker is not permitted.
The cooker should not be used as a surface to do work (besides cooking) or
a place to put stuffs.
Use a separate outlet ( power socket ) with a capacity not less than 10 A.
Cables from the electrical appliances must not be on the surface of a cooker
or the hot cookware.
The cooker is not intended to be used by persons with physical, sensory,
and mental (special) needs, or lack of experience and knowledge (including
children), unless they have been given supervision or instructions concerning
the use of the appliance by the person who is responsible for their safety.
Children should be kept away from the cooker and supervised to ensure that
they do not play around with this appliance (the cooker).

English 5
SAFETY WARNING
Never change the structure or replace any parts of this portable induction
cooker.
Do not use the cooking utensil (cookware) that is not appropriate. Make sure
the pan surface that is in contact with the cooking zone is clean (not
exposed to oil or water).
Do not use this portable induction cooker in the environment that have high
humidity levels or in other hazardous environments.
Do not insert or put something into or around the air inlet and air outlet that
can cause airflow obstruction.
Do not use the cooker with empty cookware or without cookware.
To avoid danger, do not let children to operate the cooker alone.
Do not use the cooker on a hot surface or around a fire or other heat source.
Do not spray or pour the water directly into the cooker.
There is a risk of burn from residual heat. Therefore, after the cooker is used,
do not touch the surface of the cooker.
Do not place the cooker in a place that is easily exposed to the water or oil.
Do not place the cooker on a surface that can deliver heat (iron, etc.)
Do not use the open room. This cooker is only for indoor use.
The cooker must be placed in a location with good ventilation and at least
10cm from the wall.
In case of any problems on the cooker or damage (such as cracks,
scratches, or sides) to the black crystal glass, the cooker must be turned off,
and the power plug must be removed from the power socket to prevent a
possible electric shock.
Do not place items made of metals such as knife, fork, spoon, and the pan lid
on the cooking zone, because it can be hot.
Before using this cooker, people with pacemakers should consult with a
professional doctor.

English 6
PI 1315
PI 0316, PI 1316, PI 2316
* The features and product specifications depend on the product type.
PART 2: NAME OF PARTS
Remark:
1. Air Outlet
2. Power Cord
3. Black Crystal Glass
4. Cooking Zone
5. Digital Display
6. Control Panel
7. Air Inlet
Remark:
1. Air Outlet
2. Power Cord
3. Black Crystal Glass
4. Cooking Zone
5. Digital Display
6. Control Panel
7. Air Inlet

English 7
•If you do not understand about the installation procedure of this
portable induction cooker, contact MODENA Customer Care to
perform the installation.
•Prepare the supporting equipments required for the installation
such as screwdrivers, pliers etc.
•Prepare a power socket/ power network (line) that is easily reached
by the power cord of this portable induction cooker.
•The cooker must be placed on a flat surface, so that the pan does
not slip when it is placed in the cooking zone.
•The cooker must be placed in a location with a good ventilation and
at least 10 cm away from the wall.
•Remove stickers and film from the black crystal glass cooker before
it is being used.
•The device is not intended to be operated by an external timer
means or separated remote control system.
Functions and Operation Guide of the Control Panel
A. PI 1315
PART 3: PRE-INSTALLATION STEPS
PART 4: HOW TO USE

English 8
“On/Off” Button
•Put the suitable pot/pan containing the ingredients to be cooked
before the cooker is turned on. The cookware should be placed in
the middle of the cooking zone.
•If it is possible, always put the cookware lid on. Make sure that the
air inlet and outlet are not blocked, and metal objects should not be
near the cooker.
•Then, connects the power plug to the power supply. There will be
“beep” sound, and all the power indicator light will flash once.
•Press “On/Off” button, display will show the text “ On ”, then select
the desired function/menu.
Cooking Menu Program Button
Press the “P” button to select an automatic cooking menu, press this
button several times until the indicator light on the selected menu
lights up.
“+” and “–“ Buttons
Press the controller buttons to raise “+” or lower “–“ the power, timer, or
temperature setting.
Timer
•Under the cooking mode, press “Timer” button to set the cooking
time. The default timer is 00:00.
•By the “Timer” function, the cooking time can be set as needed
when the cooker is working.
•Press “+” or “–“ button to set the cooking time. By long pressing the
“+” or “–“ button, the set time will be increased or decreased
quickly.
•If there is no instruction within 5 seconds under the time condition,
the cooker will change the condition back to the original state.

English 9
“Child Lock” Button
•The function of “Child Lock” button is to prevent children from
changing cooking program or settings.
•Press “Child Lock” button once to activate its function, the “Child
Lock” (red) indicator light will turns on, and the cooker will not
respond any time or temperature settings. The “Child Lock”
function can be activated on both working and standby mode.
•When the “Child Lock” function is activated, all buttons will be
locked, except “On/Off” button.
•To turn off the “Child Lock” function, press the “Child Lock” button
for 3 seconds until you hear a “beep” sound and the red indicator
light turns off.
“Stir Fry” Program
•This program is used to cook with short time cooking like stir fry.
•When the power is on, press the ”P” button, select the “Stir Fry”
menu until the “ Stir Fry” indicator lamp turn on.
•Then, the cooker enters the “Stir Fry” condition with default power
2000W.
•Press the “+” or “– “ to adjust the power (300W, 700W, 1000W,
1200W, 1400W, 1600W, 1800W, 2000W).
“Hot Pot” Program
•“Hot Pot” program is suitable for the cooking that requires high
temperature and boiling water. During the cooking process, the
power level and cooking time can be adjusted and changed as
needed.
•When the power on, press the “P” button, select the “Hot Pot” menu
until the “Hot Pot” indicator light turns on, and the cooker will enter
the “Hot Pot” condition with default power 1800W.
•Press the “+” or “–“ to adjust the power (300W, 700W, 1000W,
1200W, 1400W, 1600W, 1800W, 2000W).

English 10
“Porridge/Soup/Boil/Milk” Programs
•These are the auto menus; the power cannot be adjusted when in
these cooking menu.
•“Porridge” program is for cooking porridge.
•“Soup” program is for cooking soup.
•“Boil” program is for boiling water.
•“Milk” program is for boiling or warming milk.
•The display will show “AU”. Porridge default cooking time is 1 hour,
Soup is 2 hours, Boil is 20 minutes, and Milk is 30 minutes.
•The cooker will automatically switch off once the cooking time is
finished.
“Steam” Program
•The “Steam” program is used for steamer/stew.
•When the power is on, press the “P” button, select the “Steam”
menu until the “Steam” indicator light is on, and then the cooker will
enter “Steam” condition with default Timer 00:45.
•The cooker will automatically switch off once finish the cooking.
“Fry” Program
•The “Fry” program is used for fry with normal condition.
•When the power is on, press “P” button, select the “Fry” menu until
the “Fry” indicator light turns on, and then the cooker enters “Fry”
condition with default temperature 220℃.
•Press the “+” or “–“ to adjust the temperature (60℃, 80℃, 120℃,
150℃, 180℃, 200℃, 220℃, 240℃).
NOTE
•Make sure that the remaining water is 30% to 80% of pot
capacity when boiling the water.
•Factors such as uneven cookware surface and environment can
affect the process and the result of boiling.
•Use special cookware or water kettle to boil the water.
.

English 11
B. PI 0316, PI 1316, PI 2316
“On/Off” Button
•Put the suitable pot/pan containing the ingredients to be cooked
before the cooker is turned on. The cookware should be placed in
the middle of the cooking zone.
•If it is possible, always put the cookware lid on. Make sure that the
air inlet and outlet are not blocked, and metal objects should not be
near the cooker.
•Then, connects the power plug to the power supply. There will be
“beep” sound, and all the power indicator light will flash once.
•Press “On/Off” button, display will show the text “ On ”, then select
the desired function/menu.
“+” and “–“ Buttons
Press the controller buttons to raise “+” or lower “–“ the power, timer, or
temperature setting.

English 12
Timer
•Set the cooking time after you press the cooking menu. The default
timer is 00:00.
•By the “Timer” function, the cooking time can be set as needed
when the cooker is working.
•Press the “+” and “–“ buttons to set the cooking time. Long pressing
can increase or decrease the set time quickly.
•If there is no instruction within 5 seconds under the time condition,
the cooker will change the condition back to the original state.
“Child Lock” Button
•This function allows you to set the desired power and time and
then lock the control panel to avoid changing the setting by
mistake.
•To use this function, press the “+” and “–“ buttons at once. Then,
the induction cooker will be in the “Child Lock” mode.
•When the “Child Lock” function is activated, all buttons will be
locked, except “On/Off” button.
•To turn the “Child Lock” off, press and hold the “+” and “– “buttons
at once for 3 seconds or press the “On/Off” button to cancel the
lock setting.
“Stir Fry” Program
•This program is used to cook with short time cooking like stir fry.
•When the power is on, press the ”Stir Fry” button until its indicator
light turns on, and the cooker enters the “Stir Fry” condition with
the default power 2000W.
•Press the “+” or “–” to adjust the power (100W - 2000W).

English 13
“Hot Pot” Program
•The “Hot Pot” program is suitable for cooking that requires high
temperature and boiling the water. During the cooking process, you
can adjust or change the power level and cooking time as needed.
•When the power on, press the “Hot Pot” button until its indicator
light turns on, and the cooker enters the “Hot Pot” condition with
default power 2000W.
•Press the “+” or “–” to adjust the power (100 W - 2000 W).
“Porridge/Soup/Boil/Milk” Programs
•These are the auto menus; the power cannot be adjusted when in
these cooking menus.
•“Porridge” program is for cooking porridge.
•“Soup” program is for cooking soup.
•“Boil” program is for boiling water.
•“Milk” program is for boiling or warming milk.
•The display will show “AU”. Porridge default cooking time is 1 hour,
Soup is 2 hours, Boil is 20 minutes, and Milk is 30 minutes.
•The cooker will automatically switch off once the cooking time is
finished.
NOTE
•Make sure that the remaining water is 30% to 80% of pot
capacity when boiling the water.
•Factors such as uneven cookware surface and environment
can affect the process and the result of boiling.
•Use special cookware or water kettle to boil the water.
.

English 14
“Steam” Program
•The “Steam” program is used for steamer/stew.
•When the power is on, press the “Steam” button until its indicator
light is on, and then the cooker will enter “Steam” condition with
default Timer 00:30.
•The cooker will automatically switch off once finish the cooking.
“Fry” Program
•The Fry program is used for fry with normal condition.
•When the power is on, press the “Fry” button until its indicator light
is on, and then the cooker enters the “Fry” condition with default
temperature 240℃.
•Press the “+” or “–” button to adjust the temperature (60℃ -
240℃).
Usable and Non-usable Cookware
Usable Materials
Steel or cast iron, enameled iron, stainless steel, flat-bottom pans/pots
with bottom diameter from 12 cm to 26 cm.
Frying
(Made of Iron)
Pans
(Made of Steel)
Frying Pan
(Made of Iron)
Boiler
(Made of Iron)
Kettle
(Enamel-coated Steel)
Utensils
(Made of Enamel)
Plate
(Made of Iron)

English 15
Steel, enamel-coated steel
Yes
Cast iron
The usage is limited because it can
shorten the cooker durability.
Stainless steel
Yes, if it is marked specifically by its
factory
Glass, ceramics, porcelain
No
Aluminum, copper, brass
No
a) The cookware that is suitable for this portable induction cooker
has a special mark given by the factory. A cookware is suitable to
be used for the induction cooker if:
•A small amount of water has boiled up in a short time when a
cookware (e.g pan) is placed on the cooking zone at the
highest power level.
•Magnets can stick to the cookware base.
b) The cookware must be as thick as possible and certainly flat. The
certain cookware can make noise (sound) when being used on the
portable induction cooker. That sound is not due to the damage of
the cooker, and it does not affect the operation of the cooker.
c) For a certain type, the induction cooker is sold together with its
pan as one package. That pan is specifically designed to provide
optimum cooking performance. It is recommended not to use other
alternatives for avoiding the adverse effects on the performance
of the cooker. If you are using another pan, note the following
conditions:
•The materials of the pan should contain the magnetic induction
material.
•The uneven cookware base should not be used on this cooker
because it can trouble the function and make the glass broken.
•The size of the cooking zone will automatically adjust to the
cookware base to a considerable extent. The cooking zone
size of this cooker is 14.5 –20 cm.
d) The portable induction cooker can identify most of the cookware
except those which are made of the non-magnetic steel.
e) The cooker should only be used for cooking in households. The
maximum weight that can be accommodated by the cooker is 4
kg.

English 16
Non-usable Materials
Heat-resistant glass, ceramic container, brass, copper, aluminum
pans/pots, and pans/pots with rounded-base (uneven base) and with
diameter less than 12cm.
Clean the cooker regularly after being used. Make sure that the cooker
has been turned off and the power plug has been removed from the
power socket and wait for the cooker cooling down before cleaning.
•Please be careful, there is a risk of burns from residual heat.
•Sharp objects and abrasive cleaning agent can damage the cooker.
•Prevent the water or the cleaning agent from entering the air inlet
and outlet because its residue can damage the cooker.
•For the user safety, cleaning off the cooker with steam spray or
high pressure cleaning equipment is not permitted.
•Remove the stain with warm water and dishwashing liquid.
•Clean the cooker after using it. Wipe the cooker using a damp cloth
with warm water. Then, dry it using a soft, clean cloth.
•Remove stubborn stain with cleaning agent for black crystal glass.
•Some scratches and dark stain on the black crystal glasses
probably could not be removed. However, this does not affect the
function of the cooker.
•If an aluminum sheet, plastic materials, or liquids/ foods containing
high sugar melt on the black crystal glass, the stain should be
cleaned immediately before the surface of the cooker becomes
cool. Otherwise, the fine holes may occur on its surface.
PART 5: MAINTENANCE
Rounded
-bottom
Pot
Aluminum/
Copper
Pot
Bottom
Diameter
< 12 cm
Pot with
Stands
Ceramic
Pot
Heat-
resistance
Glass Pot

English 17
•The black crystal glass of the cooker can be damaged caused by
any hard or strange objects falling on it.
•The edges of the black crystal glass can be damaged due to the
cookware collision.
•The cookware that made of cast iron, cast aluminum, or cookware
with a damage base can scratch the black crystal glass if it is
shifted above the cooker surface.
•The melted and overflowed materials can burn the black crystal
glass, and they immediately should be removed.
•To prevent the damage to cookware and black crystal glass, avoid
using pots and pans in an overly long time that causes the food
burnt or dried.
PART 6: PREVENTIVE ACTION
NOTE
•The materials containing high sugar are not only jams and fruits,
but also vegetables such as peas, tomatoes, and carrots.
•The body of the cooker can be cleaned using a soft dry cloth.
Dust around the air inlet and outlet can be cleaned using a soft
brush.
.

English 18
Check the things below before contacting MODENA Customer Care if
there is trouble on this portable induction cooker:
Problem
Possible Causes and Recommended Actions
After the electricity is
connected, the cooker
cannot be turned on
•The power cord is not securely fastened to the power
socket.
•Switches, sockets, fuses, and electrical wiring are not
in a good condition.
•The power is outage.
•The voltage is over-low.
The cooker is on, but there
is no heating process, and
the alarm is beeping
•The material of the cookware is not suitable.
•There is no cookware on the cooking zone.
•The pan is not placed on the centre of cooking zone.
•For other reasons, contact MODENA Customer Care.
Heating process stops
suddenly when the cooker
works.
•Ambient temperature is too high.
•The air inlet or outlet holes are blocked.
•Electric voltage is out of the cooker’s range.
•The set time has run out.
•The cooker has been operating for 2 hours.
•Protection system is working and is testing the electric
flux.
Error
code
E0
•Inner circuit error.
E1
•No pan on the cooking zone or the pan is not suitable.
E2
•IGBT (Insulated Gate Bipolar Transistor) temperature is
overheat.
E3
•Input volt is too high.
E4
•Input volt is too low.
E5
•Heat sensor 1 is opened, or short circuit occurs.
E6
•Heat sensor 2 is opened or short circuit occurs.
E7
•The cooking zone is overheat or thermistor NTC2
(faiure protection) is active.
•Wait a few minutes until the temperature of the cooker
becomes normal.
E1, E3, E4, E7
•Please check the cooker first before contacting
MODENA Customer Care.
E0, E2, E5, E6
•Please contact MODENA Customer Care.
PART 7: TROUBLESHOOTING

English 19
Model
PI 1315
PI 0316
PI 1316
PI 2316
Type
Portable Induction Cooker
Number of Cooking
Zone
1
System Blocking
Safety
Yes
Color
Black-Siver
Black
Control Panel
Touch Control
Power Level
8 (300-2000W)
9 (100-2000W)
Timer
Yes
Operating Power
900 –2000 W
Voltage
220 V / 50 Hz
Dimension
(L x W x H)
310 x 270 x 65 mm
310 x 380 x 40 mm
Cookware Included
Induction Pot
N/A
Induction
Pot
Induction
Wok
Specifications of this appliance may change without notice to improve the quality of the
product. Pictures in this manual are schematic and may not match your product exactly.
Values stated on the machine labels or in the documentation accompanying it are obtained
in laboratory in accordance with the relevant standards. Depending on operational and
environment conditions of the appliance, values may vary.
PART 8: SPECIFICATION

5/21
