modway EEI-2278 User manual

Customer Service 908-368-1025︱www.modwayfurniture.com Page 1 of 3
EEI-2278 SWING CHAIR
Hardware:
Component:
A Bolt M10x55mm x6
B
C Spring x2
Thank you for purchasing the MODWAY SWING CHAIR！
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the chair, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approx assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that has been provided.
6.Please keep all fitting out of reach of children.
2
3
Nut M10 x6
1
E Open Wrench x1
D Allen Wrench x1
1 Left Leg x1 4 Top Stretcher x1
2 Right Leg x1 3 Bottom Stretcher x1
5 Stand x2 8 Cushion x1
6 Canopy x1 7 Basket Frame x1
9 Pillow x2 10 Canopy Cover x1
1 2
3
8
9
9 5
5
7
6
4
10

Customer Service 908-368-1025︱www.modwayfurniture.com Page 2 of 3
EEI-2278 SWING CHAIR
STEP 1:
Ax6 Bx6 Cx2 Dx1 Ex1 Hardware & Tool required
Please put all chair parts on a carpeted or padded area, find hardware package inside of the tube on Left Leg (1) and Right Leg (2).
Attach Bottom Stretcher (3) to Left Leg (1) and Right Leg (2) as shown.
Secure by using 2 pieces of Bolt (A) with 2 pieces of Nut (B).
Use Allen Wrench (D) and Open Wrench (E) to tighten Bolts (A) and Nuts (B) clockwise until secure.
STEP 5:
Hang Basket Frame (7) to Top Stretcher (4) by using 2 pieces of Spring (C) as shown.
Place Cushion (8) and 2 pieces of Pillow (9) to Basket Frame (7) as shown.
Place Canopy Cover (10) to Canopy (6) as shown.
Insert Stand (5) into left Leg (1) and Right Leg (2) as shown, secure by using 2 pieces of Bolt (A) with 2 pieces of Nut (B).
Use Allen Wrench (D) and Open Wrench (E) to tighten Bolts (A) and Nuts (B) clockwise until secure.
STEP 2:
Insert Canopy (6) with adjusters into Top Stretcher (4) as shown.
STEP 4:
STEP 3:
Attach Top Stretcher (4) to Stand (5) at two sides as shown.
Secure by using 2 pieces of Bolt (A) with 2 pieces of Nut (B).
Use Allen Wrench (D) and Open Wrench (E) to tighten Bolts (A) and Nuts (B) clockwise until secure.

Customer Service 908-368-1025︱www.modwayfurniture.com Page 3 of 3
EEI-2278 SWING CHAIR
Assembly is completed. The swing chair is ready to enjoy now!
Note: Hardware package is
packed inside of the leg tube.
1
10
A
B
B
B
Maximum Weight: 200 KG
