Mopar 68275910AB User manual

1
RAM
DT 1500 Rear Wheel Liners
www.mopar.com
2
1
7
December 9,2020
K6864217AA

Call Out
Description
Quantity
Part Number
82216333AA
1
M6 U Nut (06509500AA)
18
2
M6 Mounting Fastener
(06510175AA)
24
3
RH Wheel Liner (68275910AB)
1
4
LH Wheel Liner (68275911AB)
1
2
December 9th, 2020 K6864217AA

3
December 9th, 2020 K6864217AA
1. Remove the spat screw (3) for the
shield being serviced
2. If equipped, remove the three screws (1)
attaching the front shield (3) to the box
side.
3. Remove the inner screw (2) and remove
the shield (3)

4
December 9th, 2020 K6864217AA
4. If equipped, remove the two screws (2)
attaching the rear shield to the box side.
5. Remove the inner screw (1) and remove
the rear shield
6. Install the Full Splash Shield; Install the
supplied U-Nuts and Molding Screws (2)
to the cargo Box, Tighten Securely
7. Install the two inner screws (1), Tighten
Securely

5
December 9th, 2020 K6864217AA
9. Repeat Steps 1-8 for opposite side of
the vehicle.
8. Install the spat screw for the shield being
serviced. Tighten the screw securely.
Torque Fastener to 6Nm
