Morris MAC-16252 User manual

READ AND SAVE THESE INSTRUCTIONS
Attention: Pictures in the IM are for reference only.
Tower Fan 3 in 1
Instruction manual
Model: MAC-16252

IMPORTANT SAFETY INSTRUCTIONS
Read Rules for Safe Operation and Instructions Carefully.
Caution
WARNING
1
1. If the supply cord is damaged, it must be replaced by
manufacturer, its service agent or a similarly qualified person
in order to avoid a hazard.
2. Household and indoor use only.
3. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
4. Unplug the appliance during filling and cleaning.
5. Prior to cleaning or other maintenance, the appliance must be
disconnected from the supply mains.
6. Non-specialized personnel or unauthorized repair personnel
shall not to repair or modify the machine.
7. It is forbidden to operate with wet hands to avoid electric
shock.
8. If the unit is not in use for a long time, unplug the power cord.
9. To prevent accidental injury or damage to the unit, please do
not insert any foreign matter into the air inlet and outlet,
because the unit incorporates a high-speed wind rotor.
10. It is prohibited to use this unit in environments with flammable
and explosive gases and direct sunlight for a long period shall
be avoided.
11. Do not place this unit in an inclined or other uneven place to
prevent the unit from falling and causing damage to the unit
or internal parts.
12. This machine has a safety switch. If the honeycomb filter
support has not been installed well, the unit will not work as
usual; when the machine is working, do not remove the
honeycomb filter frame.

2
13. At any time the water level in the tank shall not exceed
"MAX" (maximum) scale, and during humidification, the total
water level in the tank shall be controlled, and shall not be
below "MIN" (minimum) scale.
14. After the water tank is filled with water, do not tilt or collide
with the unit when placing or moving it. To move the unit
body, please drive it slowly from the side to prevent water
overflow.
15. In using the unit, prohibit overturning to avoid any accident.
If the unit topples over accidentally, and it contains water,
unplug the power cord immediately and take it to repair store.
16. Do not place items on the unit, and covering the outlet is
strictly prohibited.
17. To clean the unit's appearance, apply a damp cloth (or add a
little cleaning agent) to wipe, and never use corrosive
cleaning agent or solvent for cleaning. Never rinse the unit
with water.
18. Do not keep the air inlet and outlet of the unit close to walls,
curtains and other objects, or they may block the airflow and
affect air supply.
19. When the unit is running, do not knock at or shock the unit
body forcibly or it may lead to automatic shutdown, in which
case simply restart the unit.
20. In summer, the water in the tank may easily deteriorate and
generate odor, please pay attention to regular change of
water; if the indoor temperature is below zero in winter
humidification, it is best to use warm water for humidification.
21. Do not place the unit directly below the power outlet.
22. Do not use the unit around the tub, sprinkler or swimming
pool.
23. Product repair must be carried out in a designated agency.
24. To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other liquid.
25. Use a soft cloth moisten with mild soap, and then use a dry
cloth to wipe it again.
IMPORTANT SAFETY INSTRUCTIONS
WARNING

3
1. Never insert fingers, pencils, or any other object through the
grille when fan is running.
2. Disconnect fan when moving from one location to another.
3. Be sure fan is on a stable surface when operating to avoid
overturning.
4. DO NOT use fan in window, rain may create electrical hazard.
5. Household use only.
RULES FOR SAFE OPERATION
IMPORTANT SAFETY INSTRUCTIONS
WARNING
27. Do not permit the area around the humidifier to become damp
or wet. If dampness occurs, turn the output of the humidifier
down. If the humidifier output volume cannot be turned down,
use the humidifier intermittently. Do not allow absorbent
materials, such as carpeting, curtains, drapes, or tablecloths,
to become damp.
Unplug the appliance during filling and cleaning.
Never leave water in the reservoir when the appliance is not in
use.
Empty and clean the humidifier before storage.
Clean the humidifier before next use.
26. Correct Disposal of this product
This marking indicates that this product should not be
disposed with other household wastes throughout the EU. To
prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To
return your used device, please use the return and collection
systems or contact the retailer where the product was
purchased. They can take this product for environmental safe
recycling.The packaging material is recyclable. Dispose of the
packaging in an environmentally friendly manner and make it
available for the recyclable material collection-service.

PRODUCT INTRODUCTION
Notice
Pictures in the manual are for reference only, and real objects within the packaging box will
prevail in the end.
Parts name
4
Control part
Water tank
buckles
Ice crystal box
Water tank

INSTALLATION INSTRUCTIONS
1 Take the two parts of the base out of the box, align the centers of the two bases and
place them crosswise, then rotate one of the bases to align the holes and snap them
together.2 Align the fuselage clip line with the base clip line, and press the fuselage into the base,
you can fix it with screws at the mark to the base.
Notice
Guidance on feeding water and disassemble & washing of the
water tank
INSTRUCTIONS
Please clean up water accumulated at the bottom of the water tank in a timely manner when the product
is left unused.
Please remove the power plug when feeding water and cleaning.
Please make sure that the water pump module is fixed in position before startup. Random displacement
of the water pump module can cause the abnormalities of the product in cool wind function.
Two ways for feeding water:
①Pull out half of the water tank, and feed water directly without disassembling the water pump module.
②
Separate water pump module, and fully pull out the water tank, to feed water or clean the water tank.
5

Pull out the water tank completely,
place it on a stable place, add water
and push the water tank into the fuselage.
2
Pull the water tank buckle
to the horizontal state.
1
Guidance on feeding water and disassemble & washing of the
water tank
INSTRUCTIONS
Unscrew the rotary knob in "—" shape
manually (90° anticlockwise) to separate
the water tank from the water pump
module (including the water pipe).
3Pull out the tank completely to clean
and add water.
4
After feeding water or cleaning the water
tank, install the water pump module in
the water tank. Insert front hook into the
slot of the water tank, and then rotate
rotary knob in "—" shape clockwise for
90°, and close it as shown in the figure.
Water pump module
Rotary knob in "—" shape
6
Position of clean water pump shown.
It is recommended to clean every 3 months
to extend the service life.
56

INSTRUCTIONS
7
Guidance on feeding water and disassemble & washing of the
water tank
Push the water tank inside slowly, and
stir the water tank buckle to lock it up.
7
1 Pull out the water tank completely and
place it on a stable place.
①The ice crystal box can be frozen repeatedly and recycled; You can also choose not to use it
based on the temperature.
②Please keep the ice crystal box closed to prevent from damage and liquid leakage.
③The ice crystal box is made of eco-friendly and toxic-free materials, and can be refrigerated in
fridge safely.
④When using the frozen ice crystal box in the water tank, the temperature at the air outlet will drop
after operating cool wind function.
⑤Ice blocks can be used to replace the frozen ice crystal box, to exert the same cooling effect.
⑥Control the water level of the water tank to be lower than the "max" (maximum) indicating scale
when feeding water, and if the water level is lower than "min" (minimum) indicating scale, please
feed water in time.
Take the ice crystal box out of the
package and place it inside a refrigerator
to freeze for more than 3 hours. Put the
frozen ice crystal box in the water tank,
and feed water below "max" (maximum)
indicating scale.
Usage of the ice crystal box
Notice
2
Scale of the water tank

Operating instructions of the machine body
INSTRUCTIONS
8
Product starts or stops. Anion indicator light
when the product is turned off.
is on when the product is on, and the light is off
In the startup state, press this key, the indicator light will be on, and briefly press this key to set
the timed shutdown time (press 1-2-3 ·· - 7-0-1 ··· cycle).
In standby mode, press this key, the indicator light will be on, and briefly press this key to set the
reserved startup time (press 1-2-3 ·· - 7-0-1 ··· cycle).
Touch this button to start/stop the swing.
Short press this button to switch wind speed, low , medium , high .
Short press this key to choose from three wind types:Normal wind (3 gears, wind speed indicator light
on),Sleep wind (2 gears, sleep wind indicator light on), Baby wind 'natural' (1 gear, baby wind
indicator light on).
Press briefly in the power on state to turn on or off the cool air. In dry or hot weather, turn on the cool
wind function for better experience.
If the indicator light flashes, please add water in time and briefly press again to turn on this
function.
Buttons Function description
OSC
SPEED
MODE
TIMER
COOLER

Notice
The remote control should be normally used within 5 meters of the front of the product and 30 degrees
of the deviation angle.
The battery contains many heavy metals, acids and bases, etc., which may threaten human's health;
Waste batteries should be recycled separately.
Note:
Both machine body operation " " and remote control " ... "
are buttons of cool wind.
...Open/stop
air swing
Startup/Standby
Set the timed shutdown/
reserved startup
"+" indicates accelerating
wind speed
"-" indicates decreasing
wind speed
Set wind
type
Open/close
cool wind
Remote control button description
INSTRUCTIONS
AAA Battery, 1.5 V
Battery
Use manganese or alkaline batteries of type
"AAA". DO not use rechargeable batteries.
9
CLEANING AND MAINTENANCE
Notice
Disconnect the power before cleaning the product. Clean after the product is shut down for two
minutes.
Prevent from using any abrasive tools and solvents that may damage the surface to clean up the
product. Detergent can be used in the cleaning, and then wiped clean with dried cloth in time.
Prevent from washing the machine body with water directly, and wash disassemble parts (wet
curtain parts) with a soft brush and then install them after they are cleaned and dried.
It is not allowed to take the product apart for any modification. It is recommended that this product
should be checked and cleaned regularly in order to extend its service life.

Replace water
CLEANING AND MAINTENANCE
After stopping the cool wind function for 2 minutes,
it's applicable to pull out the water tank to replace
water, as water in the pipeline and wet curtain flows
back to the water tank.
10
Stop the cool wind
function for 2 minutes.
Please check the following points before asking others for inspection or maintenance.
Faults
The product cannot be
normally operated after
being installed.
Abnormalities of cool
wind function.
Fault description
The power cord fails to be plugged in or has bad
contacts.
The machine switch fails to be opened.
Check whether the water tank lacks water.
Troubleshooting
SERVICE GUIDE

CLEANING
MAINTENANCE INSTRUCTION
The fan requires little maintenance. Do not try to fix it by yourself. Refer it to
qualified service personnel if service is needed.
1. Before cleaning and assembling, fan must be unplugged.
2. To ensure adequate air circulation to the motor, keep vents at the rear of the motor free of
dust. Do not disassemble the fan to remove dust.
3. Please wipe the exterior parts with a soft cloth soaking a mild detergent.
4. Do not use any abrasive detergent or solvents to avoid scratching the surface.
Do not use any of the following as a cleaner: gasoline, thinner.
5. Do not allow water or any other liquid into the motor housing or interior parts.
1. Make sure to unplug from the electrical supply source before cleaning.
2. Plastic parts should be cleaned with a soft cloth moisten with mild soap.
Thoroughly remove soap film with dry cloth.
11

NOTICE ABOUT RECYCLING
Your product is designed and manufactured with high quality materials
and components which can be recycled and reused.
This symbol means that electrical and electronic equipment, at their end-
of-life, should be disposed of separately from your household
waste. Please dispose of this equipment at your local community waste
collection/ recycling centre.
In the European Union there are separate collection systems for
used electrical and electronic products.
Please help us to conserve the environment we live in!
DECLARATION OF CONFORMITY
Herewith, KALLIOPI KARIDA & CO., LP states that this product, complies with
the requirements of below directives:
EMC-Directive: 14 / 30 / EU
Low Voltage Directive: 14 / 35 / EU
CE Marking: 93 / 68 / EEC
RoHS Directive: 11 / 65 / EU & 15 / 863 / EU
The detailed declaration of conformity can be found at:
www.morris.gr
Exclusive importer in Greece:
KALLIOPI KARIDA & CO., LP
87A, 17th Noemvriou str, P.C. 55535
Thessaloniki – Greece
T: [phone] | F: [phone]
www.morris.gr
