Motorola MPx User manual

FCC ID: GKRMPX001
User’s Manual
A revised preliminary draft copy of the manual follows:
EXHIBIT 8A
Revised 11-05-04

START HERE >
MPx
GSM

1
Welcome
Welcome to the world of Motorola converged devices. Your
selection, the Motorola MPx, delivers to you simplified
communications, increased productivity, and the control to
develop a superior mobile experience whether at work, at
home, on the road or at play.

2
Phone Mode
Main Screen
Ear Piece
Voice Dial
Key
Action Key
Contacts Key
4-way
Navigation Key
Keyboard
End Key
Send Key
Keypad

3
The Keypad
Your device contains a functional keypad.
Input Keys
Use the input keys to enter letters and numbers.
4-way Navigation Key
Use the 4-way navigation key to:
• scroll up, down, left, or right through the menu system
• highlight menu items—press the Action key to select a
highlighted menu item
• change feature settings
• play games
• move the cursor during text entry
Easy
Access
Keys
Input
Keys
Easy
Access
Keys
Easy
Access
Keys
4-way
Navigation
Key and
Action Key

4
Easy Access Keys
Press To
W Start open the Start menu
2 Inbox launch the messaging function
M Contacts display a shortcut menu with
control options for the selected item
j Camera activate the camera
K OK cancel the current option
N Send make and answer calls, view
recently dialed calls list
I Speech
Recognition
use Speech Recognition
J Menu open the Contacts folder
P P ower/End power the device on and off,
suspend the device, end calls, and
exit menu system

5
Landscape Mode
For the QWERTY keyboard, there are tactile nibs placed on
the
F key and the L key. Although typical implementation of
these nibs is on the
F key and the J key, this unique device
has the
L key double as the 5 key when in phone mode. Thus,
while the device is opened in phone mode the numeric
keypad can be easily navigated using the 5 key nib, and in
QWERTY messaging mode the spacing of the nibs on the
F
key and the
L key is more symmetric with the geometry of the
device.
Menu
Key
Inbox
Key
Start Key
ALT Key
Camera
Key
OK Key
Send Key
Shift
Key
Power/End
Key
Enter KeyBackspace Key

6
Front Panel
Application
Keys
SIM Card Slot
Power Jack
Sync/Charger
Port
Infrared PortEarphone Jack
Notification
LED
SD Card
Slot
Speaker
External
DIsplay
Release
Button
Reset
Switch
Camera

7
Back Panel
Battery Latch
Battery
Cover
RF Test
Point
Stylus
