Motorola H605 - Headset - Over-the-ear User manual

1
Welcome
The Motorola H605 Bluetooth Headset makes connectivity invisible and reliable.
It is astonishingly advanced and simple to use.
Motorola is actively creating Bluetooth®solutions for work, play, home, and life
everywhere around the globe.
Thank you for choosing the Motorola H605 headset with Bluetooth technology!

2
Export Law Assurances
This product is controlled under the export regulations of the United States of
America and Canada. The Governments of the United States of America and
Canada may restrict the exportation or re-exportation of this product to certain
destinations. For further information contact the U.S. Department of Com-
merce or the Canadian Department of Foreign Affairs and International Trade.
The use of wireless devices and their accessories may be prohibited or re-
stricted in certain areas. Always obey the laws and regulations on the use of
these products.
MOTOROLA and the Stylized M Logo are registered in the US Patent & Trade-
mark Office. The Bluetooth trademarks are owned by their proprietor and used
by Motorola, Inc. under license.
All other product or service names are the property of their respective owners.
© Motorola, Inc., 2005.

3
欢欢
欢欢
欢迎迎
迎迎
迎使使
使使
使用用
用用
用
摩托罗拉 H605蓝牙耳机，自由实现可靠连接。它非常先进且使用简单。
摩托罗拉一直在 极努力，为世界各地的人们能更好地工作、娱乐、生活创造全新
的Bluetooth® 解决方案。
非常感谢您选择摩托罗拉H605蓝牙耳机！

4
出出
出出
出口口
口口
口法法
法法
法律律
律律
律保保
保保
保证证
证证
证
本产品受美国、加拿大出口管理法规制约。美国、加拿大政府可能会限制本产品出
口或再出口到某些目的地。详情请垂询美国商务部或加拿大外交与国际贸易部。
一些地区可能禁止或限制使用无线设备及其配件设备。请遵守有关法律法规使用本
设备。
MOTOROLA 及 Stylized M 标识已经在美国专利商标局进行注册。蓝牙商标的
所有权归其所有者，摩托罗拉公司经批准可以使用。
所有其它产品和服务名称均为各自所属公司所有。© 2005 摩托罗拉公司版权所有。

5
歡歡
歡歡
歡迎迎
迎迎
迎使使
使使
使用用
用用
用
摩托羅拉 H605藍芽耳機，自由實現可靠連接。它非常先進且使用簡單。
摩托羅拉一直在積極努力，為世界各地的人們能更好地工作、娛樂、生活創造全
新的 Bluetooth® 解決方案。
非常感謝您選擇摩托羅拉H605藍芽耳機！

6
出出
出出
出口口
口口
口法法
法法
法律律
律律
律保保
保保
保證證
證證
證
本產品受美國、加拿大出口管理法規制約。美國、加拿大政府可能會限制本產品
出口或再出口到某些目的地。詳情請垂詢美國商務部或加拿大外交與國際貿易部。
一些地區可能禁止或限制使用無線裝置及其配件裝置。請遵守有關法律法規使用本
裝置。
MOTOROLA 及 Stylized M 標識已經在美國專利商標局進行註冊。藍芽商標的
所有權歸其所有者，摩托羅拉公司經批准可以使用。
所有其他產品和服務名稱均為各自所屬公司所有。© 2005 摩托羅拉公司版權所
有。

7
GET CONNECTED IN 4 QUICK STEPS..........................................1
USING YOUR H605......................................................................8
Contents
............................................................................................2
.........................................................................
...............................................
.................................................................................................
.....................................................................................................
.....................................................................................................
..........................................................................................9
......................................................................................
.............................................................1
................................................................................................
.......................................................................................................
..............................................................................
.........................................................................................................
.............................................................................................
BEFORE YOU BEGIN
①CHARGE Your Headset’s Battery
②START BLUETOOTH Feature On Your Handset
③PAIRYour Headset
PAIRYour Phone
④TEST AND USE
TURNING ON AND OFF
WEARING THE HEADSET

INDICATOR LIGHTS
MAKINGCALLS
CONTINUED
AUDIO TONES
TROUBLESHOOTING

8
4 步快速连接步快速连接
步快速连接步快速连接
步快速连接
使用使用
使用使用
使用 H605
..................................................................................................................2020
2020
20
........................................................................................................................21
........................................................................................................22
....................................................................................................23
............................................................................................................24
....................................................................................................25
.................................................................................................................26
..........................................................................................................................2727
2727
27
.....................................................................................................................28
.........................................................................................................................29
................................................................................................................30
.............................................................................................................................31
.........................................................................................................................32
............................................................................................................33
........................................................................................................................34
.................................................................................................................35
准备工作
①将耳机电池充电
②启动手机蓝牙功能
③匹配您的耳机
继续匹配您的手机
④测试 / 用
开机和关机
佩戴耳机
两耳交换佩戴
指示灯
进行通话
进行通话 继续
声音提示
疑难问题解答
目目
目目
目录录
录录
录

9
目目
目目
目錄錄
錄錄
錄
..................................................................................................................3939
3939
39
........................................................................................................................40
................................................................................................................41
....................................................................................................42
............................................................................................................43
............................................................................................................44
.................................................................................................................45
..........................................................................................................................4646
4646
46
....................................................................................................................47
........................................................................................................................48
........................................................................................................49
............................................................................................................................50
............................................................................................................................51
..................................................................................................................52
.........................................................................................................................53
........................................................................................................................54
準備工作
①為耳機充電
②啟動話機藍芽功能
③與耳機作配對
繼續與耳機作配對
④測試和 用
開機和關機
佩戴耳機
兩耳交換佩戴耳機
指示燈
通話時
通話時 繼續
聲音提示
疑難排解
4 步快速連接步快速連接
步快速連接步快速連接
步快速連接
使用使用
使用使用
使用 H605

1
1-CHARGE
2-START BLUETOOTH FEATURE
3-PAIR
4-TEST AND USE
GET CONNECTED IN
4 QUICK STEPS

2
BEFOREYOUBEGIN
Beforeusingthisproduct,readtheimportantSafetyandLegalinformationpamphletandfollowits
instructions.
Take a moment before you get started to familiarize yourself with your new
H605 Handsfree Headset.

3
①①
①①
① CHARGE Your Headset’s Battery
Charge your headset’s battery for 2 hours:
1
2
Note: Headset is not functional while charging.
Plug the Motorola charger into the end of the headset.
The blue indicator light turns on when the battery is charging. It may take up
to 1 minute for the light to turn on. When the headset’s battery is fully
charged (about 2 hours), the blue indicator light turns off.
Unplug the charge from the headset.

4
②②
②②
② START BLUETOOTH Feature
On Your Phone
Your phone's Bluetooth feature is off by default. To use your headset, turn on
the Bluetooth feature in your phone.
For most Motorola phones:
1Select (Menu) > Settings > Connection >Bluetooth Link > Setup.
2Scroll to Power.
3Press Change.
4 Scroll to On.
5Press Select to turn on the Bluetooth feature. Bluetooth feature remains on
until you turn it off.
Note:ThesestepsareformostMotorolaphones.Forotherphones,seeyourphone'suser'sguide.

5
③③
③③
③ PAIR
Your Headset
Step A - PUT HEADSET IN PAIRING MODE
Before you can use your headset, you must pair (link) it with your phone.
1With the headset power off, press and hold the Call button for 6 to 10
seconds until the blue indicator light turns on and remains steadily lit.(The
light will flash when you hold the Call button.)
2If the indicator light is flashing or does not remain steadily lit, turn off the
headset and repeat step 1.
Note:To turn off headset, see“Turning On andOff”on the reverse side ofthisGuide.

6
PAIR
Your Photo
Step B - SET THE PHONE TO LOOK FOR
YOURHEADSET
For most Motorola phones:
1Select (Menu) >Settings > Connection > Bluetooth Link >
Handsfree > Look for Devices.
The phone lists all Bluetooth devices it finds.
2Select Motorola H605.
3Press OK or Yes to pair (link) the handsfree device.
4Enter the passkey 0000 and Press OK.
Note: Passkey cannot be changed from 0000.
When your headset is successfully paired with your phone, the blue indicator
light changes from steadily lit to flashing.
Note:ThesestepsareformostMotorolaphones.Forotherphones,seeyourphone'suser'sguide.

7
④④
④④
④ TEST AND USE
Your phone and headset are now paired and ready to make and receive calls.
To confirm they are operating properly, make a call:
1Place the headset over your ear. See ”Wearing the Headset” on the
reverse sideof this guide.
2On your phone, dial the number you want to call and press the Send key.
3If your phone and headset are successfully paired, you will hear ringing on
the headset.
After you have successfully paired your phone and headset, you do not need
to repeat these initial setup steps each time you use the headset.

8
USING YOUR H605
Features and Functions Guide
IMPORTANT:
Be sure to first follow the
User’s Guide
to complete initial setup
of your H605.

9
TURNING ON AND OFF
To turn your headset on, press and hold the Call button until the indicator light
flashes. Then, release the button.
To turn you headset off, press and hold the Call button until the indicator light
flashes rapidly and then turns off.
To conserve battery power, turn off your headset when you don’t plan to use
it for a while.

10
WEARINGTHEHEADSET
1
2
3
Place the end of the headset with
the blue indicator light near the top
of your ear facing backwards.
Slide the headset down and around
along the back of your ear. The end
of the headset with the blue indicator
light will face forward from the bottom
of your ear (just under the earlobe).
Direct the speaker by tilting and
rotating it toward the opening of your
ear.
