PWR-100 Power Module Series
Quick Installation Guide
Power Modules for EDS-4000/G4000 Series
Version 1.0, July 2023
Technical Support Contact Information
www.moxa.com/support

2023 Moxa Inc. All rights reserved.

- 2 -
Package Checklist
The PWR-100 Series power module is shipped with the following items.
If any of these items are missing or damaged, please contact your
customer service representative for assistance.
•1 PWR-100 Series power module
•Quick installation guide (printed)
•Warranty card
•Substance disclosure table
•Product certificate of quality inspection (Simplified Chinese)
•Product notices (Simplified Chinese)
NOTE
You can find information on the relevant product pages located
on Moxa’s website: www.moxa.com
Wiring Requirements
ATTENTION
Safety First!
External metal parts are hot. Take
the necessary precautions if
you are required to handle the device.
ATTENTION
In order to ensure reliable operations, please make sure the
operating temperature of the environment does not exceed the
specifications. When mounting an EDS device with other
operating units in a cabinet without forced ventilation, a
minimum of
4 cm spac
e on both the left and right of the switch
is recommended.
ATTENTION
Safety First!
Be sure to disconnect the power cord before installing and/or
wiring your EDS device. Calculate the maximum possible
current in each
power wire and common wire. Observe all
electrical codes dictating the maximum current allowable for
each wire size. If the current goes above the maximum ratings,
the wiring could overheat, causing serious damage to your
equipment.
Be sure to read and follow these important points below:
•Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the intersection point.

- 3 -
NOTE
Do not run signal or communications wiring and power wiring
through the same wire conduit. To avoid interference, wires
with different signal characteristics should be routed separately.
•You can use the type of signal transmitted through a wire to
determine which wires should be kept separate. The rule of thumb
is that wiring that shares similar electrical characteristics can be
bundled together.
•You should separate input wiring from output wiring.
•We advise that you label the wiring to all devices in your system.
Suggested Wire Type for Wiring Relay Contact
(RELAY), Digital Input (DI), and Power Inputs
(P1/P2)
The PWR-100 Series power module has two 4-pins 3.5 mm pin-pitch
terminal blocks. When wiring the relay contact (RELAY), digital input
(DI), and power inputs (P1/P2), we suggest using the cable type AWG
18-24 and the corresponding pin type cable terminals.
NOTE
The wire must be
able to withstand at least 105°C and the
torque value should be 4.5 lb-in (0.51 N-m).
NOTE
We suggest the length of the pin type cable terminal is 8
mm.
In order to tighten the wire properly,
①use a small flathead
screwdriver to press the push
-
in button beside each terminal of
the terminal block connector before and during
②
inserting the
wire.
③Release the screwdriver after the wire has been fully
i
nserted. Please refer to the diagram below.
Wiring the Relay Contact
The PWR-100 Series power module has one set of relay outputs. This
relay contact uses two contacts of the terminal block on the power
module. Refer to the section for detailed instructions on how to connect
the wires to the terminal block connector, and how to attach the
terminal block connector to the terminal block receptor.

- 4 -
Relay:
The two contacts of
the 4-pin terminal
block connector are used to detect
user
-configured events. The two wires
attached to the
fault contacts form an
open circui
t when a user-configured
event is triggered or
there is no power
supply to the switch
. If a user-
configured event does not occur, the
fault circuit remains closed.
Wiring the Redundant Power Inputs
The PWR-100 Series includes both high-voltage and low-voltage
models. For the low-voltage (LV models) products, there are two power
inputs for redundancy; for the high-voltage (HV models) products,
there is only one power input. Refer to the instructions and diagram
below on how to connect the wires to the terminal block connector on
the receptor.
STEP 1:
Insert the Positive/Negative
DC or Line/Neutral AC wires into the
V+/V
- or L/N terminals, respectively.
STEP 2:
To keep the DC or AC wires
from pulling loose, use a small flat
-
blade screwdriver to tighten the wire
-
clamp screws on the front of the
terminal block connector.
STEP 3:
Insert the plastic terminal
block connector prongs into the

- 5 -
terminal block receptor, which is
located on the EDS devices’ right side.
Wiring the Digital Inputs
The PWR-100 Series power module has one set of digital inputs (DI).
The DI consists of two contacts of the 4-pin terminal block connector on
the EDS's right-side panel. Refer to the instructions and diagram below
on how to connect the wires to the terminal block connector on the
receptor.
STEP 1: Insert the negative
(ground)/positive DI wires into the
┴
/I terminals, respectively.
STEP 2:
To keep the DI wires from
pulling
loose, use a small flat-blade
screwdriver to tighten the wire
-clamp
button
on the front of the terminal
block connector.
STEP 3:
Insert the plastic terminal
block connector prongs into the
terminal block receptor, which is
located on the EDS devices’ right side.
Replacing or Rotating the Power Module
The power module for the EDS device can be replaced or rotated to fit
the requirements of your field site application.
Step 1:
Remove
the two screws that fasten the power module to the
EDS device
.
Step 2:
Remove the power module from the EDS device.
Step 3:
(Optional) Rotate the power module clockwise so that the
power, digital input, and relay output connectors are facing
upwards.
Step 4:
Place the module, or another module, back onto the EDS
device, then fasten the screws to secure the power module to
the device.

- 6 -
Specifications
Power
Note The EDS-4000/G4000 Series device model name
and power parameters are determined by the
installed PWR-100 power module.
PWR-100–LV: -LV/-LV-T models
PWR-105-HV-I: -HV/-HV-T models
PWR-101-LV-BP-I: -LVA/-LVA-T models (PoE
support)
PWR-103-LV-VB-I: -LVB/-LVB-T models (PoE
support)
For example:
EDS-G4008-T + PWR-100-LV = EDS-G4008-LV-T
EDS-G4008-T + PWR-105-HV-I = EDS-G4008-HV-
T
If you install a different power module, refer to the
specifications of the corresponding model. For
example, if you replace the power module of the
EDS-G4008-LV-T with the PWR-105-HV-I, refer to
the specifications of the EDS-G4008-HV-T.
Rated Voltage
PWR-100-LV: 12/24/48 VDC, redundant dual
inputs
PWR-105-LV-I: 110/220 VDC, single input
PWR-101-LV-BP-I: 48 VDC, redundant dual inputs
PWR-103-LV-VB-I: 12/24/48 VDC, redundant dual
inputs
Operating Voltage
PWR-100-LV: 9.6 to 60 VDC
PWR-105-HV-I: 88 to 300 VDC, 85 to 264 VAC
PWR-101-LV-BP-I: 44 to 57 VDC (> 52 VDC for
PoE+ output recommended)
PWR-103-LV-VB-I: 12 to 57 VDC (>52 VDC for
PoE+ output recommended)
Rated Current
PWR-100-LV: 12 to 48 VDC, 1.50 to 0.40 A or 24
VDC, 0.70 A
PWR-105-HV-I: 110 to 220 VAC, 50 to 60 Hz, 0.30
to 0.20 A or 110 to 220 VDC, 0.30 to 0.20 A
PWR-101-LV-BP-I: 48 VDC, 5.42 A
PWR-103-LV-VB-I: 12/48 VDC, 7.46/4.27 A or
24 VDC, 7.26 A
Inrush Current
-LV models: Max. 0.8 A @ 48 VDC (0.1 to 1 ms)
Power over
Ethernet
Only the EDS-4008-4P-2GT-2GS(-T), EDS-4012-
8P-4GS(-T), and EDS-G4012-8P-4QGS(-T) models

- 7 -
support PoE. If a PoE-capable PWR-100 Series
module (PWR-101-LV-BP-I, PWR-103-LV-VB-I) is
installed into an EDS-4000/G4000 Series non-PoE
model, PoE functionality will not be available.
Overload Current
Protection at Input
Present
Reverse Polarity
Protection
Present
Connection
2 removable 4-contact terminal blocks
Physical Characteristics
Dimension
PWR-100-LV: 103 x 98 x 26.6 mm (4.06 x 3.86 x
1.02 in)
PWR-105-HV-I: 103 x 98 x 39.9 mm
(4.06 x 3.86 x
1.57 in)
PWR-101-LV-BP-I: 103 x 98 x 39.9 mm (4.06 x
3.86 x 1.57 in)
PWR-103-LV-VB-I: 103 x 98 x 39.9 mm (4.06 x
3.86 x 1.57 in)
Weight
PWR-100-LV: 142 g (0.31 lb)
PWR-105-HV-I: 215 g (0.47 lb)
PWR-101-LV-BP-I: 176 g (0.39 lb)
PWR-103-LV-VB-I: 244 g (0.54 lb)
Environmental Limits
Operating
Temperature
-10 to 60°C (14 to 140°F) for standard models
-40 to 75°C (-40 to 167°F) for -T models
Storage
Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5 to 95% (non-condensing)
Altitude
Up to 2000 m
Note: Please contact Moxa if you require products
guaranteed to function properly at higher altitude.
Regulatory Approvals
Safety
EN 62368-1(LVD)
EMC
EN 55032/35, EN 61000-6-2/6-4
EMI
FCC Part 15 Subpart B Class A
EMS
EN 61000-4-2 (ESD) Level 4
EN 61000-4-3 (RS) Level 3
EN 61000-4-4 (EFT) Level 4
EN 61000-4-5 (Surge) Level 4
EN 61000-4-6 (CS) Level 3
EN 61000-4-8 Level 4
Package Drop &
Vibration
ISTA 1A
Warranty
Warranty
5 years

- 8 -
ATTENTION
This device complies with Part 15 of the FCC rules.
Operation is subject to the following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received
including interference that may cause undesired operation.
