MrHeater SunRite MH11TTPH Assembly instructions

OPERATING INSTRUCTIONS
AND OWNER’S MANUAL MODEL#
MH11TTPH
WARNING: Read and follow all instructions carefully. Place instructions in a safe place for future
reference. Do not allow anyone who has not read these instructions to assemble, light, adjust or
operate the heater.
WARNING: Do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance. An LP-cylinder not connected for use shall not be stored in the
vicinity of this or any other appliance.
TABLETOP PATIO HEATER
OFF
LOW
ON
HIGH
00173M REV A
www.mrheater.com •800-251-0001
WARNING: For Outdoor Use Only.
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
CARBON MONOXIDE HAZARD
This appliance can produce
carbon monoxide which has no
odor.
Using it in an enclosed space can
kill you.
Never use this appliance in
an enclosed space such as a
camper, tent, car or home.
DANGER FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.

Tabletop Patio Heater 2Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
WARNING:
YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS,
SO PLEASE READ THESE INSTRUCTIONS BEFORE YOU
OPERATE THIS HEATER.
WARNING:
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, injury, or
death. Read and understand the installation, operating,
and maintenance instructions thoroughly before
installing or servicing this equipment.
WARNING:
FIRE, BURN, INHALATION, AND EXPLOSION HAZARD.
KEEP SOLID COMBUSTIBLES, SUCH AS BUILDING
MATERIALS, PAPER, OR CARDBOARD, A SAFE DISTANCE
AWAY FROM THE HEATER. AS RECOMMENDED BY
THE INSTRUCTIONS NEVER USE THE HEATER IN SPACES
WHICH DO OR MAY CONTAIN VOLATILE OR AIRBORNE
COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE,
SOLVENTS, PAINT THINNER, DUST PARTICLES OR
UNKNOWN CHEMICALS.
LANGUAGES
ENGLISH .......................................................... 1 - 12
SPANISH............................................................1 - 14
FRENCH........................................................... 1 - 14
CONTENTS
PRODUCT SPECIFICATIONS ........................................... 2
PACKAGE CONTENTS.................................................... 3
HARDWARE CONTENTS ................................................ 3
PREPARATION ............................................................... 4
SAFETY INFORMATION ................................................. 4
ASSEMBLY INSTRUCTIONS............................................ 5
OPERATING INSTRUCTIONS .......................................... 7
CARE AND MAINTENANCE........................................... 8
TROUBLESHOOTING........................................................9
REPLACEMENT PARTS LIST.......................................... 10
WARRANTY ................................................................ 12
WARNING:THIS PRODUCT CAN EXPOSE
YOU TO CHEMICALS INCLUDING LEAD AND LEAD
COMPOUNDS, WHICH ARE KNOWN TO THE STATE OF
CALIFORNIA TO CAUSE CANCER AND BIRTH DEFECTS
OR OTHER REPRODUCTIVE HARM. WASH HANDS AFTER
HANDLING. VISIT WWW.P65WARNINGS.CA.GOV
WARNING: Fuels used in liquefied propane
gas appliances, and the products of combustion of such
fuel, can expose you to chemicals including benzene, which
is known to the state of California to cause cancer and
cause birth defects or other reproductive harm, for more
information go to www.P65Warnings.ca.gov
GENERAL INFORMATION
RETAIN THIS MANUAL FOR FUTURE REFERENCE.
FOR QUESTIONS, PROBLEMS, MISSING PARTS BEFORE
RETURNING TO RETAILER PLEASE CALL WITH MODEL NUMBER
AND SERIAL NUMBER OF HEATER:
1-800-251-0001
MONDAY-FRIDAY 8-5 EASTERN TIME
OR E-MAIL USING THE MR. HEATER WEBSITE:
WWW.MRHEATER.COM
In order to provide the best service possible Mr. Heater is
now giving you more ways to get in touch with us. Find
informational videos at:
Facebook: www.facebook.com/mrheaterproducts/
Twitter: https://twitter.com/MrHeater
WARNING: DO NOT STORE OR USE GASOLINE
OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE
VICINITY OF THIS OR ANY OTHER APPLIANCE.
SAFETY
PRODUCT SPECIFICATIONS
MH11TTPH
Certification CSA
Height Overall 35.2 in.
Reflector Diameter 18.2 in.
Rated Heat Input 11,000 BTU/HR
Fuel Propane/LP
Gas Supply 1-lb. LP-Gas Cylinder
Manifold Pressure 11 in. W.C.
Injector Size (Diameter) 1.0 mm
Safety Features Thermocouple & Tilt Switch
Gas Supply Pressure Max. 150 PSI, Min. 5 PSI

Tabletop Patio Heater 3Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
PACKAGE CONTENTS
Part Description QTY
A Top Dome 1
B Top Wire Guard 1
C Emitter Assembly 1
D Burner Assembly 1
E Housing 1
F Plastic Ring 1
G Base 1
A
B
C
D
E
F
G
HARDWARE CONTENTS
AA BB CC DD
S.T M4 x 10 mm
Bolt
Qty. 4
M4 x 8 mm
Bolt
Qty. 4
M4 x 10 mm
Bolt
Qty. 4
M6 Nut
Qty. 3

Tabletop Patio Heater 4Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
PREPARATION
Before beginning assembly of product, make sure all parts are
present. Compare parts with package contents list and hardware
contents list. If any part is missing or damaged, do not attempt
to assemble the product.
Estimated Assembly Time: 20 minutes
Tools Required for Assembly (not included): Phillips screwdriver
SAFETY INFORMATION
Please read and understand this entire manual before
attempting to assemble, operate or install the product.
• The installation must conform with local codes or, in the
absence of local codes, with the National Fuel Gas Code,
ANSI Z223.1/NFPA 54, Natural Gas and Propane Installation
Code, CSA B149.1, or Propane Storage and Handling Code,
B149.2.
DANGER:
• Young children should be carefully supervised when they
are in the area of the item.
• Keep the ventilation opening(s) of the cylinder enclosure
free and clear from debris. Use this appliance in a well-
ventilated space only. Do not use it in a building, garage or
any other enclosed area.
• Use this appliance in outdoor areas described below:
a. With walls on all sides, but at least one permanent
opening at ground level and no overhead cover.
b. Within a partial enclosure that includes overhead
cover and no more than two walls. These walls may be
parallel or at right angles to each other.
c. Within a partial enclosure that includes overhead cover
and no more than two walls. The following shall apply:
i. One wall that is equivalent to at least 25% of the
total wall area is completely open.
ii. 30% or more in total of the remaining wall area is
open and unrestricted.
• Store the cylinder outdoors in a well-ventilated area (not in
a building, garage, or other enclosed area) out of the reach
of children.
• Do not store a spare LP-gas cylinder under or near this
appliance.
• Never fill the cylinder beyond 80 percent full.
CAUTION:
• Minimum clearance to the combustible materials is 24 in.
• If you don’t feel the heater is on a stable surface, use a
ground screw to fix the base of the heater on the surface
where the heater is installed. Fix the base on an incline no
wider than 15 degrees.
• Any guard or other protective device removed for servicing
the heater must be replaced prior to operating the heater.
• More frequent cleaning may be required as necessary. It
is imperative that the control compartment, burners and
circulating air passageways of the heater to kept clean.
• Keep the appliance area clear and free from combustible
materials, gasoline and other flammable vapors and liquids.
• Inspect the visible portion of the hose before each use of
the appliance. When portions of the hose are located within
the confines of the heater post, instructions to inspect
the entire hose assembly at least annually. If disassembly
is required, the instructions shall also include the proper
procedure for leak checking the connections upon re-
assembly.
• More frequent cleaning may be required as necessary.
It is imperative the control compartment, burners and
circulating air passageways of the heater are kept clean.
• Keep this manual for future reference and to educate new
users of this product.
• The cylinder used must include a collar to protect the
cylinder valve.
• Installation and repair should be done by a qualified service
person; the heater should be inspected before use and at
least annually by a qualified service person.
• Do not obstruct the flow of combustion and ventilation air.
• The LP-gas supply cylinder to be used must be:
a. Constructed and marked in accordance with the
Specifications for LP-gas cylinders of the U.S.
Department of Transportation of Dangerous Goods
and Commission, CAN/CSA-B339, as applicable;
b. Provided with a listed overfilling prevention device;
and
c. Provided with a cylinder connection device
compatible with the connection for the appliance.
• Disconnect the cylinder when the appliance is not in use.
• Storage of an appliance indoors is permissible only if the
cylinder is disconnected and removed from the appliance.
• Materials or items when stored under the heater will be
subjected to intense heat and could be seriously damaged.
• Clothing or other flammable materials should not be hung
on the heater, or placed on, under or near the heater.
• Children and adults should be alerted to the hazards of high
surface temperatures and should stay away from the item to
avoid burns or clothing ignition.
WARNING:
• Inspect the visible portion of the hose before each use of
the appliance.
• Perform a leak test with a soapy solution:
a. To check gas connections.
b. After connecting a new cylinder.
c. Upon re-assembly after disassembly.
Please refer to the leak test procedure indicated in
this instruction manual.
• Replace the hose assembly prior to the appliance being put
into operation if there is evidence of excessive abrasion or
wear, or if the hose is damaged. The pressure regulator and
hose assembly supplied with the appliance must be used.
The replacement hose assembly/regulator shall be that
specified by the manufacturer.

Tabletop Patio Heater 5Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
1
E
F
G
AA
2
E
D
BB
3
C
D
CC
knv
nm
ghfg
nee
ASSEMBLY INSTRUCTIONS
1. Place the plastic ring (F) on the housing (E) and then attach
the housing (E) to the base (G) using four bolts (AA).
HARDWARE USED
HARDWARE USED
HARDWARE USED
AA
BB
CC
S.T M4 x 10 mm Bolt
M4 x 8 mm Bolt
M4 x 10 mm Bolt
X 4
X 4
X 4
2. Attach the burner assembly (D) to the 2 housing (E) using
four bolts (BB).
3. Attach the emitter assembly (C) to the burner assembly
(D), using four bolts (CC).

Tabletop Patio Heater 6Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
4
B
D
5
A
C
DD
6
I bl
HARDWARE USED
DD M6 Nut X 3
4. Insert the four legs of the wire guard (B) into the burner
assembly (D).
5. Attach the dome (A) to the emitter assembly (C) using
three nuts (DD).
6. Insert and secure an LP gas cylinder.
This appliance uses a one lb (16.4 oz)
cylinder only.
Only cylinder marked “propane” can be used.
Line up threads on the canister with those
on the regulator. Insert and rotate the
canister clockwise until they fit snugly
together.
HAND TIGHTEN ONLY. Be careful not to
cross threads when screwing in the
canister. Keep the cylinder vertically
upright on the base for vapor withdrawal.
NOTE:
Some 1-lb cylinders may form frost when
near empty.

Tabletop Patio Heater 7Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
LOW
HIGH
ON
OFF
LO
W
HIG
H
ON
OF
F
1
OPERATING INSTRUCTIONS
Before Lighting
This heater was designed and approved for OUTDOOR USE
ONLY. DO NOT use it inside a building, garage or any other
enclosed area.
Make sure surrounding areas are free of combustible materials,
gasoline and other flammable vapors or liquids.
Ensure there is no obstruction to air ventilation.
Be sure all gas connections are tight and there are no leaks.
Be sure the access panel is clear of debris.
Be sure any component removed during assembly or servicing is
replaced and fastened prior to starting.
Checking For Leaks
Make 2-3 oz. of leak solution by mixing one-part liquid dish
soap with three-parts water.
1. Make sure control knobs are off.
2. Spoon or brush several drops (or use squirt bottle) of the
solution onto the gas regulator and tank connection.
3. Turn on gas cylinder valve. Inspect the connections and
look for bubbles.
a. If no bubbles appear, the connection is safe.
b. If bubbles appear, there is leakage. Loosen and re-
tighten this connection. If it still leaks, please call
customer service.
NOTE: Whenever gas connections are loosened, removed or
re-assembled, you must perform a complete leak test.
Lighting Instructions
1. Ensure the control knob is in the “OFF” position.
2. Push in control knob and rotate it to the “ON”
position. This will activate the built-in igniter and light
the burner. If necessary, keep depressing and rotating
knob until burner lights.
3. Once burner is lit, hold control knob in for at least 30
seconds and release.
4. If burner does not stay lit, turn to “OFF” position and
wait 5 minutes and repeat steps 2 and 3.
5. If burner does not light, use a lighter positioned
against the bottom of emitter screen at burner
location.
6. Once burner is lit, rotate control knob to desired
heating level. If you experience any issues while
attempting to light the item, turn off the heater and
gas supply and refer to TROUBLESHOOTING.
CAUTION: Avoid inhaling fumes emitted from the heater’s
first use. Smoke and odor from the burning of oils used
in manufacturing will appear. Both smoke and odor will
dissipate after approximately 30 minutes. The heater should
NOT produce thick black smoke.
Re-lighting Instructions
NOTE: For your safety, control knob cannot be turned on
without first depressing control knob in off position and then
rotating to on.
1. Turn gas control knob to off.
2. Wait at least 5 minutes to let gas dissipate before
attempting to re-light burner.
3. Repeat “Lighting” steps 2 and 3.

Tabletop Patio Heater 8Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
When Heater is “ON”:
Burner will display slight blue flame at the bottom and strong
yellow at the top. The color is more visible at night.
If only yellow flame is detected, turn off heater and gas supply
and refer to TROUBLESHOOTING. Visually check burner flames
at each use and make sure flame height matches illustration to
the right.
Turning Off
1. Rotate gas control knob to “OFF” position.
NOTE: Burner will likely make a slight popping sound when
extinguished.
2. Disconnect LP-gas tank after use. Rotate LP-gas tank to
horizontal position, unscrew it counterclockwise until it is
loose. Store the LP-gas tank in a proper location.
3. Close door on housing assembly.
NOTE: After use, some discoloration of the emitter screen is
normal.
CARE AND MAINTENANCE
• Abrasive cleaners will damage this product.
• Never use oven cleaner to clean any part of heater
• Do not clean any heater part in a self-cleaning oven. The
extreme heat will damage the finish.
• More frequent cleaning may be required as necessary.
It is imperative that control compartment, burners and
circulating air passageways of the heater be kept clean.
• Spiders and insects can create a dangerous condition that
may damage heater or make it unsafe. Keep burner area
clean of all spiders, webs or insects. Clean burner holes by
using a heavy-duty pipe cleaner. Compressed air may help
clear away smaller particles.
• Inspect heater before each use.
• Have heater inspected annually and repairs should be made
by a qualified service person.
• Check heater immediately if any of the following conditions
exist:
a. The smell of gas in conjunction with extreme yellow
tipping of burner flames.
b. Heater does not reach proper temperature.
c. Heater’s glow is excessively uneven.
d. Burner makes popping noises during use.
NOTE: A slight pop is normal when burner is
extinguished.
• Carbon deposits may create a fire hazard. Keep dome and
emitter clean at all times.
• Do not clean heater with combustible or corrosive cleaners.
Use warm, soapy water.
• Do not paint engine, engine access panel or dome.
• This heater should be thoroughly cleaned on a regular
basis.
• After a period of storage and/or non use, check for leaks,
burner obstructions and inspect for any abrasion, wear,
cuts to the hose.
• Some 1-lb. cylinders may form frost when near empty,
which is normal and not a defect.
• Periodically check the hose located within the confines of
the cylinder housing for damage.
2

Tabletop Patio Heater 9Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
Cleaning
• Wipe surfaces clean with mild dish detergent or baking
soda.
• For stubborn surfaces use a citrus-based degreaser and a
nylon scrubbing brush.
• Rinse clean with water.
NOTE: While cleaning the unit, be sure to keep the area
around the burner and pilot assembly dry at all times. Do
not submerge the control valve assembly. If the gas control
is submerged in water, do NOT use it. It must be replaced.
TIP: Use high-quality automobile wax to help maintain the
appearance of the heater. Apply to exterior surfaces from
the pole down. Do not apply to emitter screen or domes.
Maintenance
• Keep exterior surfaces clean.
• Air flow must be unobstructed. Keep controls, burner
and circulating air passageways clean. Signs of possible
blockage include:
»Gas odor with extreme yellow tipping of flame.
»Heater does NOT reach the desired temperature.
»Heater glow is excessively uneven.
»Heater makes popping noises.
NOTE: In a salt-air environment (such as near an ocean),
corrosion occurs more quickly than normal. Frequently check for
corroded areas and repair them promptly.
Storage
Between uses or during periods of extended inactivity:
• Turn control knob to “OFF”.
• Disconnect LP cylinder and move to a secure, well-location
outdoors.
• Store heater upright in an area sheltered from direct
contact with inclement weather (such as rain, sleet , hail,
snow, dust and debris).
NOTE: Never leave LP gas tank exposed to direct sunlight
or excessive heat.
• If desired, use cover (K) to protect the heater and help
prevent buildup in air passages.
CAUTION: Wait until heater is cool before covering.
Symptom Possible Cause Corrective Action
Burner doesn’t stay lit 1. Thermocouple and tilt switch are broken. 1. Press down and rotate the control knob,
holding it down for at least 30 seconds,
then release. If the burner doesn’t stay lit,
contact customer service.
Burner doesn’t light 1. Gas pressure is low.
2. Blockage in orifice and gas line.
3. Blockage in venturi tube.
4. Distance between the igniter pin and thermocouple is
incorrect.
5. No sparks appear when lighting.
1. Turn control knob to “OFF” position and
replace cylinder.
2. Clear blockage.
3. Clean venturi tube.
4. Adjust the distance between igniter pin and
thermocouple to 0.12-0.2 in.
5. Check whether igniter wires are properly
connected to the igniter.
Burner flame is low.
Note: Heater operates at
reduced efficiency below
40°F.
1. Outdoor temperature is less than 40˚F and tank is less
than 1/4 full.
2. Control knob is not fully “ON” or there is a blockage.
1. Turn control knob to “OFF” position and
replace with a full cylinder.
2. Check control knob setting and check
burner and orifices for blockage.
Carbon buildup 1. Dirt or film on reflector and emitter. 1. Clean reflector and emitter.
TROUBLESHOOTING

Tabletop Patio Heater 10 Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
REPLACEMENT PARTS LIST FOR MODEL MH11TTPH
When ordering parts include the complete unit model number listed on the unit rating plate.
1
2
12
13
3
7
8
6
4
9
10
11
5

Tabletop Patio Heater 11 Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
REPLACEMENT PARTS LIST FOR MODEL MH11TTPH
SEE BACK PAGE FOR PARTS ORDERING INFORMATION
REF # DESCRIPCIÓN PARTE#
1 DOME 00187
2 TOP WIRE GUARD 00188
3 EMITTER ASSEMBLY 00189
4 BURNER ASSEMBLY 00190
5 BURNER 00191
6 TILT SWITCH 00192
7 KNOB 00193
8 HOUSING 00194
9 PLASTIC RING 00195
10 BASE 0 0196
11 WEIGHTED PLATE 00197
12 DOOR 00198
13 HARDWARE PACK 00199

Tabletop Patio Heater 12 Operating Instructions and Owner’s Manual
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
OPERATING INSTRUCTIONS
AND OWNER’S MANUAL MODEL#
MH11TTPH
READ INSTRUCTIONS CAREFULLY: YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS.
Read and follow all instructions. Place instructions in a safe place for future reference. Do not allow anyone
who has not read these instructions to assemble, light, adjust or operate the heater.
WARNING:
USE ONLY MANUFACTURER’S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD
CAUSE INJURY OR DEATH. REPLACEMENT PARTS ARE ONLY AVAILABLE DIRECT FROM THE
FACTORY AND MUST BE INSTALLED BY A QUALIFIED SERVICE AGENCY.
PARTS ORDERING INFORMATION:
PURCHASING: ACCESSORIES MAY BE PURCHASED AT ANY MR. HEATER LOCAL DEALER OR
DIRECT FROM THE FACTORY
FOR INFORMATION REGARDING SERVICE:
Please call Toll-Free 800-251-0001 • WWW.MRHEATER.COM
Our office hours are 8:00 AM – 5:00 PM, EST, Monday through Friday.
Please include the model number, date of purchase, and description of problem in all communi-
cation.
LIMITED WARRANTY:
The company warrants this product to be free from imperfections in material or workmanship,
under normal and proper use in accordance with instructions of The Company, for a period of
one year from the date of delivery to the buyer. The Company, at its option, will repair or replace
products returned by the buyer to the factory, transportation prepaid within said one year period
and found by the Company to have imperfections in material or workmanship.
If a part is damaged or missing, call our Technical Support Department at 800-251-0001.
Address any Warranty Claims to the Service Department, Mr. Heater, Inc., 4560 W. 160TH ST.,
CLEVELAND, OHIO 44135. Include your name, address and telephone number and include de-
tails concerning the claim. Also, supply us with the purchase date and the name and address of
the dealer from whom you purchased our product.
The foregoing is the full extent of the responsibility of the Company. There are no other war-
ranties, express or implied. Specifically there is no warranty of fitness for a particular purpose
and there is no warranty of merchantability. In no event shall the Company be liable for delay
caused by imperfections, for consequential damages, or for any charges of the expense of any
nature incurred without its written consent. The cost of repair or replacement shall be the ex-
clusive remedy for any breach of warranty. There is no warranty against infringement of the like
and no implied warranty arising from course of dealing or usage of trade. This warranty will not
apply to any product which has been repaired or altered outside of the factory in any respect
which in our judgment affects its condition or operation.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so
the above limitation or exclusion may not apply to you. This Warranty gives you specific legal
rights, and you may have other rights which vary from state to state.
Mr. Heater, Inc. reserves the right to make changes at any time, without notice or obligation, in
colors, specifications, accessories, materials and models.
PRODUCT REGISTRATION: Thank you for your purchase.
Please log in to http://www.egiregistration.com to register your product.
ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 1-800-251-0001
Mr. Heater is a registered trademarks of Mr. Heater, Inc.
© 2021, Mr. Heater. All rights reserved
OFF
LOW
ON
HIGH

INSTRUCCIONES DE USO Y
MANUAL DEL USUARIO
MODELO#
MH11TTPH
ADVERTENCIA: Lea y siga cuidadosamente todas las instrucciones. Conserve estas instrucciones
en un lugar seguro para futura referencia. No permita que nadie que no haya leído estas
instrucciones arme, encienda, ajuste o use el calefactor.
CALENTADOR PARA
PATIO PARA
CUBIERTA DE MESA
00173M REV A
www�mrheater�com •800-251-0001
ADVERTENCIA: Solo para uso en
exteriores.
ADVERTENCIA: No almacene ni utilice gasolina u otros vapores o líquidos Inflamables cerca
de éste u otro electrodoméstico. No deben almacenarse cilindros de gas propano que no estén
conectados y en uso cerca de éste ni de ningún otro electrodoméstico.
¡NUNCA DEJE EL CALEFACTOR DESATENDIDO CUENDO ESTÉ ENCENDIDO!
OFF
LOW
ON
HIGH
PELIGRO DE MONÓXIDO DE
CARBONO
Este aparato puede producir
monóxido de carbono, el cual es
inodoro.
Su uso en espacios cerrados
puede ser fatal.
Nunca use este aparato en un
espacio cerrado, como dentro de
remolques, carpas, automóviles
ni casas.
PELIGRO
PARA SU SEGURIDAD
Si percibe olor a gas:
1. Cierre el suministro de gas hacia el
electrodoméstico.
2. Apague cualquier llama directa.
3. Si el olor persiste, manténgase aleja-
do del electrodoméstico y llame de
inmediato a su proveedor de gas o al
departamento de bomberos.

Calentador para Patio para Cubierta de mesa 2Instrucciones de uso y manual del usuario
¡NUNCA DEJE EL CALEFACTOR DESATENDIDO CUENDO ESTÉ ENCENDIDO!
ÍNDICE
ESPECIFICACIONES DEL PRODUCTO ������������������������������ 2
CONTENIDO DEL PAQUETE ������������������������������������������� 3
ADITAMENTOS ������������������������������������������������������������� 3
PREPARACIÓN��������������������������������������������������������������� 4
INFORMACIÓN DE SEGURIDAD ������������������������������������ 4
INSTRUCCIONES DE ENSAMBLAJE�������������������������������� 6
INSTRUCCIONES DE FUNCIONAMIENTO ����������������������� 8
CUIDADO Y MANTENIMIENTO ����������������������������������� 10
DIAGNÓSTICO DE PROBLEMAS������������������������������������ 11
LISTA DE PARTES DE REPUESTO ���������������������������������� 12
GARANTÍA������������������������������������������������������������������ 14
ESPECIFICACIONES DEL PRODUCTO
MH11TTPH
Certificación CSA
Altura general 89,4 cm
Diámetro del reflector 46,2 cm
Consumo de calor nominal 2,693 frigorías/h
Combustible Propano-PL
Suministro de gas Cilindro de gas propano de
9,1 kg
Presión del tubo colector 27,9 mm CA
Tamaño del inyector (diámet-
ro)
1�0 mm
Características de seguridad Termopar e interruptor de
nivelación
Presión de suministro de gas Max� 150 PSI, Min� 5 PSI
ADVERTENCIA:
SU SEGURIDAD ES IMPORTANTE PARA USTED Y
PARA LOS DEMÁS, ASÍ QUE POR FAVOR LEA ESTAS
INSTRUCCIONES ANTES DE UTILIZAR EL CALEFACTOR�
ADVERTENCIA:
La instalación, el ajuste, la alteración, la reparación o el
mantenimiento inadecuados pueden ocasionar daños a
la propiedad, lesiones o la muerte� Lea con detención las
instrucciones de instalación, operación y mantenimiento
antes de instalar o reparar este equipo�
ADVERTENCIA:
PELIGRO DE INCENDIO, QUEMADURAS, INHALACIÓN Y
EXPLOSIÓN. MANTENGA LOS COMBUSTIBLES SÓLIDOS
COMO MATERIALES DE CONSTRUCCIÓN, PAPEL O
CARTÓN A UNA DISTANCIA SEGURA DEL CALEFACTOR.
TAL COMO LO RECOMIENDAN LAS INSTRUCCIONES,
NUNCA USE EL CALEFACTOR EN ESPACIOS QUE
CONTIENEN O PODRÍAN CONTENER COMBUSTIBLES
VOLÁTILES O PRODUCTOS COMO GASOLINA,
SOLVENTES, DILUYENTE DE PINTURA O PRODUCTOS
QUÍMICOS DESCONOCIDOS.
ADVERTENCIA: ESTE PRODUCTO PUEDE
EXPONERLO A PRODUCTOS QUÍMICOS, INCLUYENDO
PLOMO Y COMPUESTOS DE PLOMO, QUE DE ACUERDO
CON EL ESTADO DE CALIFORNIA PRODUCEN CÁNCER
Y DEFECTOS DE NACIMIENTO U OTROS DAÑOS
REPRODUCTIVOS. POR MAYOR INFORMACIÓN, VISITE
WWW.P65WARNINGS.CA.GOV
ADVERTENCIA: Los combustibles utilizados
en los artefactos a gas licuado de propano y los productos
de la combustión de dicho combustible pueden exponerlo
a sustancias químicas, incluido el benceno, que según
el estado de California puede provocar cáncer y causar
defectos de nacimiento u otros daños reproductivos� Visite
www�P65Warnings�ca�gov por mayor información� ADVERTENCIA:
NO ALMACENE NI UTILICE
GASOLINA NI NINGÚN OTRO VAPOR NI LÍQUIDO INFLAMABLE
CERCA DE ESTE NI DE NINGÚN OTRO ARTEFACTO.
SEGURIDAD
INFORMACIÓN GENERAL
GUARDE ESTE MANUAL PARA FUTURA REFERENCIA.
POR PREGUNTAS, PROBLEMAS O PARTES FALTANTES, ANTES
DE RETORNAR EL PRODUCTO A LA TIENDA LLÁMENOS
CON EL NÚMERO DE MODELO Y EL NÚMERO DE SERIE DEL
CALEFACTOR:
1-800-251-0001
DE LUNES A VIERNES DE 8 A 5 PM HORA DEL ESTE�
O ENVÍENOS UN MENSAJE A TRAVÉS DEL SITIO WEB DE MR.
HEATER:
WWW.MRHEATER.COM
IDIOMAS
INGLÉS ������������������������������������������������������������� 1 - 12
ESPAÑOL �������������������������������������������������������� 1 - 14
FRANCÉS �������������������������������������������������������� 1 - 14
Para brindarle el mejor servicio posible, ahora Mr� Heater le
ofrece más formas de ponerse en contacto con nosotros�
Encuentre videos informativos en:
Facebook: www�facebook�com/mrheaterproducts/
Twitter: https://twitter�com/MrHeater

Calentador para Patio para Cubierta de mesa 3Instrucciones de uso y manual del usuario
¡NUNCA DEJE EL CALEFACTOR DESATENDIDO CUENDO ESTÉ ENCENDIDO!
CONTENIDO DEL PAQUETE
Pieza Descripción Cantidad
A Domo Superior 1
B Protector de Alambre Superior 1
C Ensamble del Emisor 1
D Conjunto del Quemador 1
E Carcasa 1
F Anillo de Plástico 1
GBase 1
ADITAMENTOS
AA BB CC DD
Perno ST�
M4 x 10 mm
Cant� 4
Perno
M4 x 8 mm
Cant� 4
Perno
M4 x 10 mm
Cant� 4
Tuerca M6
Cant� 3
A
B
C
D
E
F
G

Calentador para Patio para Cubierta de mesa 4Instrucciones de uso y manual del usuario
¡NUNCA DEJE EL CALEFACTOR DESATENDIDO CUENDO ESTÉ ENCENDIDO!
PREPARACIÓN
Antes de comenzar a ensamblar el producto, asegúrese de
tener todas las piezas� Compare las piezas con la lista del
contenido del paquete y la lista de aditamentos� No intente
ensamblar el producto si falta alguna pieza o si estas están
dañadas�
Tiempo estimado de ensamblaje: 20 minutos.
Herramientas necesarias para el ensamblaje (no se incluyen):
Destornillador Phillips�
INFORMACIÓN DE SEGURIDAD
Lea y comprenda complet amente este manual antes de intentar
ensamblar, usar o instalar el producto�
• La instalación debe cumplir con los códigos locales o, en su
defecto, con el Código nacional de gas combustible, ANSI
Z223�1 /NFPA 54 y con el Código nacional de instalación de
gas propano y gas natural C SA B149�2, o con el Código de
manejo y almacenamiento de propano, B149�2 B149�2�
PELIGRO:
• Se debe supervisar cuidadosamente a los niños pequeños
cuando se encuentren en el área del artículo.
• Mantenga despejadas y limpias las aberturas de ventilación
del compartim iento del cilindro. Use este aparato
solamente en espacios bien ventilados. No use en edificios,
garajes ni otras áreas cerradas.
• Utilice este aparato en las áreas exteriores que se describen
a continuación continuación:
a. Con paredes en todos los lados, pero con al menos una
abertura permanente a nivel del suelo y sin cubierta
superior.
b. Dentro de un área parcialmente cerrada que incluya
una cubierta superior y no más de dos paredes. Estas
paredes deben ser paralelas o en ángulos rectos con
respecto a la otra.
c. Dentro de un área parcialmente cerrada que incluya
una cubierta superior y no más de dos paredes. Se
aplica lo siguiente:
i. Una pared que equivale al 25% del área total de la
pared está completamente abierta.
ii. 30% o más en total del área de la pared restante
está abierta y sin restricciones restricciones.
• Almacene el cilindro en exteriores, en un área con buena
ventilación (no en un edificio, garaje ni cualquier otra área
cerrada), alejado del alcance de los niños.
• No almacene un tanque de gas PL de reserva debajo o cerca
de este aparato.
• Nunca llene el tanque más allá del 80% de su capacidad
capacidad.
ADVERTENCIA:
• Inspeccione la parte visible del manguito antes de usar el
aparato.
• Haga una prueba de detección de fugas con una solución
jabonosa:
a. Para revisar las conexiones de gas.
b. Después de conectar un cilindro de gas nuevo.
c. Al volver a ensamblar luego de desensamblar.
Consulte el procedimiento de detección de fugas
indicado en este manual de instrucciones.
• Reemplace el conjunto de la manguera antes de hacer
funcionar el aparato si hay prueba de abrasión o desg aste
excesivos o si la manguera está dañada. Se debe usar el
regulador de presión y el conjunto de la manguera que
se suministra con el aparato. El conjunto de la manguera/
regulador de repuesto debe ser el especificado por el
fabricante fabricante.
• El cilindro utilizado debe incluir un anillo para proteger su
válvula.
• Un técnico calificado debe instalar, reparar y hacer una
inspección del calentador antes del primer uso y al menos
una vez al año.
• No obstruya el flujo del aire de combustión ni d e
ventilación.
• El cilindro de suministro de gas PL que usará debe ser:
a. Fabricado y marcado según las especificaciones para
cilindros de gas PL del Departamento de transporte
de mercancías peligrosas y la Comisión, CAN/CSA
CSA-B339, según corresponda;
b. Equipado con un dispositivo de prevención de
sobrellenado homologado y
c. Equipado con una conexión de cilindros compatible
con la conexión para el aparato.
• Desconecte el cilindro cuando el aparato no esté en uso.
• Puede almacenar la unidad en interiores so lo si desconecta
y retira el cilindro del aparato.
• Los materiales o artículos, cuando se almacenan bajo el
calentador, pueden verse sujetos al calor intenso y dañarse
seriamente.
• No se debe colgar ropa ni otros materiales inflamables del
calentador ni colo carse sobre este , debajo o cerca de él.
• Tanto niños como adultos deben estar informados sobre
los peligros de la alta temperatura de la superficie y deben
permanecer alejados del artículo para evitar quemaduras o
incendio de la ropa.

Calentador para Patio para Cubierta de mesa 5Instrucciones de uso y manual del usuario
¡NUNCA DEJE EL CALEFACTOR DESATENDIDO CUENDO ESTÉ ENCENDIDO!
PRECAUCIÓN:
• La distancia de separación mínima de los materiales
combustibles es de 24 pulgadas.
• Si cree que el calentador no está en una superficie estable,
use un tornillo de puesta a tierra para fijar la base del
calentador a la superficie en la que está instalado. Fije la
base con una inclinación no mayor a los 15 grados.
• Cualquier protector u otro dispositivo de protección que
se haya ret irado para dar mantenimiento al calentador se
debe volver a colocar antes de hacerlo funcionar.
• Es posible que se requiera una limpieza más frecuente
según sea necesario. Es esencial que mantenga limpios el
compartimiento del control, los quemadores y los pasajes
de circulación de aire del calentador.
• Mantenga el área del aparato limpia y libre de materiales
combustibles, gasolina y otros vapores o líquidos
inflamables.
• Inspeccione la parte visible de la manguera antes de
cada uso del aparato. Cuando partes de la manguera se
encuentran dentro de los límites del puesto calentador,
instrucciones para inspeccionar todo el conjunto de
la manguera al menos anualmente. Si se requiere el
desmontaje, las instrucciones también incluirán el
procedimiento adecuado para la comprobación de fugas las
conexiones bajo el reensamblaje.
• Es posible que se requiera una limpieza más frecuente
según sea necesario. Es esencial que el compartimiento del
control, los quemadores y los pasajes de circulación de aire
del calentador calentadoresté n limpios.
• Guarde el manual para consultas futuras y para educar a
nuevos usuarios sobre el uso de este producto.

Calentador para Patio para Cubierta de mesa 6Instrucciones de uso y manual del usuario
¡NUNCA DEJE EL CALEFACTOR DESATENDIDO CUENDO ESTÉ ENCENDIDO!
INSTRUCCIONES DE ENSAMBLAJE
1� Coloque el anillo de plástico (F) en la carcasa (E) y luego fije
la carcasa (E) a la base (G) con cuatro pernos (AA).
ADITAMENTOS UTILIZADOS
2� Conecte el conjunto del quemador (D) 2 a la carcasa (E)
con cuatro pernos (BB)�
3� Conecte el ensamble del emisor (C) al ensamble del
quemador (D) con cuatro pernos (CC)�
ADITAMENTOS UTILIZADOS
ADITAMENTOS UTILIZADOS
1
E
F
G
AA
AA Perno S�T M4 x 10 mm X 4
2
E
D
BB
BB Perno M4 x 8 mm X 4
3
C
D
CC
knv
nm
ghfg
nee
CC Perno M4 x 10 mm X 4

Calentador para Patio para Cubierta de mesa 7Instrucciones de uso y manual del usuario
¡NUNCA DEJE EL CALEFACTOR DESATENDIDO CUENDO ESTÉ ENCENDIDO!
4� Inserte las cuatro patas de la protección de alambre (B) en
el ensamble del quemador (D)�
5� Conecte el domo (A) al ensamble del emisor (C) con tres
tuercas (DD)�
6� Inserte y asegure un cilindro de gas LP
Este aparato utiliza únicamente un cilindro de 0,45 kg
(485,01 ml)�
Solo se pueden usar cilindros marcados como “propano”.
Alinee las roscas en el recipiente con las del regulador�
Inserte y gire el recipiente en dirección de las manecillas del
reloj hasta que encaje bien�
APRIETE A MANO SOLAMENTE. Tenga cuidado de
no cruzar las roscas cuando las atornille en el recipiente�
Mantenga el cilindro en posición vertical sobre la base para
la extracción de vapor�
NOTA:
Algunos cilindros de 0,45 kg pueden formar escarcha
cuando están casi vacíos�
ADITAMENTOS UTILIZADOS
4
B
D
5
A
C
DD
DD Tuerca M6 X 3
6
I bl

Calentador para Patio para Cubierta de mesa 8Instrucciones de uso y manual del usuario
¡NUNCA DEJE EL CALEFACTOR DESATENDIDO CUENDO ESTÉ ENCENDIDO!
INSTRUCCIONES DE FUNCIONAMIENTO
Antes del Encendido
El artículo está diseñado y aprobado SOLAMENTE PARA USO
EN EXTERIORES� NO lo utilice dentro de un edificio, garaje o
cualquier otra área cerrada�
Asegúrese de que las áreas que lo rodean no contengan
materiales combustibles, gasolina ni otros vapores o líquidos
inflamables�
Asegúrese de que no haya obstrucciones en la ventilación�
Asegúrese de que todas las conexiones de gas estén apretadas
y que no haya fugas�
Asegúrese de que el panel de acceso esté libre de desechos�
Asegúrese de que cualquier componente retirado durante el
ensamblaje o el mantenimiento vuelva a colocarse y esté fijo
antes de comenzar�
Búsqueda de Fugas
Prepare entre 59,15 y 88,92 ml de solución para fugas
mezclando una parte de detergente líquido para platos con tres
partes de agua�
1� Asegúrese de que las perillas de control estén en la
posición de apagado�
2� Vierta o aplique varias gotas de la solución con una
cuchara o use una botella rociadora sobre el regulador de
gas y la conexión del tanque�
3� Abra la válvula de gas del cilindro� Revise si se forman
burbujas en las conexiones�
a� Si no se forman burbujas, la conexión es segura�
b� Si se forman burbujas, hay una fuga� Suelte y vuelva
a apretar esta conexión� Si la fuga persiste, llame a
servicio al cliente�
NOTA: cada vez que las conexiones de gas se afloja o retiran,
debe relizar una prueba de fugas completa�
Instrucciones de Encendido
1� Asegúrese de que la perilla de control esté en la posición
de apagado (“OFF”).
2� Presione la perilla de control y gírela hacia laposición de
encendido (“ON”). Esto activará el encendedor integrado
y encenderá el quemador� Si fuera necesario, siga
presionando y rotando la perilla hasta que se encienda el
quemador�
3� Una vez que el quemador se encienda, mantenga
presionada la perilla de control durante 30 segundos y
después suéltela�
4� Si el quemador no queda encendido, gire la perilla hasta la
posición “OFF”, aguarde 5 minutos y repita los pasos 2 y 3.
5� Si el quemador no se enciende, use un encendedor
ubicado contra la parte inferior de la pantalla del emisor en
el lugar del quemador�
6� Cuando el quemador esté encendido, gire la perilla
de control hacia el nivel de calefacción deseado� Si
experimenta problemas al intentar encender el artículo,
apague el calentador y el suministro de gas y consulte la
SOLUCIÓN DE PROBLEMAS.
LOW
HIGH
ON
OFF
LO
W
HIG
H
ON
OF
F
1
