NANLITE Compac 40B User manual

Guangdong NanGuang Photo&Video Systems Co., Ltd
USER MANUAL
Compac 40B LED Studio Light

1
Compac 40B LED Studio Light
Technical Data
LED Quantity: 400pcs
Voltage: AC 100V-240V
LED Power: 40W x 2
Color Temperature: 3200K-5600K
CRI(Ra): 95
Product Show

2
1. Color temperature knob
3. Power switch
4. Bracket fixing knob
2. Dimmer knob
6. AC power socket
7. Angle fixing knob
5. Fuse base
Detailed description
1. Color temperature knob: For adjusting the color temperature.
2. Dimmer knob: For adjusting the brightness.
3. Power switch: Turn on/off the fixture.
4. Bracket fixing knob: For connecting the fixture with the light stand.
5. Fuse base: For placing the fuse.
6. AC power socket: AC power input port.
7. Angle fixing knob: For adjusting the illumination direction of fixture.
Product Details

3
Usage
1. Please install the fixture on the light stand, then adjust the fixture to the desired position.
2. Please switch off the power then connect to AC 100-240V power.
3. Press the power switch to turn on the fixture.
4. Rotate the "Dimmer knob" to adjust the brightness, rotate the "Color temperature knob" to adjust the color
temperature.
5. Please turn off the fixture and unplug the power cord when stop using the light.
Security Warning Info
1. Please open the package to check if it is damaged from transportation after receiving the light. In case of damage
caused by transportation, please do not use this light and contact the dealer as soon as possible.
2. Do not use a power cord if damaged insulation. Do not unplug hard or drag the power cord directly.
3. Make sure that the power supply voltage used matches the voltage specified by the light before installation.
4. When not using or cleaning the light, please turn it off.
5. Keep the light safely stored and away from children.
Notice
1. Before using, please read the instruction sheet carefully and then install the product according to the instruction sheet.
2. The product should be operated within the normal voltage.
3. Pull insert plug, please do not use too much force to pull connection. And do not touch the connection by wet hand.
4. Please keep this product in dry and ventilated place, to avoid the circuit get wet, and cause short circuit.
5. When stop using, please turn off the power to preserve the life of the LEDs.

4The instruction was written according to the strict prodution test of our company, if there are
any changes related to the design of the product later, we will not keep you updated for that.
Compac 40B x 1 Power Cord x 1
What's in the box? Please kindly check.
User Manual X1
Potential Malfunction
The light can not light up.
The lamp is flickering.
1. Please check if the fixture is in the "off" position.
2. Please check whether the connection between power
cord plug and fixture is loose.
3. Pull out the fuse base, to check whether the fuse has
disconnected.
1. Please check whether the voltage value is within
specified parameters.
2. Check if there is any high temperature object near
the light that could cause the operating environment
temperature too high.
Diagnosis
Troubleshooting List
If the failure is not solved after the above troubleshooting procedures, please contact the dealer or manufacturer for repair.
Guangdong NanGuang Photo&Video Systems Co., Ltd
USER MANUAL
Compac 40B LED Studio Light

www.nanlite.com
[phone]
[email protected]
[phone]
Zhanglin,324,Dongli Chenghai Shantou Guangdong China
Version:V2 2019-10-22
