USER MANUAL
Compac 68 LED Studio Light

1
Compac 68 LED Studio Light
Product Show
LED Quantity: 340pcs
Voltage: AC 100V-240V
LED Power: 68W
Color Temperature: 5600K
CRI(Ra): 95
Technical Data

2
Product Details
1. Power switch: Turn on/off the fixture.
2. Bracket fixing knob: For connecting the fixture with the light stand.
3. Dimmer knob: For adjusting the brightness.
4. Fuse base: For placing the fuse.
5. AC power socket: AC power input port.
6. Angle fixing knob: For adjusting the illumination direction of fixture.
Detailed Description
3. Dimmer knob
2. Bracket fixing knob
1. Power switch
4. Fuse base
5. AC power socket
6. Angle fixing knob

3
1. Please install the fixture on the light stand, then adjust the fixture to the desired position.
2. Please switch off the power then connect to AC 100-240V power.
3. Press the power switch to turn on the fixture.
4. Rotate the "Dimmer knob" to adjust the brightness.
5. Please turn off the fixture and unplug the power cord when stop using the light.
Usage
1. Please open the package to check if it is damaged from transportation after receiving the light. In case of damage
caused by transportation, please do not use this light and contact the dealer as soon as possible.
2. Do not use a power cord if damaged insulation. Do not unplug hard or drag the power cord directly.
3. Make sure that the power supply voltage used matches the voltage specified by the light before installation.
4. When not using or cleaning the light, please turn it off.
5. Keep the light safely stored and away from children.
Security Warning Info
1. Before using, please read the instruction sheet carefully and then install the product according to the instruction sheet.
2. The product should be operated within the normal voltage.
3. Pull insert plug, please do not use too much force to pull connection. And do not touch the connection by wet hand.
4. Please keep this product in dry and ventilated place, to avoid the circuit get wet, and cause short circuit.
5. When stop using, please turn off the power to preserve the life of the LEDs.
Notice

4The instruction was written according to the strict prodution test of our company, if there are
any changes related to the design of the product later, we will not keep you updated for that.
Compac 68 x 1 Power Cord x 1 User Manual X1
What's in the box ? Please kindly check
Troubleshooting List
Potential Malfunction
The light can not light up.
The lamp is flickering.
1. Please check if the fixture is in the "off" position.
2. Please check whether the connection between power
cord plug and fixture is loose.
1. Please check whether the voltage value is within specified
parameters.
2. Check if there is any high temperature object near the light
that could cause the operating environment temperature
too high.
Diagnosis
If the failure is not solved after the above troubleshooting procedures, please contact the dealer or manufacturer for repair.
Guangdong NanGuang Photo&Video Systems Co., Ltd
USER MANUAL
Compac 68 LED Studio Light

www.nanlite.com
[phone]
[email protected]
[phone]
Zhanglin,324,Dongli Chenghai Shantou Guangdong China
Version:V1 2019-10-22
