NANLITE PavoTube II 15C User manual

Guangdong NanGuang Photo&Video Systems Co., Ltd.
PavoTube $ 15C
PavoTube $ 30C
USER MANUAL

1
Product Diagram
PavoTube $ 15C/30C
RGBWW LED Tube Light
Technical Data
Model No: PavoTube II 15C
Rated Power: 30W
Input: DC15V/2A Max
AC100-240V 50/60Hz
PD3.0 (9V-20V) 20W Min
Lithium Battery Capacity: 14.8V/2200mAh
Color Temperature: 2700K-7500K
CRI: Average 97
TLCI: Average 98
Model No: PavoTube II 30C
Rated Power: 60W
Input: DC15V/4A Max
AC100-240V 50/60Hz
PD3.0 (12V-20V) 30W Min
Lithium Battery Capacity: 14.8V/4400mAh
Color Temperature: 2700K-7500K
CRI: Average 97
TLCI: Average 98
PavoTube $ 30C
PavoTube $ 15C

2
Product Details
Detailed Description
1. Power Switch: Turn on/off the fixture.
2. Display: To display data.
3. USB Type-C Port: For updating the firmware and power input. (Note:PavoTube II 15C is compatible with power
adapter with PD3.0/20W and above, PavoTube II 30C is compatible with power adapter with PD3.0/30W and
above.)
4. Mode Button: For switching among CCT, HSI, EFFECT modes and MENU.
5. Dimmer Knob: For adjusting the brightness and other parameters.
1
9
10876
2 3 4 5

3
6. Lock Button: Long press the LOCK button to lock all functions, any operation won't change the current settings.
Long press the LOCK button again to unlock.
7. Fixing Hole: For hanging the fixture with steel wire rope.
8. Function Knob: For selecting among functions.
9. DMX Port: For inserting a DMX adapter cable, for DMX signal input and output.
(Note: DMX adapter cable is not included and is sold separately.)
10. DC Power Socket: DC power input port.
Usage
1. Power Connection
①Connection between light fixture and power adapter
②The fixture has built-in lithium battery, it can supply power after being charged by power adapter.

4
2. Light Fixture Installation
①Horizontal & vertical standing options.
Upward in 90°
Upward in 60°
Upward in 60°
Upward in 0°

5
MENU
BT: RESET
CH: 512
Remote Control
·PavoTube II 15C/30C support remote control via DMX/RDM and 2.4G, and include built-in Bluetooth module as well.
▲The channel needs to be set before operating the remote control via 2.4G, DMX/RDM.
1. CHANNEL/DMX, including CHANNEL, DMX MODE, DMX REDUCED CHANNELS, DMX DIMMING CURVE and
DMX SMOOTHING.
Press the MODE button to access options.
Rotate the “function knob” to CHANNEL.
②The fixture can be hung with steel wire rope (The max load is 20KG).
③The fixture can be also mounted on the light stand with 1/4-20" screws mount
(There are two 1/4-20" screw holes on the clip), or attached with a ball head, then mounted on the light stand.
①CHANNEL
Serial ConnectionParallel Connection
MODE
LOCK
MENU
BT: RESET
CH: 512

6
MENU
DMX REDUCED: OFF
DMX MODE: CCT 8bit
MENU
DMX REDUCED: OFF
DMX MODE: CCT 8bit
MENU
DMX REDUCED: OFF
DMX MODE: CCT 16bit
MENU
BT: RESET
CH: 512
MENU
BT: RESET
CH: 512
MENU
BT: RESET
CH: 511
Rotate the "dimmer knob" to set the channel code.
Press the MODE button to access options.
Rotate the "function knob" to DMX MODE.
②DMX MODE
MODE
LOCK
Rotate the "dimmer knob" to select from CCT 8bit, CCT 16bit, HSI 8bit, HSI 16bit, RGBW 8bit, RGBW 16bit,
ULTIMATE 8bit, CCT&RGBW 8bit, CCT&RGBW 16bit, CCT&HSI 8bit and CCT&HSI 16bit.

7
MENU
DMX MODE: CCT 16bit
DMX REDUCED: OFF
MENU
DMX MODE: CCT 16bit
DMX REDUCED: OFF
MENU
DMX MODE: CCT 16bit
DMX REDUCED: ON
MENU
BT: RESET
CH: 512
MENU
BT: RESET
CH: 512
Press the MODE button to access options.
Rotate the "function knob" to DMX REDUCED CHANNELS.
③DMX REDUCED CHANNELS
MODE
LOCK
Rotate the "dimmer knob" to select ON or OFF.
Press the MODE button to access options.
④DMX DIMMING CURVE
MODE
LOCK

8
MENU
DMX DIM: LINEAR
DMX SMOOTHTN: OFF
MENU
DMX SMOOTHTN: OFF
DMX DIM: LINEAR
MENU
DMX SMOOTHTN: OFF
DMX DIM: LINEAR
MENU
DMX SMOOTHTN: OFF
DMX DIM: EXPONENT
MENU
BT: RESET
CH: 512
Press the MODE button to access options.
Rotate the "function knob" to DMX SMOOTHING.
⑤DMX SMOOTHING
MODE
LOCK
Rotate the "function knob" to DMX DIMMING CURVE.
Rotate the "dimmer knob" to select LINEAR, EXPONENT, LOGARITHM, S CURVE or GAMMA 2.2.

9
MENU
DMX DIM: LINEAR
DMX SMOOTHTN: OFF
MENU
DMX DIM: LINEAR
DMX SMOOTHTN: ON
2. DMX Remote Control
①Connect the light fixture to the DMX/RDM console with a DMX connection cable.
Connect the DMX connection cable to the console as shown below:
Rotate the "dimmer knob" to select ON or OFF.
DMX IN
NC
NC
DMX OUT
GND 1
DATA - 2
DATA + 3
1 GND
2 DATA -
3 DATA +
NC
NC

10
②DMX Terminator
ln DMX control mode, the DMX output of the last fixture should be connected with a DMX terminator
(not included). The terminator is connected with a 120Ω(OHM) resistor across Pin 2 and Pin 3 (as shown below).
This prevents interference caused by DMX signals in the transmitting process.
DMX Terminator Connection
Connect a 120Ω(OHM) resistor
across Pin 2 and Pin 3 in an XLR
plug and insert into the DMX OUT
socket on the last unit.
PIN 2PIN 3
120Ω
1
2
3
5
4
Please scan the QR code to check or download the latest DMX reference guide.
③Channel Setting
④Refer to the DMX reference guide and control the fixture via DMX/RDM console. (For detailed operation, please
refer to the DMX/RDM console operation manual.)
Note: DMX reference guide《PavoTube_II_15C_30C_DMX_REFERENCE_GUIDE_EN》is downloadable from
www.nanlite.com or from the QR code as below.
3. RDM Romote Control
①Connect the light fixture to the console with RDM function with a connection cable.

11
MENU
BT: RESET
CH: 512
4. 2.4G Remote Control
·PavoTube II 15C/30C can be remotely controlled by 2.4G remote controller and by NANLINK APP via the
WS-TB-1 transmitter box. PavoTube II 15C/30C also has built-in bluetooth and can be controlled via bluetooth.
Note: ①2.4G remote controller and transmitter box are sold separately.
②The fixture supports the 2.4G wireless protocol V1.0 and V2.0. The fixture should be set in V2.0 while using
WS-RC-C1 or WS-RC-C2 remote controller, set in V1.0 while using other remote controllers.
②Control the light fixture to the console with RDM function(For specific operation methods, please refer to the
RDM console operation manual.)
Note: The UID format of the fixture is as follow:
0008 XXXX XXXX
Serial Number
0601：PavoTube II 15C
0602：PavoTube II 30C
Manufacturer: Nanguang
Press MODE button to access options.
MODE
LOCK

12
MENU
FW UPDATE: UPDATE
WIRELESS PRO: V1.0
MENU
FW UPDATE: UPDATE
WIRELESS PRO: V1.0
MENU
FW UPDATE: UPDATE
WIRELESS PRO: V2.0
1. Toggle the power switch to turn on the fixture, "NANLITE" logo will be displayed, that means the fixture starts up
normally.
2. MODE button: Press the MODE button to switch among CCT, HSI, EFFECT and MENU.
①CCT Mode: Press the MODE button to CCT, rotate the "function knob" to select DIM, CCT or G/M,
rotate the "dimmer knob" to set the parameters of DIM, CCT and G/M. DIM range: 000% --- 100%,
CCT range: 2700K --- 7500K, G/M range: -150 --- +150.
Operating Instructions
Rotate the "function knob" to WIRELESS PROTOCOL.
Rotate the "dimmer knob" to select V1.0 or 2.0.

13
CCT
CCT: 5600K G/M: 0
DIM: 100%
CCT
CCT: 5600K G/M: 0
DIM: 100%
CCT
CCT: 5600K G/M: 0
DIM: 100%
CCT
CCT: 5600K G/M: 0
DIM: 099%
Press the MODE button to CCT.
Rotate the "function knob" to select DIM, CCT or G/M.
MODE
LOCK
Rotate the "dimmer knob" to set the parameters of DIM, CCT and G/M.
Note:
①In EFFECT modes, the DIM parameter is the same as that in CCT mode.
②In EFFECT modes, the CCT and G/M parameters are not synchronized with that in CCT mode, the CCT and
G/M range are the same as that in CCT mode.
③When the fixture function is unlocked, in any mode, press the "dimmer knob" to turn off the fixture, and the
DIM percentage on the screen will be 000%. Press again to restore the fixture to its previous state. Press
continuously to switch the fixture betweeen on and off.

14
HSI
HUE: 000 SAT: 100
DIM: 100%
HSI
HUE: 000 SAT: 100
DIM: 100%
HSI
HUE: 000 SAT: 100
DIM: 100%
HSI
HUE: 000 SAT: 100
DIM: 099%
Note:
①In EFFECT modes, the DIM parameter is the same as that in CCT mode.
②In EFFECT modes, the HUE and SAT range are the same as that in HSI mode.
②HSI mode: Press the MODE button to HSI, rotate the "function knob" to select DIM, HUE or SAT,
rotate the "dimmer knob" to set the parameters of DIM, HUE and SAT.
DIM range: 000% --- 100%, HUE range: 000 --- 360, the HUE is with a loop regulation, SAT range: 000 --- 100.
Press the MODE button to HSI.
Rotate the "function knob" to select DIM, HUE or SAT.
MODE
LOCK
Rotate the "dimmer knob" to set the parameters of DIM, HUE and SAT.

15
EFFECT
DIM: 100%
FX: HUE LOOP
EFFECT
DIM: 000% - 100%
FX: WELDING
③EFFECT mode, press the MODE button to EFFECT, rotate the "dimmer knob", PavoTube II 15C/30C have
built-in effects including HUE LOOP, CCT LOOP, INT LOOP, CCT FLASH, HUE FLASH, CCT PULSE,
HUE PULSE, STORM AUTO, POLICE CAR, TV, PAPARAZZl, CANDLE/FIRE, DISCO, BAD BULB,
FIREWORK, EXPLOSION AUTO and WELDING.
Press the MODE button to EFFECT.
Rotate the "function knob" to FX.
MODE
LOCK
Rotate the "dimmer knob" to select the effects.
EFFECT
DIM: 100%
FX: HUE LOOP
EFFECT
DIM: 100%
FX: HUE LOOP
HUE LOOP
.
.
.
.
.
WELDING

16
EFFECT
DIM: 100%
FX: HUE LOOP
EFFECT
DIM: 100%
FX: HUE LOOP
EFFECT
DIM: 100%
FX: CCT LOOP
EFFECT
DIM: 100%
FX: HUE LOOP
EFFECT
DIM: 099%
FX: HUE LOOP
EFFECT
DIM: 100%
FX: CCT LOOP
(1) HUE LOOP
HUE LOOP setting, rotate the "function knob" to select DIM, HUE or SPEED (range from: 2s -30s),
and rotate the "dimmer knob" to set the parameters.
Rotate the "function knob" to select DIM, HUE or SPEED.
Rotate the "dimmer knob" to set the parameters.
(2) CCT LOOP
CCT LOOP setting, rotate the "function knob" to select DIM, CCT or SPEED (range from: 2s -30s),
and rotate the "dimmer knob" to set the parameters.
Rotate the "function knob" to select DIM, CCT or SPEED.

17
EFFECT
FX: INT LOOP
DIM: 000% - 100%
EFFECT
FX: INT LOOP
DIM: 000% - 100%
EFFECT
FX: INT LOOP
DIM: 000% - 099%
EFFECT
DIM: 100%
FX: CCT LOOP
EFFECT
DIM: 099%
FX: CCT LOOP
EFFECT
DIM: 000% - 100%
FX: INT LOOP
(3) INT LOOP
INT LOOP setting, rotate the "function knob" to select DIM, SPEED (range from: 2s -30s) or COLOR
(including CCT and HUE), and rotate the "dimmer knob" to set the parameters.
Rotate the "function knob" to select DIM, SPEED or COLOR.
Rotate the "dimmer knob" to set the parameters.
Rotate the "dimmer knob" to set the parameters.

18
EFFECT
SPD: 08S
CLR: CCT CCT: 5600K
EFFECT
SPD: 08S
CLR: HUE HUE: 000
EFFECT
SPD: 08S
CLR: HUE HUE: 000
EFFECT
SPD: 08S
CLR: HUE HUE: 001
EFFECT
SPD: 08S
CLR: CCT CCT: 5600K
EFFECT
SPD: 08S
CLR: CCT CCT: 5700K
EFFECT
FX: INT LOOP
DIM: 000% - 099%
EFFECT
FX: INT LOOP
DIM: 000% - 099%
·When COLOR setting is in CCT, rotate the "function knob" to CCT, and rotate the "dimmer knob" to set the CCT
parameters.
Rotate the "function knob" to CCT.
Rotate the "dimmer knob" to set the CCT parameters.
·When COLOR setting is in HUE, rotate the "function knob" to HUE, and rotate the "dimmer knob" to set the HUE
parameters.
Rotate the "function knob" to HUE.
Rotate the "dimmer knob" to set the HUE parameters.

19
EFFECT
DIM: 100%
FX: CCT FLASH
EFFECT
DIM: 099%
FX: CCT FLASH
(4) CCT FLASH
CCT FLASH setting, rotate the "function knob" to select DIM, CCT, G/M or INTERVALS
(range from: 0.1s -10.0s), and rotate the "dimmer knob" to set the parameters.
Rotate the "function knob" to select DIM, CCT, G/M or INTERVALS.
Rotate the "dimmer knob" to set the parameters.
(5) HUE FLASH
HUE FLASH setting, rotate the "function knob" to select DIM, HUE, SAT or INTERVALS
(range from: 0.1s -10.0s), and rotate the "dimmer knob" to set the parameters.
Rotate the "function knob" to select DIM, HUE, SAT or INTERVALS.
EFFECT
DIM: 100%
FX: CCT FLASH
EFFECT
DIM: 100%
FX: CCT FLASH
EFFECT
DIM: 100%
FX: HUE FLASH
EFFECT
DIM: 100%
FX: HUE FLASH
