NANLITE DSA Series User manual

USER MANUAL
600DSA/900DSA/1200DSA
LED Studio Light
Guangdong NanGuang Photo&Video Systems Co., Ltd

600DSA/900DSA/1200DSA LED Studio Light
Technical Data
Model: 600DSA
LED Quantity: 600pcs
LED Power: 36W
AC Input Power: 100V - 240V
DC Input Power: 15V
Color Temperature: 3200K/5600K
CRI(Ra):95
Product Show
Model: 900DSA
LED Quantity: 900pcs
LED Power: 54W
AC Input Power: 100V - 240V
DC Input Power: 15V
Color Temperature: 3200K/5600K
CRI(Ra):95
Model: 1200DSA
LED Quantity: 1152pcs
LED Power: 72W
AC Input Power: 100V - 240V
DC Input Power: 15V
Color Temperature: 3200K/5600K
CRI(Ra):95
1
600DSA 900DSA 1200DSA

1. Barndoor
2. Dimmer knob
3. Angle fixing knob
4. Sony V-Mount
battery holder
5. Battery lock button
6. Yoke
7. Digital display
8. ADDR button
9. DMX in
10. DMX out
11. Power switch
12. DC power socket
13. Filter
Product Detail
3. Angle fixing knob
2

Detail Description
1. Barndoor: For adjusting the illuminated area.
2. Dimmer knob: For adjusting the brightness.
3. Angle fixing knob: For fixing the fixture on the light stand and adjusting the illumination direction of fixture.
4. Sony V-Mount battery holder: For installing the Sony V-mount battery, or holding the power adapter when install
the adapter holder.
NOTE: If using Anton/Panasonic battery, make sure change to corresponding battery holder.
5. Battery lock button: For installing or removing the battery.
6. Yoke: For connecting the fixture to the light stand and adjusting the tilt and pan of fixture.
7. Digital display: For showing the fixture's brightness and lighting code.
8. ADDR button: For adjusting the adress of the fixture.
9. DMX in: DMX signal input interface.
10. DMX out: DMX signal output interface.
11. Power switch:Turn on/off the fixture.
12. DC power socket: DC power input interface.
13. Filter: Soft diffuser, enhanced soft diffuser, orange filter (3200K). Without diffuser, it creates spotlight effect and
suitable for shooting at a relatively long distance. With diffuser or enhanced soft diffuser, it creates the
corresponding soft effect. With orange filter(3200K), the color temperature changes from 5600K to 3200K.
Usage
1. Please install the fixture on the light stand and adjust the fixture according to desired position, then open the barndoor.
2. Make sure the fixture is in the "off" position and connect the power adapter or battery.
Install the attaching plug of fixture to the DC power socket.①
NOTE: Make sure the power, voltage and frequency are consistent with the provided power adapter.
②When using battery, make sure to turn off the fixture, then plug in the battery.
3

3. When turn on the fixture, the display will light up normally, that means the power is active.
4. Adjust the fixture's brightness via "Dimmer knob", the brightness range is represented as L.000 - L.100.
5. Please change the filters to get different lighting effects.
6. 2.4G Wireless Remote Control
600DSA/900DSA/1200DSA are designed to work with a 2.4G remote controller or NANLITE Wi-Fi app via Wi-Fi
transfer device to control light freely.
NOTE: 2.4G remote controller or WiFi transfer devices should be bought additionally. (See separate instructions
for remote controller or Wi-Fi transfer device.)
7. Turn off the switch when you stop using it and remove the power adapter or battery.
DMX lighting console connection
The connection between the light fixture and a DMX lighting console should use 3-pin cable and make sure its
diameter is less than 0.5mm. Please use the 5-pin XLR plug to connect the DMX signal input/output interface.
XLR plug/socket and the cable should be connected as pictured above.
Please connect the DMX signal output interface of the console to the DMX signal input interface of the first fixture
with XLR cable, then from this first fixture's output interface to the second one's input interface and so on.
NOTE: The length of XLR cable should be within 300m and bought additionally.
4

Channel Detail
For the fixture with single color temperature, the lighting adress is chosen 001, so it will match the CH1 fader of the
console. When you release the lighting adress, the default adress will be kept until next time you turn on the switch.
Safety Precautions
1. Please open the package to check if it is damaged due to transportation after receiving the light. In the case of
damage caused in transportation, please do not use this light and contact the dealer or manufacturer as soon as
possible.
2. Do not use a power cord with damaged insulation. Do not unplug hard or drag the power cord directly.
3. Make sure that the power supply voltage used match the voltage specified by the light before installation.
4. When not using or cleaning the light, please turn it off.
5. Keep the light safely stored and away from children.
Notice
1. Before using, please read the instruction sheet carefully and install the product according to the instruction sheet.
2. Pull insert plug, please do not use to much force to pull connection. And do not touch the connection by wet hand.
3. Please keep this fixture in dry and ventilated place, to avoid the circuit get wet, and cause short circuit.
4. When stop suing, please turn off the power to preserve the life of the LEDs.
5

600DSA/900DSA/1200DSA × 1pcs
Potential Malfunction
The light can not light up!
The lamp is flickering.
1. Check if the battery is properly installed.
2. Press the power switch, if the display doesn't light up, consider
using a different compatible battery.
3. Check if the connection between adapter and fixture is loose ,
adapter's voltage and current is within specified range.
1. Check if the battery capacity is enough, or change a
compatible battery with full capacity to test.
2. Check if the power adapter is within the specified range.
3. Check if there is any high temperature object near the
light that could cause the operating environment
temperature too high.
Diagnosis
Genaral Fault Detection and Diagnosis
Filters × 1set
Power Adapter × 1pcs Power Cable × 1pcs
User Manual × 1pcs
Carrying Bag × 1pcs
What's in the box? Please kindly check.
Guan gdon g Na nGua ng P hoto &Vi deo S yste ms C o., L td
USER MANUAL
600DSA/900DSA/1200DSA
LED Studio Light
6
The instruction was written according to the strict prodution test of our company, if there are
any changes related to the design of the product later, we will not keep you updated for that.

www.nanlite.com
[phone]
[email protected]
[phone]
Zhanglin,324,Dongli Chenghai Shantou Guangdong China
Version:V2 2020-02-15
