Nec N331i User manual

Emergency Services and Safety Precautions

Emergency Services

To make an emergency call in any country

☛Press 1 1 2 .

Ask the operator for the service which you require: Police, Ambulance, Fire Brigade,

Coastguard or Mountain Rescue Services. Give your position and, if possible, remain

stationary to maintain phone contact.

The 112 emergency number service is available on every digital network service. The

number 999 is an alternative emergency number for the UK only, and can only be used

with a valid SIM card.

2Due to the nature of the cellular system, the success of emergency calls cannot be

guaranteed.

General Care

A cellphone contains delicate electronic circuitry, magnets, and battery systems. You

should treat it with care and give particular attention to the following points.

•Do not allow the phone or its accessories to come into contact with liquid or moisture

at any time.

•Do not place anything in the folded phone.

•Do not expose your phone to extreme high or low temperatures.

•Do not expose your phone to naked flame, cigars or cigarettes.

•Do not paint your phone.

•Do not drop or subject your phone to rough treatment.

•Do not place the phone alongside computer disks, credit cards, travel cards and other

magnetic media. The information contained on disks or cards may be affected by the

phone.

•Do not leave the phone or the battery in places where the temperature could exceed

60°C; e.g. on a car dashboard or on a window sill, behind glass in direct sunlight, etc.

•Do not remove the phone’s battery while the phone is switched on.

•Take care not to allow metal objects, such as coins or key rings, to contact or short-

circuit the battery terminals.

•Do not dispose of battery packs in a fire. Your phone's Li-ion batteries may be safely

disposed of at Li-ion recycling points. For more specific battery and power supply

information, see page 4.

•Do not put your phone's battery in your mouth as battery electrolytes may be toxic if

swallowed.

•Do not attempt to dismantle the phone or any of its accessories.

•This equipment is fitted with an internal battery that can only be replaced by a qualified

service engineer. There is a risk of explosion if the battery is replaced by an incorrect

type. Dispose of the used battery in accordance with the manufacturer's instructions.

•Using any battery pack, AC adapter, Vehicle power adapter (option) or Desktop

charger (option) not specified by the manufacturer for use with this phone creates a

potential safety hazard.

•The earpiece may become warm during normal use and the unit itself may become

warm during charging.

•Use a damp or anti-static cloth to clean the phone. Do NOT use a dry cloth or

electrostatically charged cloth. Do not use chemical or abrasive cleaners as these

could damage the case.

•Remember to recycle: the cardboard packaging supplied with this phone is ideal for

recycling.

•Do not leave the battery pack empty or disconnected for a long time, otherwise some

data may be initialized.

•Your phone contains metal which may cause you an itch, a rash or eczema depending

on your constitution or physical condition.

•Take care not to put your phone in the back pocket of your trousers or skirt and then

sit on it. Also, do not put your phone at the bottom of bag where it may subject to

excessive weight or pressure.

Doing so may damage the LCD and camera lens and cause them malfunction.

•Take care not to hold the Light too close to your or other people’s eyes when the Light

is lit.

Aircraft Safety

•Switch off your phone and remove its battery when inside or near aircraft. The use of

cellphones in aircraft is illegal. It may be dangerous to the operation of the aircraft and

it may disrupt the cellular network. Failure to observe this instruction may lead to

suspension or denial of cellphone service to the offender, or legal action, or both.

•Do not use your phone on the ground without the permission of the ground crew.

Hospital Safety

•Switch off your phone in areas where the use of cellphones is prohibited. Follow the

instructions given by the respective medical facility regarding the use of cellphones on

their premises.

General Safety

•Observe ‘Turn off 2-way radio’ signs, such as those near stores of fuel, chemicals or

explosives.

•Do not allow children to play with the phone, charger or batteries.

•Small parts are included in your phone. Keep them out of reach of small children, for

whom it could be a choking hazard.

•The operation of some medical electronic devices, such as hearing aids and

pacemakers, may be affected if a cellphone is used next to them. Observe any warning

signs and manufacturer's recommendations.

•If you have a weak heart, you should take extra precautions when setting functions

such as the Vibrator and Ringer volume functions for incoming calls.

•If you set the Vibrator setting to anything other than OFF, be careful that the phone is

not near a source of heat (e.g. a heater) and that it does not fall from a desk due to the

vibration.

Road Safety

•You MUST exercise proper control of your vehicle at all times. Give full attention to

driving.

•Observe all the recommendations contained in your local traffic safety documentation.

•Pull off the road and park before making or answering a call if driving conditions so

require.

•You MUST NOT stop on the hard shoulder of a motorway to answer or make a call,

except in an emergency.

•Switch off your phone at a refuelling point, such as a petrol station, even if you are not

refuelling your own car.

•Do not store or carry flammable or explosive materials in the same compartment where

a radio transmitter, such as a cellphone, is placed.

•Electronic vehicle systems, such as anti-lock brakes, speed control and fuel injection

systems are not normally affected by radio transmissions. The manufacturer of such

equipment can advise if it is adequately shielded from radio transmissions. If you

suspect vehicle problems caused by radio transmissions, consult your dealer and do

not switch on your phone until it has been checked by qualified approved installers.

Vehicles Equipped with an Air Bag

An air bag inflates with great force. Do not place objects, including either installed or

portable

wireless equipment, in the area over the air bag or in the air bag deployment area. If in

vehicle wireless equipment is improperly installed and the air bag inflates, serious injury

could result.

Third Party Equipment

The use of third party equipment, cables or accessories, not made or authorized by NEC,

may invalidate the warranty of your cellphone and also adversely affect the phone’s

operation. For example use only the NEC mains cable supplied with the AC charger.

Service

The cellphone, batteries and charger contain no user-serviceable parts. We recommend

that your NEC cellphone is serviced or repaired by an NEC authorized service centre.

Please contact your Service Provider or NEC for advice.

Non-Ionizing Radiations

The radio equipment shall be connected to the antenna via a non-radiating cable (e.g.

coax).

The antenna shall be mounted in a position such that no part of the human body will

normally rest close to any part of the antenna unless there is an intervening metallic

screen, for example, the metallic roof.

Use only an antenna that has been specifically designed for your phone. Use of

unauthorized antennas, modifications or attachments could damage your phone and

may violate the appropriate regulations, causing loss of performance and radio

frequency (RF) energy above the recommended limits.

Efficient Use

For optimum performance with minimum power consumption, note the following:

•Your phone has the internal antenna. Do not cover part of the internal antenna of the

phone with your hands. This affects call quality, may cause the phone to operate at a

higher power level than needed and may shorten talk and standby times.

Radio Frequency Energy

Your phone is a low-power radio transmitter and receiver. When it is turned on, it

intermittently receives and transmits radio frequency (RF) energy (radio waves). The

system that handles the call controls the power level at which the phone transmits.

Exposure to Radio Frequency Energy

Your phone is designed not to exceed the limits for exposure to RF energy set by

national authorities and international health agencies. * These limits are part of

comprehensive guidelines and establish permitted levels of radio wave exposure for the

general population. The guidelines were developed by independent scientific

organizations such as ICNIRP (International Commission on Non-Ionizing Radiation

Protection) through periodic and thorough evaluation of scientific studies. The limits

include a substantial safety margin designed to assure the safety of all persons,

regardless of age and health, and to account for any variations in measurements.

*Examples of radio frequency exposure guidelines and standards that your phone is

designed to conform to:

•ICNIRP, “Guidelines for limiting exposure to time-varying electric, magnetic, and

electromagnetic fields (up to 300 G Hz)-International Commission on Non-Ionizing

Radiation Protection (ICNIRP)”.

•Health Physics, vol. 74. pp, 494-522, April 1998.

•99/519/EC Council Recommendation on the limitation of exposure to the general

public to electromagnetic fields 0 Hz-300 GHz, Official Journal of the European

Communities, July 12,1999.

•ANSI/IEEE C95.1-1992. “Safety levels with respect to human exposure to radio

frequency electromagnetic fields, 3kHz to 300 GHz”. The Institute of Electrical and

Electronics Engineers Inc., New York, 1991.

•FCC Report and Order, ET Docket 93-62, FCC 96-326, Federal Communications

Commission (FCC), August 1996.

•Radio communications (Electromagnetic Radiation Human Exposure) Standard 1999,

Australian Communications Authority (ACA), May 1999.

Declaration of Conformity

This product complies with the requirements of the R&TTE Directive 1999/5/EC.

The ‘Declaration of Conformity’ leaflet can be found within this box.

Licenses

•T9®Text Input and the T9 logo are registered trademarks of Tegic Communication.

“T9 Text Input is licensed under one or more of the following:

U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, 6,011,554, and

6,307,548; Australian Pat. No. 727539; Canadian Pat. No. 1,331,057; United Kingdom

Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore

Pat. No. 51383; Euro. Pat. No. 0 842 463 (96927260.8) DE/DK, FI, FR, IT, NL, PT. ES,

SE, GB; Republic of Korea Pat. Nos. KR201211B1 and KR226206B1; and additional

patents are pending worldwide”

•This product contains ACCESS CO., LTD’s Compact NetFront™ Plus internet browser

software.

Compact NetFront™ is a registered trademark or trademark of ACCESS CO., LTD in

Japan and selected countries worldwide.

•The James Bond Theme by Monty Norman

©EMI Unart Catalog Inc. (BMI)

•i-mode and i-mode logos are trademarks or registered trademarks of NTT DoCoMo.

For the purpose of improvement, the specifications for this product and its

accessories are subject to complete or partial change without prior notice.

iii

Before You Start

Cellphone system structure

It is worth remembering that every time you use your phone, three or four different organizations are involved:

All the features described in this user’s manual are supported by your phone. However, for all these features to work, you must have a SIM card (supplied

by your Service Provider) that also supports these features. Even if you have a fully featured SIM card, any feature not supported by the Network

transmitting your call will not work. This last point is especially important when you are roaming networks (see page 13).

User’s manual conventions

The instructions in this user’s manual make use of the shortcuts selection except special cases.

The following markers are used throughout the user manual to attract your attention:

/This type of paragraph will contain details of where to find information related to the topic in question.

2This type of paragraph will contain information worth noting.

,This type of paragraph will contain important information.

The people that supply

your SIM card and bills

Service

Provider

The people that

transmit your calls

Network

The people that

provide your Internet services

i-mode Service Provide

The people that

make your phone

Display information

Check box/ Radio button

A check box enables/ disables an option out of a set of options, and multiple check boxes can be selected at the same time. On the other hand, selecting

a radio button automatically cancels the previous selection, so only one radio button can be selected at one time.

A check box/ radio button option can be selected/ cancelled by highlighting it and pressing .

Status icon area

This area contains icons

which indicate the battery

strength, new SMS/mail/

MMS message(s), signal

strength etc.

(see page vii).

Help area

This area contains help

information as appropriate

(e.g. key presses remaining

when composing a message).

Softkey area

This area contains context sensitive

descriptions of the Softkeys’

functions as appropriate.

Shortcut number

Press the appropriate

number to jump straight to a

next menu.

A button colour is changed

when selected (e.g. for

enable/disable settings).

Help icon

Displayed when you can use the

key represented by this icon

(see page vii).

Next menu icon

Displayed when you can press the key

or the shortcut number to show the next

menu.

▼

Page scroll bar

Displayed when you can press

the ▼key to scroll to the next

page.

Shortcut menu number

The current menu number is

displayed.

Menu title

Parts and functions

Earpiece Light

Main-LCD

Battery lock

Speaker

Earphone

jack cover

Softkey 2

Softkey 1

Select key

4 way

navigation key

Menu key

Clear (CLR)/Back key

Send key

Phone book key

End/On-Off key

Internal antenna

Charger connection

cover

Alphanumeric keys

Mouthpiece

Through-hole

for strap

Battery

Side down key

Side up key

2nd-LCD/

Backlight illumination

Camera

Keypad shortcuts

The following operations are available from the standby screen.

Key Operation that involves pressing a key See page Operation that involves pressing and holding a key See page

Accessing the Main menu screen 14 Setting the Side key lock to On/Off –

Softkey 1 Accessing the Mail screen 55 Accessing the Mail Inbox screen 59

Softkey 2 Accessing the i-mode menu screen 52 – –

Accessing the Phonebook list screen 24 Accessing the Message menu screen 36

▲Accessing the Phone modes screen 15 Setting the phone to Meeting mode 15

▼Accessing the My data screen 75 Accessing the Voice recall 8

Accessing the Received calls list 9 – –

Accessing the Missed calls list 9 – –

Accessing the Dialled calls list 9 – –

Accessing the Camera finder screen 46 – –

Ending a call or cancelling various operations – Switching off 3

CLR Deleting character or returning to the previous screen – Deleting all characters when you enter text –

1Entering phone numbers 6 Calling the Voice mail centre 30

2to 9Entering phone numbers 6 Going to the corresponding phone number in the phone-

book(SIM) (One-touch dial) –

0Entering phone numbers 6 Entering + when you make an international call 12

#– – Entering a pause –

––

Toggling the selected line 18

Muting or retrieving the sound during a call 8

Side up Adjusting the volume when your phone is open 15 ––

Activating Ring silencer function when you receive a call 18 –

Side down Adjusting the volume when your phone is open 15 Turning on the Light –

Activating Ring silencer function when you receive a call 18 –

▼

vii

LCD and displayed icons

Indicates the battery level.

Appears during charging.

Indicates that there is a new message(s) in your

phone.

Indicates that there is a new message(s) on server.

Indicates that the SIM memory is full.

Indicates that the Inbox folder in your phone is full.

Indicates the Burst mode in the Camera mode.

(beige)

Indicates that there is a new i-mode message(s) in

your phone. When a mail(s) or MMS is being

downloaded, the beige icon blinks.

Indicates that the phone memory for i-mode

message is full.

(green)

Indicates that there is a mail(s) on server.

(blue)

Indicates that there is a new MMS on server.

(pink)

Indicates that there are both mail(s) and MMS on server.

Indicates the Brightness setting level in the Camera

mode. The “+2” setting is for brighter.

(red) (green) (green/red)

Indicates that new Voice mail messages are on the

network (No ALS/ALS Line 1, ALS Line 2, ALS Line 1 & 2).

Indicates Self timer in the Camera mode.

Indicates the Image quality (Super fine, Normal or

Economy).

Indicates secured communication on SSL.

Indicates the Zoom level in the Camera mode.

(gray)

Indicates that the GSM network is active and GPRS

is attached.

(yellow)

Indicates that the GPRS is attached and i-mode is active.

Indicates that i-mode communication is being carried out.

Indicates that i-mode lock is On.

Indicates that PDP Context is activated.

Indicates the photography environment in the

Camera mode (Standard, Person, Room, Sepia,

Monochrome or Darkness).

Indicates the Line status (ALS Line 1/No ALS).

Indicates the Line status (ALS Line 2).

( displayed in red)

Indicates the Line status (ALS Line 1 Unencrypted/

No ALS).

( displayed in red)

Indicates the Line status (ALS Line 2 Unencrypted).

Indicates that Light is set to On in the Camera mode.

Indicates the signal strength level.

Appears when you are outside the service area.

Remote time or a day of the week when the screen

displays Local time only.

Local time.

Indicates that you can move to the Camera finder

screen by pressing .

Indicates that you can use the options menu by

pressing .

Indicates that you can use the Phonebook list by

pressing .

“Network Name”

The colour of “Network Name” changes to “Orange”

when you are provided “Roaming Service”.

Appears when the alarm is set.

Indicates that Call diversion is set.

Indicates that Meeting mode is set to On.

Indicates that Pocket mode is set to On.

Indicates that Car mode is set to On.

When there is no icon, Normal mode is set to On.

Indicates that the Vibrator is set to On.

Indicates that the Vibrator and the Silent are set.

Indicates that the Vibrator is Off and the Silent is set.

2The Silent is the status that all the volume

settings (Ringer tone, Msg tone, and Clock

alarm tone) are set to the lowest.

Date

123456789

viii

Overview of menu function

Key Main menu Second level menu

3 i-mode Settings

i-mode

4 Phonebook Lists

Information #

Call options

5 Camera

6 My data Pictures

Sounds

Key Main menu Second level menu

1 Settings Phone

Phone modes

Main-LCD

2nd-LCD

Power saving

Calls

Security

Network

Reset settings

2 Message Inbox

Drafts

Outbox

Sent

Folder1

Folder2

Key Main menu Second level menu

7 Game Poker

Belt

Clover

8 Accessory Calculator

Clock alarm

Scheduler

ToDo list

Notepad

Voice memo

Currency

9 SIM toolkit

➡➡

Standby screen Main menu screen

CLR

Attaching and Removing the Emblem

Attaching the Emblem Removing the Emblem

Attach the Emblem to the rear

cover in the order ➀and ➁.

Push the Emblem firmly to

attach it to the rear cover.

Hook your finger underneath the dent

of the rear cover and remove the

Emblem.

Getting Started 1

Caring for Batteries 4

Basic Calls & Phone Use 6

Selecting Features 14

Setting up Your Phone 15

Phonebook 23

Text Entry 31

Security 33

Message 36

Camera Function 45

i-mode Facilities 48

Accessory 67

My data 75

Game 79

Abbreviations 80

Index 81

Before You Start iii

Cellphone system structure ............................................ iii

Display information ......................................................... iv

Parts and functions .......................................................... v

LCD and displayed icons ............................................... vii

Overview of menu function ............................................viii

Attaching and Removing the Emblem............................. ix

Getting Started 1

Preparing the phone ........................................................1

Start-up ............................................................................3

Caring for Batteries 4

Standby and talk times.....................................................4

Checking the battery ........................................................4

Low battery alarm ............................................................4

Changing the battery........................................................5

Basic Calls & Phone Use 6

Making basic calls............................................................6

Ending calls......................................................................6

Receiving calls .................................................................6

Putting a call on hold........................................................7

Unsuccessful calls ...........................................................7

Emergency calls...............................................................7

Last number redial ...........................................................7

One-touch dial..................................................................8

Fast dialling......................................................................8

Displaying your own phone number.................................8

Multi-party calls ................................................................8

Voice recall ......................................................................8

Mute.................................................................................8

Call options ......................................................................9

Call settings ................................................................... 10

International dialling codes ............................................ 12

Roaming.........................................................................13

Selecting Features 14

Main menu .....................................................................14

Menu shortcuts selection ............................................... 14

Setting up Your Phone 15

Earpiece volume setting................................................. 15

Phone Mode...................................................................15

Answer options ..............................................................18

Activating Side keys....................................................... 18

ALS setup ......................................................................18

Time & date setting ........................................................ 19

Setting the display to your language of preference........ 20

Main-LCD settings ......................................................... 20

2nd-LCD settings ........................................................... 21

Power saving .................................................................22

Reset settings ................................................................22

Phonebook 23

Phonebooks................................................................... 23

Phonebook list Options menu ........................................24

Personal data Options menu .........................................29

Scratchpad number........................................................ 30

Voice mail ...................................................................... 30

xii

Text Entry 31

Mode change ................................................................. 31

T9®English text input ..................................................... 31

Normal text input............................................................ 32

Numeric input................................................................. 32

Keys allocations............................................................. 32

Security 33

Change PINs ................................................................. 33

PIN activate ................................................................... 34

Phone lock ..................................................................... 34

Bar calls ......................................................................... 35

FDN setting.................................................................... 35

Message 36

Message overview ......................................................... 36

Reading messages ........................................................ 37

Options menus............................................................... 38

Creating a message....................................................... 40

Settings.......................................................................... 43

Broadcast messages ..................................................... 44

Camera Function 45

Notes on using the Camera ........................................... 45

Activating and terminating a Camera function ............... 45

Taking a picture ............................................................. 46

Camera Options............................................................. 46

i-mode Facilities 48

About i-mode ................................................................. 48

What can I download ..................................................... 48

i-mode icons .................................................................. 49

i-mode quick start .......................................................... 49

i-mode settings .............................................................. 50

i-mode menu.................................................................. 52

Mail menu ...................................................................... 55

i-mode user settings ...................................................... 63

Mail settings................................................................... 65

Accessory 67

Calculator....................................................................... 67

Clock alarm.................................................................... 68

Scheduler....................................................................... 70

ToDo list......................................................................... 72

Notepad ......................................................................... 73

Voice memo................................................................... 73

Currency converter ........................................................ 74

My data 75

Pictures.......................................................................... 75

Sounds........................................................................... 76

File selector menu ......................................................... 77

Game 79

Poker ............................................................................. 79

Belt................................................................................. 79

Clover ............................................................................ 80

Abbreviations 80

Index 81

Getting Started

Preparing the phone

Before trying to use your phone, make sure the followings have been carried out.

•Valid SIM card inserted

•Battery charged

SIM card

Before using your phone, you must sign-up with one of the digital network Service Providers. In addition to your subscription details you will receive a

personal SIM (Subscriber Identity Module) card which is inserted into your phone.

If the SIM card is removed, the phone becomes unusable until a valid SIM card is fitted. It is possible to transfer your SIM card to another compatible

phone and resume your network subscription. The screen on your phone will display appropriate messages if no SIM card is fitted.

,If the phone, or the SIM card, is lost or stolen then you should contact your Service Provider immediately in order to bar it from use.

2The phone supports a number of languages and the keyboard symbols have been chosen for world-wide operation.

2The digital technology of your NEC GSM phone helps to ensure that your conversations are kept secure.

2The SIM card contains personal data such as your electronic phonebook, messages (see page 36) and also details of the network services you have

subscribed to. The phone will not work (except for emergency calls on some networks) unless a valid SIM card is fitted.

,Be sure to turn the phone off before inserting/removing the SIM card. If not, damage to the SIM card can occur.

Inserting a SIM card

☛While pressing down the area (A) of the rear cover, especially the place indicated by the arrow ➀, slide the rear cover in the direction of arrow ➁

with your finger tip. Then, lift the cover up in the direction of arrow ➂to remove it.

☛Lift the knobs of the battery pack up in the direction of arrow ➃. Then slide the battery pack out in the direction of arrow ➄.

☛Insert the SIM card sliding it under the holders of the both sides. Slide the SIM card until it locks.

,Do not scratch the phone body or the rear cover with your finger nail, when removing the rear cover.

,Do not press too firmly on the rear cover and the phone body. The use of excessive force could damage the rear cover and the phone body.

,If the SIM card is not fully inserted when the battery is replaced, damage to the SIM card can occur.

,Do not scratch the holders of the both sides when inserting or removing a SIM card.

2If the SIM card is already fitted, see “Start-up” on page 3.

Removing a SIM card

☛With the battery removed, remove the SIM card sliding it lightly.

Finger tab

Battery

Holder

SIM card

Rear cover

(A)

Charging the battery

Before trying to use your phone, insert the phone’s battery, connect the NEC battery charger (AC adapter) supplied

with your phone to a suitable mains power socket and then connect the charger’s output to the phone’s charger

connector.

☛Connect the charger plug (AC adapter) into the connector at the side of the phone. Check that the Backlight

illumination glows Apple. When charging is completed, the Backlight illumination goes out.

You are recommended to switch off the phone during charging. If you need to receive calls, your phone can

be switched on and left in standby while being charged, although the total time taken to charge is then

increased.

,Using any battery pack, AC adapter, Vehicle power adapter (option) or Desktop charger (option) not specified by NEC for use with this

phone can be dangerous and may invalidate any warranty and approval given to the cellphone. Do not connect more than one charger at

any time. Do not leave the charger connected to the mains supply when it is not in use.

,Do not try to charge the battery if the ambient temperature is below 5°C(41°F) or above 35°C(95°F).

,DO NOT connect a charger or any other external DC source until the phone’s battery is inserted.

,Damage may result if you do not press in the charger connector’s side catches when removing it from your phone.

2If the phone does not respond, please wait for a few minutes. The charging will then start.

2If you use the phone during charging, handle the phone carefully since the cable or adapter is connected.

2You can also charge the phone by using Desktop charger (option).

Start-up

Switching the phone on

☛Press and hold for about a second to switch on. The screen will display the selected greeting (see page 20) and the phone is then in standby.

2You may need to charge the battery before using your phone. If the phone gives no response when switched on, read the information about batteries

on page 4.

2When your phone is turned on, the specified Ringer may sound.

Switching the phone off

☛Press and hold until the display shows the switch off message.

PIN code

The SIM card issued by your service provider has a security feature called PIN code protection. The PIN (Personal Identification Number) is a number

put on to the card by your Service Provider, and is 4 to 8 digits long. Some service providers supply SIM cards which will cause your phone to prompt

for a PIN code when it is turned on. If this is the case, enter your code with the phone’s keypad. If you insert a SIM card other than your own, information

such as call logs may be lost.

Backlight illumination

Charger connector

Caring for Batteries

Standby and talk times

Your phone works closely with the network you are using to provide the services you need, and the standby and talk times achieved will depend on how

you use the phone and choices made by the network operator.

In particular, factors such as your location within the network, the frequency at which this location is updated, the type of SIM card you have, your

reception of area or Cell broadcast messages and the use of Full Rate or Enhanced Full Rate speech, will affect both standby and talk times.

,IMPORTANT BATTERY CHARGING INFORMATION

Charging a very low battery

The battery’s charge continues to drop after the warning is displayed. In extreme cases where the battery is left

uncharged for some considerable time after this warning is displayed, a trickle charge is used to slowly top-up the battery to the safe level at which

the fast charging can begin. The phone can be in trickle charge for a few minutes before the fast charging starts.

,DO NOT connect a charger or any other external DC source if the phone’s battery is not inserted.

Checking the battery

☛Check icon at the left of status icon area.

The block on the display shows the charge of your battery pack.

Full battery power Partial battery power Low battery power Battery empty

Low battery alarm

When the battery voltage falls below the working level, is displayed on screen accompanied by a short tone along with an

empty battery icon. The phone will automatically power down shortly afterwards.

2Please charge the battery as much as possible when the battery is very low.

Changing the battery

,Be sure to turn the phone off before replacing the battery pack.

☛While pressing down the area (A) of the rear cover, especially the place indicated by the arrow ➀, slide the rear cover in the direction of arrow ➁

with your finger tip. Then, lift the cover up in the direction of arrow ➂to remove it.

☛With the caution of the label on the battery pack facing upwards, insert it into the cavity in the phone body in the direction of arrow ➃, making sure

that the tabs on the battery pack fit properly into the notches in the phone. Then press the battery pack down in the direction of arrow ➄to clip it

into the phone.

☛Make sure that the battery pack is securely attached to the phone and align the rear cover with the grooves on the phone so that there is a gap

of about 3 mm at the end of the cover. Then, while pressing down as indicated by arrow ➅, slide the rear cover in the direction of arrow ➆until

you hear a click.

,Do not scratch the phone body or the rear cover with your finger nail, when removing the rear cover.

,Do not press too firmly on the rear cover and the phone body. The use of excessive force could damage the rear cover and the phone body.

Rear cover

(A)

Notches

Tabs

Check that there is no gap

between the rear cover

and the phone body.

About 3 mm

Basic Calls & Phone Use

Making basic calls

You make a simple call in the same way as you would with a normal phone, except that you need to press after entering the area STD code and the

phone number. To make international calls, you must first enter the international dialling code (see page 12).

2Use the full STD area code even if you are calling to a person in the same town. If the numbers are too long to be displayed within one line, excess

part is deleted and ‘...’ is added at its end.

2The Main LCD display shows the strength of the radio signal that links your phone to the network. A maximum signal is shown by 4 shaded blocks

and a minimum signal by 1 block.

Starting a call

☛Key in the phone number. Check the number on the display.

☛Press to send the call.

When the call is sent, the screen displays the number called or the name stored in the phonebook and a connection graphic or a CLI picture that has

been allocated to the number called (see page 23).

Correcting mistakes

Use the and keys to scroll through the number, then press CLR to clear individual digits or press and hold CLR to completely clear a phone number.

Ending calls

☛Press briefly or fold your phone. The phone returns to the standby screen.

2If is held down, your phone will switch off.

Receiving calls

When someone calls your number, the Ringer will sound (if set - see page 16), the Backlight illumination glows in specified colour, and the phone number

of the caller may be displayed if the calling line identification facility is available and the caller has activated the feature. If the caller’s phone number has

been stored in your phonebook along with a name and a CLI picture (see page 26), that name and picture will be displayed. If the caller has withheld

their identity, the screen will give a message that the caller’s number is being withheld.

Accepting a call

☛Press .

▼

Rejecting a call

☛Press briefly or fold your phone.

You also have options for holding calls and forwarding calls. These options depend on your network and your subscription arrangements.

If your phone receives a call and you do not answer it, the screen will display the phone number (or the name if stored) of the caller (if available). This

information is stored in the Missed calls list. Up to 10 missed calls are stored in this list.

2You can set your phone to answer a call when any key is pressed (see “Any key answer” on page 18).

2If you are making a call, the phone gives priority to receiving a call unless you have already pressed .

/See also: “Call diversion” on page 10 and “Call waiting and holding” on page 11.

/See also: “Call options” on page 9.

Putting a call on hold

You can put the received or dialled call on hold by pressing Softkey 1. To retrieve the call, press Softkey 1 again.

Unsuccessful calls

If dialled call is not successfully connected, the display will give an appropriate message.

If your phone is set to Auto redial, the number will be automatically called again after a short delay (see page 12).

Emergency calls

The standard emergency number of 112 can be used.

☛Key in 1 1 2.

☛Press to connect the call to the local emergency services.

2On some networks, emergency calls can be made using the 112 number without a SIM card inserted.

Last number redial

To redial the last number you called:

☛Ensure the standby screen is displayed and no phone number is shown.

☛Press twice. The last number you called will be dialled.

/See also: “Call options” on page 9.

One-touch dial

One-touch dial for the phonebook(SIM) is available by pressing and holding a number 2 to 9.

2A number for the One-touch dial corresponds to the location number in the phonebook(SIM).

2One-touch dial is available only for the phone numbers with the location number 2 to 9 stored in the phonebook(SIM).

Fast dialling

Fast dials for the phonebook(SIM) is available by entering a number 1 to 255 (depending on the SIM card) and pressing and .

Fast dials for the phonebook(phone) is available by entering 1 to 500, then pressing and .

2A number for the Fast dials corresponds to the location number in the phonebook(SIM/phone).

Displaying your own phone number

☛With the standby screen displayed, press and 0.

2You can also display your own phone number by pressing 4, 1and 6from the standby screen.

Multi-party calls

If your SIM card is Multi-party enabled, you can make a conference call to more than one caller. You can even leave the call while the remaining

participants carry on with the call.

,Multi-party call facilities are SIM card and network dependent.

Voice recall

You can store up to 10 Voice recall recordings which can be allocated to a personal data stored in the phonebook(phone). To store the Voice recall sound,
