NEC NEC-101T User manual

NEC-101T
User Guide

2
Thank you for purchasing of this product. Before using this product, read this
manual.

3
Precautions
To e n sure that youuse thisproduct correctly, please read
the following before use. These precautionsmust be
observed at all timesasthey contain information
intended to prevent body injury or damage to property.
• Do not use, keep, or leave the devices(thisproduct,
battery pack, AC charger, SIM card, and other supplied
options) in locationssubject to high temperatures, such
asnear fire, indirect sunlight, inside of a car on a hot
day, or near a heating system.
• Do not put the devicesin heating equipment such asa
microwave oven or pressurized container.
• Do not put the deviceson the unstable place such as
an unstable chair.
• Do not disassemble or modify the devices.
• Do not place electrically conductive objects(wires,
pencil leads, etc.) in contact with the charging product
or microUSB connector. Do not insert such materials
inside the product.
• Do not cover or wrap the deviceswith bedding, etc.
while in using or charging.
•Ifsomething unusual happens, such asunusual odor,
overheating, discoloration, or deformation during use,
charge or storage, be sure to:
-Unplug the AC charger from the power outlet.
-Turn off the power.
- Remove the battery pack from thisproduct.
• Do not leave or use the devicesin humid or dusty
places.
•Use a battery pack and AC charger specified by NEC
de México, S.A. de C.V.
• Do not throw the devices, or expose to excessive shock
or mechanical vibration.
• Do not use damaged devices.
• The supplied AC charger and battery pack are
exclusive for thisproduct. Do not use these with other
devices.
Precautions for this product
•Avoidusing thisproduct in extremely high or low
temperatures. The ambient temperature for operating
should be 5°C to 40°C (limited to the temporary use in
a bathroom etc. when temperature isabove 36°C) with
humidity of 45% to 85%.
• Make sure to turn off thisproduct and stop charging
before youget close to placeslike a gasstation where
a flammable gasisgenerated.
• Do not turn on the light near a person'sor pets' eyes.
• Do not turn on the light against car drivers, etc. Doing
so may interfere with driving and cause a traffic
accident.
•Please turn off thisproduct when inside an airplane,
hospital, or other area where use in prohibited.
- The product may adversely affect electronic or
medical equipment. Follow the instructionsprovided
by the medical facility for the use of mobile phones.
-Using the phone in an airplane isprohibited, and is
punishable by law. However, to enable use inside an
airplane such asusing a non-emission setting, follow
the instructionsof the airplane before using.
•Makesure to hold thisproduct at a safe distance from
your ear when youtalk with the speaker on, or when
the ring tone sounds. Also, when youplay gamesor
music with an earphone / microphone etc. connected to
the product, adjust the volume properly.
• When viewing the display, maintain a proper distance
between your eyesand the screen in a bright place.
• Do not view the display for a long period continuously.
• There may be caseswhere the customer'sphysical
condition or predisposition leadsto itchiness, rashes, or
sores. If thisoccurs, immediately stop using this
product and see a doctor.
For materialsof each part, refer to "Material list" (P.6).
• Operationsof thisproduct for a long period repeatedly
may cause pain on your hand, arthralgia, backache,
stiff shoulders, etc.
•Ifyouhave a weak heart, take precautionswhen
setting the Vibrator or Ring volume.
•Please turn off the power near electronic equipment
that containshigh-precision mechanismsor handles
delicate signals.
The product may interfere with the operation of
sensitive electronic equipment. Electronic equipment to
watch out for includeshearing aids, implanted
pacemakers, ICDs, and other electronic medical
devices; fire alarms, automatic doors, and other
automatically controlled apparatus. Usersof implanted
pacemakers, ICDs, and other electronic medical
devicesare advised to ask their doctor, the
manufacturer of the equipment, or the shop of
purchase whether or not these devicescan be affected
by radio waves.
• If the display or camera lensisbroken, be careful with
broken glass and any exposed product parts. A
protective film isused for the display, and a plastic
panel isused for the camera lenssurfacesto avoid
glass scattering. However, touching broken or exposed
partsmay cause injury.
• If the display isbroken and the liquid crystal leaks, do
not touch it with your face, hands, etc.
• The display hasa protective film on itssurface. It helps
youensure safety even when the display getsdamaged
due to a fall or shock (shatterproof hardened glass). Do
not remove or scratch the protective film.
• Do not swing thisproduct by the strap or other parts.
• Do not use thisproduct outside when youhear thunder.
• The service of the emergency callsisnot supported for
all areas. Please only consider thisproduct isone way
to make emergency calls, such ascalling the
ambulance.
• Do not place water or other liquid, metal items, easily
burnable objects, etc., around the SIM card tray or
microSD card slot.
• Do not paint or put labels/ stickerson thisproduct.

4
Precautions for children and pets
• Keep the devicesout of children'sor pets' reach.
Children or petsmay try to swallow them, etc., or suffer
injury.
• Keep your petsaway from the battery pack asthey may
accidentally bite it.
• If a child isto use thisproduct, instruct him / her on how
to use it. Check if he / she alwaysusesthisproduct
correctly asyouinstruct.
Precautions for charging
•Payspecial attention when youuse thisproduct
connected to the AC charger for a long period.
If youuse for a long time while charging, the
temperature of the product, battery pack, or AC charger
may rise.
If youtouch the warm part of these devicesfor a long
period of time, it may cause redness, itch, skin
irritation, or low temperature burnsdepending on your
constitution or physical condition.
• Do not use the AC charger if the microUSB cable is
damaged.
• Do not use the AC charger in humid locationssuch as
a bathroom.
• Do not touch the AC charger when yousee lightning or
hear thunder.
• Do not use the AC charger outside.
• Do not short-circuit the charging terminalswhen the AC
charger isplugged into the power outlet. Also, do not
let the charging terminalscontact with your body (hand,
fingers, etc.).
• Do not put heavy objectson the microUSB cable of the
AC charger.
• When plugging / unplugging the AC charger into / from
the power outlet, make sure that no metallic strapsor
other metallic objectsare caught between the plug and
the socket.
• When plugging the AC charger into the power outlet,
make sure to insert it firmly.
•Use the specified voltage and current.
AC charger: AC 100 V to 240 V (household AC outlet
only)
• Wipe off any dust on the plug.
•Alwaysgrasp the AC charger when unplugging the plug
from the power outlet. Do not pull the microUSB cable
itself.
• If water or other liquid getsinto the AC charger,
immediately unplug it from the power outlet.
• Unplug the AC charger from the power outlet when the
AC charger will be left unused for a long period.
• Unplug the AC charger from the power outlet before
cleaning it.
• The ambient temperature of the room should be 5°C to
35°C.
Precautions for the battery pack
• Check the orientation of the battery pack before
attaching. If youhave difficulty attaching to thisproduct,
do not put excessive pressure on the battery pack.
• Do not place metal itemssuch aswiresin contact with
the charging terminals. Also, do not carry or store the
battery pack with metal itemssuch asa necklace.
• Do not throw the battery pack into fire.
• Do not puncture the battery pack, hit it with a hammer
or step on it.
• Do not use or charge the battery pack if wet.
•Neveruse the battery pack if something abnormal such
asdeformation or damaged hasoccurred.
• If the battery pack leaksor emitsan unusual odor, stop
using it immediately and move it away from any flame
or fire.
• If the battery pack leaks, do not touch any leaked
battery fluid etc., with your face, hands, etc.
Failure to observe thisprecaution may cause loss of
eyesight or damage to your skin. If the battery fluid etc.
getsinto your eyesor mouth, or it adheresto your skin
or clothing, immediately rinse with clean water. In this
case of contact with your eyesor mouth, see a doctor
immediately after rinsing.
Precautions for the SIM card
• Be careful with sharp edgeswhen removing the SIM
card.
Precautions for using near electric
medical devices
•Ifyouare wearing electronic medical devices, ask your
doctor whether the devicescan be affected by radio
wavesbefore using.
• Take care of the following inside hospitals.
- Do not take thisproduct into the operating room,
intensive care unit (ICU), or coronary care unit
(CCU).
-Turn off the power even in hospital lobbies, waiting
roomsand corridorsif electronic medical devices
may be in use near you.
-Foruse inside medical institutions, please follow the
instructionsgiven at individual locations.
• A person with an implanted pacemaker or ICD should
use or carry thisproduct at a distance more than 22 cm
from the site of implantation. Radio wavesemitted by
thisproduct may adversely affect implanted
pacemakersand ICDswhen using in close proximity.

5
Precautions for driving
• Before using in a vehicle, ask the manufacturer or sales
agent whether the operation of the vehicle can be
affected by radio waves. In some typesof vehicle, using
thisproduct may interfere with the operation of the
vehicle'selectronic equipment. In thiscase, stop using
thisproduct immediately.
•Becareful when using thisproduct while driving. A fine
may be imposed for holding a mobile phone while
driving. However, exceptionsare made in case of
emergency, such asto safeguard injured personsor to
maintain public safety.
•Please check the law and regulationsof the area for
using a mobile phone, and follow them.
•Please do not place thisproduct near the air bag of a
car. When the air bag operates, it may be injured by
thisproduct.
Disposing the battery pack
• Do not dispose of used battery packswith ordinary
garbage. Check local regulationsby contacting your
local city office or your household waste disposal
service for disposing.

6
■Material list
Part Material / Surface treatment
Outer case Display surface Nylon resin / UV coating
PC resin / UV coating
Acrylic resin / UV coating
Battery side Nylon resin / UV coating
PPE Polyphenyleneether (black sheet under back cover)
Camera lens Acrylic resin / UV coating
Display Glass
Anti-splinter film PET resin
Key Power switch PC / UV coating
Volume keys PC / UV coating
Side frame Aluminum / Alumite painting
Back cover Outer side PC resin / UV coating
Water stop Silicone / Silicon coating
Cap (microUSB
connector)
Outer side PC resin / UV coating
Water stop Silicone / Silicon coating
microUSB connector Stainless alloy
Machine screw Stainless alloy
Battery pack recess Recess surface Side: Nylon resin
Bottom: Polyester film (Label)
: Stainless alloy (Metal Part)
: Epoxy resin (Substrate)
SIM slot tray POM resin
Battery terminal Terminal connector LCP resin
Terminals Gold plating
Battery pack
(terminal)
Battery pack Resin: PC resin
Label: PET resin
Terminals Gold plating

7
Handling Precautions
• While thisproduct isdesigned to be waterproof, do not
allow water to seep into thisproduct. Also, do not allow
accessoriesand optional equipment to get wet.
The battery pack, AC charger, SIM card, microSD card,
and other supplied optionsare not waterproof. Do not
use them in a humid place such asa bathroom or in the
rain. If youcarry thisproduct close to your body,
perspiration may corrode the internal partsof this
product and cause malfunction. Note that if trouble is
diagnosed asexposure to water or other liquid, repair
of thisproduct may not be covered by the warranty or
repair may not be possible. Repair, when possible, is
not covered by the warranty and iscarried out at cost.
• Wipe with a soft, dry cloth (such asan eyeglass
cleaning cloth).
-Rubbing the display of thisproduct with a dry cloth
may scratch the display surface.
- The display surface may be stained if moisture or dirt
isleft on it for a long period.
-Neveruse chemicalssuch asalcohol, thinners,
benzen, or detergents, asthese agentsmay erase
the printing on thisproduct or cause discoloration.
• Occasionally clean the connection terminalswith a dry
cotton swab, etc.
- Soiled connectorsmay result in poor connections,
loss of power, or incomplete charging. Wipe with a
dry cloth or cotton swab.
• Do not place thisproduct near an air conditioning vent.
Condensation may form due to rapid changesin
temperature, and thismay cause internal corrosion and
malfunction.
• Do not put excessive pressure on thisproduct or
battery pack.
- Do not put thisproduct in a bag filled with many
objectsor sit down with it in a hip pocket.
-Excessive pressure may result in malfunction or
damage to the display, internal circuit or the battery
pack, etc. Also, if an external device isconnected to
the external connector terminal (earphone /
microphone terminal), excessive pressure may result
in malfunction or damage to the connector.
• Do not scratch the display with metallic objects.
Handling the product
• Do not use forcefully push or use a pointed object
(nails, ball pointed pen, pin, etc.) on the touch panel.
• Reception may be affected if youuse thisproduct near
a land-line phone, television, or radio in use. Use this
product away from such devices.
•Ensure thisproduct doesnot come near a fire such as
a stove, or fall from a tabletop (the product may slide
when it vibrates).
• When connecting an external device to the microUSB
connector (earphone / microphone terminal), do not
insert at an angle to connect or pull the cord.
•Itisnormal for thisproduct to become warm while
being used or charged. Thisisnot a malfunction.
• Do not leave the camera exposed to direct sunlight.
Doing so may discolor or burn itscomponents.
• Keep the microUSB connector cap closed when not in
use.
• Do not use thisproduct with the back cover removed.
Doing so may cause the battery pack to fall out, or
cause malfunction or damage.
• Do not insert hard, sharp objectsinto the earpiece,
mouthpiece, speaker, or sub-microphone.
• Do not remove the microSD card or turn off the power
while in use. Doing so may cause data loss or
malfunction.
• Do not let magnetic cards, etc. come close to this
product or itsparts. The magnetic data in cash cards,
credit cards, prepaid cards, floppy disks, etc. may be
erased.
• Do not let strong magnetic objectscome close to this
product or itsparts. Strong magnetism may cause a
malfunction.
• Keep a separate record of the information youhave
registered for thisproduct.
- NEC de México, S.A. de C.V. bearsno obligation or
responsibility in the event that data isaltered or lost.
Handling the battery pack
• The battery pack isreplaceable.
Battery life variesdepending on usage conditions, etc.,
but it istime to change the battery charger when the
usage time hasbecome extremely short, even when it
hasbeen fully charged. In thiscase, purchase a new
battery pack.
• Depending on the usage condition, the battery pack
may expand slightly when the battery life isalmost over.
Thisisnot a malfunction.
• Do not store the battery pack in the following cases.
- The battery isfully charged (immediately after the
charging iscomplete).
- The battery hasrun out (the phone cannot power on).
The performance and life of the battery pack may
deteriorate.
It isrecommended that youstore the battery pack with
around 40% of a full charge.

8
Handling the AC charger
• Do not charge the battery pack at the following places.
-Ahumid, dusty or unstable place
- Near a land-line phone, TV, or radio
• Do not expose the AC charger to strong shocks. Do not
deform the charging terminal.
•Ifyouuse an electrical outlet with an unplugging-
protection mechanism, follow the instructionsof the
manual for the outlet.
• Do not use a car DC adapter to charge the battery pack
when the car engine isnot running.
Handling the SIM card
• Do not apply excessive force to the SIM card when
attaching / removing it.
• Note that the warranty doesnot cover damage caused
by inserting the SIM card into another type of the IC
card reader or writer.
•Alwayskeep the IC part clean.
• Wipe with a soft, dry cloth (such asan eyeglass
cleaning cloth) for cleaning.
• Keep a separate record of the information youhave
registered in your SIM card.
- NEC de México, S.A. de C.V. bearsno obligation or
responsibility in the event that data isaltered or lost.
• Do not damage, scratch, unnecessarily touch, or short-
circuit the IC part.
• Do not drop the SIM card or expose it to strong shocks.
• Do not bend the SIM card or place a heavy object on it.
• Do not put a label or sticker on the SIM card when
attaching it to thisproduct.
Statements of
Compliance
COFETEL
"The operation of thisproduct isthe subject to the
following conditions:
(1) Thisproduct may not cause harmful interference, and
(2) Thisproduct must accept any interference, including
interference that may cause the undesired operation."

9
Table of Contents
Precautions ...................................................................3
Precautionsfor thisproduct ......................................3
Precautionsfor children and pets.............................4
Precautionsfor charging ...........................................4
Precautionsfor the battery pack ...............................4
Precautionsfor the SIM card ....................................4
Precautionsfor using near electric medical devices
..................................................................................4
Precautionsfor driving ..............................................5
Disposing the battery pack........................................5
Handling Precautions...................................................7
Handling the product.................................................7
Handling the battery pack .........................................7
Handling the AC charger...........................................8
Handling the SIM card ..............................................8
Statements of Compliance...........................................8
COFETEL .................................................................8
About This Manual......................................................11
Notes............................................................................11
Bluetooth®Function....................................................12
Wireless LAN...............................................................12
Waterproof / Dustproof Function ..............................13
Thingsto keep in mind............................................13
Important notices....................................................14
Draining water when the product getswet..............15
When charging the battery pack .............................15
Getting Started .......................................16
Parts Names ................................................................16
Removing / Attaching the Back Cover......................16
Inserting the SIM Card................................................17
Inserting the microSD Card .......................................17
Attaching the Battery Pack ........................................18
Opening / Closing the microUSB Connector Cap ...18
Charging the Battery ..................................................19
Charging with the PC connection............................19
Basic Operation ..........................................................19
Using the front keys................................................19
Using the touch panel .............................................19
Turning Power On and Off .........................................20
Turning power on ....................................................20
Turning power off ....................................................20
Initial Settings .............................................................21
Access Point Settings ................................................21
Adding an access point...........................................21
Initializing an access point ......................................21
Wi-Fi Settings..............................................................22
Connecting with Wi-Fi easy settings.......................22
Adding a Wi-Fi network manually ...........................22
Disconnecting a connected Wi-Fi network..............22
Optional settingsfor Wi-Fi.......................................22
Setting an Email Account ..........................................23
Setting a Google or other account ..........................23
Idle Screen...................................................................23
Adding an application shortcut................................23
Creating an application folder .................................24
Setting the wallpaper ..............................................24
Status Bar....................................................................24
Status icons............................................................24
Notification icons.....................................................25
Applications List Screen............................................25
Applicationslist ....................................................... 26
Widgetslist .............................................................27
Task Manager..............................................................27
Text Entry ....................................................................28
Calling ..................................................... 29
Making a Call...............................................................29
Operationsduring a call..........................................29
Making an international call ....................................29
Receiving a Call ..........................................................30
Call forwarding........................................................30
Voicemail ................................................................30
Using the earphone cable (hands-free phone) .......30
Call Log .......................................................................31
Contacts (Phonebook) ...............................................31
Creating a contact...................................................31
Displaying the profile screen................................... 32
Favorites......................................................................32
Email / Browser ...................................... 33
Email ............................................................................33
Displaying email......................................................33
Creating and sending email ....................................33
Opening mailboxes.................................................33
Changing email settings.........................................33
Gmail............................................................................34
Displaying Gmail.....................................................34
Creating and sending Gmail ...................................34
Managing message threads...................................34
Changing Gmail settings.........................................34
Messaging (SMS / MMS) ............................................35
Creating and sending Message ..............................35
Displaying sent / received Message .......................35
Displaying the Message conversation ....................35
Displaying the folder list..........................................35
Moving Message.....................................................35
Deleting Message ...................................................35
Changing Message settings...................................35
Google Talk .................................................................36
Browser .......................................................................36
Using bookmarks....................................................37
Changing browser settings.....................................37
Android Market ....................................... 38
Installing Applications ...............................................38
Deleting applications...............................................38
Changing Android Market settings..........................38

10
GPS..........................................................39
Enabling the Location Service ..................................39
Google Maps ...............................................................40
Looking up directions..............................................40
Navigation ...................................................................41
Places ..........................................................................41
Latitude ........................................................................42
Multimedia...............................................43
Camera.........................................................................43
Shooting photos......................................................43
Shooting videos......................................................43
Gallery..........................................................................44
Music Player................................................................44
Using playlist...........................................................45
Clock / Calendar .....................................46
Clock ............................................................................46
Setting the alarm.....................................................46
Calendar ......................................................................46
Creating a schedule ................................................46
Changing calendar settings....................................46
Settings ...................................................47
Setting List ..................................................................47
Wireless & networks...............................................47
Call settings............................................................47
Ringtonesand sounds............................................48
Display ....................................................................48
eco mode ................................................................48
Location & security..................................................48
Applications.............................................................49
Accounts& sync .....................................................49
Privacy ....................................................................49
Storage ...................................................................49
Language & keyboard.............................................49
Voice input & output................................................50
Accessibility ............................................................50
Date & time .............................................................50
About phone............................................................50
Wizard.....................................................................50
Mobile Networks .........................................................51
Bluetooth .....................................................................51
Connecting to a Bluetooth device ...........................52
Connecting to a VPN ..................................................52
Adding a VPN .........................................................52
Connecting to a VPN ..............................................52
Security Code..............................................................53
PIN1 code / PIN2 code ...........................................53
Enabling the SIM'sPIN ...........................................53
PIN unblocking key (PUK) ......................................53
File Management ....................................54
Bluetooth Communication .........................................54
Sending...................................................................54
Receiving ................................................................54
Connecting a PC.........................................................54
Appendix................................................. 55
Troubleshooting .........................................................55
Error message ........................................................57
Warranty and After-Sales Service.............................57
Warranty .................................................................57
After-salesservice .................................................. 57
Precautions .................................................................58
Memory dial (Contacts) and downloaded data .......58
Updating Software......................................................59
Before updating software........................................59
Updating immediately .............................................59
Confirming update ..................................................60
Automatically Software Update (Auto update)........60
Specifications .............................................................61
Radio Frequency (RF) Signals ..................................63
FCC Regulations.........................................................64
Declaration of Conformity .........................................65
Intellectual Property Right.........................................65
Copyright and portrait rights...................................65
Trademarks.............................................................65
Others.....................................................................66
Notational conventionsfor Windows.......................66
GPL / LGPL - applicable software ..........................66

11
About This Manual
• Some of contentsof thismanual are not supported in
all countries/ regionsor by all networksand / or
service providersin all areas.
Contact your network operator or service provider for
any specific service or feature and to determine
whether additional access or usage feesapply.
•Inthismanual, operationsare simplified asfollows.
•Display examplesused in thismanual are for
explanation only and may be different from the actual
display.
•Thismanual assumesthe settingsare the same as
they were when youpurchased the product, Therefore
the viewsand operationsmay differ if youhave
changed the settings.
• The reproduction or reprinting of all or part of this
manual without prior permission isprohibited.
• The contentsof thismanual are subject to change
without notice.
Notes
• Google applicationsand service content may change
without notice.
• Setting the phone to silencesthe ringtone and
notification sounds. However, sound from video
playback, music, etc., isunaffected and will continue to
be heard.
•Youcan update the software (P.59).
• Updatesfor product quality improvement and operating
system (OS) upgradesmay be applied. Such updates
or upgradesmay cause applicationsyouare using to
be unusable or have unexpected errors.
• When the memory capacity of a microSD card or the
product become nearly full, applicationsmay not
function correctly. If thishappens, delete some of the
saved data.
•Forsecurity, set a screen lock password (P.48).
• Refer to the Google Inc. termsof usage regarding
servicesthat Google provides. Also refer to the
respective termsof usage for other web services.
•Ifthisproduct islost, change your password for each
account via a PC to prevent other personsfrom using
your account with Google servicessuch asGoogle
Talk, Gmail, Android Market, etc.
Description Operation
From the Idle screen, tap
`"Settings" `
"Wireless & networks".
From the Idle screen, tap
, then "Settings",
then "Wireless &
networks".

12
Bluetooth®Function
• This product supports a security function
compliant with Bluetooth standards, but the
security may not be sufficient, depending on the
setting.
Concern about communication using the Bluetooth
function.
• NEC de México, S.A. de C.V. is not responsible for
data leak when making data communications using
Bluetooth.
• You can use a headset, handsfree, audio, object
push, serial port, and phonebook access on the
product. The audio / video remote control may be
available for audio. (Only on Bluetooth compatible
devices.)
• Bluetooth cautions
The operating frequency band of this product is
used by industrial, scientific, consumer and
medical equipment including microwave ovens,
premises radio stations for identifying mobile units
used in manufacturing (radio stations requiring a
licence), specified low power radio stations (radio
stations requiring no licence) and amateur radio
stations. (Hereinafter, any of the above stations is
referred to as "another station").
1 Before using Bluetooth with thisproduct, confirm that
"another station" isnot being operated nearby.
2 In the event that thisproduct iscausing radio
interference with "another station", immediately
change the operating frequency or stop radio wave
emission by turning off the power, etc.
3 If youhave further questions, contact General
Inquirieson the last page of thismanual.
Wireless LAN
• A wireless LAN (Wi-Fi) uses radio waves for
transmission, and thereby has the benefit of
allowing a LAN connection anywhere in an area
reachable by those radio waves. Conversely,
eavesdropping by a third party or wrongful
intrusion are possible if security settings are not
configured. You are advised to use discretion and
configure security settings before using.
• Wireless LAN
Do not use wireless LAN near magnetic devicessuch as
electrical appliancesor AV / OA devices, or in radio
waves.
- Magnetism or radio wavesmay increase noisesor
disable communications(especially when using a
microwave oven).
- When used near TV, radio, etc., reception
interference may occur, or sound and imageson the
TV screen may be disturbed.
- If there are multiple wireless LAN access points
nearby and the same channel isused, search may
not work correctly.
• Available channelsvary depending on the country /
region.
•Foruse in an aircraft, contact the airline beforehand.
•Foruse of Wi-Fi in another country / region , there may
be limitationson the locationswhere youcan use it.
Before using Wi-Fi in another country / region, confirm
the locally available frequencies, laws, regulations, and
other conditionsfor the use of Wi-Fi.

13
• 2.4 GHz device cautions
The operating frequency band of thisWi-Fi device is
used by home electrical appliancessuch asmicrowave
ovens, aswell asindustrial, scientific and medical
equipment including private radio stationson factory
premisesfor identifying mobile unitsused in
manufacturing lines(radio stationsrequiring a licence),
specified low power radio stations(radio stations
requiring no licence), and amateur radio stations(radio
stationsrequiring a licence).
1 Before using the device, confirm that private radio
stationsfor identifying mobile units, specified low
power radio stationsand amateur radio stationsare
not being operated nearby.
2 If the device causesharmful radio interference to
private radio stationsfor identifying mobile units,
immediately change the frequency band or stop use,
and contact a Call Center on the Warranty Guide.
3 If the device causesradio interference to low power
radio stationsor amateur radio stations, contact a
Call Center on the Warranty Guide.
Waterproof / Dustproof
Function
Thisproduct iswaterproof to IPX5 / IPX7 and dustproof
to IP5X standardsif the microUSB connector cap is
closed aswell asthe back cover issecurely attached.
- IPX5: meansthat thisproduct continuesto function as
a phone after being sprayed from all directionswith
12.5 litersof water per minute from a 6.3 mm diameter
nozzle for at least 3 minutes, from a distance of approx.
3 meters.
- IPX7: The product retainsphone functionality after
slowly immersing in still, room-temperature tap water to
a depth of 1 meter and leaving it there for 30 minutes
before bringing it out of the water.
- IP5X: The product can be operated and the safety can
be kept after keeping the product inside of the
equipment including dust with a diameter of less than
75µm for 8 hours.
•Youcan talk without an umbrella in the rain (approx.
20 mm of rain in an hour).
• Do not attach / remove the back cover or do not open /
close the microUSB connector cap when your hands
are wet or when thisproduct haswater dropson it.
•Youcan rinse the product by immersing and slowly
moving in tap water of room temperature filled in a
bowl, or rinse it with handsunder light running water
from the faucet.
-Rinse the product with the back cover securely
attached while covering the external connector
terminal cap to prevent it from opening.
- Do not use a brush, sponge, soap, or detergent for
washing.
- Do not apply running water directly to the mouthpiece
or earpiece / speaker.
- Do not immerse or drop in pool water or sea water.
Things to keep in mind
• Before use, ensure that yousecurely close the
microUSB connector cap and back cover so that they
are completely attached. If any fine dirt (fine fibers,
hairs, or sands) isbetween the cap / cover and the
product, water could enter the inside of the product.
• Do not use the product (operate keys, etc.) under
water.
• Do not spray or immerse the product in liquidsother
than water of room temperature, such assoap /
detergent / bath powder, sea water, pool, hot spring,
sand / mud.

14
Important notices
• If the product getswet with the microUSB connector
cap or the back cover open, the liquid may get inside
the product causing electric shock or malfunction. Stop
using the product, turn the power off, remove the
battery pack and contact a Call Center on the Warranty
Guide.
• The microUSB connector cap and the rubber packing
of the back cover play an important role in maintaining
waterproof / dustproof function. Do not remove or
scratch them. Also, prevent dust from adhering to them.
If the microUSB connector cap and the rubber packing
of the back cover isdamaged or deformed, contact a
Call Center on the Warranty Guide.
• Do not insert sharp objectsthrough the gap of the
microUSB connector cap or back cover. Doing so may
damage the rubber packing and allow water to seep in.
• If the back cover isdamaged, replace it. Water may
seep into the inside of the product through a damaged
section causing electric shock, corrosion of the battery
pack, or other malfunctions.
• Do not leave the product with water drops.
• To prevent condensation, do not bring the product from
a cold place to a warm place, etc., without letting the
product get back to room temperature.
• Do not apply water flow stronger than allowed (e.g.,
such water flow that givesyoupain when applied to
your skin directly from a faucet or shower head). Doing
so may cause malfunction though the product is
waterproof to IPX5 standard.
• Do not wash the product in a washing machine, etc.
• Accessoriesand optionsare not waterproof.
•Donotput the product in hot water, use it in a sauna or
apply hot air flow to it.
• Do not leave the product on the sand at a beach.
Sand might enter the mouthpiece or earpiece / speaker
and result in smaller sound.
•Using the product with water or sand still in it may result
in unclear sound.
• Water may enter by the microUSB connector cap or
back cover even if only a tiny amount of sand lodgesin
them.
• Do not poke the mouthpiece or earpiece / speaker with
cotton swabsor sharp objects. The waterproof /
dustproof protection may deteriorate.
•Thisproduct doesnot float on water.
• Do not drop the product. Scratchesmay lead to
lowered waterproof / dustproof capability.
• Do not leave water on the mouthpiece or earpiece /
speaker. If water adheresto the product, the volume
during a call or ringtone may be decreased or sound
quality may deteriorate. In such a case, drain the water
to recover the function.
• NEC de México, S.A. de C.V. doesnot guarantee all
operationsunder actual use conditions. Malfunctions
deemed to be caused by inappropriate operation by the
customer are not covered by the warranty.
• Even if the back cover issecurely attached, removing
the sealing shown may result in a loss of waterproof /
dustproof capability. Do not remove the sealing.

15
Draining water when the product
gets wet
If water adheresto the mouthpiece or earpiece / speaker,
the volume or sound quality may deteriorate. In such a
case, drain the water following the stepsbelow and dry
the product in open air.
1Wipe the surface with a clean dry cloth.
2Securely hold the product and shake it
approximately 20 times until no more water
comes out.
Draining from mouthpiece or earpiece / speaker
3Softly press a clean dry cloth to wipe off water
remaining in the mouthpiece or earpiece /
speaker.
Do not use a cotton swab, etc., to poke into any of the
recesses.
4Thoroughly wipe off the product with a clean dry
cloth.
Any water remaining in the product may leak out after
wiping off.
When charging the battery pack
Accessoriesand optionsare not waterproof / dustproof.
Check the following before and after charging.
•Makesure that the product isnot wet before connecting
the microUSB cable.
• When the microUSB connector cap isopened for
charging, close the cap securely after charging.
• Do not touch the AC charger with wet hands.
•Use the AC charger in a place not exposed to water. Do
not use it in a bathroom, shower room, kitchen,
washroom or other placessubject to water.

16
Getting Started
Parts Names
1Power switch
2microUSB connector
3Proximity / Illuminance
sensor
* The display may be dark
during callsif thissensor is
covered. Do not put labelsor
stickerson the sensor.
4Notification LED
5Earpiece (receiver)
6Display (Touch panel)
7Mouthpiece /
microphone
8Front keys
(menu) key
(home) key
(back) key
(search) key
9Speaker
10 Camera
11 Light
12 + / - (volume) keys
13 Sub-microphone
14 microSD card slot
15 Antenna sensor
* For the best performance,
do not cover these areasby
your finger, etc. when using
thisproduct.
16 Back cover
17 SIM slot
18 Strap slot
Removing / Attaching
the Back Cover
To remove the back cover, hook your finger in the slot
and remove in the direction shown, without too much
force.
To attach the back cover, insert the tabson top of the
back cover into the slots, slide it in the direction shown,
and push it down securely in the direction shown.
Securely push the areasillustrated by the dotsand make
sure that there isno space between the back cover and
thisproduct.
Notes
• When removing the back cover, make sure that you remove
water and wipe moisture off this product.
• When attaching the back cover, make sure that no dust or dirt
adheres to the back cover (especially to the rubber packing).
• Water might enter the inside of this product unless you attach
the back cover securely.
• When attaching the back cover, make sure that the SIM card,
the microSD card, and the battery pack are attached
securely. If the SIM card or microSD card is not securely
inserted, the battery pack will sit on the SIM or microSD card
and create a gap between this product and the back cover
when attaching the back cover. The waterproof functionality
of the product might be lost as a result.
12
345 6
87
10
91112 13
15 16 1714
18

17
Getting Started
Inserting the SIM Card
The SIM card isan IC card that storesyour phone
numbersand other information. Some functionsare not
available if the SIM card isnot inserted.
1Hold the tab to slide the tray.
2Place the SIM card on the tray with the IC surface
(gold-colored) facing up and seating correctly.
3Slide the tray to the end.
Inserting the microSD
Card
Insert the microSD card with the microSD logo side
up into the microSD card slot until it is locked.
To remove the microSD card, push it asshown.

18
Getting Started
Attaching the Battery
Pack
Insert in the direction by hooking the tabs on the
battery pack in the slots.
Opening / Closing the
microUSB Connector
Cap
To open the microUSB connector cap, hook your finger in
the slot and open the cap in the direction of the arrow.
To close the microUSB connector cap, insert the tab on
the back of the cap in direction (1), and then close the
cap by pressing securely in direction (2).
2
1

19
Getting Started
Charging the Battery
1Open the microUSB connector cap.
2Connect the microUSB plug with the supplied
microUSB cable engraved side facing down with
the microUSB connector.
3Connect the USB plug of the cable with the
supplied AC charger.
4Insert the AC charger plug into the power outlet.
■About the notification LED
Notification LED turnsred while charging.
Notification LED turnsgreen when the battery level is
over 90%, and off when charging iscomplete.
When charging starts, such aswhen the battery is
depleted, the notification LED may not immediately light.
However, charging hasstarted.
Note
• When connecting to the microUSB connector of this product,
hold the microUSB plug straight against the connector without
tilting it vertically or horizontally and insert it gently.
Charging with the PC connection
1Open the microUSB connector cap.
2Connect the microUSB plug with the supplied
microUSB cable with engraved side facing down.
3Connect the USB plug of the cable to your PC.
Basic Operation
Using the front keys
• displaysthe menuavailable for the current
screen.
• displaysthe Idle screen.
• goesback to the previous screen.
• opens"Google Search" when pressing on the
Idle screen.
Using the touch panel
■Tap
With touching and releasing your finger, the item is
selected or run.
■Touch and hold
In some screens, continuing to touch the touch panel
displaysa menu.
■Slide
With sliding your finger, the screen scrollsup / down / left
/ right in direction.
■Drag
Quickly slide your finger while touching an item (icon,
etc.) to move.
1
2
3
4
1
2
3

20
Getting Started
■Flick
With quickly sliding and releasing your finger, the screen
quickly scrollsin direction.
■Pinch with two fingers
To zoom in or zoom out, touch the touch panel with two
fingers, and then slide them apart or together.
Turning Power On and
Off
Turning power on
Press and hold the power switch for two seconds or
longer.
When the power isturned on for the first time, tap
"Aceptar". The language selecting screen appears. After
tapping the language, tap "Next" twice. The "Get started
!!!" screen appears.
•"Basic": Basic instruction screensappears. When
these instruction screensare finished, the "Get started
!!!" screen appearsagain.
• "Applications": The instruction screensfor operating an
application appear. Tap an application to see that
instruction. When these instruction screensare
finished, the "Get started!!!" screen appearsagain.
•"Setting
s": See "Initial Settings".
To skip these screens, tap "Exit". Youcan start from the
language selecting screen again. Tap `"Settings"
`"Wizard".
Turning power off
1Press and hold the power switch for one second
or longer.
2Tap "Power off".
3Tap "OK".
■Sleep mode
When thisproduct isnot operated for a specified duration
of time, the display turnsoff and thisproduct enterssleep
mode automatically. To enter sleep mode manually, press
the power switch.
Pressing the power switch quitssleep mode.
For automatically turning on sleep mode, set "Screen
timeout" (P.48).
■Screen lock
When youturn the power on or quit sleep mode, the
touch panel islocked. Drag to to unlock the
screen.
