NEC Univerge SV8100 User guide

NECIC-AP-001
Issue 2.0
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

Nothing contained in this manual shall be deemed to be, and this manual does not constitute, a
warranty of, or representation with respect to, any of the equipment covered. This manual is
subject to change without notice and NEC Infrontia has no obligation to provide any updates or
corrections to this manual. Further, NEC Infrontia also reserves the right, without prior notice, to
make changes in equipment design or components as it deems appropriate. No representation is
made that this manual is complete or accurate in all respects and NEC Infrontia shall not be
liable for any errors or omissions. In no event shall NEC Infrontia be liable for any incidental or
consequential damages in connection with the use of this manual. This document contains
proprietary information that is protected by copyright. All rights are reserved. No part of this
document may be photocopied or reproduced without prior written consent of NEC Infrontia.
©2008 by NEC Infrontia Corporation All Rights Reserved.
PrintedinJapan
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
Regulatory
Chapter 1; Introduction to SV8100
SECTION 1GENERAL INFORMATION.........................................................................1-1
SECTION 2EQUIPMENT LIST.....................................................................................1-5
Chapter 2; SV8100 System Specifications
SECTION 1GENERAL INFORMATION.........................................................................2-1
SECTION 2SYSTEM BLOCK DIAGRAM .....................................................................2-1
SECTION 3MAXIMUM SYSTEM CAPACITIES.............................................................2-5
3.1 SYSTEM CONFIGULATION -SV8100..................................................................2-6
SECTION 4POWER-BASED CALCULATOR CHART...........................................2-11
SECTION 5SYSTEM REQUIREMENT AND SPECIFICATION .................................2-14
5.1 CABLING........................................................................................................2-14
5.2 POWER REQUIREMENTS.................................................................................2-17
5.2.1 POWER SUPPLY SPECIFICATION ..........................................................2-17
5.2.2 POWER SUPPLY CONSUMPTION ...........................................................2-18
5.3 ENVIRONMENTAL CONDITIONS ........................................................................2-18
5.3.1 TEMPERATURE AND HUMIDITY .............................................................2-18
5.4 OUTSIDE LINE TYPE .......................................................................................2-19
5.5 TRANSMISSION,NETWORK AND CONTROL SPECIFICATIONS..............................2-20
5.5.1 TRANSMISSION ..................................................................................2-20
5.5.2 NETWORK ..........................................................................................2-20
5.5.3 CONTROL ..........................................................................................2-20
5.6 DIALING SPECIFICATIONS................................................................................2-21
5.6.1 DIAL PULSE ADDRESS SIGNALING ........................................................2-21
5.6.2 DUAL TONE MULTIFREQUENCY(DTMF)ADDRESS SIGNALING ................2-21
5.6.3 EXTERNAL EQUIPMENT CONNECTION ...................................................2-22
5.6.4 MUSIC SOURCE FOR MUSIC ON HOLD VIA CHASSIS ...............................2-22
5.6.5 MUSIC SOURCE FOR STATION BACKGROUND MUSIC VIAACI..................2-22
5.6.6 EXTERNAL PAGING (AUDIO) .................................................................2-22
5.6.7 EXTERNAL TONE RINGER/NIGHT CHIME OUTPUT ..................................2-22
5.6.8 SMDR................................................................................................2-22
5.6.9 PC CONNECTION ................................................................................2-22
5.6.10 RELAY CONNECTION............................................................................2-22
5.7 BATTERY BACKUP ..........................................................................................2-23
5.7.1 SYSTEM BACKUP(OPTIONAL)...............................................................2-23
5.7.2 MEMORY BACKUP................................................................................2-23
5.8 WEIGHTAND DIMENSIONS ..............................................................................2-24
System Hardware Manual
I
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
Chapter 3; Installing the SV8100 Chassis
SECTION 1GENERAL INFORMATION..................................................................3-1
SECTION 2INSTALLING THE CHASSIS...............................................................3-1
2.1 WALL MOUNT THE 19” CHASSIS........................................................................3-2
2.1.1 CHS2U CHASSIS WALL MOUNT INSTALLATION........................................3-3
2.2 FLOOR MOUNTING THE 19” CHASSIS...............................................................3-10
2.2.1 CHS2U CHASSIS INFORMATION...........................................................3-10
2.2.2 MULTIPLE CHS2U CHASSIS INSTALLATION ...........................................3-12
2.3 STAND MOUNTING THE 19” CHASSIS...............................................................3-14
2.3.1 CHS2U CHASSIS INFORMATION...........................................................3-14
2.3.2 MULTIPLE CHS2U CHASSIS INSTALLATION ...........................................3-16
2.4 RACK MOUNTING THE 19” CHASSIS.................................................................3-19
2.5 INSTALLING THE 19” CHASSIS .........................................................................3-21
2.5.1 UNPACKING THE EQUIPMENT................................................................3-21
2.5.2 BEFORE INSTALLATION.........................................................................3-21
2.5.3 INSTALLING THE 19” CONTROLLING CHASSIS.........................................3-22
2.5.4 INSTALLING EXPANSION BLADE IN THE 19” CHASSIS (OPTIONAL)..........3-23
2.5.4.1 CONNECTOR PIN-OUT ON THE PZ-BS10/PZ-BS11....................3-24
2.5.4.2 INSTALL THE PZ-BS10 EXPANSION BASE BLADE IN THE CHS2U
CONTROLLING CHASSIS ..........................................................3-24
2.5.4.3 INSTALL THE PZ-BS11 EXPANSION BLADE IN THE CHS2U
EXPANSION CHASSIS................................................................3-27
2.5.4.4 CONNECT THE CONTROLLING AND EXPANSION CHASSIS .............3-31
2.5.5 INSTALLING 19” CHASSIS GROUNDING..................................................3-33
2.5.6 INSTALLING 19” CHASSIS GROUNDING ON MULTIPLE CHASSIS
(OPTIONAL).........................................................................................3-33
2.5.7 INSTALL AC POWER CORDS.................................................................3-34
2.5.8 INSTALL AC POWER CORDS ON MULTIPLE-CHASSIS (OPTIONAL)............3-35
2.5.9 INSTALL ADDITIONAL BLADES................................................................3-35
2.5.10 APPLY POWER TO THE 19” CHASSIS ...................................................3-35
SECTION 3BATTERY CONNECTION.................................................................3-36
3.1 INSTALLING THE INTERNAL BATTERIES .............................................................3-36
3.2 INSTALLING THE EXTERNAL BATTERIES............................................................3-42
3.2.1 FLOOR MOUNTING THE CHS LARGE BATT BOX ................................3-42
3.2.2 BATTERY INSTALLATION........................................................................3-44
3.2.3 CHS LARGE BATT BOXTO CHS2U CONNECTION.............................3-48
3.2.4 CHS LARGE BATT BOX FUSE REPLACEMENT ...................................3-51
SECTION 4REMOVE AND INSTALL COOLING FAN ............................................3-55
II
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
4.1 CHS2U CHASSIS...........................................................................................3-55
4.1.1 REMOVE COOLING FUN .......................................................................3-55
4.1.2 INSTALL COOLING FUN.........................................................................3-57
Chapter 4; Installing the SV8100 Blades
SECTION 1GENERAL INFORMATION..................................................................4-1
1.1 SLOT LOCATIONS .............................................................................................4-1
SECTION 2INSTALLATION.................................................................................4-3
2.1 INSTALLATION AND SAFETY PRECAUTIONS .........................................................4-3
2.2 INSTALLING AN EXTENSION OR TRUNK BLADE ....................................................4-4
2.2.1 INSTALLING THE BLADE..........................................................................4-4
2.2.2 ORDER OF INSTALLING EXTENSION BLADES ............................................4-4
2.2.3 ORDER OF INSTALLING TRUNK BLADES...................................................4-5
2.2.3.1 INSTALLING CD-4COTA, CD-4DIOPB, CD-4ODTB OR
CD-2BRIABLADES....................................................................4-5
2.2.3.2 INSTALLING CD-PRTA(T1/E1/PRI) BLADES................................4-5
2.3 REMOVE AN EXTENSION OR TRUNK BLADE........................................................4-6
2.4 UNINSTALLING A BLADE SLOT THROUGH SOFTWARE..........................................4-6
2.5 BLADE CAPACITIES...........................................................................................4-6
2.6 POWERING UP THE SV8100.............................................................................4-8
2.6.1 PERFORMING A COLD START ..................................................................4-8
2.6.2 PERFORMING A HOT START....................................................................4-9
2.6.3 RESETING THE SYSTEM .........................................................................4-9
2.6.3.1 INITIAL PROGRAMMING................................................................4-9
2.6.3.2 PORT DEFAULTS .......................................................................4-10
2.6.3.3 SETTING UP EXTENSION CIRCUIT TYPES....................................4-10
2.6.3.4 SAVING YOUR CONFIGURATION ................................................. 4-11
2.6.3.5 BACKING UP/RESTORING A DATABASE ....................................... 4-11
2.6.4 PERFORMING A SOFTWARE UPGRADE...................................................4-12
SECTION 3COMMON CONTROL BLADE...........................................................4-14
3.1 CD-CP00 (SV8100 CENTRAL PROCESSING UNIT)..........................................4-14
3.1.1 DESCRIPTION......................................................................................4-15
3.1.2 INSTALLATION......................................................................................4-17
3.1.3 SWITCH SETTINGS...............................................................................4-19
3.1.4 LED INDICATION..................................................................................4-20
3.1.5 CONNECTORS .....................................................................................4-22
3.2 PZ-ME50 (MEMORY EXPANSION DAUGHTER BOARD)......................................4-24
System Hardware Manual
II
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
3.2.1 DESCRIPTION......................................................................................4-24
3.2.2 INSTALLATION......................................................................................4-26
3.3 PZ-VM21 (VOICE MAIL DAUGHTER BOARD)....................................................4-27
3.3.1 DESCRIPTION......................................................................................4-27
3.3.2 INSTALLATION......................................................................................4-28
3.3.3 SWITCH SETTINGS...............................................................................4-29
3.4 PZ-32IPLA/PZ-64IPLA/PZ-128IPLA(VOICE OVER IP DAUGHTER BOARDS)...4-30
3.4.1 DESCRIPTION......................................................................................4-30
3.4.2 INSTALLATION......................................................................................4-31
3.4.3 SWITCH SETTINGS...............................................................................4-31
3.4.4 LED INDICATIONS................................................................................4-32
3.4.5 CONNECTORS .....................................................................................4-33
SECTION 4STATION BLADES..........................................................................4-35
4.1 CD-8DLCA/CD-16DLCA (DIGITAL STATION INTERFACE) ...............................4-35
4.1.1 DESCRIPTION......................................................................................4-36
4.1.2 INSTALLATION......................................................................................4-37
4.1.3 LED INDICATIONS................................................................................4-37
4.1.4 CONNECTORS .....................................................................................4-38
4.2 PZ-8DLCB (DIGITAL STATION DAUGHTER BOARD) .........................................4-40
4.2.1 DESCRIPTION......................................................................................4-40
4.2.2 INSTALLATION......................................................................................4-41
4.2.3 PZ-8DLCB DAUGHTER BOARD CABLE CONNECTION............................4-41
4.3 CD-4LCA/ CD-8LCA (4-PORT/8-PORT SINGLE LINE INTERFACE) ...................4-42
4.3.1 DESCRIPTION......................................................................................4-43
4.3.2 INSTALLATION......................................................................................4-44
4.3.3 LED INDICATIONS................................................................................4-45
4.3.4 CONNECTORS .....................................................................................4-46
4.4 PZ-4LCA/PZ-8LCE (4-PORT/8-PORT SLT DAUGHTER BOARDS)....................4-47
4.4.1 DESCRIPTION......................................................................................4-49
4.4.2 INSTALLATION......................................................................................4-50
4.4.3 CONNECTORS .....................................................................................4-51
4.5 CD-LTA (DTERM/SLT COMBINATION) ............................................................4-52
4.5.1 DESCRIPTION......................................................................................4-52
4.5.2 INSTALLATION......................................................................................4-53
4.5.3 LED INDICATIONS................................................................................4-54
4.5.4 CONNECTORS .....................................................................................4-55
SECTION 5TRUNK BLADES............................................................................4-56
IV
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
5.1 CD-4COTA (4 LOOP START INTERFACE)........................................................4-56
5.1.1 DESCRIPTION......................................................................................4-56
5.1.2 INSTALLATION......................................................................................4-58
5.1.3 LED INDICATIONS................................................................................4-58
5.1.4 CONNECTORS .....................................................................................4-59
5.2 PZ-4COTE (4 LOOP START INTERFACE DAUGHTER BOARD)...........................4-60
5.2.1 DESCRIPTION......................................................................................4-60
5.2.2 INSTALLATION......................................................................................4-62
5.2.3 CONNECTORS .....................................................................................4-62
5.3 CD-2BRIA (2 BASIC RATE INTERFACE) ..........................................................4-63
5.3.1 DESCRIPTION......................................................................................4-63
5.3.2 INSTALLATION......................................................................................4-64
5.3.3 LED INDICATIONS................................................................................4-65
5.3.4 CONNECTORS .....................................................................................4-66
5.4 PZ-2BRIA (2 BASIC RATE INTERFACE DAUGHTER BOARD)..............................4-67
5.4.1 DESCRIPTION......................................................................................4-68
5.4.2 INSTALLATION......................................................................................4-69
5.4.3 CONNECTORS .....................................................................................4-70
5.5 CD-4DIOPB (DID/OPX INTERFACE)..............................................................4-71
5.5.1 DESCRIPTION......................................................................................4-71
5.5.2 INSTALLATION......................................................................................4-72
5.5.3 LED INDICATIONS................................................................................4-72
5.5.4 CONNECTORS .....................................................................................4-73
5.6 CD-PRTA (PRI/T1/E1 INTERFACE)............................................................4-74
5.6.1 DESCRIPTION......................................................................................4-74
5.6.2 INSTALLATION......................................................................................4-75
5.6.3 LED INDICATIONS................................................................................4-77
5.6.4 CONNECTORS .....................................................................................4-79
5.7 CD-4ODTB (4-PORT TIE LINE INTERFACE BLADE)..........................................4-81
5.7.1 DESCRIPTION......................................................................................4-81
5.7.2 INSTALLATION......................................................................................4-82
5.7.3 LED INDICATIONS................................................................................4-83
5.7.4 CONNECTORS .....................................................................................4-84
5.7.5 CONNECTIONS ....................................................................................4-85
SECTION 6OPTIONAL BLADES.......................................................................4-87
6.1 CD-VM00 (VOICE MAIL AND SERVER)............................................................4-87
6.1.1 DESCRIPTION......................................................................................4-87
System Hardware Manual
V
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
6.1.2 INSTALLATION......................................................................................4-88
6.1.3 LED INDICATIONS................................................................................4-89
6.1.3.1 ACTIVE LED -GREEN ..............................................................4-89
6.1.3.2 BUSY LED -RED......................................................................4-90
6.1.3.3 APPLICATION LED -RED/GREEN (DUAL COLOR)......................4-90
6.1.3.4 COMPACTFLASH CARD ACTIVITY LED -RED ............................4-90
6.1.4 CONNECTORS .....................................................................................4-90
6.1.4.1 RS-232 INTERFACE .................................................................4-90
6.1.4.2 DB9 TO 6-PIN MODULAR RS-232 ADAPTER...............................4-91
6.1.4.3 RS-232 SERIAL CABLE (DTE)...................................................4-91
6.1.4.4 RS-232 SERIAL CABLE (DCE)..................................................4-92
6.1.4.5 USB INTERFACE.......................................................................4-92
6.1.4.6 VGA DISPLAY INTERFACE.........................................................4-92
6.1.4.7 10 BASE-T/100 BASE-TX ETHERNET INTERFACE .....................4-92
6.2 CD-PVAA (CONFERENCE BRIDGE) ................................................................4-94
6.2.1 DESCRIPTION......................................................................................4-94
6.2.2 INSTALLATION......................................................................................4-95
6.2.3 SWITCH SETTINGS...............................................................................4-95
6.2.4 LED INDICATIONS................................................................................4-96
6.2.5 CONNECTORS .....................................................................................4-96
6.3 CD-RTB (4-PORT ROUTER)...........................................................................4-97
6.3.1 DESCRIPTION......................................................................................4-97
6.3.2 INSTALLATION......................................................................................4-99
6.3.3 LED INDICATIONS................................................................................4-99
6.4 CD-ETIA (GIGABIT POESWITCH) ................................................................4-100
6.4.1 DESCRIPTION....................................................................................4-100
6.4.2 INSTALLATION....................................................................................4-101
6.4.2.1 STACKING ARCHITECTURE .....................................................4-101
6.4.2.2 CD-CP00 IP ADDRESS ASSIGNMENT ......................................4-101
6.4.2.3 GROUP FORMATION................................................................4-102
6.4.2.4 PORT NUMBER DETERMINATION..............................................4-102
6.4.2.5 UNMANAGED SWITCH FUNCTIONS ...........................................4-103
6.4.3 LED INDICATIONS..............................................................................4-103
6.4.4 CONNECTORS ...................................................................................4-103
SECTION 7CABLING AND MDF CONNECTION ..............................................4-104
7.1 CONNECTION REQUIREMENTS ......................................................................4-104
7.2 CABLING PRECAUTIONS ...............................................................................4-104
VI
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
7.3 WIRING BETWEEN THE CHASSIS AND THE MDF .............................................4-104
7.3.1 CHASSIS CABLES ..............................................................................4-104
7.3.2 OUTSIDE LINES .................................................................................4-108
Chapter 5; Installing DT300/DT700 Series (DTL/ITL) Digital and IP Multiline
Terminals
SECTION 1GENERAL INFORMATION..................................................................5-1
SECTION 2DT300 SERIES DIGITAL MULTILINE TERMINALS ...............................5-7
2.1 DIGITAL MULTILINE TERMINALS .........................................................................5-7
2.1.1 DTL-2E-1( )(BK)TEL..........................................................................5-7
2.1.2 DTL-6DE-1( )(BK)TEL .......................................................................5-8
2.1.3 DTL-8LD-1( )(BK) TEL/ DTL-8LD-1( )(WH)TEL................................5-8
2.1.4 DTL-12BT-1( )(BK) TEL......................................................................5-9
2.1.5 DTL-12D-1( )(BK) TEL/ DTL-12D-1( )(WH)TEL..............................5-10
2.1.6 DTL-12PA-1( )(BK) TEL.................................................................... 5-11
2.1.7 DTL-24D-1( )(BK) TEL/ DTL-24D-1( )(WH)TEL..............................5-12
2.1.8 DTL-32D-1( )(BK) TEL/ DTL-32D-1( )(WH)TEL..............................5-13
SECTION 3DT700 SERIES IP MULTILINE TERMINALS......................................5-15
3.1 IPMULTILINE TERMINALS ...............................................................................5-15
3.1.1 ITL-2E-1( )(BK)TEL..........................................................................5-15
3.1.2 ITL-6DE-1( )(BK) TEL.......................................................................5-16
3.1.3 ITL-8LD-1( )(BK)TEL/ ITL-8LD-1( )(WH) TEL .................................5-16
3.1.4 ITL-12D-1( )(BK)TEL/ ITL-12D-1( )(WH) TEL .................................5-17
3.1.5 ITL-12PA-1( )(BK) TEL .....................................................................5-18
3.1.6 ITL-24D-1( )(BK)TEL/ ITL-24D-1( )(WH) TEL .................................5-19
3.1.7 ITL-32D-1( )(BK)TEL/ ITL-32D-1( )(WH) TEL .................................5-20
3.1.8 ITL-320C-1( )(BK)TEL .....................................................................5-21
SECTION 4INSTALL MULTILINE TERMINALS ....................................................5-23
4.1 CONNECTING THE DT300 SERIES MULTILINE TERMINAL TO THE SYSTEM ..........5-23
4.2 APPLYING POWER TO THE DT700 MULTILINE TERMINALS.................................5-24
4.3 CONNECTING THE IP MULTILINE TERMINAL TO THE NETWORK AND PC..............5-25
4.4 ADJUSTING THE LCD ON THE MULTILINE TERMINAL..........................................5-26
4.5 INSTALLING LINE KEY KIT (12LK-LKIT) ..........................................................5-27
4.5.1 INSTALLING THE 12LK-LKIT................................................................5-27
4.5.2 CONFIGURING THE DIGITAL TELEPHONE FOR THE CORRECT NUMBER
OF LINE KEYS......................................................................................5-32
System Hardware Manual
VI
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
4.5.3 CONFIGURING THE IPTELEPHONE FOR THE CORRECT NUMBER
OF LINE KEYS......................................................................................5-32
4.6 INSTALLING THE DIRECTORY CARD ON THE MULTILINE TERMINAL......................5-34
4.7 REMOVAL AND REPLACEMENT OF THE NUMBERED KEYPADL.............................5-35
4.7.1 REMOVING THE NUMBERED KEYPAD.....................................................5-36
4.7.2 INSTALLING THE NUMBERED KEYPAD ....................................................5-37
4.8 REMOVAL AND REPLACEMENT OF THE BS ()-LKIT (TEN KEY KIT).....................5-38
4.8.1 REMOVE THE BS ()–LKIT ................................................................5-38
4.8.2 INSTALL THE BS ()-KIT .....................................................................5-39
4.8.3 CONFIGUREING THE DIGITAL TELEPHONE FOR THE TEN KEY KIT ...........5-41
4.8.4 CONFIGUREING THE IPTELEPHONE FOR THE NUMBERED KEY ..............5-41
4.9 ADJUSTING THE HEIGHT ON THE MULTILINE TERMINAL .....................................5-43
4.10 REMOVING OR INSTALLING THE TILT LEGS ON THE MULTILINE TERMINAL..........5-44
4.10.1 REMOVE TILT LEGS ..........................................................................5-44
4.10.2 INSTALL TILT LEGS.............................................................................5-45
4.11 WALL MOUNTING THE MULTILINE TERMINAL...................................................5-46
4.11.1 WALL MOUNTING A MULTILINE TERMINAL USING THE BASE PLATE.........5-46
4.11.1.1 ADJUSTING THE HANGER HOOK...............................................5-46
4.11.1.2 WALL MOUNTING THE MULTILINE TERMINAL..............................5-47
4.11.1.3 REMOVING THE MULTILINE TERMINAL FROM THE WALL
MOUNTED BASE PLATE...........................................................5-49
4.11.1.4 WALL MOUNTING THE BASE ON A SWITCH BOX .........................5-50
SECTION 5MULTILINE TERMINALS OPTIONAL EQUIPMENT ..............................5-51
5.1 DT300/DT700 SERIES TERMINAL OPTIONS ....................................................5-51
5.2 DT300/DT700 SERIES OPTIONAL TERMINAL EQUIPMENT................................5-52
5.2.1 8LK-L(BK) UNIT/8LK-L(WH) UNIT .................................................5-52
5.2.1.1 INSTALLING THE 8LK-LUNIT ...................................................5-52
5.2.2 8LKD (LD)-L(BK) UNIT/8LKD (LD)-L(WH) UNIT..............................5-54
5.2.2.1 INSTALLING THE 8LKD(LD)-LUNIT ..........................................5-55
5.2.3 8LKI (LD)-L(BK) UNIT/8LKI (LD)-L(WH) UNIT.................................5-58
5.2.3.1 INSTALLING THE 8LKI(LD)-LUNIT ...........................................5-59
5.2.4 DCL-60-1( )(BK) CONSOLE/DCL-60-1( )(WH) CONSOLE ............5-62
5.2.4.1 INSTALLING THE DCL-60-1 CONSOLE.....................................5-63
5.2.5 LCD (BL)-L(BK) UNIT/LCD (BL)-L(WH) UNIT ................................5-67
5.2.6 PANEL( )-LUNIT...............................................................................5-68
5.2.7 WM-LUNIT........................................................................................5-69
5.2.7.1 MOUNT MULTILINE TERMINAL ON WALL USING WM-LUNIT.........5-69
VIII
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
5.2.7.2 MOUNT MULTILINE TERMINAL ON WALL PLATE USING WM-LUNIT5-73
5.2.8 DSS WM-LUNIT ...............................................................................5-77
5.2.8.1 MOUNT DCL-60-1 CONSOLE ON WALL USING DSS WM-LUNIT 5-77
5.2.8.2 MOUNT DCL-60-1 CONSOLE ON WALL PLATE USING
DSS WM-LUNIT....................................................................5-78
SECTION 6BLUETOOTH CORDLESS HANDSET ................................................5-80
6.1 BLUETOOTH CORDLESS HANDSET (BCH) INTERFACE ......................................5-80
6.2 SELECTING A LOCATION..................................................................................5-81
6.3 CONTROLS AND INDICATORS...........................................................................5-82
6.4 INSTALLING THE BLUETOOTH CORDLESS HANDSET ..........................................5-84
6.4.1 INSTALLING THE BLUETOOTH HANDSET CRADLE...........................5-84
6.4.2 WALL MOUNTING THE BLUETOOTH CRADLE ......................................5-90
6.4.3 REMOVE AND REPLACE HANDSET BATTERY ..........................................5-93
SECTION 7BLUETOOTH HUB ADAPTER ..........................................................5-94
7.1 BLUETOOTH HUB ADAPTER (BHA) FEATURES .................................................5-94
7.1.1 INSTALLING THE BHA-L UNIT..............................................................5-94
7.1.2 PAIRING A BLUETOOTH DEVICE AND MULTILINE TRMINAL
(BLUETOOTH INSTALLED) .....................................................................5-96
7.1.2.1 ACCESSING THE BLUETOOTH DEVICE SETUP SCREEN ................5-96
7.1.2.2 ENTERING A PIN CODE .............................................................5-96
7.1.2.3 PAIRING....................................................................................5-96
7.1.2.4 CONNECTING THE PAIRED DEVICE .............................................5-97
7.1.2.5 UNPAIRING ...............................................................................5-97
7.1.2.6 VISIBILITY SETTING ...................................................................5-97
7.1.2.7 BTINFORMATION ......................................................................5-98
SECTION 8SINGLE LINE TELEPHONE .............................................................5-99
8.1 INSTALLING THE IP1E-1SLTAD ......................................................................5-99
8.2 WALL MOUNTING THE IP1E-1SLTAD............................................................5-100
Chapter 6; Installing SV8100 Optional Equipment
SECTION 1GENERAL INFORMATION..................................................................6-1
SECTION 2IP1WW-2PGDAD..........................................................................6-1
2.1 USING A IP1WW-2PGDAD..............................................................................6-1
2.2 LED INDICATION ..............................................................................................6-2
2.3 SETTING UP IP1WW-2PGDAD CONNECTIONS .................................................6-2
SECTION 3BACKGROUND MUSIC...................................................................6-11
3.1 INSTALLING BACKGROUND MUSIC ................................................................... 6-11
System Hardware Manual
IX
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
SECTION 4DOOR BOX ............................................................................................6-12
4.1 INSTALLING A DOOR BOX ................................................................................6-12
SECTION 5EXTERNAL PAGING .......................................................................6-16
5.1 EXTERNAL PAGE ............................................................................................6-16
5.2 INSTALLING AN EXTERNAL PAGE SYSTEM.........................................................6-16
SECTION 6EXTERNAL PAGING AND DOOR BOX/PAGE RELAYS........................6-18
6.1 EXTERNAL PAGE RELAYS................................................................................6-18
6.2 DOOR BOX /EXTERNAL PAGE RELAY CONTACTS ..............................................6-19
6.2.1 CONNECTING A CONTACT RELAY DEVICE TO A DOOR BOX
/EXTERNAL PAGE RELAY......................................................................6-19
SECTION 7EXTERNAL RECORDING SYSTEM/EXTERNAL RINGER ....................6-20
7.1 EXTERNAL RECORDING SYSTEM OR EXTERNAL RINGER...................................6-20
7.2 INSTALLING AN EXTERNAL RECORDING SYSTEM OR EXTERNAL RINGER ............6-21
7.3 PROGRAMMING..............................................................................................6-21
SECTION 8MUSIC SOURCES .........................................................................6-25
8.1 MUSIC ON HOLD ............................................................................................6-25
8.2 INSTALLING EXTERNAL MUSIC ON HOLD ..........................................................6-25
SECTION 9TELEPHONE LABELING .................................................................6-28
9.1 DESI PRINTER SHEETS..................................................................................6-28
9.1.1 REMOVING THE FACEPLATE..................................................................6-28
9.1.2 REPLACING THE FACEPLATE.................................................................6-28
SECTION 10 TELEPHONE ADAPTERS ..............................................................6-29
10.1 USING ADAPTERS ........................................................................................6-29
10.2 IN-LINE POWER ADAPTER (ILPA-R)...............................................................6-30
10.2.1 CONDITIONS......................................................................................6-30
10.2.2 INSTALLATIONS..................................................................................6-31
10.3 ADA-LUNIT...............................................................................................6-33
10.3.1 ADA-L UNITSWITCH SETTINGS ........................................................6-34
10.3.2 INSTALLING THE ADA-LUNIT ............................................................6-36
10.3.3 ADA-L UNITCONNCTION..................................................................6-38
10.3.3.1 ADA-LUNIT CONNECTION FOR RECORDING ONLY ..................6-38
10.3.3.2 ADA-LUNIT CONNECTION FOR SENDING RECORDED CALLS
TO THE TELEPHONE ..............................................................6-39
10.4 APR-LUNIT...............................................................................................6-39
10.4.1 APR-LUNIT SWITCH SETTINGS ........................................................6-40
10.4.2 INSTALLING THE APR-LUNIT ............................................................6-40
10.5 PSA-L(BK) UNIT /PSA-L(WH) UNIT........................................................6-43
X
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
10.5.1 INSTALLING THE PSA-LADAPTER.......................................................6-44
10.5.2 USING THE PSA-LADAPTER ..............................................................6-51
SECTION 11 POWER FAILURE TELEPHONES....................................................6-52
11.1 POWER FAILURE ..........................................................................................6-52
11.2 CONNECTOR PIN-OUTS ON COIU BLADE FOR POWER FAILURE CIRCUITS.......6-53
11.3 INSTALLING THE POWER FAILURE TELEPHONES..............................................6-53
System Hardware Manual
XI
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
XII
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
System Hardware Manual R-1
Regulatory
BATTERY DISPOSAL
The UNIVERGE SV8100 system includes the batteries listed below. When disposing of these
batteries, Chassis, and/or Blades, you must comply with applicable federal and state regulations
regarding proper disposal procedures.
Unit Name Type of Battery Quantity
CD-CP00 Lithium 1
CT-12 Headset Cordless Ni MH 1
DTH-4R-2 Ni MH 1
DTL-8R-1 Ni MH 1
DTR-1HM-1 TEL Lithium 1
DTR-1R-2 Nickel-Cadmium 1
DTR-4R-2 TEL Nickel-Cadmium 1
DTU-4R-1 TEL Lead Acid 1
C124 (SIP DECT Wireless) Ni MH 1
CHS LARGE BATT SET Sealed Lead 1
Headset Cordless II Ni MH 1
Internal Batteries Sealed Lead 1
Bluetooth® Cordless Handset Lithium-ion 1
Table R-1 Battery Types and Quantities for Chassis and Blades
The UNIVERGE SV8100 CD-CP00 provides memory backup for approximately three years. The
Lithium battery should be replaced every two years.
IMPORTANT SAFEGUARDS FOR BATTERY DISPOSAL
DO NOT PLACE USED BATTERIES IN YOUR REGULAR TRASH! THE PRODUCT YOU
PURCHASED CONTAINS LITHIUM, NICKEL-CADMIUM OR SEALED LEAD BATTERIES.
LITHIUM, NICKEL-CADMIUM OR SEALED LEAD BATTERIES MUST BE COLLECTED, RECYCLED,
OR DISPOSED OF IN AN ENVIRONMENTALLY SOUND MANNER.
The incineration, landfilling or mixing of nickel-cadmium or sealed lead batteries with the municipal
solid waste stream is PROHIBITED BY LAW in most areas. Contact your local solid waste
management officials for other information regarding the environmentally sound collection, recycling,
and disposal of the battery.
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
Regulatory
R-2
Nickel-Cadmium (or sealed lead) batteries must be returned to a federal or state approved
nickel-cadmium (or sealed lead) battery recycler. This may be where the batteries were originally sold
or a local seller of automotive batteries. Contact your local waste management officials for other
information regarding the environmentally sound collection, recycling and disposal of the battery
contained in this product.
The packaging for the UNIVERGE SV8100 system contains the following labels regarding proper
disposal.
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
EUROPEAN UNION INFORMATION
Notice to the user
The system described in this manual is intended to be connected to analog and digital networks and
supports a wide range of peripheral equipment. The following interfaces are available for connection
to public analog and digital telecommunication networks:
TBR3 ISDN basic rate interface
TBR4 ISDN primary rate interface
ES203-021 Analogue interface
To take advantage of all features of this system and the connected equipment, the country or network
specific features should match the supported features of the system. For an overview of the
supported features, refer to the detailed documentation that comes with this system, contact your
local supplier.
Declaration of conformityHereby, “NEC Infrontia”, declares that the SV8100 is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
Electromagnetic Compatibility
For the SV8100 system the following warning is applicable:
Warning
This is a class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
System Hardware Manual R-3
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
Regulatory
R-4
PRODUCT DISPOSAL INFORMATION
For Countries in the European Union
The symbol depicted here has been affixed to your product in order to inform you that electrical and
electronic products should not be disposed of as municipal waste.
Electrical and electronic products including the cables, plugs and
accessories should be disposed of separately in order to allow proper
treatment, recovery and recycling. These products should be taken to a
designated facility where the best available treatment, recovery and
recycling techniques are available. Separate disposal has significant
advantages: valuable materials can be re-used and it prevents the
dispersion of unwanted substances into the municipal waste stream.
This contributes to the protection of human health and the environment.
Please be informed that a fine may be imposed for illegal disposal of
electrical and electronic products via the general municipal waste
stream.
In order to facilitate separate disposal and environmentally sound
recycling arrangements have been made for local collection and recycling. In case your electrical and
electronic products need to be disposed of please refer to your supplier or the contractual agreements
that your company has made upon acquisition of these products.
Battery information
Defective or exhausted batteries should never be disposed of as municipal waste. Return old
batteries to the battery supplier, a licensed battery dealer or a designated collection facility. Do not
incinerate batteries. This product uses Lithium batteries. Do not use any other type.
For an overview of the location of batteries used in these systems, the battery replacement or removal
instructions please refer to the UNIVERGE SV8100 System Hardware Manual.
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn

UNIVERGE SV8100
System Hardware Manual 1-1
Chapter1; Introduction to SV8100
SECTION 1 GENERAL INFORMATION
The SV8100 is a full-featured IP based communications system providing a rich
feature set of existing system, with pure Voice over IP (VoIP) communications,
across corporate Local and Wide Area Networks (LAN and WAN).
The DT700 series telephones provide a converged infrastructure at the desktop,
with a 10Base-T/100Base-TX connection to the LAN and built-in hub for a PC
connection to the telephone itself. The system can provide peer-to-peer
connections between the DT700 series telephones with voice compression,
offering existing IP telephone features with an enhanced user interface. On the
WAN side, the system can provide peer-to-peer connections over IP networks with
the voice compression, on CCIS over IP or Remote Unit over IP.
The SV8100 can provide legacy line/trunk interfaces to support the existing Time
Division Multiplexing (TDM) based infrastructure, such as analog telephones, digital
telephones (DT300 series), analog networks and digital networks (T1/E1, ISDN,
etc.).
The new compact 19” chassis provides 111 total ports (80 digital terminals) and can
be expanded, using three additional 19” chassis, for a maximum of 444 ports (368
digital terminals). Through IP connection and four additional 19” chassis, the
system can be expanded to a maximum of 512 ports for SV8100 (refer to Table 2-2
SV8100 Maximum System Capacities – Trunks/Ports/Channels on page 2-5).
Communications between legacy stations/trunks and DT700 series telephones/IP
networks are made using a VoIP daughter board, which converts packet-based
voice data to TDM-based voice data, and vice versa. Both peer-to-peer
connections and TDM-based connections are controlled by the CPU blade. The
CPU incorporates a built-in Device Registration Server (DRS) and a single interface
point of IP connection to IP telephone, PCPro and OAI / ACD servers. Figure 1-1
shows a simplified view of SV8100 system connectivity.
CHUYÊN CUNG CẤP TỔNG ĐÀI NEC
http//vietpro.com.vn
