NEC DSX Owner's manual

DSX Telephone Feature
Handbook
P/N 1093099
Printed in U.S.A.
1093100-0025-092209
Empowered by Innovation

This manual has been developed by NEC Unified Solutions, Inc. It is intended for the use of its customers and service
personnel, and should be read in its entirety before attempting to install or program the system. Nothing contained in this
manual shall be deemed to be, and this manual does not constitute, a warranty of, or representation with respect to, any of the
equipment covered. This manual is subject to change without notice and NEC Unified Solutions, Inc. has no obligation to
provide any updates or corrections to this manual. Further, NEC Unified Solutions, Inc. also reserves the right, without prior
notice, to make changes in equipment design or components as it deems appropriate. No representation is made that this
manual is complete or accurate in all respects and NEC Unified Solutions, Inc. shall not be liable for any errors or omissions.
In no event shall NEC Unified Solutions, Inc. be liable for any incidental or consequential damages in connection with the
use of this manual. This document contains proprietary information that is protected by copyright. All rights are reserved. No
part of this document may be photocopied or reproduced without prior written consent of NEC Unified Solutions, Inc.
©2009 by NEC Unified Solutions, Inc. All Rights Reserved.
Printed in U.S.A.

Table of Contents
Introduction...........................................................................................................................9
Dial Codes Sorted by Feature.................................................................................................................11
DSX Dial Codes Sorted by Feature............................................................................................11
22-Button Display Telephone Key Layout.............................................................................................13
22-Button Display Telephone Key Layout.................................................................................13
34-Button Display Telephone Key Layout.............................................................................................14
34-Button Display Telephone Key Layout.................................................................................14
34-Button Super Display Telephone Key Layout...................................................................................15
34-Button Super Display Telephone Key Layout.......................................................................15
60-Button DSS Console Key Layout.....................................................................................................16
60-Button DSS Console Key Layout.........................................................................................16
Features................................................................................................................................17
About Your Telephone Display and Dial Pad.........................................................................................19
Using the Display Presets...........................................................................................................19
Enabling Dial Pad Illumination..................................................................................................21
Account Codes.......................................................................................................................................22
Optional (Unforced) Account Codes..........................................................................................22
Forced Account Codes................................................................................................................22
Attendant Call Queuing (Intercom Queue Key).....................................................................................24
Using your Intercom Queue Key................................................................................................24
Attendant Position..................................................................................................................................25
Calling the Attendant..................................................................................................................25
Auto Redial............................................................................................................................................26
Using Auto Redial......................................................................................................................26
Background Music.................................................................................................................................27
Using Background Music...........................................................................................................27
Barge In (Intrusion)................................................................................................................................28
Using Barge In............................................................................................................................28
Call Coverage Keys................................................................................................................................29
Using Call Coverage Keys.........................................................................................................29
Call Forwarding......................................................................................................................................32
To set up Call Forwarding at a keyset:.......................................................................................32
To set up Call Forwarding at a Super Display:...........................................................................34
To quickly turn off Call Forwarding and clear your Call Forwarding setup:.............................35
Clear All Call Forward Using the Menu Soft Key.....................................................................35
Call Forwarding Off Premises................................................................................................................36
To set up Call Forwarding Off Premises at a keyset:.................................................................36
To set up Call Forwarding Off Premises at a Super Display:.....................................................37
To quickly turn off Call Forwarding and clear your Call Forwarding setup:.............................39
Call Timer...............................................................................................................................................40
Using the Call Timer..................................................................................................................40
DSX | TOC | 3
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

Call Waiting / Camp-On.........................................................................................................................42
Using Call Waiting / Camp-On..................................................................................................42
Callback..................................................................................................................................................43
To leave a Callback at a busy co-worker's extension:................................................................43
To clear (cancel) a Callback you have left:................................................................................43
Caller ID.................................................................................................................................................44
Using Caller ID..........................................................................................................................44
Caller ID Logging..................................................................................................................................45
Using Caller ID Logging............................................................................................................45
Central Office Calls, Answering............................................................................................................50
Answering Outside Calls............................................................................................................50
Setting the Ringing Volume Preset.............................................................................................51
Central Office Calls, Placing..................................................................................................................53
Using Line Keys.........................................................................................................................53
Using Line Dial-up or Direct Line Access.................................................................................53
Placing Outside Calls Using Line Groups..................................................................................54
Check Key..............................................................................................................................................55
Checking Feature Key Assignments...........................................................................................55
Checking Personal Speed Dial Assignments..............................................................................55
Using the Check Key to get System Information.......................................................................55
Clear Key................................................................................................................................................57
To use the CLEAR key at a keyset:............................................................................................57
To use the CLEAR key at a Super Display:...............................................................................57
Conference.............................................................................................................................................59
Using Conference.......................................................................................................................59
Delayed Ringing.....................................................................................................................................60
To set up Line Key ringing at your keyset:................................................................................60
To set up Line Key ringing at your Super Display:....................................................................60
Dial Number Preview.............................................................................................................................62
Using Dial Number Preview......................................................................................................62
Editing the Displayed Number...................................................................................................62
Dial Number Preview Editing Example.....................................................................................62
Direct Inward Line.................................................................................................................................63
Handling Your Direct Inward Lines...........................................................................................63
Direct Line Access.................................................................................................................................64
Using Direct Line Access...........................................................................................................64
Direct Station Selection (DSS)...............................................................................................................65
Using Direct Station Selection...................................................................................................65
To assign your DSS keys at a keyset:.........................................................................................66
To assign your DSS keys at a Super Display:............................................................................66
Direct Station Selection (DSS) Console.................................................................................................67
Using the Speed Processing Keys on the DSS Console.............................................................67
DSS Console Feature Key Assignments.....................................................................................67
Directed Call Pickup..............................................................................................................................73
Using Directed Call Pickup........................................................................................................73
4| DSX | TOC
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

Directory Dialing....................................................................................................................................74
Using Directory Dialing.............................................................................................................74
Distinctive Ringing.................................................................................................................................77
Using Distinctive Ringing..........................................................................................................77
Do Not Disturb.......................................................................................................................................82
Enabling or Disabling Do Not Disturb.......................................................................................82
Do Not Disturb Override........................................................................................................................83
Using Do Not Disturb Override.................................................................................................83
Door Box................................................................................................................................................84
Calling to and from the Door Box..............................................................................................84
Remotely Controlling the Door..................................................................................................84
Extension Hunting..................................................................................................................................85
Sending Calls to Hunt Groups....................................................................................................85
Remove or Install your Extension from your UCD Group........................................................85
Extension Locking..................................................................................................................................86
Locking and Unlocking Your Extension....................................................................................86
Entering or Changing Your PIN Number...................................................................................86
Unlocking an Extension and Erasing It's PIN Number..............................................................87
Feature Keys...........................................................................................................................................89
Customizing your Feature Key Assignments.............................................................................89
Flash.......................................................................................................................................................97
Flashing an Outside Line............................................................................................................97
Forced Line Disconnect..........................................................................................................................98
Using Forced Line Disconnect...................................................................................................98
Group Call Pickup..................................................................................................................................99
Answering a Pickup Group Call.................................................................................................99
Group Listen.........................................................................................................................................101
Using Group Listen..................................................................................................................101
Group Ring...........................................................................................................................................102
Answering Ring Group Calls...................................................................................................102
Placing and Transferring Ring Group Calls.............................................................................102
Handsfree and Handsfree Answerback................................................................................................103
Using Handsfree.......................................................................................................................103
To allow or prevent incoming voice announcements to your keyset:.......................................103
To allow or prevent incoming voice announcements to your Super Display:..........................104
To set up Handsfree Reply on your keyset:..............................................................................104
To set up Handsfree Reply on your Super Display:.................................................................105
Headset Compatibility..........................................................................................................................106
Using the Headset.....................................................................................................................106
To enable the Headset Mode at a keyset:.................................................................................106
To enable the Headset Mode at a Super Display:.....................................................................107
To enable the Headset Voice Announce option at your keyset:................................................107
To enable the Headset Voice Announce option at a Super Display:.........................................107
Hold......................................................................................................................................................109
Using System Hold...................................................................................................................109
DSX | TOC | 5
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

Using Exclusive Hold...............................................................................................................110
Using Intercom Hold................................................................................................................110
Hot Dial Pad.........................................................................................................................................112
Using Hot Dial Pad...................................................................................................................112
Hotline..................................................................................................................................................113
Using Hotline...........................................................................................................................113
Intercom...............................................................................................................................................115
Placing and Answering Intercom Calls....................................................................................115
To allow or prevent incoming voice announcements to your keyset:.......................................115
To allow or prevent incoming voice announcements to your Super Display:..........................116
To set up Handsfree Reply on your keyset:..............................................................................116
To set up Handsfree Reply on your Super Display:.................................................................116
Setting the Ringing Volume Preset...........................................................................................117
Language Selection..............................................................................................................................119
Selecting the Display Language...............................................................................................119
Last Number Redial.............................................................................................................................120
Using Standard Last Number Redial........................................................................................120
Using Enhanced Last Number Redial......................................................................................120
Line Group Routing.............................................................................................................................122
Using Line Group Routing.......................................................................................................122
Line Groups..........................................................................................................................................123
Using Line Groups ..................................................................................................................123
Line Keys..............................................................................................................................................124
Using Your Line Keys...............................................................................................................124
Line Queuing / Line Callback..............................................................................................................126
Using Line Queuing and Line Callback...................................................................................126
Line-to-Line Transfer...........................................................................................................................127
Setting up a Tandem Call.........................................................................................................127
Disconnecting a Tandem Call...................................................................................................127
Barging In on a Tandem Call....................................................................................................127
Setting up a Line-to-Line Transfer...........................................................................................128
Loop Keys............................................................................................................................................129
Using Loop Keys......................................................................................................................129
Meet-Me Conference............................................................................................................................130
Using Meet-Me Conference.....................................................................................................130
Message On Hold.................................................................................................................................131
Recording a Message on Hold if your System has IntraMail..................................................131
Recording a Message on Hold if your System does not have IntraMail..................................131
Message Waiting..................................................................................................................................132
Using Message Waiting............................................................................................................132
Microphone Mute.................................................................................................................................133
Using Microphone Mute .........................................................................................................133
To allow or prevent incoming voice announcements to your keyset:.......................................133
To allow or prevent incoming voice announcements to your Super Display:..........................133
To set up Handsfree Reply on your keyset:..............................................................................134
6| DSX | TOC
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

To set up Handsfree Reply on your Super Display:.................................................................134
Monitor / Silent Monitor......................................................................................................................136
Using Monitor / Silent Monitor................................................................................................136
Names for Extensions and Lines..........................................................................................................137
Programming Extension Names...............................................................................................137
Night Service / Night Ring...................................................................................................................139
Using Night Service / Night Ring............................................................................................139
Off-Hook Signaling..............................................................................................................................140
Setting Your Off-Hook Signaling Options...............................................................................140
Setting the Off Hook Ringing Volume Preset...........................................................................143
Paging...................................................................................................................................................144
Making a Page Announcement ................................................................................................144
Setting the Incoming Page Volume Preset................................................................................145
Enable Incoming Page..............................................................................................................146
Park.......................................................................................................................................................147
Using Park at a Keyset.............................................................................................................147
Using Park at a Super Display..................................................................................................148
Prime Line Preference..........................................................................................................................149
Using Prime Line Preference...................................................................................................149
Privacy Release Groups........................................................................................................................151
Using Privacy Release Groups.................................................................................................151
Programmable Idle Menu Soft Keys....................................................................................................152
Customizing your Idle Menu Soft Keys at your Super Display...............................................153
Pulse to Tone Conversion.....................................................................................................................154
Converting Dialing from DP to DTMF ...................................................................................154
Removing Lines and Extensions from Service....................................................................................155
Removing Lines and Extensions from Service .......................................................................155
Reverse Voice Over..............................................................................................................................156
Using Reverse Voice Over........................................................................................................156
To place a call to your Reverse Voice Over partner:................................................................156
To Transfer a call using your Reverse Voice Over key:............................................................156
To assign a Reverse Voice Over key:........................................................................................157
Ringdown Extension............................................................................................................................158
Using Ringdown.......................................................................................................................158
Ringing Line Preference.......................................................................................................................159
Using Ringing Line Preference................................................................................................159
Room Monitor......................................................................................................................................161
Using Room Monitor...............................................................................................................161
Save Number Dialed............................................................................................................................163
Using Save Number Dialed......................................................................................................163
Selectable Display Messaging..............................................................................................................164
Setting Up Selectable Display Messaging...............................................................................164
Speed Dial............................................................................................................................................167
Storing Speed Dial Numbers....................................................................................................167
Calling a Stored Speed Dial Number.......................................................................................170
DSX | TOC | 7
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

Split (Alternate)....................................................................................................................................172
Using Split................................................................................................................................172
Line-to-Line Transfer...........................................................................................................................173
Setting up a Tandem Call.........................................................................................................173
Disconnecting a Tandem Call...................................................................................................173
Barging In on a Tandem Call....................................................................................................173
Setting up a Line-to-Line Transfer...........................................................................................174
Time and Date......................................................................................................................................175
Setting the System Time and Date...........................................................................................175
Transfer................................................................................................................................................177
Using Transfer..........................................................................................................................177
User Programmable Features (Menu)..................................................................................................179
Using the Menu Soft Key to Customize your Telephone.........................................................179
Voice Mail (IntraMail) Basics..............................................................................................................184
Using the Basic Voice Mail Features........................................................................................184
Voice Over............................................................................................................................................186
Using Voice Over......................................................................................................................186
Setting Your Off-Hook Signaling Options...............................................................................186
Walking Class of Service.....................................................................................................................190
Using Walking Class of Service...............................................................................................190
Entering or Changing Your PIN Number.................................................................................190
8| DSX | TOC
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

Introduction
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

10 | DSX |
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

Dial Codes by Feature
DSX Dial Codes Sorted by Feature
Dial Codes by Feature
When you areDial this code
For this feature
Barging-In on a co-worker’s call4Barge In (Intrusion)
Using Line Dial-Up to place an
outside call
INTERCOM + #9 + Line number
(e.g., 01)
Call Waiting / Camp-On
Using Line Dial-Up to place an
outside call
INTERCOM + #9 + Line number
(e.g., 01)
Central Office Calls, Placing
Using Direct Line Access to place
an outside call
INTERCOM + Line extension
number (e.g., 101)
Accessing a Line Group to place
an outside call
INTERCOM + 9or 90-98
Previewing a number before
dialing
*Dial Number Preview
Intercepting a call ringing a
co-worker’s extension
INTERCOM + ** + ExtensionDirected Call Pickup
Flashing a line at a single line
extension
#3Flash
Using Forced Line Disconnect to
disconnect a busy outside line
#Forced Line Disconnect
Answering a call ringing a phone
in your Pickup Group
INTERCOM + *#Group Call Pickup
Picking up an outside call on
System Hold at a co-worker’s
extension
INTERCOM + *4 + Line number
(e.g., 01)
Hold
Placing an Intercom call to a co-
worker
INTERCOM + Extension (e.g., 301)Intercom
Setting up or joining a Meet-Me
Conference
INTERCOM + #11 or #12Meet-Me Conference
Setting up Monitor after calling a
busy co-worker
6Monitor / Silent Monitor
Answering a call ringing UNA at
night
** + UNA code (01-04)Night Service / Night Ring
Making an internal Paging
announcement
INTERCOM + *1 + Page zone (1-7
or 0 for All Call)
Paging
Parking or retrieving a call from
System Park Orbit
INTERCOM + *+ System Park
Orbit (60-69)
Park
DSX | Introduction | 11
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

Using Personal Park to Park or
retrieve a call at a co-workers
extension
INTERCOM + ** + Extension (e.g.,
301)
Removing or returning an
extension or line to service
INTERCOM + #40 + Extension
(e.g., 301) or line (e.g., 101) + 4
(to return) or 6(to remove)
Removing Lines and Extensions
from Service
Enabling a Selectable Display
Message
INTERCOM + *38 + Message
(00-16) + Hold + Add additional
digits + HOLD
Selectable Display Messaging
Dialing a System or Personal
Speed Dial number
INTERCOM + #+ System bin
(201-299) or Personal number
(701-720)
Speed Dial
Transferring a call to a co-worker’s
extension
TRANSFER + Extension (e.g.,
301)
Transfer
Transferring a call to a co-worker’s
mailbox
TRANSFER + Extension (e.g.,
301) + V-MAIL
Calling your mailbox from your
keyset
V-MAILVoice Mail (IntraMail)
Calling your mailbox from your
single line telephone
Lift handset + *8
Transferring a call to a co-worker’s
mailbox from your keyset
TRANSFER + Extension (e.g.,
301) + V-MAIL
Transferring a call to a co-worker’s
mailbox from your single line
telephone
Hookflash + Extension (e.g., 301)
+ 8
Setting up Personal Answering
Machine Emulation
INTERCOM + *37 + 2(all calls) or
8(outside calls)
Canceling Personal Answering
Machine Emulation
INTERCOM + *30
Initiating a Voice Over to a busy
extension (after hearing busy/ring
tone)
9Voice Over
12 | DSX | Introduction
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

22-Button Display Telephone
22-Button DisplayTelephone Key Layout
DSX | Introduction | 13
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

34-Button Display Telephone
34-Button DisplayTelephone Key Layout
14 | DSX | Introduction
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

34-Button Super Display Telephone
34-Button Super DisplayTelephone Key
Layout
DSX | Introduction | 15
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

60-Button DSS Console
60-Button DSS Console Key Layout
16 | DSX | Introduction
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

Features
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

18 | DSX |
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

About Your Telephone Display and Dial Pad
Your telephone's display helps you process calls, identify callers and customize features.
Display Types
The 22- and 34-Button Display Telephones have a three-line alphanumeric display that shows the date and time, feature
status messages, and a row of soft key definitions.
The 34-Button Super Display Telephone has a nine-line alphanumeric display that also shows the date and time and feature
status messages. Additionally, it has six more rows for the extensive soft keys.
The 34-Button Display and 34-Button Super Display Telephones have a backlit display; the 22-Button Telephones do not.
Display Contrast Control
While your phone is idle, you can press VOLUME Up or VOLUME Down to adjust the contrast of the display. The system
"remembers" your settings.
Contrast Control Preset
Use the Contrast Control Preset to set the default contrast level.
Backlit Display Brightness Control Presets
You can preset the default idle backlight brightness and active backlight brightness for your 34-Button Display or 34-Button
Super Display Telephone display. You set one brightness level for when your phone is idle and another for when it is
active. The 22-Button Telephone doesn't have a backlit display so the idle and active presets are not available.
Automatic Backlight with Ambient Light Sensitivity Adjustment
The 34-Button Display and 34-Button Super Display Telephones have a Light Sensitivity Adjustment which you can
optionally set. In a brightly lit room (and when you are busy on the phone) the display will stay at its maximum backlit
level. If the room light dims or goes out, the display will automatically change to the minimum backlit level.
Turn the sensitivity adjustment down for a bright room and up for a dimly lit room.
Illuminated Dial Pad
The 34-Button Display and 34-Button Super Display Telephones also have an illuminated dial pad. The dial pad lights
when you are using the phone and goes dark when the phone is idle. You'll be sure to find dial pad illumination helpful if
you work in a difficult lighting area.
Using the Display Presets
•Use these presets set the default values of your display's contrast and backlight options.
To set up the display presets at a keyset:
Setting up the Display Presets (Keyset)
Next: Go to next selection. Prev: Go to previous selection. Select: Select current Option. Back: Back out
of current option. Exit: Exit Menu setup.
Select the contrast preset.
Menu +
21
DSX | Features | 19
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/

Setting up the Display Presets (Keyset)
Turn the display contrast down.
Down
Turn the display contrast up.Up
Save your setting and back up to the previous level.Back
Select the minimum brightness preset.Menu +
22
Turn the display minimum brightness level down.Down
Turn the display minimum brightness level up.Up
Save your setting and back up to the previous level.Back
Select the maximum brightness preset.Menu +
23
Turn the display maximum brightness level down.Down
Turn the display maximum brightness level up.Up
Save your setting and back up to the previous level.Back
Select the Automatic Backlight Light Sensitivity preset.Menu +
24
Turn the light sensitivity level down (for bright rooms). The minimum setting is off.Down
Turn the light sensitivity level up (for dimly lit rooms).Up
Save your setting and back up to the previous level.Back
To set up the display presets at a Super Display:
Setting up the Display Presets (Super Display)
Next: Go to next selection. Prev: Go to previous selection. Select: Select current Option. Back: Back out
of current option. Exit: Exit Menu setup.
Select the Display Presets sub-menu.
Menu +
Display
Select the contrast preset.
Contrast
Turn the display contrast down.VOLUME v
Turn the display contrast up.VOLUME ^
Select the minimum brightness preset.Min
Brightness
Turn the display minimum brightness level down.VOLUME v
Turn the display minimum brightness level up.VOLUME ^
Select the maximum brightness preset.Max
Brightness
Turn the display maximum brightness level down.VOLUME v
Turn the display maximum brightness level up.VOLUME ^
20 | DSX | Features
XML to PDF by RenderX XEP XSL-FO Formatter, visit us at http://www.renderx.com/
