Neilsen CT4793 User manual

19 PIECE LAMINATE FLOOR & WORKTOP REPAIR KIT
CT4793
ORIGINAL INSTRUCTIONS
IMPORTANT:
These instructions accompanying the product are the original instructions. This
document is part of the product, keep it for the life of the product passing it on to
any subsequent holder of the product. Read all these instructions before
assembling, operating or maintaining this product.
Cannon Tools Limited
Address: 20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.

1
EC DECLARATION OF CONFORMITY
We CANNON TOOLS LTD
20 Station road, Rowley Regis, West Midlands,B65 0JU.U.K.
Declare that the following machine complies with the appropriate basic safety
and health requirements of the EC Directive based on its design and type, as
brought into circulation by us.
In case of alteration of the machine, not agreed upon by us, this declaration will
lose its validity.
Product description: WAX MELTER
Model: CT4793
Applicable EC Directives:
EC Low Voltage Directive 2014/35/EU
EC-Directive on electromagnetic compatibility(EMC)2014/30/EU
Harmonized standards
EN 60335-2-45:2002+A1:2008+A2:2012,
EN 60335-1:2012+AC:2014+A11:2014+A13:2017，
EN 62233:2008,
EN 55014-1:2006/+A1:2009/+A2:2011,
EN 55014-2:2015
20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
Mr. Gurcharan Tony Singh Sanghera
Managing Director
CANNON TOOLS LTD
2020-11-09

2
1. SPECIFICATION
Wax Melter -DC3V, 3W, Class III
CONTAINS:
1x Wax Melter, 1 x flattening scraper , 1 x cleaning scraper ,
1 x cleaning cloth , 1 x abrasive sponge, 2 x AA battery,
1 x storage case
2. IMPORTANT SAFETY INFORMATION
Read all safety warnings and all instructions.
WARNING! Failure to follow the warnings and instructions may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
In this chapter you will receive important safety information regarding the
handling of the appliance. This appliance complies with the statutory safety
regulations. Incorrect usage can lead to personal injury and property damage.
1) Work area safety
a) keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) do not operate power tools in explosive atmospheres, such as in the presence
of flammable liquids, gases or dust. Power tools create sparks which may ignite
the dust or fumes.
c) keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. never modify the plug in any way. do
not use any adapter plugs with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce risk of electric shock.
b) avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body
is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power

3
tool will increase the risk of electric shock.
d) Do not abuse the cord. never use the cord for carrying, pulling or unplugging
the power tool. keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric
shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating
a power tool. do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. always wear eye protection. Protective
equipment such as dust mask, nonskid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off‐position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
f) Dress properly. do not wear loose clothing or jewellery. keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of these devices
can reduce dust-related hazards.
h) Do not use the appliance in locations where there is a risk of fire or explosion,
e.g. in the vicinity of inflammable liquids or gases.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it was

4
designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the
power tool before making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of starting the
power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tools
operation. if damaged, have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these
instructions and in the manner intended for the particular type of power tool,
taking into account the working conditions and the work to be performed. Use of
the power tool for operations different from those intended could result in a
hazardous situation.
5) Basic safety instructions
For safe handling of the appliance, follow the safety information below:
■ Before use, check the appliance for visible external damage. Do not take into
use a damaged appliance or one that has been dropped.
■ Do not make any unauthorised modifications or alterations to the appliance.
■ This appliance may be used by children aged 8 over and by persons with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge, provided that they are under supervision or have been told how to
use of the appliance safely and are aware of the potential risks. Children must
not play with the appliance. Cleaning and user maintenance tasks must not
be carried out by children unless they are supervised.
■ Protect the appliance against moisture and liquid penetration.
■ Do not operate the appliance close to open flames (e.g. candles).
■ Avoid direct sunlight.
■ Avoid unintentional operation of the wax melter. Ensure that the wax melter is
switched off before lifting or carrying it.
■ On ceasing work, always switch the wax melter off with the slide

5
switch(position OFF) when you put it down.
■ Avoid skin contact with the wax melter tip and protect yourself against dripping
wax. There is a risk of burns!
6) Battery tool use and care
a) Ensure the switch is in the off position before inserting battery pack. Inserting
the battery pack into power tools that have the switch on invites accidents.
b) Use power tools only with specifically designated battery packs. Use of any
other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects like
paper clips, coins, keys, nails, screw, or other small metal objects that can make
a connection from one terminal to another. Shorting the battery terminals
together may cause burns or fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid
contact, if contact accidentally occurs, flush with water. If liquid contacts eyes,
additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
e) Risks from uses other than those intended! There is a risk of explosions and
leakage!
For the safe handling of batteries, take note of the following safety instructions:
► Do not throw batteries into a fire.
► Never short-circuit batteries.
► Do not attempt to recharge batteries.
► Regularly check the condition of the batteries. Leaking battery acid can cause
permanent damage to the appliance. Special caution should be exercised when
handling damaged or leaking batteries. There is a risk of receiving acid burns!
Wear protective gloves.
► Store batteries in a place inaccessible to children. If a battery should be
swallowed, seek medical attention IMMEDIATELY.
► If you do not intend to use the appliance for an extended period, remove the
batteries.
7) Service
a) Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that that safety of the power tool is
maintained.

6
3. TECHNICAL DESCRIPTION
1. Wax melter
2. Wax melter tip
3. On/Off switch
4. Activation button
5. Battery compartment
6. Cleaning scraper
7. Scraper with planer function
8. Wax melter tip cover
9. Sanding sponge
10. Cleaning cloth
11. Colour Wax Blocks(11pcs)

7
4. OPERATION
Intended use
This laminate/parquet repair kit is intended for the repair of laminate, parquet,
cork and wood or plastic surfaces. The supplied wax melter is intended
exclusively for the melting of hard wax suitable for these applications. The
appliance is intended exclusively for domestic use. Do not use the appliance for
commercial or industrial applications. Use the appliance only in a dry
environment resp. in indoor areas. This appliance is not intended for any other
use or for uses beyond those detailed. Claims of any kind for damage resulting
from unintended use will not be accepted. The user alone bears the risk.
Switching the appliance on/off
♦ To switch the appliance on, place the On/Off switch-3 at the position "ON".
♦ Press and hold the activation button-4 to heat up the wax melter tip-2.
♦ To switch the appliance off, place the On/Off switch-3 at the position "OFF".
Application example
1. Preparation (Fig. A)
♦ Clean the damaged area with the spatula-7 and remove all loose parts. Press
the edges of the damaged area round.
2. Colour selection (Fig. B)
♦ Select the matching colour tone.
Ensure that several colour tones, from light to dark, are always used.
3. Melting and filling (Figs. C + D)
♦ Place the On/Off switch‐3 at the position "ON" to switch the appliance on.
♦ Press and hold the activation button-4 to heat up the wax melter tip‐2.
♦ Now melt small portions of the hard wax(11) and place them into the damaged
area, until it is slightly overfilled. Start with the light colour tones and progress
step by step to the dark colour tones.
NOTICE
► At pressure points it is often sufficient if you use only the transparent hard
wax .
4. Filling (Fig. E)
♦ For vertical surfaces it is recommended to mix the colour tone beforehand,
collect it on the spatula-7 and then fill the damaged area.
5. Smoothing (Fig. F)
♦ Allow the hard wax to cool for a few seconds (about 10 seconds).
♦ After cooling, smooth any protrusion with the planing grooves of the scraper-7.

8
Use only light pressure to smooth the protrusion.
6. Fine matching (Fig. G)
♦ For fine matching, now imitate the grain structure with a darker colour tone.
♦ Subsequently, again smooth any protrusion with the planing grooves of the
scraper- 7 .
7. Degreasing (Fig. H)
♦ To finish, remove the last hard wax residues with the sanding sponge-9.
Thereby the gloss level of the surface will also be simultaneously matched. Job
done!
8. Cleaning the planer grooves (Fig. I)
♦ Place the cleaning scraper- 6 on the cooled wax melter tip-2 and scrape the
wax residues from the plane grooves.

9
5. Cleaning
CAUTION
Damage to the appliance!
► Ensure that, when cleaning it, no moisture can penetrate into the appliance,
so as to avoid irreparable damage to it.
► Do not use chemical or abrasive cleaning agents. These could damage the
housing.
♦ Clean the wax melter-1 and the wax melter tip-2 with the cleaning cloth‐10
only when they have cooled down.
6. Storage
If you do not intend to use the appliance for an extended period of time, remove
the batteries.
Store all parts of the Repair Kit in the storage case and at a clean, dry location
out of direct sunlight.
7. DISPOSAL
At the end of the machine’s working life, or when it can no longer be repaired, ensure
that it is disposed of according to national regulations.
– Contact your local authority for details of collection schemes in your area.
In all circumstances:
● Do not dispose of power tools with domestic waste.
● Do not incinerate.
● Do not dispose of WEEE* as unsorted
municipal waste.

CANNON TOOLS LTD
Add: 20 station road, Rowley Regis, west midlands,B65 0JU.U.K.
Made in China
