Introduction
The AROB Series Controller BACnet Communication Module User Guide provides information about using the
controller with BACnet communications feature. The BACnet communication protocol for building automation and
control networks enables communication between client devices within a network. The controller provides a BACnet
network interface between BACnet client devices and Neptronic Controller series devices. It uses the BACnet Master
Slave/Token Passing (MS/TP) protocol at the BACnet MAC layer.
Pre-requisites
The BACnet communication user guide assumes that you are familiar with the concepts of BACnet and its
terminology.
Advantages of BACnet
BACnet enabled controllers have the following advantages:
 Quick Message Transmission. The controller uses a synchronous implementation for BACnet messages
making it quick and efficient. Each BACnet confirmed service request is answered quickly without using the
Reply Postponed frame. The MS/TP implementation is performed within Tusage_delay of 15 minutes to
ensure a Tusage_timeout value within 20 minutes.
 MS/TP Support. The controller supports a Full Master Node state machine for MS/TP. The Max_Master and
the instances are configured to the device object through BACnet WriteProperty service or the device's
Programming Mode. The MAC address and the MS/TP baud rate setting of 9600, 19200, 38400, 57600, and
76800 are also set through the BACnet Write Property service or the device's Programming Mode. In the
Programming mode, the device is configured through the device’s keypad. For more information about the
WriteProperty, refer to Table 3 - Object Types Supported.
 BIBB Support. The controller functions the same way as the B-ASC type profile server and supports the
specific BIBB as per their relevant definitions.
o DS-RP-B
o DS-RPM-B
o DS-WP-B
o DS-WPM-B
o DM-DCC-B
o DM-DDB-B
o DM-DOB-B
o DM-RD-B
 Object Support. The controller supports a fixed list of BACnet visible values, which appear as Present_Values
of various BACnet standard object types in addition to a device object. For more information, refer to Table 3 -
Object Types Supported.
 Alarms. The controller supports the indication of various alarm conditions through value changes in properties
of several objects. However, it does not generate BACnet event notifications.

AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 2

BACnet Properties Configuration
To establish communication on the network, and guarantee a unique ID of devices in a BACnet system, the following
properties may have to be configured.
Table 1 - BACnet Properties Configuration
Property Default
Value
Configuration
MAC Address 000
 Set to a unique address on the network between 000 and 254.
 The value can be set manually using the menu.
 The value can be set manually through the WriteProperty service to Device
Object.proprietary-property#1000 MSTP-Address.
 The values from 128-254 represent MS/TP non-token passing slave devices.
Device Instance Auto
 The controller automatically configures its device instance to 153,000 + MAC
address.
 The value can be set manually using the menu.
 The value can be set manually through the WriteProperty service to Device
Object.Object_Identifier.
 The device’s Object_Identifier is a combination of the Device Object_Type
(8) and the Device_Instance (0-4194302). Therefore its decimal or
hexadecimal representation tends to be incomprehensible.
 For example, the Device_Instance = 1000 has an equivalent
Object_Identifier of 0x020003E8 hexadecimal or 33555432 decimal.
Baud Rate 0 = Auto
 The controller configures its baud rate automatically by detecting the network
upon connection.
 The value can be set manually from the available values of (0) Auto, 9600,
19200, 38400, 57600, and 76800.
Max_Master 127
 Configure Max_Master value to increase network efficiency when there are
less than 127 devices on the network.
 The Max_Master value can be changed through the WriteProperty service to
Device Object.Max_Master.
For more information, refer to the MAC Address and Max_Master section.
Device Object.Object_Name Name of
the device
 Configure the name of the device through the WriteProperty service to Device
Object.Object_Name. For example, ARO24TGVH.



AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 3

Configuration Options
The following Configuration options enable you to configure and run the BACnet features of the controllers quickly.
Quick Setup
Configure the controller for BACnet communication without programming.
1. Ensure that no other device on the network has a MAC address of 0 (the controller's default address).
2. Connect the controller to the network and power it up.
3. The controller automatically configures the baud rate and device instance allowing BACnet Property
Configuration through the Write Property service. See Table 1 - BACnet Properties Configuration.
4. Repeat the steps for each controller.
Manual Setup
Configure the controller for BACnet communication with programming.
1. Access Operation Mode (jumper set to RUN position).
2. Press and hold both function buttons for 5 seconds to access the Quick Access menu.
3. Enter the password, 637.
4. Follow the instructions to configure the MAC Address, MAX Master, Device Instance, and Baud Rate
manually.
5. Disconnect the power to the controller, connect the controller to the network, and connect the power again.
MAC Address and Max_Master
The MAC address must be unique on the entire MS/TP network. However, having a unique MAC address and a high
baud rate does not guarantee efficient operation of the controller and other MS/TP units on the MS/TP network. Some
MAC address and Max_Master combinations are more efficient than others. BACnet requires token-passing units to
occasionally “poll” for other masters based on the MAC address and Max_Master.
A poor combination of MAC addresses and Max_Master can lead to a slower network due to lost time polling for
masters that are not present. Unless there are 126 other units on the MS/TP network, the default Max_Master value of
127 is not the most efficient choice for the controller. The Max_Master default value of 127 was selected to ensure
that any master, specifically a BACnet client can be found when the controller is initially started.
Examples of MAC Address and Max_Master Configurations
The following are some of the examples to indicate the optimum combination of MAC address and Max_Master
configurations to ensure a quick and efficient output.
Example 1
 MAC=0. Max_Master=127
 MAC=1, Max_Master=127
This configuration is slow and inefficient because every time either unit is required to find another master unit, it has to
poll 126 units until it finds the right one to pass the token.
Example 2
 MAC=0. Max_Master=5
 MAC=1 to MAC=4 are not used
 MAC=5, Max_Master=5
This configuration is better than Example 1 but it is still not optimal. The Max_Master is set to the most efficient value,
but the gap between the two MAC addresses is high. Therefore, each unit must poll four units until it finds the right
one to pass the token.
Example 3
 MAC=0, Max_Master=1
 MAC=2, Max_Master=2

AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 4

This is an incorrect configuration. The MAC=0 will never find MAC=2 because it will never poll for the master MAC
address=2.
Example 4
 MAC=0. Max_Master=3
 MAC=1, Max_Master=3
 MAC=2, Max_Master=3
 MAC=3, Max_Master=3
This is an efficient configuration as the units are numbered consecutively, and the MAX_Master is set to the most
efficient value. As a general guideline, the most efficient setup for an MS/TP network is one in which the units are
consecutively numbered starting at MAC address 0 and having Max_Master=the maximum MAC address in the
system. If consecutive numbering is not possible, then the next most efficient setup is one in which all units have
Max_Master=the maximum MAC address in the system.
Network Reset
Reset the controller through BACnet using the Reinitialize Device service. The Reinitialize Device service can be
accessed using the following password: nep.
The Reinitialize Device service has two types of reset such as:
 Warm Reset: The Warm Reset restarts the controller with actual configuration.
 Cold Reset: The Cold Reset restarts the controller with Factory configuration.
Warning: The Cold Reset erases the actual configuration when setting the MSTP address. Therefore, exercise
caution while performing a Cold Reset.



AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 5

Device Object Properties
The following table lists all the BACnet properties supported for the device object. The W indicates that the property is
writable using the BACnet WriteProperty service.
Table 2 - Device Object Properties
Property Value Writable
Object_Identifier
 Programmable where the instance part of the Object_Identifier is in the range of
0-4194302
 The device instance must be unique system-wide
 The default value for the device instance=153000 (Vendor_Identifier*1000)
W
Object_Name AROB24TGVH, programmable up to 32 Bytes W
Description Programmable up to 32 Bytes (default: BACnet Unit Controller) W
Object_Type Device
System_Status Operational
Vendor_Identifier Always 153
Vendor_Name Always Neptronic
Model_Name Example, ARBGVH
Firmware_Revision currently, 1.06
Application_Software_Version currently, 1.27
Protocol_Version Always 1
Protocol_Revision Always 14
DataBase_Revision Default 0; incremented if Object Name, Object List, and/or device ID change
Max_APDU_Length_Accepted Always 480
Segmentation_Supported (3) = No Segmentation
APDU_Timeout 3000 W
Number_of_APDU_Retries Always 3
Protocol_Services_Supported
 readProperty
 readPropertyMultiple
 WriteProperty

writePropertyMultiple
 deviceCommunicationControl
 reinitializeDevice
 who-Has
 who-Is
Protocol_Object_Types_Supported
 analog-input
 analog-output
 analog-value

binary-input
 binary-output
 binary-value
 device
 multi-state-value
Object_List 167
Device_Address_Binding Always empty
Max_Master Programmable in the range of 1-127 (default: 127) W
Max_Info_Frames Always 1
Active_COV_Subscription Empty by default. COV subscription is not supported by the AROB Series Controllers
Property_List List of properties that exist within the object
Proprietary property #1000
 Programmable (default:0)
 Represents the MS/TP MAC address in the range of 0 to 254
 Values 128 to 254 represent MS/TP non-token passing slave devices
W
Proprietary property #1001
 Programmable (default: Auto)
 Represents the MS/TP Baud rate (unsigned type)
 Values are 0 (Auto), 9600, 19200, 38400, 57600, and 76800
W
Proprietary property #1002
 Programmable (default: 15 minutes)
 Represents the period that an object in/out of service will automatically return to
normal. Range = 0-120 minutes (unsigned type)
 Writing 0 means no automatic return to normal
W


AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 6

Object Types Supported
The following table lists all the BACnet properties supported for each object type. Most of the properties are locked.
The exception is Present_Value, which represents the dynamic operating values of the device, and the Status_Flag,
Event_State, and Reliability properties, which reflect the availability of the Present_Value. Unless otherwise specified,
properties are not changeable.
Table 3 - Object Types Supported
Object
Type Enabled Optional Properties
Supported
Writable Properties Notes
Note: Writable properties are different for some objects. Refer to the respective Object Table information to know the writable property for objects.
Analog
Input 
 Reliability
 Description
 Min_Present_Value
 Max_Present_Value
 Resolution
Out_of_Service

If "Out_of_Service" is true, Present_Value and Status_Flag
become writable properties. Refer to Out of Service Property
section on page 6 for more information.
 The object will automatically return to Normal after a
programmable period. Refer to Proprietary property #1002 of
Device Object in Table 2 - Device Object Properties.
Analog
Value 
 Reliability
 Description
 Present_Value
 Out_of_Service
 Refer to Out_of_Service Property section on page 6 for more
information.
 The object will automatically return to Normal after a
programmable period. Refer to Proprietary property #1002 of
Device Object in Table 2 - Device Object Properties.
Analog
Output 
 Description
 Reliability
 Min-Pres-Value
 Max-Pres-Value
 Resolution
Present_Value
Binary
Input 
 Reliability
 Active_Text
 Inactive_Text
 Description
Out_of_Service

If "Out_of_Service" is true, Present_Value and Status_Flag
become writable properties. Refer to Out_of_Service Property
section on page 6 for more information.
 The object will automatically return to Normal after a
programmable period. Refer to Proprietary property #1002 of
Device Object in Table 2 - Device Object Properties.
Binary
Value 
 Reliability
 Active_Text
 Inactive_Text
 Description
Present_Value .
Binary
Output 
 Description
 Reliability
 Inactive-text
 Active-text
Present_Value
Device 
 Max_Master
 Max_Info_Frame
 Description
 active-cov-
subscriptions
 #1000 (MSTP addr)
 #1001 (Baud rate)
 #1002 (Time out)
 Apdu_Timeout
 Object_Identifier
 Object_Name
 Max_Master
 Description
 Apdu_Timeout
 #1000
 #1001
 #1002
Multi-
State
Value

 Description
 Reliability
 State_Text
Present_Value
Out_of_Service Property
Neptronic controllers offer the use of the Out_of_Service writable property. When the value of this property is set to
True, it disconnects the object from the physical input, enabling you to input other values. This is useful for special
applications or while troubleshooting. For example, you can ignore the temperature read from a sensor and input the
desired temperature value to perform specific tests.
For security reasons, a timeout will set the Out_of_Service property back to False after 15 minutes. This value can be
modified to between 0 and 120 minutes (For more information, see proprietary property #1002 in Table 2 - Device
Object Properties).

AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 7

Object Table Information
The AROB Series controllers use the following BACnet object tables, categorized by their ID. The type is the BACnet Object type; the instance is the BACnet Object.
Together, the type and instance form the BACnet Object_Identifier for an object according to the following C-language algorithm:
 object_identifier=(unsigned long)((unsigned long)type<<22)+instance
The object ids are available based on the App Profile (Application Profile) selected.
All object ids are available for App Profile, 0 = No Profile (manual configuration).
Analog Input (AI)
Table 4 - Object Table Information: Analog Input (AI)
ID Name Description W? Notes
Factory
AI.3 Status AI 1 m V
Represents the sensor reading value on analog input 1 in millivolts.
Status AI 1 m V is only available for App Profile, 0 = No Profile (manual
configuration).
Read Only 0 to 10,000 millivolts, Resolution 1mV
AI.4 Status PCB Temp m V Represents the temperature of the printed circuit board in millivolts. Read Only 0 to 3,300 millivolts, Resolution 1mV
AI.5 Status Micro Temp m V Represents the measured temperature of the on-board microprocessor in
millivolts. Read Only 0 to 3,300 millivolts, Resolution 1mV
Analog Output (AO)
Table 5 - Object Table Information: Analog Output (AO)
ID Name Description W? Notes
Integrator
AO.1 Status AO.1 Status value that represents the modulation percentage of analog output 1
based on demand.
Present Value
Relinquish Default 0% to 100%, Resolution 1%
AO.2 Status AO.2
Status value that represents the modulation percentage of analog output 2
based on demand. Status AO.2 is only available for App Profile, 0 = No Profile
(manual configuration).
Present Value
Relinquish Default 0% to 100%, Resolution 1%


AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 8

Analog Value (AV)
Table 6 - Object Table Information: Analog Value (AV)
ID Name Description W? Notes
Integrator
AV.1 User Cooling Setpoint
Configuration value used to set the actual user cooling setpoint of the zone in
the operation mode. The cooling setpoint values are restricted by the
temperature deadband and the heating setpoint.
Present Value 32°F to 257°F or 0°C to 125°C (AV.2 + AV.91 to 257°F/125°C),
Resolution 0.2°F/0.1ºC
AV.2 User Heating Setpoint
Configuration value used to set the actual user heating setpoint of the zone in
the operation mode. The heating setpoint values are restricted by the
temperature deadband and the cooling setpoint.
Present Value 32°F to 257°F or 0°C to 125°C (32°F/0°C to AV.1 - AV.91),
Resolution 0.2°F/0.1°C
AV.3 User Dehumidification Setpoint
Configuration value that represents the dehumidification setpoint of the zone in
the operation mode set by the user, based on relative humidity. The
dehumidification setpoint value is restricted by the humidity deadband and the
humidification setpoint. The User Dehumidification Setpoint requires a
functioning humidity sensor installed.
Present Value 0% RH to 100% RH (AV.4 + AV.92 to 100% RH),
Resolution 0.1% RH
AV.4 User Humidification Setpoint
Configuration value used to set the actual user humidification setpoint of the
zone in operation mode. The humidification setpoint values are restricted by the
humidity deadband and the dehumidification setpoint. The User
Humidification Setpoint requires a functioning humidity sensor installed.
Present Value 0% RH to 100% RH (0% RH to AV.3 - AV.92),
Resolution 0.1% RH
AV.5 User Cooling Unocc Setpoint
Configuration value used to set the actual user cooling setpoint of the zone in
unoccupied operation mode. The unoccupied cooling setpoint values are
restricted by the temperature deadband and unoccupied heating setpoint. Only
appears if MSV.18 or MSV.19 is set to OCC or NSB.
Present Value 32°F to 257°F or 0°C to 125°C (AV.6 + AV.91 to 257°F/125°C),
Resolution 0.2°F/0.1°C
AV.6 User Heating Unocc Setpoint
Configuration value used to set the actual user heating setpoint of the zone in
unoccupied operation mode. The unoccupied heating setpoint values are
restricted by the temperature deadband and unoccupied cooling setpoint. Only
appears if MSV.18 or MSV.19 is set to OCC or NSB.
Present Value 32°F to 257°F or 0°C to 125°C (32°F/0°C to AV.5 - AV.91),
Resolution 0.2°F/0.1°C
AV.7 User CO2 Setpoint
Configuration value that represents the user CO2 setpoint in parts per million
(PPM) at which the outside air damper opens or shuts proportionally to allow
the fresh air into the zone. The User CO2 Setpoint requires a functioning CO2
sensor installed.
Present Value 0 to 2,000 PPM, Resolution 1 PPM
AV.8 User VOC Setpoint
Configuration value that represents the setpoint value that is compared with the
concentrations of odorous substances and gases in the room air measured by
the Volatile Organic Compounds (VOC) sensor in parts per billion (PPB). The
fan or the air damper actuator is activated or deactivated to improve the air
quality. The User VOC Setpoint requires a functioning VOC sensor installed.
Present Value 0 to 1,000 PPB, Resolution 1 PPB
AV.9 Status CO2 level
Represents the status of the carbon dioxide sensor (CO2). This is the value
read by the CO2 sensor in parts per million (PPM). The Status CO2 level
requires a functioning CO2 sensor installed.
Out_of_Service 0 to 2,000 PPM, Resolution 1 PPM
AV.10 Status Temp level Represents the internal temperature sensor reading. Out_of_Service -40°F to 257°F or -40°C to 125°C, Resolution 0.2°F/0.1°C
AV.11 Status Humidity level Represents the humidity sensor reading. The Status Humidity level requires a
functioning humidity sensor installed. Out_of_Service 0% RH to 100% RH, Resolution 0.1%
AV.13 Status VOC Level Represents the VOC sensor reading. The Status VOC Level requires a
functioning VOC sensor installed. Out_of_Service 0 to 1,000 PPB, Resolution 1 PPB
AV.14 Status Outdoor Temp level Represents the outdoor temperature. Only appears if MSV.18 is set to OAT
Sensor. Out_of_Service -40°F to 257°F or -40°C to 125°C, Resolution 0.2°F/0.1°C

AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 9

ID Name Description W? Notes
AV.15 Status Enthalpy Represents the calculated enthalpy. The Status Enthalpy requires a
functioning humidity sensor installed. Read Only -133.19 to 148.56 BTU/lb or -327.68 to 327.67 kJ/kg,
Resolution 0.02 BTU/lb/0.01 kJ/kg
AV.16 Status Dew Point Represents the calculated dew point. The Status Dew Point requires a
functioning humidity sensor installed. Read Only -40°F to 257°F or -40°C to 125°C, Resolution 0.2°F/0.1°C
AV.17 Status Cooling Demand Represents the status value of the cooling demand. The Status Cooling
Demand value is based on zone temperature and setpoint. Read Only 0% to 100%, Resolution 1%
AV.18 Status Heating Demand Status value that represents the heating demand. The Status Heating
Demand value is based on zone temperature and setpoint. Read Only 0% to 100%, Resolution 1%
AV.19 Status Dehumidification Demand
Status value that represents the dehumidification percentage based on relative
humidity. The Status Dehumidification Demand requires a functioning
humidity sensor installed.
Read Only 0% to 100%, Resolution 1%
AV.20 Status Humidification Demand
Status value that represents the humidifier modulation based on relative
humidity. The Status Humidification Demand requires a functioning humidity
sensor installed.
Read Only 0% to 100%, Resolution 1%
AV.21 Status CO2 Demand Status value that represents the CO2 demand based on CO2 level. The Status
CO2 Demand requires a functioning CO2 sensor installed. Read Only 0% to 100%, Resolution 1%
AV.22 Status VOC Demand Status value that represents the VOC demand based on VOC level. The Status
VOC Demand requires a functioning VOC sensor installed. Read Only 0% to 100%, Resolution 1%
AV.23 Status AO 1 Demand Represents the status of the value of analog output 1 value in percentage
based on demand. Read Only 0% to 100%, Resolution 1%
AV.24 Status AO 2 Demand
Represents the status of the value of analog output 2 value in percentage
based on demand. The Status AO 2 Demand is available only when App
Profile 0 = No Profile (manual configuration) is selected.
Read Only 0% to 100%, Resolution 1%
AV.25 Status BO 1 Demand Represents the status of the value of binary output 1 value in percentage based
on demand. Read Only 0% to 100%, Resolution 1%
AV.26 Status BO 2 Demand
Represents the status of the value of binary output 2 value in percentage based
on demand. The Status BO 2 Demand is available only when App Profile 0 =
No Profile (manual configuration) is selected.
Read Only 0% to 100%, Resolution 1%
AV.27 Cfg CO2 calibration
Configuration value applied to the displayed CO2 level reading that is used to
calibrate against a known value from a CO2 sensing device. The Cfg CO2
calibration requires a functioning CO2 sensor installed.
Present Value -200 to 200 PPM, Resolution 1 PPM
AV.28 Cfg VOC calibration
Configuration value applied to the displayed VOC level reading that is used to
calibrate against a known value from a VOC sensing device. The Cfg VOC
calibration requires a functioning VOC sensor installed.
Present Value -100 to 100 PPB, Resolution 1 PPB
AV.29 Cfg Temp calibration
Configuration value applied to the displayed temperature level reading that is
used to calibrate against a known value from a thermometer or other
temperature sensing device.
Present Value -18°F to 18°F or -10°C to 10°C, Resolution 0.2°F/0.1°C
AV.30 Cfg Humidity calibration
Configuration value applied to the displayed humidity level reading that is used
to calibrate against a known value from a humidistat or other humidity sensing
device. The Cfg Humidity calibration requires a functioning humidity sensor
installed.
Present Value
-10% RH to 10% RH, Resolution 1% RH
AV.32 Cfg Outdoor Temp calibration
Configuration value applied to the displayed outdoor air temperature level
reading that is used to calibrate against a known value from a thermometer
and/or other temperature sensing device. Only appears if MSV.18 is set to OAT
Sensor.
Present Value -18°F to 18°F or -10°C to 10°C, Resolution 0.2°F/0.1°C
AV.33 Cfg AO 1 Min Value
Represents the desired minimum voltage (“zero” value) for analog output 1.
The minimum value is restricted by the maximum value. In other words, the
minimum value should be less than the maximum value configured in AV.34.
Present Value 0 Volts to 10 Volts (0 Volts to AV.34), Resolution 0.1 Volt

AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 10

ID Name Description W? Notes
AV.34 Cfg AO 1 Max Value
Represents the desired maximum voltage (“span” value) for analog output 1.
The maximum value is restricted by the minimum value. In other words, the
maximum value should not be less than the minimum value configured in
AV.33.
Present Value 0 Volts to 10 Volts (AV.33 to 10 Volts), Resolution 0.1 Volt
AV.35 Cfg AO 2 Min Value
Select the desired minimum voltage (“zero” value) for analog output 2. The
minimum value is restricted by the maximum value. In other words, the
minimum value should be less than the maximum value configured in AV.36.
The Cfg AO 2 Min Value is only available for App Profile, 0 = No Profile
(manual configuration).
Present Value 0 Volts to 10 Volts (0 Volts to AV.36), Resolution 0.1 Volt
AV.36 Cfg AO 2 Max Value
Select the desired maximum voltage (“span” value) for analog output 2. The
maximum value is restricted by the minimum value. In other words, the
maximum value should not be less than the minimum value configured in
AV.35. The Cfg AO 2 Max Value is only available for App Profile, 0 = No
Profile (manual configuration).
Present Value 0 Volts to 10 Volts (AV.35 to 10 Volts), Resolution 0.1 Volt
AV.37 Cfg AO1 Hi OAT Lockout
Select the desired high temperature limit for outside air temperature on analog
output 1. If the temperature read from the Outside Air Temperature sensor
connected to AI1 is higher than the value set here, the AO1 output will no
longer modulate and remain at its minimum voltage (default: 0Vdc). Only
appears if MSV.18 is set to OAT Sensor.
Present Value -40°F to 257°F or -40°C to 125°C (AV.38 to 257°F/125°C),
Resolution 0.2°F/0.1°C
AV.38 Cfg AO1 Low OAT Lockout
Select the desired low teperature limit for outside air temperature on analog
output 1. If the temperature read from the Outside Air Temperature sensor
connected to AI1 is lower than the value set here, the AO1 output will no longer
modulate and remain at its minimum voltage (default: 0Vdc). Only appears if
MSV.18 is set to OAT Sensor.
Present Value -40°F to 257°F or -40°C to 125°C (-40°F/-40°C to AV.37),
Resolution 0.2°F/0.1°C
AV.39 Cfg AO2 Hi OAT Lockout
Select the desired high temperature limit for outside air temperature on analog
output 2. If the temperature read from the Outside Air Temperature sensor
connected to AI1 is higher than the value set here, the AO2 output will no
longer modulate and remain at its minimum voltage (default: 0Vdc).
The Cfg AO2 Hi OAT Lockout:
 Only available for App Profile, 0 = No Profile (manual configuration).
 Only appears if MSV.18 is set to OAT Sensor.
Present Value -40°F to 257°F or -40°C to 125°C (AV.40 to 257°F/125°C),
Resolution 0.2°F/0.1°C
AV.40 Cfg AO2 Low OAT Lockout
Select the desired low teperature limit for outside air temperature on analog
output 2. If the temperature read from the Outside Air Temperature sensor
connected to AI1 is lower than the value set here, the AO2 output will no longer
modulate and remain at its minimum voltage (default: 0Vdc).
The Cfg AO2 Low OAT Lockout:
 Only available for App Profile, 0 = No Profile (manual configuration).
 Only appears if MSV.18 is set to OAT Sensor.
Present Value -40°F to 257°F or -40°C to 125°C (-40°F/-40°C to AV.39),
Resolution 0.2°F/0.1°C
AV.41 Cfg BO1 Hi OAT Lockout
Select the desired high temperature limit for outside air temperature on binary
output 1. If the temperature read from the Outside Air Temperature sensor
connected to AI1 is higher than the value set here, the output will remain at its
normal state (default: open). Only appears if MSV.18 is set to OAT Sensor.
Present Value -40°F to 257°F or -40°C to 125°C (AV.42 to 257°F/125°C),
Resolution 0.2°F/0.1°C
AV.42 Cfg BO1 Low OAT Lockout
Select the desired low teperature limit for outside air temperature on binary
output 1. If the temperature read from the Outside Air Temperature sensor
connected to AI1 is lower than the value set here, the output will remain at its
normal state (default: open). Only appears if MSV.18 is set to OAT Sensor.
Present Value -40°F to 257°F or -40°C to 125°C (-40°F/-40°C to AV.41),
Resolution 0.2°F/0.1°C

AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 11

ID Name Description W? Notes
AV.43 Cfg BO2 Hi OAT Lockout
Select the desired high temperature limit for outside air temperature on binary
output 2. If the temperature read from the Outside Air Temperature sensor
connected to AI1 is higher than the value set here, the output will remain at its
normal state (default: open).
The Cfg BO2 Hi OAT Lockout:
 Only available for App Profile, 0 = No Profile (manual configuration).
 Only appears if MSV.18 is set to OAT Sensor.
Present Value -40°F to 257°F or -40°C to 125°C (AV.44 to 257°F/125°C),
Resolution 0.2°F/0.1°C
AV.44 Cfg BO2 Low OAT Lockout
Select the desired low teperature limit for outside air temperature on binary
output 2. If the temperature read from the Outside Air Temperature sensor
connected to AI1 is lower than the value set here, the output will remain at its
normal state (default: open).
The Cfg BO2 Low OAT Lockout:
 Only available for App Profile, 0 = No Profile (manual configuration).
 Only appears if MSV.18 is set to OAT Sensor.
Present Value -40°F to 257°F or -40°C to 125°C (-40°F/-40°C to AV.43),
Resolution 0.2°F/0.1°C
AV45 Cfg BO 1 Anti Cycle Timer
Configuration value that represents the binary output 1 anti-cycle delay in
seconds before activating or reactivating the cooling contact to protect the
compressor.
Present Value 0 to 300 seconds, Resolution 1 second
AV.46 Cfg BO 2 Anti Cycle Timer
Configuration value that represents the binary output 2 anti-cycle delay in
seconds before activating or reactivating the cooling contact to protect the
compressor. The Cfg BO 2 Anti Cycle Timer is only available for App Profile,
0 = No Profile (manual configuration).
Present Value 0 to 300 seconds, Resolution 1 second
AV.53 Cfg FAN ON Speed Configuration value that represents the minimum fan speed when the fan
system mode is on. Present Value 0% to 100%, Resolution 1%
AV.54 Cfg BO 1 Hysteresis Low Limit
Configuration value that represents the desired binary output 1 hysteresis low
percentage. The low limit value is restricted by the high limit value. The Cfg BO
1 Hysteresis Low Limit only appears if MSV.24 is set to Hysteresis Mode.
Present Value 0% to 100% (0% to AV.55), Resolution 1%
AV.55 Cfg BO 1 Hysteresis Hi Limit
Configuration value that represents the desired binary output 1 hysteresis high
percentage. The high limit value is restricted by the low limit value. The Cfg BO
1 Hysteresis Hi Limit only appears if MSV.24 is set to Hysteresis Mode.
Present Value 0% to 100% (AV.54 to 100%), Resolution 1%
AV.56 Cfg BO 2 Hysteresis Low Limit
Configuration value that represents the desired binary output 2 hysteresis low
percentage. The low limit value is restricted by the high limit value. The Cfg BO
2 Hysteresis Low Limit is:
Available for App Profile, 0 = No Profile (manual configuration).
Only appears if MSV.25 is set to Hysteresis Mode.
Present Value 0% to 100% (0% to AV.57), Resolution 1%
AV.57 Cfg BO 2 Hysteresis Hi Limit
Configuration value that represents the desired binary output 2 hysteresis high
percentage. The high limit value is restricted by the low limit value. The Cfg BO
2 Hysteresis Hi Limit is:
Available for App Profile, 0 = No Profile (manual configuration).
Only appears if MSV.25 is set to Hysteresis Mode.
Present Value 0% to 100% (AV.56 to 100%), Resolution 1%
Factory
AV.58 Status Board Temp level Represents the temperature of printed circuit board. Out_of_Service 32°F to 122°F or 0°C to 50°C, Resolution 0.2°F/0.1°C
AV.59 Status Micro Temp level Represents the measured temperature of the on-board microprocessor. Out_of_Service -40°F to 185°F or -40°C to 85°C, Resolution 0.2°F/0.1°C
AV.60 Cfg Cooling P Band Configuration value that represents the desired proportional band value for the
cooling ramp. Present Value 3.6°F to 90°F or 2°C to 50°C, Resolution 0.2°F/0.1°C
AV.61 Cfg Cooling I Time Configuration value that represents the time for cooling integral factor
compensation. Present Value 1 to 120 seconds, Resolution 1 second

AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 12

ID Name Description W? Notes
AV.62 Cfg Heating P Band Configuration value that represents the desired proportional band value of the
heating ramp. Present Value 3.6°F to 90°F or 2°C to 50°C, Resolution 0.2°F/0.1°C
AV.63 Cfg Heating I Time Configuration value that represents the desired time for heating integral factor
compensation. Present Value 1 to 120 seconds, Resolution 1 second
AV.64 Cfg Humidity P Band
Configuration value that represents the desired proportional band value of the
dehumidification and humidification ramps. The Cfg Humidity P Band requires
a functioning humidity sensor installed.
Present Value 2% RH to 50% RH, Resolution 0.1% RH
AV.65 Cfg Humidity I Time
Configuration value that represents the desired value for humidification integral
factor compensation of the dehumidification and humidification ramps. The Cfg
Humidity I Time requires a functioning humidity sensor installed.
Present Value 1 to 120 seconds, Resolution 1 second
AV.66 Cfg CO2 P Band Configuration value that represents the desired proportional band value of the
CO2 ramp. The Cfg CO2 P Band requires a functioning CO2 sensor installed. Present Value 10 to 2,000 PPM, Resolution 1 PPM
AV.67 Cfg CO2 I Time
Configuration value that represents the desired value for CO2 integral factor
compensation. The Cfg CO2 I Time requires a functioning CO2 sensor
installed.
Present Value 1 to 120 seconds, Resolution 1 second
AV.68 Cfg VOC P Band Configuration value that represents the desired proportional band value of the
VOC ramp. The Cfg VOC P Band requires a functioning VOC sensor installed. Present Value 10 to 1,000 PPB, Resolution 1 PPB
AV.69 Cfg VOC I Time
Configuration value that represents the desired value for VOC integral factor
compensation. The Cfg VOC I Time requires a functioning VOC sensor
installed.
Present Value 1 to 120 seconds, Resolution 1 second
AV.70 Cfg Cooling setpoint min Configuration value that represents the minimum cooling setpoint. The
minimum cooling setpoint value is restricted by the maximum cooling setpoint. Present Value 32°F to 257°F or 0°C to 125°C (32°F/0°C to AV.71),
Resolution 0.2°F/0.1°C
AV.71 Cfg Cooling setpoint max
Configuration value that represents the maximum cooling setpoint. The
maximum cooling setpoint value is restricted by minimum cooling setpoint
value.
Present Value 32°F to 257°F or 0°C to 125°C (AV.70 to 257°F/125°C),
Resolution 0.2°F/0.1°C
AV.72 Cfg Cooling Unocc setpoint min
Configuration value that represents the minimum cooling setpoint value used
during no occupancy. The minimum cooling setpoint during no occupancy value
is restricted by the maximum cooling setpoint during no occupancy value. Only
appears if MSV.18 or MSV.19 is set to OCC or NSB.
Present Value 32°F to 257°F or 0°C to 125°C (32°F/0°C to AV.73),
Resolution 0.2°F/0.1°C
AV.73 Cfg Cooling Unocc setpoint max
Configuration value that represents the maximum cooling setpoint value used
during no occupancy. The maximum cooling setpoint during no occupancy
value is restricted by the minimum cooling setpoint during no occupancy value.
Only appears if MSV.18 or MSV.19 is set to OCC or NSB.
Present Value 32°F to 257°F or 0°C to 125°C (AV.72 to 257°F/125°C),
Resolution 0.2°F/0.1°C
AV.74 Cfg Heating Setpoint min
Configuration value that represents the minimum heating setpoint. The
minimum heating setpoint value is restricted by the maximum heating setpoint
value.
Present Value 32°F to 257°F or 0°C to 125°C (32°F/0°C to AV.75),
Resolution 0.2°F/0.1°C
AV.75 Cfg Heating Setpoint max Configuration value that represents the maximum heating setpoint. The
maximum heating setpoint is restricted by the minimum heating setpoint value. Present Value 32°F to 257°F or 0°C to 125°C (AV.74 to 257°F/125°C), Resolution 0.2°F/0.1°C
AV.76 Cfg Heating Unocc Setpoint min
Configuration value that represents the minimum heating setpoint value used
during no occupancy. The minimum heating setpoint during no occupancy
value is restricted by the maximum heating setpoint during no occupancy value.
Only appears if MSV.18 or MSV.19 is set to OCC or NSB.
Present Value 32°F to 257°F or 0°C to 125°C (32°F/0°C to AV.77),
Resolution 0.2°F/0.1°C
AV.77 Cfg Heating Unocc Setpoint max
Configuration value that represents the maximum heating setpoint value used
during no occupancy. The maximum heating setpoint during no occupancy
value is restricted by the minimum heating setpoint during no occupancy value.
Only appears if MSV.18 or MSV.19 is set to OCC or NSB.
Present Value 32°F to 257°F or 0°C to 125°C (AV.76 to 257°F/125°C),
Resolution 0.2°F/0.1°C
AV.78 Cfg Dehumidification Setpoint min
Configuration value that represents the value set as the minimum
dehumidification setpoint. The minimum dehumidification setpoint value is
restricted by the maximum dehumidification setpoint value.
The Cfg Dehumidification Setpoint min requires a functioning humidity
sensor installed.
Present Value 0% RH to 100% RH (0% RH to AV.79), Resolution 0.1%

AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 13

ID Name Description W? Notes
AV.79 Cfg Dehumidification Setpoint max
Configuration value that represents the value set as the maximum
dehumidification setpoint. The maximum dehumidification setpoint is restricted
by the minimum dehumidification setpoint value. The Cfg Dehumidification
Setpoint max requires a functioning humidity sensor installed.
Present Value 0% RH to 100% RH (AV.78 to 100% RH), Resolution 0.1%
AV.80 Cfg Humidification Setpoint min
Configuration value that represents the value set as the minimum humidification
setpoint. The minimum humidification setpoint is restricted by the maximum
humidification setpoint. The Cfg Humidification Setpoint min requires a
functioning humidity sensor installed.
Present Value 0% RH to 100% RH (0% RH to AV.81), Resolution 0.1%
AV.81 Cfg Humidification Setpoint max
Configuration value that represents the value set as the maximum
humidification setpoint. The maximum humidification setpoint is restricted by
the minimum humidification setpoint. The Cfg Humidification Setpoint max
requires a functioning humidity sensor installed.
Present Value 0% RH to 100% RH (AV.80 to 100% RH), Resolution 0.1%
AV.82 Cfg CO2 Setpoint min
Configuration value that represents the value set as the minimum CO2 setpoint.
The minimum CO2 setpoint is restricted by the maximum CO2 setpoint. The
Cfg CO2 Setpoint min requires a functioning CO2 sensor installed.
Present Value 0 to 2,000 PPM (0 PPM to AV.83), Resolution 1 PPM
AV.83 Cfg CO2 Setpoint max
Configuration value that represents the value set as the maximum CO2
setpoint. The maximum CO2 setpoint is restricted by the minimum CO2
setpoint. The Cfg CO2 Setpoint max requires a functioning CO2 sensor
installed.
Present Value 0 to 2,000 PPM (AV.82 to 2,000 PPM), Resolution 1 PPM
AV.84 Cfg VOC Setpoint min
Configuration value that represents the value set as the minimum VOC
setpoint. The minimum VOC setpoint is restricted by the maximum VOC
setpoint. The Cfg VOC Setpoint min requires a functioning VOC sensor
installed.
Present Value 0 to 1,000 PPB (0 PPB to AV.85), Resolution 1 PPB
AV.85 Cfg VOC Setpoint max
Configuration value that represents the value set as the maximum VOC
setpoint. The maximum VOC setpoint is restricted by the minimum VOC
setpoint. The Cfg VOC Setpoint max requires a functioning VOC sensor
installed.
Present Value 0 to 1,000 PPB (AV.84 to 1,000 PPB), Resolution 1 PPB
AV.88 Cfg CO2 Sensor Calibration Period
Configuration value that represents the CO2 sensor calibration period in hours.
The Cfg CO2 Sensor Calibration Period requires a functioning CO2 sensor
installed.
Present Value 0 to 2,160 hours, Resolution 1 hour
AV.89 Cfg Board Temp calibration
Configuration value applied to the displayed board temperature reading that is
used to calibrate against a known value from a thermometer or other
temperature sensing device.
Present Value -18°F to 18°F or -10°C to 10°C, Resolution 0.2°F/0.1°C
AV.90 Cfg Micro Temp calibration
Configuration value applied to the displayed microcontroller temperature
reading that is used to calibrate against a known value from a thermometer or
other temperature sensing device.
Present Value -18°F to 18°F or -10°C to 10°C, Resolution 0.2°F/0.1°C
AV.91 Cfg Temp Deadband
Configuration value that represents the temperature deadband. This is the
minimum range between the cooling and heating setpoint within which the
controller will not take action for the temperature reading.
Present Value 0°F to 36°F or 0°C to 20°C, Resolution 0.2°F/0.1°C
AV.92 Cfg Humidity Deadband
Configuration value that represents the humidity deadband. This is the
minimum range between the dehumidification and humidification setpoint within
which the controller will not take action for the humidity reading. The Cfg
Humidity Deadband requires a functioning humidity sensor installed.
Present Value 0% RH to 20% RH, Resolution 0.1% RH
AV.93 Status AO 1 m V Status value that represents the analog output 1 in millivolts. Read Only 0 to 10,000 millivolts, Resolution 1mV
AV.94 Status AO 2 m V Status value that represents the analog output 2 in millivolts. Status AO 2 m V
is only available for App Profile, 0 = No Profile (manual configuration). Read Only 0 to 10,000 millivolts, Resolution 1mV


AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 14

Binary Input (BI)
Table 7 - Object Table Information: Binary Input (BI)
ID Name Description W? Notes
Integrator
BI.1 Status BI 1 Represents the status of the binary input 1 reading. (0) Open, (1) Close Out_of_Service 0 = Open, 1 = Close
Factory
BI.2 Status Programing Mode Represents the status of the programming mode, jumper JP3 (B and C).
(0) Open, (1) Close Read Only 0 = Open, 1 = Close
BI.3 Status Production Mode Represents the status of the production mode jumper J4 (3 and 4).
(0) Open, (1) Close Read Only 0 = Open, 1 = Close
Binary Output (BO)
Table 8 - Object Table Information: Binary Output (BO)
ID Name Description W? Notes
Integrator
BO.1 Status BO 1 Represents the contact status of the binary output 1. (0) Open, (1) Close Present Value
Relinquish Default 0 = Open, 1 = Close
BO.2 Status BO 2
Represents the contact status of the binary output 2. (0) Open, (1) Close
The Status BO 2 is only available for App Profile, 0 = No Profile (manual
configuration).
Present Value
Relinquish Default 0 = Open, 1 = Close
Binary Value (BV)
Table 9 - Object Table Information: Binary Value (BV)
ID Name Description W? Notes
Integrator
BV.1 Status Occupancy Status Represents the occupancy status based on AI1 or BI1 set to Occupancy or
Night Setback. (0) No, (1) Yes Read Only 0 = No, 1 = Yes
BV.2 Status AO 1 OAT Lockout Represents the status value to inform if the OAT lockout alarm is active for the
analog output 1. (0) No, (1) Yes Only appears if MSV.18 is set to OAT Sensor. Read Only 0 = No, 1 = Yes
BV.3 Status AO 2 OAT Lockout
Represents the status value to inform if the OAT lockout alarm is active for the
analog output 2. (0) No, (1) Yes
The Status AO 2 OAT Lockout:
 Only available for App Profile, 0 = No Profile (manual configuration).
 Only appears if MSV.18 is set to OAT Sensor.
Read Only 0 = No, 1 = Yes
BV.4 Status BO 1 OAT Lockout
Represents the status value to inform if the OAT lockout alarm is active for the
binary output 1. (0) No, (1) Yes
Only appears if MSV.18 is set to OAT Sensor.
Read Only 0 = No, 1 = Yes

AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 15

ID Name Description W? Notes
BV.5 Status BO 2 OAT Lockout
Represents the status value to inform if the OAT lockout alarm is active for the
binary output 2. (0) No, (1) Yes
The Status BO 2 OAT Lockout:
 Only available for App Profile, 0 = No Profile (manual configuration).
 Only appears if MSV.18 is set to OAT Sensor.
Read Only 0 = No, 1 = Yes
BV.6 Status Dirty filter Status
Represents the status value to inform if a filter change is required.
(0) No, (1) Yes
The Status Dirty filter Status only appears if MSV.18 or MSV.19 is set to Dirty
Filter.
Read Only 0 = No, 1 = Yes
BV.7 Status Air Flow Switch Status
Represents the status value to inform if an airflow alarm is active.
(0) No, (1) Yes
The Status Air Flow Switch Status only appears if MSV.18 or MSV.19 is set
to Air Flow Switch.
Read Only 0 = No, 1 = Yes
BV.8 Status Air Flow Lockout Status
Represents the status value to inform if an airflow lockout alarm is active.
(0) No, (1) Yes
The Status Air Flow Lockout Status only appears if MSV.18 or MSV.19 is set
to Air Flow Lockout.
Read Only 0 = No, 1 = Yes
BV.9 CfgDisplayCO2Level Display CO2 in RUN mode. (0) No, (1) Yes
The CfgDisplayCO2Level requires a functioning CO2 sensor installed. Present Value 0 = No, 1 = Yes
BV.10 CfgDisplay VOCLevel Display VOC in RUN mode. (0) No, (1) Yes
The CfgDisplay VOCLevel requires a functioning VOC sensor installed. Present Value 0 = No, 1 = Yes
BV.11 CfgDisplayTempLevel Display Temp in RUN mode. (0) No, (1) Yes Present Value 0 = No, 1 = Yes
BV.12 CfgDisplayHumidityLevel
Display %RH in RUN mode. (0) No, (1) Yes
The CfgDisplayHumidityLevel requires a functioning humidity sensor
installed.
Present Value 0 = No, 1 = Yes
BV.16 Cfg Enable Backlight Represents the desired status of LCD backlight. (0) Off, (1) On Present Value 0 = Off, 1 = On
BV.17 Cfg Enable Auto- Scroll Represents the desired status of the auto-scroll of sensor readings in the RUN
mode. (0) Off, (1) On Present Value 0 = Off, 1 = On
BV.18 Cfg Key Pad Upper Left Lock Lock the star (*) button. (0) Off, (1) On Present Value
0 = Off, 1 = On
If set to On, the functionality of these buttons will not be
available.
BV.19 Cfg Key Pad Bottom Left Lock Lock the enter/return button. (0) Off, (1) On Present Value 0 = Off, 1 = On
If set to On, functionality of these buttons will not be available.
BV.20 Cfg Key Pad Arrows Lock Lock the arrow buttons. (0) Off, (1) On Present Value 0 = Off, 1 = On
If set to On, functionality of these buttons will not be available.
BV.21 Cfg Program Mode Lock Locks the Program Mode when the jumper JP3 is set to PGM. (0) Off, (1) On Present Value 0 = Off, 1 = On
If set to On, Program Mode will not be available.
Advanced
BV.22 Cfg Cooling Command AO 1
Represents the status of the cooling command for Analog Output 1.
If you select No Profile as the App Profile, the Cfg Cooling Command AO 1
becomes writable. (0) No, (1) Yes
Present Value 0 = No, 1 = Yes
BV.23 Cfg Heating Command AO 1
Represents the status of the heating command for Analog Output 1. (0) No, (1)
Yes If you select No Profile as the App Profile, the Cfg Heating Command AO
1 becomes writable.
Present Value 0 = No, 1 = Yes

AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 16

ID Name Description W? Notes
BV.24 Cfg Dehumidification Command AO 1
Represents the status of the dehumidification command for Analog Output 1.
(0) No, (1) Yes
 If you select No Profile as the App Profile, the Cfg Dehumidification
Command AO 1 becomes writable.
 The Cfg Dehumidification Command AO 1 requires a functioning humidity
sensor installed.
Present Value 0 = No, 1 = Yes
BV.25 Cfg Humidification Command AO 1
Represents the status of the humidification command for Analog Output 1. (0)
No, (1) Yes
 If you select No Profile as the App Profile, the Cfg Humidification
Command AO 1 becomes writable.
 The Cfg Humidification Command AO 1 requires a functioning humidity
sensor installed.
Present Value 0 = No, 1 = Yes
BV.26 Cfg CO 2 Command AO 1
Represents the status of the CO2 command for Analog Output 1.
(0) No, (1) Yes
 If you select No Profile as the App Profile, the Cfg CO 2 Command AO 1
becomes writable.
 The Cfg CO 2 Command AO 1 requires a functioning CO2 sensor installed.
Present Value 0 = No, 1 = Yes
BV.27 Cfg VOC Command AO 1
Represents the status of the VOC command for Analog Output 1.
(0) No, (1) Yes
 If you select No Profile as the App Profile, the Cfg VOC Command AO 1
becomes writable.
 The Cfg VOC Command AO 1 requires a functioning VOC sensor installed.
Present Value 0 = No, 1 = Yes
BV.28 Cfg FAN Command AO 1
Represents the status of the fan command for Analog Output 1. (0) No, (1) Yes
If you select No Profile as the App Profile, the Cfg FAN Command AO 1
becomes writable.
Present Value 0 = No, 1 = Yes
BV.29 Cfg Cooling Command AO 2
Represents the status of the cooling command for Analog Output 2.
(0) No, (1) Yes
The Cfg Cooling Command AO 2 is only available for App Profile, 0 = No
Profile (manual configuration).
Present Value 0 = No, 1 = Yes
BV.30 Cfg Heating Command AO 2
Represents the status of the heating command for Analog Output 2.
The Cfg Heating Command AO 2 is only available for App Profile, 0 = No
Profile (manual configuration).
Present Value 0 = No, 1 = Yes
BV.31 Cfg Dehumidification Command AO 2
Represents the status of the dehumidification command for Analog Output 2.
(0) No, (1) Yes
The Cfg Dehumidification Command AO 2:
 Only available for App Profile, 0 = No Profile (manual configuration).
 Requires a functioning humidity sensor installed.
Present Value 0 = No, 1 = Yes
BV.32 Cfg Humidification Command AO 2
Represents the status of the humidification command for Analog Output 2.
(0) No, (1) Yes
The Cfg Humidification Command AO 2:
 Only available for App Profile, 0 = No Profile (manual configuration).
 Requires a functioning humidity sensor installed.
Present Value 0 = No, 1 = Yes
BV.33 Cfg CO 2 Command AO 2
Represents the status of the CO2 command for Analog Output 2.
(0) No, (1) Yes
The Cfg CO 2 Command AO 2:
 Only available for App Profile, 0 = No Profile (manual configuration).
 Requires a functioning CO2 sensor installed.
Present Value 0 = No, 1 = Yes

AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 17

ID Name Description W? Notes
BV.34 Cfg VOC Command AO 2
Represents the status of the VOC command for Analog Output 2.
(0) No, (1) Yes
The Cfg VOC Command AO 2:
 Only available for App Profile, 0 = No Profile (manual configuration).
 Requires a functioning VOC sensor installed.
Present Value 0 = No, 1 = Yes
BV.35 Cfg FAN Command AO 2
Represents the status of the fan command for Analog Output 2. (0) No, (1) Yes
The Cfg FAN Command AO 2 is only available for App Profile, 0 = No Profile
(manual configuration).
Present Value 0 = No, 1 = Yes
BV.36 Cfg Cooling Command BO 1
Represents the status of the cooling command for Binary Output 1.
(0) No, (1) Yes
If you select No Profile as the App Profile, the Cfg Cooling Command BO 1
becomes writable.
Present Value 0 = No, 1 = Yes
BV.37 Cfg Heating Command BO 1
Represents the status of the heating command for Binary Output 1.
(0) No, (1) Yes
If you select No Profile as the App Profile, the Cfg Heating Command BO 1
becomes writable.
Present Value 0 = No, 1 = Yes
BV.38 Cfg Dehumidification Command BO 1
Represents the status of the dehumidification command for Binary Output 1.
(0) No, (1) Yes
 If you select No Profile as the App Profile, the Cfg Dehumidification
Command BO 1 becomes writable.
 The Cfg Dehumidification Command BO 1 requires a functioning humidity
sensor installed.
Present Value 0 = No, 1 = Yes
BV.39 Cfg Humidification Command BO 1
Represents the status of the humidification command for Binary Output 1.
(0) No, (1) Yes
 If you select No Profile as the App Profile, the Cfg Humidification
Command BO 1 becomes writable.
 The Cfg Humidification Command BO 1 requires a functioning humidity
sensor installed.
Present Value 0 = No, 1 = Yes
BV.40 Cfg CO 2 Command BO 1
Represents the status of the CO2 command for Binary Output 1. (0) No, (1) Yes
 If you select No Profile as the App Profile, the Cfg CO 2 Command BO 1
becomes writable.
 The Cfg CO 2 Command BO 1 requires a functioning CO2 sensor installed.
Present Value 0 = No, 1 = Yes
BV.41 Cfg VOC Command BO 1
Represents the status of the VOC command for Binary Output 1.
(0) No, (1) Yes
 If you select No Profile as the App Profile, the Cfg VOC Command BO 1
becomes writable.
 The Cfg VOC Command BO 1 requires a functioning VOC sensor installed.
Present Value 0 = No, 1 = Yes
BV.42 Cfg FAN Command BO 1
Represents the status of the fan command for Binary Output 1. (0) No, (1) Yes
If you select No Profile as the App Profile, the Cfg FAN Command BO 1
becomes writable.
Present Value 0 = No, 1 = Yes
BV.43 Cfg Cooling Command BO 2
Represents the status of the cooling command for Binary Output 2.
(0) No, (1) Yes
The Cfg Cooling Command BO 2 is only available for App Profile, 0 = No
Profile (manual configuration).
Present Value 0 = No, 1 = Yes
BV.44 Cfg Heating Command BO 2
Represents the status of the heating command for Binary Output 2.
(0) No, (1) Yes
The Cfg Heating Command BO 2 is only available for App Profile, 0 = No
Profile (manual configuration).
Present Value 0 = No, 1 = Yes
BV.45 Cfg Dehumidification Command BO 2
Represents the status of the dehumidification command for Binary Output 2. (0)
No, (1) Yes
 The Cfg Dehumidification Command BO 2 is only available for App Profile,
Present Value 0 = No, 1 = Yes

AROB Series Universal Room Controller
BACnet Communication Module User Guide
www.neptronic.com Page | 18

ID Name Description W? Notes
0 = No Profile (manual configuration).
 The Cfg Dehumidification Command BO 2 requires a functioning humidity
sensor installed.
BV.46 Cfg Humidification Command BO 2
Represents the status of the humidification command for Binary Output 2. (0)
No, (1) Yes
 The Cfg Humidification Command BO 2 is only available for App Profile, 0
= No Profile (manual configuration).
 The Cfg Humidification Command BO 2 requires a functioning humidity
sensor installed.
Present Value 0 = No, 1 = Yes
BV.47 Cfg CO 2 Command BO 2
Represents the status of the CO2 command for Binary Output 2. (0) No, (1) Yes
 The Cfg CO 2 Command BO 2 is only available for App Profile, 0 = No
Profile (manual configuration).
 The Cfg CO 2 Command BO 2 requires a functioning CO2 sensor installed.
Present Value 0 = No, 1 = Yes
BV.48 Cfg VOC Command BO 2
Represents the status of the VOC command for Binary Output 2.
(0) No, (1) Yes
 The Cfg VOC Command BO 2 is only available for App Profile, 0 = No
Profile (manual configuration).
 The Cfg VOC Command BO 2 requires a functioning VOC sensor installed.
Present Value 0 = No, 1 = Yes
BV.49 Cfg FAN Command BO 2
Represents the status of the fan command for Binary Output 2.
(0) No, (1) Yes
The Cfg FAN Command BO 2 is only available for App Profile, 0 = No Profile
(manual configuration).
Present Value 0 = No, 1 = Yes
Multi State Value (MSV)
Table 10 - Object Table Information: Multi State Value (MSV)
ID Name Description W? Notes
Integrator
MSV.1 User main system mode
Status of the actual mode selected. This value can be changed via AROB
and/or BACnet.
Off: Controller does not respond to any demand.
On: Controller turns the system mode on.
Present Value Off
On
MSV.2 User Temp system mode
Represents the status of the actual temperature system mode. This value can
be changed via AROB and/or BACnet.
Off: Controller does not respond to any demand.
Cool: Controller activates the cooling mode.
Auto: Controller activates the Auto mode, enabling heating and cooling as per
demand.
Heat: Controller activates the heating mode.
Present Value
Off
Cool
Auto
Heat
MSV.3 User Humidity system mode
Represents the status of the actual humidity system mode. This value can be
changed via AROB and/or BACnet. The User Humidity system mode requires
a functioning humidity sensor installed.
Off: Controller does not respond to any demand.
Dehumidification: Controller activates dehumidification.
Auto: Controller activates the Auto mode, enabling dehumidification and
humidification as per demand.
Humidification: Controller activates humidification.
Present Value
Off
Dehumidification
Auto
Humidification
