Neptronic BT000F User manual

Actuator
Specification & Installation instructions
BTF-210802 1
Technical Data
BT000F
BT060F
BT020F
BT080F
BBTF1000A
BBTF1060A
BBTF1021A
BBTF1080A
Fail safe - Enerdrive
No
Yes
No
Yes
Power consumption
15 VA
24VA Peak, 15VA
15 VA
24VA Peak, 15VA
Control signal
3 wire / 2 position,
3 wire / 3 point floating
2 wire / 2 position,
4 wire / 3 point floating
3 wire / 2 position,
3 wire / 3 point floating
2 wire / 2 position,
4 wire / 3 point floating
Auxiliary switches
No
Yes (2)
Ingress protection
IP22 equivalent to Nema type 2,
IP54 equivalent to Nema type 3R if water tight inlet
bushings (not supplied NEP617) are installed
IP22 equivalent to Nema type 2
Running time through
90º
6 to 8 sec Torque dependant
Torque
50 in.lb. [5,6 Nm] at rated voltage
Power supply
22 to 26 VAC or 28 to 32 VDC
Electrical connection
18 AWG [0.8 mm2] minimum
Inlet bushing
2 inlet bushing of 13/16 in [20.6 mm]
Angle of rotation
0 to 90 degrees, mechanically adjustable (factory set with 90º stroke)
Direction of rotation
Reversible, Clockwise (CW) or Counterclockwise (CCW) (factory set with CW direction)
Ambient temperature
-22ºF to +122ºF [-30ºC to +50ºC]
Storage temperature
-22ºF to +122ºF [-30ºC to +50ºC]
Relative Humidity
5 to 95 % non condensing.
Weight
3 lbs. [1.4 kg]
Warning: Do not press the clutch when actuator is powered
Dimensions
Dimension
Inches
Metric (mm)
A
1.50
38.1
B
3.64
92.5
C
6.60
167.5
D
model 000 & 060
3.02
76.8
model 020 & 080
3.81
96.8
Caution
We strongly recommend that all neptronic® products be wired to a separate transformer and that transformer shall service only neptronic® products. This precaution will
prevent interference with, and/or possible damage to incompatible equipment.
When multiple actuators are wired on a single transformer, polarity must be observed. Long wiring runs create voltage drop which may affect the actuator performance.
1
Enerdrive System U.S.A. Patent #5,278,454
Feature:
•Mounts easy on round
& square shaft (with option –8).
•External clutch for manual adjustments.
•Maintenance free.
•Position indicator.
•Fail safe by Enerdrive System1
(on model 060 & 080).
•Auxiliary switches
(on model 020 & 080).
Old Number
BBTF1000A
BT000F
BBTF1021A
BT020F
BBTF1060A
BT060F
BBTF1080A
BT080F

BT000F/020F/060F/080F
Specification & Installation instruction
2
Mechanical installation
1. Manually close the damper blades and positioned the
actuator at 0º or 90º.
2. Slide the actuator onto the shaft.
3. Tighten the nuts on the “U” bolt to the shaft with a 8mm
wrench to a torque of 60 in.lb. [6,7 Nm].
4. Slide the mounting bracket under the actuator. Ensure free
movement of the slot at the base of the actuator. The
bracket pin must be placed in the mid distance of the slot.
5. Fix the bracket to the ductwork with #8 self-tapping screws.
Wiring Diagrams
Models BT000F & 020F
Models BT060F & 080F
3 wire / 2 position (ON-OFF)
2 wire / 2 position (ON-OFF)
3 wire / 3 point floating
4 wire / 3 point floating
PC Board
BBT1060A
Dip switch
Reset button
LED
Terminal
1 2 3 4
ON
1 2 3
Dip switch settings
Stroke adjustment
To adjust the stroke, press and release the reset button to start the auto-stroke process. The LED should be illuminated.
•First option:
The actuator will then travel in both directions to find it's limit.
The LED will extinguish, the process is complete.
•Second option:
When the desired end position is reached, press and release the reset button. The actuator will now return back to its
origin position. (you can also press and release the reset button when It's reaches the origin position)
The LED will extinguish, the process is complete.
CLUTCH
MOUNTING
BRACKET
COMMON (-)
SUPPLY (+) DRIVE
CW
1 2 3 4
DRIVE
CCW
COMMON (-)
SUPPLY (+) DRIVE CW
1 2 3 4
COMMON (-)
SUPPLY (+) DRIVE
CW
1 2 3 4
DRIVE
CCW
COMMON (-)
SUPPLY (+) DRIVE
CW
1 2 3 4
DRIVE
CCW
ON
1 2 3
Rotation: CCW
Fail safe return at 90º
Not used
ON
1 2 3
Rotation: CW
Fail safe return at 0º
Not used
