NEUTRIK NBNB75GLP9 User manual

Neutrik - NBNB75GLP9
Product
Connector Type BNC 75 Ohm
Gender Female
Electrical
Signal Type HD,SDI,Video,AES/EBU,Composit,YUV,RGB,RGBH,RGBHV
Contact Resistance ≤3 mΩ(Inner)
Dielectric Strength 1,5 kVdc
Impedance 75 Ω
Insulation Resistance > 5 GΩ
Rated Voltage 500 V
VSWR ≤1.050 / > 32 dB up to 1 GHz
≤1.065 / > 30 dB up to 2 GHz
≤1.100 / > 26 dB up to 3 GHz
Mechanical
Cable O.D. 6.3 mm
Cable Retention Force > 30 N (Center)
Crimp Size 6,47 Hex crimp (shield) acc. IEC 60803 (die designation E)
Crimp size 1,6 Square crimp (pin) acc. IEC 60803 (die designation 2)
Insertion Force < 25 N
Lifetime > 1000 Mating Cycles
Locking Device Bayonett
Mounting Direction Rear
Chassis Shape 12.7 mm
Cable anchoring Jacket Crimping

Material
Contacts Bronze (CuSn6), 0.2 µm AuCo over 2 µm NiP15 (Ground contact)
Contacts Brass (CuZn35Pb2), 0.2 µm AuCo (Center contact)
Insert Teflon PTFE
Shell Brass (CuZn39Pb3)
Shell Plating Optalloy®
Environmental
Standard Compliance IEC 6016908, MIL 348A
Temperature Range -30 °C to +85 °C
Contact Crimpability Complies with IEC 60803 and IEC 60352-2
The BNC cable jack is a mountable panel version for grounded installations. Like all Neutrik BNCs
it offers a true 75 Ωdesign and is perfectly suitable for HD applications.
Suitable Cables:
Belden 1505A, Belden 8241F, Canare L-4CFB, CommScope 5565, Draka 0.8/3.7 AF, Draka
755-801 (803, 804), Gepco VPM2000, Suhner S04263, Sommer 600-0451
Crimp Size:
Pin: 1.6 mm (square)
Shield: 6.47 mm (hex)

Slide the crimp ferrule onto the cable
Spread the braided shield
- position the pin on the center conductor
- Crimp the pin with the tool
- Pin can also be soldered (Optional)!
- Straighten the pin if misaligned.
crimp
and push the cable and leading ferrule to it`s end
position until you hear a snap noise.
Crimp the ferrule with the tool
(It`s easily with the Neutrik
“SHIELD-SPREADING-TOOL”!)
(For best crimping-results it is recommended to use the original
Neutrik tool - HXBNC with the corresponding insert)
(For best crimping-results it is recommended to use the
original Neutrik crimp tool
- HXBNC with the corresponding insert
or hexcrimp acc. to IEC 803-W (SW 1.7)
or squarecrimp acc. to IEC 803-2 (SW 1.6)
Prepare cable as shown
- Use an adjustable coaxial cable stripper
Crimp the pin
Insert the cable into the connector body
Slide the ferrule over the shield to the front
Please note:
Position the connector body
flush with the die face.
A
A
B
C
D
D
E
F
G
B
C
CRIMP
OPERATION!
Don't damage the foil!
(if existing)
Pin flush to the insulator
G
C: 4 [.16”]
B: 9 [.354”]
A: 16 [.630”]
Crimp ferrule
X
Labeling
X
E
F
X
BNC 75 Cable Jack Panel version
|W
ASSEMBLY INSTRUCTION
Draft. Nr.: BDA 120 Update: 09.04.2008/ 3102M1201 II Data subject to change without prior notice. 2008NEUTRIK . ALL RIGHTS RESERVED.©®
