Nexmosphere XPERIENCE XN-125 User manual

Xperience platform
All of Nexmosphere’s controllers are built on the same platform principles. If this is your rst time using a Nexmosphere
controller, we recommend to rst read https://nexmosphere.com/technology/xperience-platform/ to learn the basics about
our platform and its terminology.
XN-125
The XN-125 is an Xperience controller with 2 X-talk interfaces:
1. X-talk interface 001
2. X-talk interface 002
USB. 5V Power input and API interface (micro-USB connector)
LED. White status LED
Hardware setup
1. Connect one or more Elements to any of the 2 X-talk interfaces.
2. Connect the micro-USB cable to a 3rd party device (e.g. Digital Signage Player or PC).
3. Wait until the white status LED stops blinking. This lasts about 5 seconds.
Software setup for testing (Terminal)
Typically, the XN-125 controller is connected to a 3rd party device, such as a Digital Signage Player, on which CMS software is installed which has built-in
functionality for sending and receiving Serial Events. However, if you want to do a rst test on a PC or Mac, follow the instructions below:
1. Download a terminal program. For example Termite or Hercules.
2. Open the Terminal program and go to settings. Choose the COM port on which the XN-125 controller enumerated*.
In most cases this is the highest available number in the COM port drop-down setting.
3. Set the COM port settings to the following values
Baudrate 115200 Flow Control None
Parity None EOL CR+LF
Data Bits 8 Protocol ASCII
Stop Bits 1
4. Set the COM port to “Open”. The controller is now ready for use.
5. When sending consecutive API serial commands to the XN-125 controller, place a 50mS delay between each command.
*In case the XN-125 controller is not recognized as a COM port by the 3rd party device, a driver (Prolic PL2303) can be downloaded here.
Functionality
The XN-125 runs our API which provides serial output when a specic sensor Element is triggered (for example a pick-up,
or -motion sensor or touch button) and provides control over output Elements (for example controlling LED strips) via serial
input commands. These API serial commands are typically used to create interactive Xperiences for Digital Signage.
The complete API Manual and additional helpful documents can be found on https://nexmosphere.com/support-
documentation. To get you started, we’ve included some starter examples of our Elements and the corresponding API serial
commands on the following pages.
3rd party devices and software
This Quick Start Guide oers a generic explanation of the setup and operation of the XN-125 Xperience controller. It does
not cover information on how to integrate the Controllers, Elements and their API triggers in specic 3rd party devices or
software. We have manuals available with step-by-step instructions on how to integrate Nexmosphere products with the
products of our hardware, -and software partners. You’ll nd these on the support and partner pages of our website.
Nexmosphere
Le Havre 136
5627 SW Eindhoven • The Netherlands
T [phone]
[e-mail]
QUICK START GUIDE

© 2023 Nexmosphere. All rights reserved. v1.0 / 04-23
All content contained herein is subject to change without prior notice.
1
1 2
USBLED
XN

Nexmosphere
Le Havre 136
5627 SW Eindhoven • The Netherlands
T [phone]
[e-mail]
2


When an XY presence sensor connected to X-talk interface
001 detects a person in distance zone 4, the following API
serial command is sent from the XN-125 to the 3rd party
device: X001B[Dz=04]
When an XY-Presence sensor connected to X-talk
interface 001 does not detect a person, the following API
serial command is sent from the XN-125 to the 3rd party
device: X001A[1]

When tag 2 is picked up from an antenna connected to
X-talk interface 001 the following API serial commands are
sent from the XN-125 to the 3rd party device:
XR[PU002]
X001A[1]
When tag 1 is placed on an antenna connected to X-talk
interface 001, the following API serial commands are sent
from the XN-125 to the 3rd party device:
XR[PB001]
X001A[0]

When button 1 of a (touch) button interface connected
to X-talk interface 002 is pressed, the following API serial
commands are sent from the XN-135 to the 3rd party
device: X002A[3]
When button 4 of a (touch) button interface connected
to X-talk interface 002 is pressed, the following API serial
commands are sent from the XN-125 to the 3rd party
device: X002A[17]
XN-125
(Xperience controller)
XY-240
(presence sensor)
USB-A to Micro-USB cable
(connect to 3rd party device)
XN
XR
XR-C10
(RFID antenna)
XR-C10
RFID Tags
(number 1-3)
XR-DR1
(RFID antenna driver
XN-125
(Xperience controller)
USB-A to Micro-USB cable
(connect to 3rd party device)
XN
XT-B4N
(4x bu�on interface)
XT-4F
(Touch bu�ons)
Push bu�ons
(with LED, 4x)
XT-B4 1 2 3 4
XN-125
(Xperience controller)
USB-A to Micro-USB cable
(connect to 3rd party device)
XN
© 2023 Nexmosphere. All rights reserved. v1.0 / 04-23
All content contained herein is subject to change without prior notice.

© 2023 Nexmosphere. All rights reserved. v1.0 / 04-23
All content contained herein is subject to change without prior notice.
Nexmosphere
Le Havre 136
5627 SW Eindhoven • The Netherlands
T [phone]
[e-mail]
3


To set all button LEDs of a (touch) button interface
connected to X-talk interface 002 to “on”, send the
following API commands from the 3rd party device to the
XN-125 controller:

To initiate an X-Wave LED pattern on an X-Wave connected
to X-talk interface 002, send one of the following API
example commands from the 3rd party device to the XN-
125 controller:

The XN-125 Xperience controller has 2 X-talk interfaces to which any combination of Elements can be connected. For
example, two of the examples in this Quick Start Guide can be combined on a single XN-125. The API commands and
operation will remain the same. When connecting multiple Elements that require a high amount of current (LEDs or push
buttons with LED ring), calculate the total required current of the Elements and check if this is within the specication of
the controller and its power supply source.
To set all button LEDs of a (touch) button interface
connected to X-talk interface 002 to “o”, send the
following API commands from the 3rd party device to the
XN-125 controller:
40% brightness, color 0 (white), 0.5 second ramp time
Blue pulsing pattern (99% to 20%), 1.8 second ramp time
White wave pattern moving to the left
X002A[255]
X002B[240005]
X002B[399C1801020C180018]
X002B[499018001200009]
X002A[0]
XW-L96
(X-Wave LED)
XW-L9
XN-125
(Xperience controller)
XY-240
(presence sensor)
USB-A to Micro-USB cable
(connect to 3rd party device)
XN
XW-L96
(X-Wave LED)
XW-L9
XN-125
(Xperience controller)
USB-A to Micro-USB cable
(connect to 3rd party device)
XN
XT-B4N
(4x bu�on interface)
XT-4F
(Touch bu�ons)
Push bu�ons
(with LED, 4x)
XT-B4 1 2 3 4
XN-125
(Xperience controller)
USB-A to Micro-USB cable
(connect to 3rd party device)
XN
