Nice Titan 912L User manual

Nice
Titan
912L
Vehicular Swing Gate Operator
Revision 5.1.0.0_6-2017
Gate
Operators
The Titan 912L Gate Operator is intended for use with vehicular swing
gates. The Titan 912L Gate Operator can be used in Class I, Class II and
Class III applications.
Part# 10001700

This page intentionally left blank.

TABLE OF CONTENTS
CAUTIONS AND NOTES 1
EXTREMELY IMPORTANT 1
DEFINITIONS COMPLIANT TO UL325 1
1- OVERVIEW 1
1.1 - Titan Swing Gate Opener 1
1.2 - Titan Swing Gate Opener Specifications
1
2 - GATE INFORMATION 1
2.1 - ASTM F2200
1
2.2 - Gate latches 2
2.3 - Specific applications 2
2.4 - Swing gates 2
2.5 - General requirements
2
3 - SAFETY AND CAUTIONS 2
3.1 - Properly installed safety devices
2
3.2 - Safety signs, notices to personnel warning signs
2
3.3 - Gate system safety devices 3
3.4 - Infrared beams and warning signs 3
3.5 - Establish the location
3
3.6 - Read and follow all instructions
3
3.7 - Keep children away 3
3.8 - Test the gate system
3
3.9 - Keep gates properly maintained 3
4 - PRE-INSTALLATION NOTES 3
4.1 - Follow instructions
3
4.2 - Intended usage
3
4.3 - Warnings, cautions and notes 3
5 - INSTALLATION PROCEDURES 5
5.1 - Pivot arm installation
5
Fig ure 5 - 1 P ULL T O O P EN INS TAL LATIO N
5
Fig ure 5 - 2 V ER TICAL P IV O T P O S ITIO N
5
5.2 - Push to open installation 6
Fig ure 5 - 3 P US H TO O P EN INS TALLATIO N
6
5.3 - Actuator mounting
6
F igu re 5 - 4 A CTUATO R MO UNTIN G
6
F igu re 5 - 5 G A TE B RACKET M O UNTING
6
5.4 - Manual release/manual operation 7
F igu re 5 - 6 M ANUAL REL EA S E D IS EN G AG E
7
F igu re 5 - 7 M AUAL REL EA S E R E- ENG AG E
7
5.5 - Titan actuator wiring
8
Fig u re 5 - 8 MAUAL RELEASE HANDLE
8
Fig ure 5 - 9 WIRE H AR NES S IN S ERTIO N
8
Fig u re 5 - 10 TITAN ACTUATO R WIRING
8
5.6 - Control board wiring 9
F igu re 5 - 11 WIRING D IA G RAM F O R 10 5 0 CO NT RO L BO ARD
9
F igu re 5 - 12 WIRING D IA G RAM F O R 9 3 6 CO NT RO L BO ARD
9
5.7 - Limit switch adjustment
10
F igure 5- 13 LIM IT SWIT C H A D JUST M E N T 10
F igu re 5 - 14 LIMIT L ED LO CATIO N 10 5 0 C O NT R O L BO ARD
10
F igu re 5 - 15 LIMIT L ED LO CATIO N 9 3 6 C O NT R O L BO ARD
10
6 - GENERAL LAYOUT AND SAFETY ACCESS 11
F igu re 6 - 1 L AY O UT F O R IN - G RO UND L O O P S
11
F igu re 6 - 2 L AY O UT F O R P H O TO CEL LS
11
7 - ACCESSORIES AND SENSORS 12
8 - INSPECTION AND OPERATION 13
9 - EMERGENCY VEHICLE ACCESS 13

1
• Vehicular Swing-Gate Operator (or system) - A vehicular
gate operator (or system) that controls a gate which swings
or rotates in a direction that is intended for use for vehicular
entrance or exit to a drive, parking lot, or the like.
• Gate - A moving barrier such as a Swinging, sliding, raising,
lowering, rolling, or like barrier that is a stand-alone passage
barrier or is that portion of a wall or fence system that
controls entrance and/or egress by persons or vehicles and
completes the perimeter of a defined area.
• Residential Vehicular Gate Operator - Class I - A vehicular
gate operator (or system) intended for use in a home of one
to four single family dwellings, or a garage or parking area
associated therewith.
• Commercial / General Access Vehicular Gate Operator -
Class II - A vehicular gate operator (or system) intended for
use in a commercial location or building such as a multi-
family housing unit (five or more single family units), hotel,
garages, retail store, or other buildings servicing the general
public.
• Commercial / General Access Vehicular Gate Operator -
Class III - A vehicular gate operator (or system) intended for
use in an industrial location, loading dock area, or other
location not intended to service the general public.
912L
The Titan 912L swing gate operator delivers the next generation of
easily installed, configured and maintained swing gate operators
from Nice. With a maximum gate capacity of 600 lbs and 20 ft,
this operator has a key lockable manual release, easily accessible
limit switch settings as well as simple in-the-field maintenance and
repair. The Titan gives dealers, installers and homeowners the
ability to take control of their access and security systems. This
operator includes a 2-year factory warranty against manufacturing
defects and lifetime customer support.
operator

2.2 - Gate latches
2.4 - Swing gates
and slide g control
point to or
or slide
autono
periodic schedule.
2.5 - General requirements
countless
AUTOMATIC GATES ARE
NOT FOR PEDESTRIANS!
3 - SAFETY AND CAUTIONS
WARNING
IMPORTANT SAFETY INSTRUCTIONS
WARNING - TO REDUCE THE RISK OF INJURY OR DEATH READ AND
FOLLOW ALL INSTRUCTIONS.
3.1 - Properly installed safety devices
3.2 - Safety signs, notices to personnel warning signs
danger posed
tlashing lamp that is
acti te tim
2
This swing gate actuator is intended for those locations where vehicle traf-
(gate). The Titan 912L actuator is only to be used in conjunction with Nice
brand control boards. If the gate, actuator and control system are not fully
closed off from public access, the opening and closing of the gate system
may result in severe damage, injury or death.
In association with this gate actuator and this (these ) swing gate(s), at no
time should manual gate latches or locks be used. The forces applied to a
swing gate by the actuator could be in excess to those forces which are safe
for bystanders. Should unnecessary forces be applied to a gate system,
such as a manual lock or impediment, catastrophic failure of the gate,
actuator or control system could result in substantial damage, extensive
physical injury or death.
for vehicular traffic. They are powerful and
safety, security and longevity throughout the life of the system.
required for that specific installation. Care should always be used during
installation!
qualified service person make repairs to gate hardware.

main
them regu
application.
4.1 - Follow Instructions
4.2 - Intended usage
4.3 - Warnings, cautions and notes
can
can
incorporated in all installations.
tions.
and shoul
d
3.3 - Gate system safety devices
3.4 - Infrared beams and warning signs
3.5 - Establish the location
3.6 - Read and follow all instructions
3.7 - Keep children away
3.8 - Test the gate system
release.
3.9 - Keep gates properly maintained
i
technicians are not recommended.
4 - PRE-INSTALLATION NOTES
the application.
operator.
gate operation.
reach through gate
3
THIS ACTUATOR IS INTENDED FOR USE WITH VEHICULAR
SWING GATES ONLY, WHEN COMBINED WITH A NICE BRAND
CONTROL BOARD.
for these warnings, cautions and notes are intended to
an automatic gate system is installed.

4
4.3.53 All gate systems must utilize a monitored contact or non-contact
presence detection sensor.
4.3.55 Hardwired contact or non-contact sensors to signal the gate
actuator of entrapment conditions are recommended.

5
5 - INSTALLATION PROCEDURES
OVERHEAD VIEW
FIGURE 5 - 1 PULL TO OPEN INSTALLATION
FIGURE 5 - 2 VERTICAL PIVOT POSITION
VERTICAL POSITION OF PIVOT ARM
SIDE VIEW
The top edge of the Pivot Arm will be located 1/2”
below the center line for the gate bracket. The Pivot
Arm must be level when secured.
NOTE If you have columns built around
your gate hinge post, check these
measurements for proper clearance
before proceeding with this pull to
open installation.
5.1 - Pivot Arm Installation
IMPORTANT - Never weld parts to the gate or posts when the operator circuit board is powered. Doing so may
damage the board beyond repair.
PULL TO OPEN INSTALLATION - PIVOT ARM INSTALLATION - Location of Pivot Point
The following instructions provide up to 105° of swing.
Measurements are taken from the center of pivot of the gate hinge.
The pivot arm needs to be securely mounted to the hinge post or equivalent mounting surface. It is recommended to weld
the pivot arm to a metal post. In order to achieve the correct articulation, geometry and rate of speed of the gate it is
critical that the measurements below are followed. The pivot arm may need to be cut to achieve the correct placement of
the actuator mounting hole. Measurements are taken from the center of pivot of the gate hinge.
Center line of
attachment point
for gate bracket
Hinge Post

5.2 - Push to open installation
PIVOT ARM INSTALLATION - Location of Pivot Point
Measurements are taken from the center of pivot of the gate hinge.
The pivot arm needs to be securely mounted to the hinge post or equivalent mounting surface. It is recommended
to weld the pivot arm to a metal post. In order to achieve the correct articulation, geometry and rate of speed of the
gate it is critical that the measurements below are followed. The pivot arm may need to be cut to achieve the correct
placement of the actuator mounting hole. Measurements are taken from the center of pivot of the gate hinge.
DIRECTION OF OPENING
GATES CLOSED
HINGE POST HINGE POST
LEFT HAND SWING RIGHT HAND SWING
TOP VIEW
6”
11”
6”
11”
5.3 - Actuator mounting
Mount the actuator to the pivot arm as shown.
Please notice the washer goes below the actuator
The lock nut should be tight to prevent movement or
shifting when the actuator is running. This will also
prevent excessive “bounce” or “wobble” when the gate
stops moving.
FIGURE 5 - 3 PUSH TO OPEN INSTALLATION
FIGURE 5 - 4 ACTUATOR MOUNTING
6
FIGURE 5 - 5 GATE BRACKET MOUNTING

7
Manual Release In
Engaged Position
RUBBER
KEY
COVER
5.4 - Manual release/manual operation
1. Close handle
2. Rotate key 90° counterclock wise
and remove key.
3. Replace rubber key cover.
4. Operator is now in re-engaged in
Automatic Mode (manual
operation is not possible).
Manual Release Re-engage
FIGURE 5-7 MANUAL RELEASE RE-ENGAGE
1. Lift rubber key cover and insert
key into lock and rotate 90°
clockwise.
2. Lift handle
3. Actuator is now Disengaged
(manual operation is possible).
Manual Release Disengage
Manual Release in
Disengaged Position 90°
FIGURE 5-6 MANUAL RELEASE DISENGAGE
