Norac UC4+ User manual

Hagie 2005 STS
Installation Manual
Spray Height Controller
Improving the competitiveness of Industry and
Agriculture through Precision Measurement

Printed in Canada
Copyright  2005-08 by NORAC Systems International Inc
Reorder P/N: UC4+BC+HG3-INST Rev F (Hagie 2005 STS)
NOTICE
NORAC Systems International Inc reserves the right to improve products and their specifications without notice and without the
requirement to update products sold previously Every effort has been made to ensure the accuracy of the information contained
in this manual The technical information in this manual was reviewed at the time of approval for publication

TABLE OF CONTENTS
1 INTRODUCTION .................................................................................................................................. 1
2 GENERAL SYSTEM DESCRIPTION .................................................................................................. 2
3 PARTS LISTS ...................................................................................................................................... 3
4 INSTALLATION PROCEDURE ........................................................................................................... 8
4.1 WING SENSOR INSTALLATION......................................................................................................... 8
4.2 MAIN LIFT SENSOR INSTALLATION ................................................................................................ 11
4.3 ROLL SENSOR INSTALLATION ....................................................................................................... 12
4.3.1 Boom Roll Sensor Mounting.................................................................................................. 13
4.3.2 Chassis Roll Sensor Mounting ..............................................................................................14
4.3.3 Temperature probe................................................................................................................ 14
4.4 HYDRAULIC INSTALLATION ........................................................................................................... 15
4.4.1 Valve Mounting...................................................................................................................... 15
4.4.2 H draulic Plumbing ............................................................................................................... 16
4.5 ELECTRICAL INSTALLATION .......................................................................................................... 17
4.6 COMPLETING THE INSTALLATION .................................................................................................. 18
5 ELECTRICAL REFERENCE – CABLE DRAWINGS ........................................................................ 1
5.1 ITEM C03: 44656D – VALVE CABLE VARIABLE RATE DT.............................................................. 1
5.2 ITEM C04: 44664 – CABLE UC4 CAN NODE DUAL...................................................................... 1
5.3 ITEM C05: 44687 – CABLE UC3 SENSOR AMPM TO AMPF .......................................................... 20

1
1 INTRODUCTION
Congratulations on your purchase of the NORAC UC4+ Spray Height Controller This system is
manufactured with top quality components and is engineered using the latest technology to
provide operating features and reliability unmatched for years to come
When properly used the system can provide protection from sprayer boom damage, improve
sprayer efficiency, and ensure chemicals are applied correctly
Please take the time to read this manual completely before attempting to install the system A
thorough understanding of this manual will ensure that you receive the maximum benefit from
the system
YOUR INPUT CAN HELP MAKE US BETTER! If you find issues or ha e suggestions
regarding the parts list or the installation procedure, please don’t hesitate to contact us ia
the information gi en below:
Phone: [phone] Canada (Toll Free)
1-866-306-6722 United States (Toll Free)
([phone] Europe
1-306-664-6711 all other regions
E-mail: ser [email protected]
Website: www.norac.ca

2
2 GENERAL SYSTEM DESCRIPTION
Figure 1 depicts the general system layout of the UC4+ Spray Height Control system Some of
your parts may look different and you may not have all the parts shown here
Figure 1 – System Components and General Location
NOTICE:
Every effort has been made to ensure the
accuracy of the information contained in this
manual All parts supplied are selected
specially to fit the sprayer to facilitate a
complete installation However, NORAC
cannot guarantee all parts fit as intended due
to the variations of the sprayer by the
manufacturer Please read this manual in
its entirety before attempting installation.
ATTENTION:
When installing the UC4+ Spray Height
Control system please be aware that at a
point in the installation your sprayer booms
will be inoperative until the installation is
complete Any installation procedure
requiring boom mo ement will need to be
done first. Once the hydraulics have been
disconnected you must complete the
electrical installation before the booms
become operative

3
3 PARTS LISTS
The parts that come with your UC4+ Sprayer Boom System are listed in Table 1. The item number on
the left side of this table references each part
Please ensure that all parts in your kit are present before proceeding with your installation.
Table 1 – Hagie 2005 STS Spray Height Control system Parts
Item Part Number Name Quantity
B06 105728 RAM-233 RAIL MOUN ADAP ER KI FOR RAM-202 BASE 1
B11 44743 MOUN ING BRACKE MAIN LIF SENSOR UC4 PLUS 1
B13 44728 MOUN ING BRACKE COMPLE E UC4 BREAKAWAY EX ENDED 2
B16 44695-11 MOUN ING BRACKE BREAKAWAY ADAP ER UC3 SENSOR NI RO/HAGIE 2
C03 44656D CABLE VALVE VARIABLE RA E D 1
C04 44664 CABLE UC4 CAN NODE DUAL 5 F 1
C05 44687 CABLE UC3 SENSOR RUNK P EX ENS ION AMPM O AMPF BLACK 14FEE 1
E01 4461BC+HG UC4 PLUS BOOM CON ROL PANEL HAGIE 1
E02 44631 UC4 UL RASOUND SENSOR 3
E03 44641 UC4 PLUS ROLL SENSOR W EMPERA URE PROBE 1
E04 44642 UC4 PLUS ROLL SENSOR 1
H20 44865-15 HYDRAULICS FI ING KI - HG3 1
M01 446BC+MAN7 OPERA OR MANUAL UC4+ SPRAY HEIGH CON ROL 1
M10 UC4+BC+HG3-INS MANUAL INS ALLA ION UC4+ HAGIE 2006 S S 1
V01 44963D VALVE BLOCK ASSEMBLY 2 S A ION CC/LS PROP D 4 BOL 1

4
Substitution parts will in no way affect the operation of the system pro ided that they are installed
as directed.
Item V01 – 2 Station Val e Block (44963D) may be substituted with:
Item Part Number Name Quantity
V01 44933D VALVE BLOCK ASSEM UC4-BC 2-S A ION CC/LS VARIABLE RA E 1
The 44933D is a direct replacement for the 44963D Both valve blocks function the same The blocks
are identifiable by the filter cap shape and by the part number stamped on the side
The A and B ports are opposite on each al e block so erify that the hoses are being connected to
the correct port. The raise lines always go to the “B” port and the lower lines go to the “A” port.
44933D Val e Block Shown Alongside 44963D Val e Block
Filter Cap Part Number
(44933D)
Filter Cap Part Number
(44963D)

5
Table 2 – 44865-15 - Hydraulics Fittings Kit Details
Item Part Number Name Quantity
F04 103071 MALE 90 DEGREE ADAP ER - 8MB 6MJ90 2
F05 103312 MALE ADAP ER - 6MB-6MJ 6
F08 105011 ORIFICE INSER .026 IN ONE WAY 2
6 M B - 6 M OR X 90
SIZE IN
1/16 TH'S
GENDER: MA E
OR FEMA E
90 ° ANG E
SWIVE
TYPE
GENDER
SIZE
TYPE:
B - ORB
J - JIC
OR - F AT
FACE
P - PIPE
Fitting Name
Example:
The use of dielectric grease is not recommended on any NORAC electrical connections.
To ensure all stainless steel hardware does not gall or seize apply a light coating of the supplied
Permatex Anti-seize grease to all threaded parts upon installation. Permatex Anti-seize lubricant is
preferred, but other similar anti-seize products may be used.

6
The parts that come with your UC4+ Spray Height Control system are shown below in their general
installation configuration.
Figure 2 – UC4+ Spray Height Control Components

7
Figure 3 – Hydraulic Plumbing Schematic

8
4 INSTALLATION PROCEDURE
4.1 W ING S ENSOR I NSTALLATION
1 Assemble the Breakaway Sensor
Mounting Brackets (B11) as show in
Figure 4 and Figure 5
Figure 4 – Breakaway Sensor Bracket
Exploded View
Figure 5 – Breakaway Sensor Mounting
Bracket Assembly
To assemble the breakaway sensor
bracket:
a) Assemble the bolt and nut into the
collar
b) Grease the bottom edge of the collar
and the angled tube of the base
c) Place the collar onto the angled tube
of the mounting base
d) Install the spring between the collar
and the upper ring of the base
e) Insert tube through assembly and
tighten the collar
2 Mount the sensor bracket onto the boom
If possible, mount the sensor
brackets while the booms are in
their folded position to ensure that
they will not interfere with
anything when the boom is folded
for transport.
3 The sensor mounting brackets can be
installed on the 45 degree tube using the
provided adapter plate (B16) Then
attach B13 directly to B16
Mounting the sensor bracket to
the break-away section of the
boom may cause the boom to drop
suddenly as a break-away occurs.
This will occur on break-away
sections which lift as they break
away.
For optimal boom tip protection, it
is recommended that the sensor be
mounted within approximately
two feet (60cm) of the boom tip.
Please refer to the UC4+ Spray Height
Control system warranty at the end of
the UC4+ Spray Height Control
Operator’s Manual (M01) for
implications
4 Mount the NORAC UC4+ ultrasonic
sensor (E02) into the sensor brackets

9
The sensors should be oriented forward
(ahead) of the boom (see Figure 6 and
Figure 8)
When installing the UC4+ sensors
(E02), start with the smallest serial
number on the left hand side
proceeding to the largest serial
number on the right hand side
(Figure 9).
5 Sensor cables should run through the
mounting bracket tube and then behind
the member the bracket is mounted onto
Cable-tie the connector in place The
cable must not be allowed to hang below
the boom (Figure 6)
Figure 6 – Another Acceptable Mounting
A oid mounting sensors in
locations where they may read
from parts of the boom as shown
in Figure 7.
Figure 7 – Poor Mounting
(Sensor Reading off Boom)
General mounting rules for UC4+
ultrasonic wing sensors:
a) In its lowest position, the sensor
mouth must be 9 inches or more
from the ground
b) The bottom of the sensor must be at
least 9 inches in front of the spray
nozzles
c) The bottom of the sensor must be at
least 9 inches above the spray
nozzles
d) Ensure that there are no obstructions
within a 12-inch diameter circle
projected directly below the center of
the sensor
e) The sensor should be approximately
vertical at normal operating heights
Figure 8 – Sensor Mounting Guidelines
A
D
C
Ultrasonic
Acoustic Cone

10
Figure 9 – Sensor Serial Number Installation Location
3 SENSOR SYSTEM
5 SENSOR SYSTEM

11
4.2 M AIN L IFT S ENSOR I NSTALLATION
1 Assemble the main lift sensor bracket
(B11) as shown in Figure 10
Figure 10 – Main Lift Sensor Bracket
2 The bracket should be mounted to the
lowest frame member on the center
section of the sprayer The bracket
should be mounted so the sensor
mounting collar is approximately in the
center of the sprayer
Make sure the sensor has
clearance when the main section is
raised and lowered.
3 Mount the sensor onto the sensor
mounting collar
4 The final assembly is shown in Figure
11
Figure 11 – Main Lift Sensor Bracket
Mounting Position
General mounting rules for ultrasonic
main lift sensor:
a) Mount the sensor at the midpoint of
the main lift section
b) The sensor must have a 12-inch
diameter clear view of the ground
without any obstructions
c) Ensure that there will be no contact
between the sensor and the booms
when folding and unfolding, or
raising and lowering
d) The bottom of the sensor must be at
least 9 inches in front or behind the
spray nozzles
e) The bottom of the sensor must be at
least 9 inches above the spray
nozzles
Figure 12 - An example of how to mount
the main lift sensor on a front mounted
boom
Bracket Tube
Sensor
Mounting Tab
Sensor Mounting
Collar
Bracket Base

12
4.3 R OLL S ENSOR I NSTALLATION
To mount the roll sensors, the roll sensor
brackets will have to be bent The brackets
are supplied with a 90° bend and must be
bent to a 45° bend to fit properly on the
frame members
Mount the roll sensors to the included roll
sensor brackets using the machine screws
and nylon lock nuts, as illustrated in Figure
13
The roll sensors must be mounted
tightly to the brackets
Figure 13 – Mounting the Roll Sensor to
the Roll Sensor Mounting Bracket
When mounting the roll sensors use the
following guidelines and refer to Figure 14
1 Ensure the roll sensors are sitting
relatively level when the sprayer chassis
and boom are level
2 Both roll sensors must be mounted with
the circular AMP connector facing
towards the Right-Hand Wing (when
looking from the rear of the sprayer)

13
Figure 14 – Mounting Guidelines
Figure 15 – Roll Sensor Mounting with Respect to Sprayer Orientation
4.3.1 Boom Roll Sensor Mounting
The boom roll sensor is the roll sensor with
the temperature probe attached to it (E03)
To mount the boom roll sensor refer to these
guidelines
1 The boom roll sensor must be attached to
the center part of the boom
2 Use cable-ties to secure the bracket to a
square edge feature (square tube)
3 The AMP (circular) connector must be
pointing to the right hand wing (when
looking from the rear)
4 The ring terminal on the boom roll sensor
is a temperature probe and must be
attached to the side of the valve block
(Section 4.3.3)
The roll sensors must be
mounted with the Amp
connectors pointing to
the right.
Chassis
Roll
Sensor
Boom
Frame
Roll
Sensor

14
4.3.2 Chassis Roll Sensor Mounting
The chassis roll sensor must be attached to
the chassis of the sprayer To mount the
chassis roll sensor, refer to the following
guidelines
1 The chassis roll sensor does not have a
temperature probe (E04)
2 Cable-tie the bracket to a square edge
(square tube)
3 The AMP (circular) connector must exit
towards the right hand wing (when
looking from the rear)
Figure 16 - Chassis Roll Sensor Mounting Location
4.3.3 Temperature probe
Fasten the temperature probe (E03) to the
UC4+ valve block using the included
3/8x1/2” bolt as illustrated in Figure 17
Figure 17 – UC4+ Val e Block with
Temperature Probe Installed

15
4.4 H YDRAULIC I NSTALLATION
WARNING!
The hydraulic system creates ery high
pressure. Before disconnecting any
hydraulic lines ensure all pressure has
been bled from the system. When
changing the boom hydraulic hoses lea e
the booms in TRANSPORT POSITION.
IMPORTANT:
Component failure due to oil
contamination is not co ered under the
UC4+ Spray Height Control system
warranty. It is recommended that a
qualified technician does the hydraulic
installation.
Depending on the al e block part
number, the A and B ports may be
re ersed. Ensure that the orifices are
oriented properly for the A and B ports
or the system will not function properly.
4.4.1 Valve Mounting
1. On a clean surface remove all plastic
plugs from the NORAC hydraulic Valve
(V01) (Figure 18)
44963D
44933D
Figure 18 – NORAC Val e Block
2. Install the orifices (F08) into the "A"
ports with the notch facing inward as
shown in Figure 19
3. Install the 6MB-6MJ fittings (F05) into
the A and B ports and tighten to 18 ft-
lbs
4. Install 6MB-6MJ fittings (F05) into the
P and T ports and tighten to 18 ft-lbs
44963D

16
44933D
Figure 19 – Val e Block Assembly
5. Mount the NORAC valve (V01) to the
left side of the sprayer, on the center
rack, using the supplied bolts (Figure
20) The NORAC valve block should
mount to a valve mounting plate along
with the Hagie valve block
Figure 20 – Val e Mounting Location
4.4.2 Hy raulic Plumbing
WARNING!
From this point in the installation the
booms will be inoperati e until the
electronics are fully installed.
After the NORAC valves are mounted, the
hydraulic hoses and fittings can be plumbed
The plumbing for the hydraulic circuit is
shown schematically in Figure 3
The “B” lines of the NORAC al e
block must be connected to the
Hagie “raise” lines.
Ensure there are no other orifices
present between the NORAC al e
block and the boom cylinders.
You must ensure no hydraulic
components will interfere with any
sprayer parts or be pulled tight at
any time.
Pressure and
Tank Lines

17
4.5 E LECTRICAL I NSTALLATION
1. Install the UC4+ Control Panel (E01) in
the cab of the sprayer Mount the panel
where it will be clearly visible and
within easy reach of the operator
In the Hagie cab, a good spot to
mount the UC4+ control panel is
on the right hand side of the cab,
next to the spray controller
Figure 21 – Control Panel Mounting
If mounting the panel to a round
pole, use the rail mount adapter
kit (B06) (Figure 22).
Figure 22 – Mounting the Control Panel
Using the Adapter Kit (B06)
Depending on the al e block part
number, the “UP” and “DOWN”
connectors will be on opposite sides of the
block.
2 The connectors on the valve cable (C03)
are marked RIGHT UP, LEFT UP,
RIGHT DOWN and LEFT DOWN
• Cables labeled with DOWN go on the
same side as the hydraulic hoses on the
44933D block
• Cables labeled with UP go on the same
side as the hydraulic hoses on the
44963D block
44933D
44963D
Figure 23 – Val e Cable Connections
ROP
