Norac UC4 Total Control User manual

UC 4
Total Control
Automatic Boom Height
System
Hardi OEM End-User
Installation Manual
Canada
NORAC Systems International Inc.
CALL TOLL FREE: 1-800-667-3921
[phone]
SHIPPING ADDRESS:
3702 Kinnear Place
Saskatoon, SK
S7P 0A6
United States
NORAC, Inc.
CALL TOLL FREE: 1-866-306-6722
[phone]
SHIPPING ADDRESS:
1290 Osborne Rd. NE, Suite F
Fridley, MN
55432-2892
For other service locations please view our website:
www.norac.ca
Improving the Competitiveness of Industry and Agriculture through
Precision Measurement

Printed in Canada
Copyright 2006 by NORAC Systems International Inc.
Reorder P/N: UC4-BC-HD3-INSTE Rev A
NOTICE
NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and without
the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information
contained in this manual. The technical information in this manual was reviewed at the time of approval for publication.

1 INTRODUCTION
Congratulations on your purchase of the NORAC UC4 automated sprayer boom
height control system. This system is manufactured with top quality components
and is engineered using the latest technology to provide operating features and
reliability unmatched for years to come.
Your height control system has been factory installed to your Hardi sprayer by
Hardi Inc, however a few small steps are required to install the system interface to
your tractor. This document describes these instructions.
2 NORAC CONTACT INFORMATION
Phone: [phone] in Canada (Toll Free)
1-866-306-6722 in the United States (Toll Free)
0-800-404-8389 in the United Kingdom (Toll Free)
1-306-664-6711 all other regions
Website: www.norac.ca E-mail: [email protected]
3 PARTS LIST
The parts that come with your UC4 Hardi End User Kit are listed in Table 1. In
this document, the item number shown on the left side of this table references each
part.
Table 1 – HD3E Kit Parts
Item Number Part #
Item Description
Quantity Per Units
C10 44650-35 CABLE POWER GENERIC PULL-TYPE 1 EA
E1 4461BC-HD UC4 OEM BOOM CONTROL PANEL HARDI 1 EA
M13 UC4-BC-HD3-INSTE MANUAL INSTALLATION END-USER HARDI AUS 1 EA
M1A 446BC-MAN5-1 BOOM CONTROL 2007 TECHNICAL LARGE
BOOKLET
1 EA
M2 100609 BOLT HEX NC GR5 PLTD 3/8X1/2 FOR LOAD PINS 1 EA
M2A 446BC-MAN5-2 MANUAL UC4 BOOM CONTROL 2007 QUICK
REFERENCE SMALL BOOKLET
1 EA
M4 104409 FOAM DISC 45 PPI CONDUCTIV 1/2 X 2-3/4 DIA 6 EA
M5 105435 CHAIN 1/2 IN PLASTIC 126 IN
M6 100660 BOLT HEX NC GR5 PLTD ¼ X 1 3 EA
M7 100853 NUT HEX HC GR5 PLTD ¼ IN 3 EA

2
ROP
4 CONTROL PANEL MOUNTING
Install the UC4 Control Panel (Item E1) in the cab of the sprayer with the supplied
mounting bracket. Mount the panel where it will be clearly visible and within easy
reach of the operator. The location must facilitate connecting the UC4 power cable
(Item C10) to the bottom of the UC4 Control Panel.
Generally, a good spot to mount the UC4 Control Panel is on the right hand side of
the cab to the ROP (Roll-Over Protection) Bar. Hardware is included for mounting
the Panel (Item M6 and M7).
Figure 1 – Control Panel Mounting
Figure 2 – Hole Spacing for Adjustable UC4 Panel Mount

3
5 CABLE INSTALLATION
Figure 3 – Cable Configurations: C10 and C11, Viewed from rear of tractor
1. Connect C10 to the UC4 Control Panel in the sprayer cab. Ensure that both
plugs (P16A and P4) are connected to the panel.
2. Connect the 3-pin AMP connector of C10 to an auxiliary power connection
inside the cab.
-If an appropriate connector can not be found, it may be necessary to
cut off the connector(s) and splice into the existing wiring. Optional
power interface cables can also be ordered.
3. Route the receptacle end (R16) of C10 to the exterior of the cab and connect
to C11 at the hitch. Ensure cable is routed in a safe manner to avoid damage.

4
6 COMPLETING THE INSTALLATION
1. Turn on the power for the UC4 Control Panel using the switch on the side of its
chassis. Ensure that the display lights up to confirm that the panel has proper
+12 Volt power.
2. After a moment the UC4 panel will display the Main Operational Screen:
↓32 MM 35↓
3. For optimal performance, the UC4 system must calibrate itself to the tractor
unit powering the sprayer hydraulics, which is an automated process.
Performing a RETUNE requires that the sprayer is unfolded and the
booms have full range of moment. This should also be performed on a flat
area of ground, over gravel or dirt. Do not attempt to perform a retune
over grass.
4. To initiate the RETUNE process, navigate from the Main Operational Screen to
the “RETUNE” menu, following the instructions below:
•Using the left-hand toggle switch on the UC4 panel, toggle the switch down
towards “Setup” until ↓RETUNE?↓ appears on the display.
•At this point, answer YES to the panel by toggling the right-hand toggle
switch up towards “Yes”.
•The panel will start the RETUNE process. Follow the on-screen prompts.
Additional information concerning the RETUNE procedure may be found in the:
•Norac Technical Manual and the
•Norac Quick Reference Manual
5. The installation of the UC4 system is now complete. Refer to the Quick Guide
(Item M2A) for operation instructions.
