Nortel 2033 Specification sheet

IP Audio Conference Phone 2033 Emissions Statement
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/television technician for help.
The user should not make any changes or modifications not expressly approved by Nortel. Any such
changes could void the user’s authority to operate the equipment.
Refer to the Nortel IP Audio Conference Phone 2033 User Guide for full regulatory information.
Copyright © 2007 Nortel Networks. All rights reserved.
Document Number: NN43111-102
Document Version: Standard 01.02
Date: June 2007
To provide feedback or report a problem in this document, go to www.nortel.com/documentfeedback.
Nortel IP Audio Conference Phone
2033
Getting Started
IP Audio Conference Phone 2033
Basic Operation

This Getting Started Card describes the Nortel IP Audio Conference Phone 2033. The IP
Audio Conference Phone 2033 brings voice and data to the tabletop audio conference
environment by connecting directly to a Local Area Network (LAN) through an Ethernet
connection.
The design of the IP Audio Conference Phone 2033 provides single-button access to
functionality and features to maximize personal productivity and efficiency.
The IP Audio Conference Phone 2033 includes a superior display to present information to
the user, making it easy to use. The three soft keys guide users through feature use as
supported on any Nortel communication system.
For feature descriptions and provisioning information regarding the use of your IP Audio
Conference Phone 2033 on a specific Nortel communication system, refer to the
documentation provided with the system, including the Nortel IP Audio Conference Phone
2033 User Guide.
Installing the IP Audio Conference Phone 2033
Refer to the picture of the bottom of the IP Audio Conference Phone 2033, the Power
Interface Module (PIM), and the Extension microphone on this card.
Step 1
Plug one end of the CAT5 Ethernet cable into the data network port on the PIM. Plug the
other end of the cable into your IP network interface.
Step 2
Plug one end of the AC power adapter cord to the power supply port on the PIM. Thread
the cord through the channel on the bottom of the PIM, and plug the other end of the cord
into the AC power source.
Step 3
The middle port of the PIM has an attached CAT5 Ethernet cable. Plug the other end of this
cable into the PIM port on the telephone, and thread the cable through the channels on the
bottom of the telephone.
Step 4
To connect an extension microphone, thread the microphone cord through the channels on
the bottom of the telephone and plug the cord into one of the extension microphone jacks
on the bottom of the telephone.
Make a Call
Press the Line key to make a call using the IP Audio Conference Phone 2033, and enter
the phone number on the Dialpad. Once the called party has answered, speak in the
direction of the microphone, either on the telephone or the extension microphone, to be
heard by the person you are calling. When your call is complete, press the Release
(Goodbye) key to terminate the call.
Answer a Call
Press the Line key to answer a ringing call.
Place a Call on Hold
While on a call, press the Hold key to place the caller on hold. Press the Line key to
retrieve your call.
Mute a Call
While on a call, press the Mute key on the main unit or any extension microphone to mute
all microphones. You will be able to hear the other person on the call, but they will not be
able to hear you. To un-mute the microphones, press any Mute key again.
Volume Control
Press the Volume control keys to adjust the volume of the ringer and speakers.
