Nortel Communication Server 1000
ISDN Primary Rate Interface
Installation and Commissioning
NN43001-301
.

Document status: Standard
Document version: 02.03
Document date: 7 December 2007
Copyright © 2003-2007, Nortel Networks
All Rights Reserved.
Sourced in Canada
LEGAL NOTICE
While the information in this document is believed to be accurate and reliable, except as otherwise expressly agreed
to in writing NORTEL PROVIDES THIS DOCUMENT "AS IS" WITHOUT WARRANTY OR CONDITION OF ANY
KIND, EITHER EXPRESS OR IMPLIED. The information and/or products described in this document are subject
to change without notice.
Nortel, the Nortel Logo, the Globemark, SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.
All other trademarks are the property of their respective owners.

3
Contents
New in this release 9
Other 9
Revision History 9
How to get help 11
Getting help from the Nortel web site 11
Getting help over the telephone from a Nortel Solutions Center 11
Getting help from a specialist by using an Express Routing Code 11
Getting help through a Nortel distributor or reseller 12
Introduction 13
Subject 13
Applicable systems 13
Intended audience 14
Related information 14
ISDN Primary Rate Interface equipment overview 15
Contents 15
Introduction 17
Primary Rate Interface (PRI) hardware requirements 17
ISDN Signaling Link (ISL) hardware 18
D-Channel Handler description 20
NT6D11 DCH 20
QPC757 DCH 21
NT6D80 MSDL 23
NTBK51 Downloadable D-Channel Daughterboard 25
Standard PRI cards 25
NT8D72 PRI2 25
QPC720 PRI 30
Disk drive hardware 34
NT5D97 Dual-port DTI2/PRI2 card 34
NT5D12 Dual-port DTI/PRI 57
DCH installation 79
Contents 79
Install the NT6D11AB, NT6D11AE, NT6D11AF DCH 79
Set up the NT6D11AB, NT6D11AE, NT6D11AF DCHI 80
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

4Contents
Install the NT6D11AB, NT6D11AE, NT6D11AF DCHI 85
Remove the NT6D11AB, NT6D11AE, NT6D11AF DCH 86
Install the QPC757 DCH 87
NTBK51 DDCH installation and removal 91
Contents 91
Introduction 91
Install NTBK51 DDCH on NT5D97 dual-port DTI2/PRI2 card 91
Remove NTBK51 DDCH from NT5D97 dual-port DTI2/PRI2 card 92
Install NTBK51 DDCH on NT5D12 dual-port DTI/PRI 93
Remove NTBK51 DDCH from NT5D12 dual-port DTI/PRI 94
MSDL installation for all systems 95
Contents 95
Install the MSDL 95
Replace the MSDL 98
NT8D72 and QPC720 PRI card installation 101
Contents 101
Introduction 101
PRI circuit pack locations 101
Cable requirements 102
Switch settings 120
Install NT8D72 and QPC720 PRI cards on Large Systems 123
Remove NT8D72 and QPC720 PRI cards from Large Systems 124
Install an additional network shelf 125
NT5D97 Dual-port DTI2/PRI2 installation and removal 127
Contents 127
Introduction 127
NT5D97 circuit card locations 127
Port definitions 128
Case Scenarios for replacing a digital trunk NT8D72BA, QPC536E, or NTCK43
by a DDP2 card 128
NT5D97AA/AB DIP switch settings 129
NT5D97AD DIP switch settings 134
Install the NT5D97 DDP2 139
Remove the NT5D97 DDP2 140
Configure the NT5D97 DDP2 141
NT5D12 Dual-port DTI/PRI card installation 143
Contents 143
Introduction 143
NT5D12 circuit card locations 143
Port definitions 144
Scenarios for replacement of a digital trunk card (QPC720/QPC472) by a DDP
card 144
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

Contents 5
NT5D12 switch settings 145
Install the NT5D12 DDP 150
Remove the NT5D12 DDP 152
Configure the NT5D12 DDP 153
Clock Controller description and installation 155
Contents 155
Introduction 156
Description 156
Installation procedures 168
ISL installation 179
Contents 179
ISL configurations 179
DCHI switch settings 180
MSDL switch settings 181
Dedicated mode using leased line 183
Dedicated mode using dialup modem 184
ISL installation 189
Echo canceller installation 191
Contents 191
Introduction 191
Echo canceller operating parameters 191
Echo canceller initialization procedures 191
PRI to Echo canceller pin assignments 192
Electromagnetic Interference 192
1.5 Mb PRI implementation 195
Contents 195
Overview 195
Hardware requirements 195
Hardware description 196
Install PRI hardware 203
1.5 Mb DTI implementation 219
Contents 219
Overview 219
Hardware requirements 219
Hardware description 220
Install DTI hardware 220
Software enable the DTI/PRI cards 222
1.5 Mb ISL implementation 227
Contents 227
Overview 227
Hardware requirements 227
Basic ISL implementation 232
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

6Contents
2.0 Mb DTI implementation 237
Contents 237
Overview 237
Hardware requirements 237
NTAK10 2.0 Mb DTI card 238
Install DTI hardware 238
DTI software implementation 241
2.0 Mb PRI implementation 257
Contents 257
Overview 257
Hardware requirements 257
Hardware description 258
Install the NTAK79 PRI card 261
Install the NTBK50 PRI card 266
PRI software implementation 272
2.0 Mb ISL implementation 283
Contents 283
Overview 283
ISL hardware requirements 283
ISL hardware installation 286
ISL software implementation 288
Nonstandard cables 295
Contents 295
Introduction 296
NT5K40AA, NT5K41AA, NT5K86AA 296
NT8D7206, NT8D7207 296
QCAD128 297
QCAD129 298
QCAD133 298
NT8D7205 299
QCAD328 300
NT8D74 Clock Controller to InterGroup cable 301
NT8D75 Clock Controller to Clock Controller cable 301
NT8D79 PRI/DTI to Clock Controller cable 301
NT8D83 PRI/DTI to I/O cable 301
NT8D85 Network to IPE cable 302
NT8D86 Network to I/O cable 302
NT8D97AX PRI/DTI I/O to MDF cable 302
NT9J93AD PRI/DTI Echo Canceller to I/O cable 303
NTND26 PRI to MSDL cables 303
NTND27 MSDL to I/O panel cables 303
NTND98 PRI to I/O panel cables 303
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

Contents 7
Procedures
Procedure 1 Install the NT6D11AB, NT6D11AE, NT6D11AF DCH 85
Procedure 2 Remove the NT6D11AB, NT6D11AE, NT6D11AF DCH 86
Procedure 3 Install the QPC757 DCHI 87
Procedure 4 Remove the QPC757 DCH 90
Procedure 5 Install the NTBK51 on the NT5D97 dual-port DTI2/PRI2
card 92
Procedure 6 Remove the NTBK51 from the NT5D97 dual-port DTI2/PRI2
card 93
Procedure 7 Install the NTBK51 DDCH on the NT5D12 dual-port
DTI/PRI 94
Procedure 8 Remove the NTBK51 from the NT5D12 dual-port DTI/PRI
card 94
Procedure 9 Install the MSDL card 95
Procedure 10 Replace the MSDL card 98
Procedure 11 Install the NT8D72 and QPC720 PRI on Large Systems 123
Procedure 12 124
Procedure 13 Install an additional network shelf on Half Group and Single
Group systems 125
Procedure 14 Install the NT5D97 on Large Systems 139
Procedure 15 Remove the NT5D97 from Large Systems 141
Procedure 16 Install the NT5D12 on Large Systems 151
Procedure 17 Remove the NT5D12 DDP 152
Procedure 18 Install a clock controller for Half Group and Single Group
Systems. 171
Procedure 19 Install a Clock Controller on a Single Group and Multi Group
System 173
Procedure 20 Remove old equipment 175
Procedure 21 Installing new equipment 176
Procedure 22 Install ISL in dedicated mode 189
Procedure 23 Install ISL in shared mode 189
Procedure 24 Mounting the NTAK20 daughterboard on the NTRB21 203
Procedure 25 Inserting the NTRB21 TMDI card 205
Procedure 26 Removing the NTRB21 TMDI card 206
Procedure 27 Mounting the daughterboards on the NTAK09 206
Procedure 28 Removing the daughterboards from the NTAK09 207
Procedure 29 Installing the NTAK09 209
Procedure 30 Connecting the cables 209
Procedure 31 Enabling the NTRB21 TMDI card 210
Procedure 32 Enabling the NTAK09 DTI/PRI card 211
Procedure 33 Implementing basic PRI 212
Procedure 34 Enabling the NTRB21 TMDI card 222
Procedure 35 Enabling the NTAK09 card 222
Procedure 36 Implementing DTI 223
Procedure 37 Installing ISL hardware 230
Procedure 38 Implementing dedicated mode 232
Procedure 39 Connecting the cables 240
Procedure 261
Procedure 40 Connecting the cables 264
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

8Contents
Procedure 266
Procedure 41 Inspecting the NTBK50 circuit card 266
Procedure 42 Installing the NTAK02 286
Procedure 43 Setting up the D-channel 287
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

9
New in this release
There have been no updates to the document in this release
Other Revision History
December 2007 Standard 02.03. This document has been up-issued to support
Communication Server Release 5.5.
August 2007 Standard 01.03. This document has been up-issued to support a
change request.
June 2007 Standard 01.02. This document is up-issued to remove the Nortel
Networks Confidential statement.
May 2007 Standard 01.01. This document is issued to support Communication
Server 1000 Release 5.0. This document contains information
previously contained in the following legacy document, now retired:
ISDN Primary Rate Interface Installation and Commissioning
(NN43001-301). No new content has been added for Communication
Server 1000 Release 5.0. All references to Communication Server
1000 Release 4.5 are applicable to Communication Server 1000
Release 5.0.
August 2005 Standard 3.00. This document is up-issued to support
Communication Server 1000 Release 4.5.
September 2004 Standard 2.00. This document is up-issued for Communication
Server 1000 Release 4.0.
October 2003 Standard 1.00. This document is a new technical document for
Succession 3.0. It was created to support a restructuring of the
Documentation Library, which resulted in the merging of multiple
legacy technical documents. This new document consolidates
information previously contained in the following legacy documents,
now retired:
•ISDN Primary Rate Interface: Installation (553-2901-201)
•1.5Mb DTI/PRI: Description, Installation and Maintenance
(553-3011-310) (Content from 1.5Mb DTI/PRI: Description,
Installation and Maintenance (553-3011-310) also appears in
ISDN Primary Rate Interface Maintenance (NN43001-717).)
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

10 New in this release
•2.0Mb DTI/PRI: Description, Installation and Maintenance
(553-3011-315) (Content from 2.0Mb DTI/PRI: Description,
Installation and Maintenance (553-3011-315) also appears in
ISDN Primary Rate Interface Maintenance (NN43001-717).)
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

11
How to get help
This chapter explains how to get help for Nortel products and services.
Getting help from the Nortel web site
The best way to get technical support for Nortel products is from the Nortel
Technical Support web site:
http://www.nortel.com/support
This site provides quick access to software, documentation, bulletins, and
tools to address issues with Nortel products. From this site, you can:
•download software, documentation, and product bulletins
•search the Technical Support Web site and the Nortel Knowledge Base
for answers to technical issues
•sign up for automatic notification of new software and documentation
for Nortel equipment
•open and manage technical support cases
Getting help over the telephone from a Nortel Solutions Center
If you do not find the information you require on the Nortel Technical Support
web site, and you have a Nortel support contract, you can also get help over
the telephone from a Nortel Solutions Center.
In North America, call 1-800-4NORTEL (1-800-466-7835).
Outside North America, go to the following web site to obtain the telephone
number for your region:
http://www.nortel.com/callus
Getting help from a specialist by using an Express Routing Code
To access some Nortel Technical Solutions Centers, you can use an Express
Routing Code (ERC) to quickly route your call to a specialist in your Nortel
product or service. To locate the ERC for your product or service, go to:
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

12 How to get help
http://www.nortel.com/erc
Getting help through a Nortel distributor or reseller
If you purchased a service contract for your Nortel product from a distributor
or authorized reseller, contact the technical support staff for that distributor
or reseller.
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

13
Introduction
This document is a global document. Contact your system supplier or your
Nortel representative to verify that the hardware and software described
are supported in your area.
Subject
Note on legacy products and releases
This technical document contains information about systems, components,
and features that are compatible with Nortel Communication Server
1000 Release 5.5 software. For more information on legacy products
and releases, click the Technical Documentation link under Support &
Training on the Nortel home page:
www.nortel.com
Applicable systems
This document applies to the following systems:
•Communication Server 1000E (CS 1000E) CP PII, CP PIV and CP PM
•Communication Server 1000M Single Group (CS 1000M SG) CP PII,
CP PIV
•Communication Server 1000M Multi Group (CS 1000M MG) CP PII,
CP PIV
•Meridian 1 PBX 11C Chassis
•Meridian 1 PBX 11C Cabinet
•Meridian 1 PBX 61C CP PII, CP PIV
•Meridian 1 PBX 81C CP PII, CP PIV
Note: When upgrading software, memory upgrades may be required on
the Signaling Server, the Call Server, or both.
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

14 Introduction
System migration
When particular Meridian 1 systems are upgraded to run CS 1000 software
and configured to include a Signaling Server, they become CS 1000
systems. Table 1 "Meridian 1 systems to CS 1000 systems" (page 14) lists
each Meridian 1 system that supports an upgrade path to a CS 1000 system.
Table 1
Meridian 1 systems to CS 1000 systems
This Meridian 1 system... Maps to this CS 1000 system
Meridian 1 PBX 11C Chassis CS 1000E
Meridian 1 PBX 11C Cabinet CS 1000E
Meridian 1 PBX 61C CS 1000M Single Group
Meridian 1 PBX 81C CS 1000M Multi Group
Intended audience
This document is intended for individuals responsible for installing and
configuring ISDN PRI.
Related information
This section lists information sources that relate to this document.
Technical Documents
The following technical documents are referenced in this document:
•Features and Services Fundamentals (NN43001-106)
•Software Input Output Administration (NN43001-611)
•Software Input Output Reference — Maintenance (NN43001-711)
Online To access Nortel documentation online, click the Technical Documentation
link under Support & Training on the Nortel home page:
www.nortel.com
CD-ROM
To obtain Nortel documentation on CD-ROM, contact your Nortel customer
representative.
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

15
ISDN Primary Rate Interface equipment
overview
Contents The section contains information on the following topics:
"Introduction" (page 17)
"Primary Rate Interface (PRI) hardware requirements" (page 17)
"ISDN Signaling Link (ISL) hardware" (page 18)
"64 Kbit/s Clear Data Hardware" (page 20)
"D-Channel Handler description" (page 20)
"NT6D11 DCH" (page 20)
"Power requirements" (page 20)
"DCH/PRI interface" (page 20)
"DCH faceplate" (page 20)
"QPC757 DCH" (page 21)
"Power requirements" (page 21)
"DCH/PRI interface" (page 21)
"QPC757 faceplate" (page 22)
"NT6D80 MSDL" (page 23)
"Power requirements" (page 23)
"MSDL/PRI interface" (page 24)
"MSDL faceplate" (page 24)
"NTBK51 Downloadable D-Channel Daughterboard" (page 25)
"Standard PRI cards" (page 25)
"NT8D72 PRI2" (page 25)
"Power requirements" (page 25)
"NT8D72 faceplate" (page 25)
"Cable requirements" (page 27)
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

16 ISDN Primary Rate Interface equipment overview
"Carrier interface" (page 27)
"Echo canceller interface" (page 28)
"QMT21 High Speed Data Module" (page 28)
"QPC720 PRI for 1.5/2.0 Mb gateway" (page 28)
"Clock operation for the NT8D72" (page 28)
"QPC720 PRI" (page 30)
"Power requirements" (page 30)
"QPC720 faceplate" (page 31)
"QPC720 Cable requirements" (page 32)
"Carrier interface" (page 32)
"Echo Canceller interface" (page 32)
"64 T-link version 2 protocol" (page 33)
"Disk drive hardware" (page 34)
"NT5D97 Dual-port DTI2/PRI2 card" (page 34)
"External D-Channel Interface DCH or MSDL" (page 34)
"NT5D97 faceplate" (page 35)
"System capacity and performance" (page 39)
"Testability and diagnostics" (page 40)
"Cable requirements" (page 40)
"Cable diagrams" (page 47)
"Clock for the NT5D97" (page 49)
"NT5D12 Dual-port DTI/PRI" (page 57)
"D-Channel and MSDL interface" (page 58)
"NT5D12 faceplate" (page 59)
"System capacity and performance" (page 64)
"Power requirements" (page 65)
"Testability and diagnostics" (page 65)
"NT5D12 Cable requirements" (page 65)
"Trunk Tip/Ring cables" (page 66)
"Reference clock cables" (page 68)
"MSDL/DCHI cables" (page 68)
"Cable diagrams" (page 69)
"Clock" (page 70)
"Reference clock errors" (page 71)
"Automatic clock recovery" (page 72)
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

Primary Rate Interface (PRI) hardware requirements 17
"Automatic clock switching" (page 72)
"Clock configurations" (page 72)
IntroductionThis chapter describes the basic hardware needed to equip ISDN PRI on
CS 1000 and Meridian 1 systems.
Primary Rate Interface (PRI) hardware requirements
The following hardware is required to equip ISDN PRI on a Large System:
•NT6D11(AB/AE/AF) D-Channel Interface (DCH) card (for 2.0 Mb PRI)
•QPC757 D-channel Interface (DCH) for (1.5 Mb PRI)
•NT6D80 Multipurpose Serial Data Link (MSDL) card
•NTBK51 Downloadable D-Channel Daughterboard (DDCH), the NT5D97
dual-port DTI2/PRI2 card, or the NT5D12 dual-port 1.5 Mb DTI/PRI card
•NT8D72 (AB/BA) PRI2 card
•NT5D97 dual-port DTI2/PRI2 card
•QPC720 1.5 Mb PRI card
•NT5D12 dual-port 1.5 DTI/PRI card
•QPC775 or NTRB53 Clock Controller
Note: The NTRB53 Clock Controller cannot be combined with a
QPC775 or a QPC471 card in one system
Additional hardware is also required for PRI capability and applications.
Installation instructions are given in other Nortel publications, or supplied by
the manufacturer. This additional hardware includes:
•QPC414 Network card
•Channel Service Unit (CSU)
•Echo canceller
•ROM circuit card requirements:
— the QPC939A for a CS 1000M HG
— the QPC939A for CS 1000M SG
Note: CS 1000M MG ROM requirements are fulfilled by the NT6D66
Call Processor (CP) card.
•QMT8 Asynchronous Data Module (ADM)
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

18 ISDN Primary Rate Interface equipment overview
See Figure 1 "PRI hardware (shown without downloadable PRI and DCH
cards)" (page 18) for a representation of the basic PRI system hardware.
Note: Figure 1 shows a basic configuration, not the dual-port NT5D12
DTI/PRI card, nor the associated dual-port NTBK51AA Downloadable
D-Channel daughterboard.
Figure 1
PRI hardware (shown without downloadable PRI and DCH cards)
ISDN Signaling Link (ISL) hardware
The following hardware is required for ISDN Signaling Link (ISL) capability
and applications.
Equipment required for shared mode capability:
•NT6D11(AB/AE/AF) D-Channel (DCH) card (for 2.0 Mb PRI)
•QPC757 D-channel (DCH) for (1.5 Mb PRI)
•NT6D80 Multipurpose Serial Data Link (MSDL) card
•NTBK51 Downloadable D-Channel Daughterboard (DDCH), the NT5D97
dual-port DTI2/PRI2 card, or the NT5D12 dual-port 1.5 Mb DTI/PRI card
•NT8D72 (AB/BA) PRI2 card
•NT5D97 dual-port DTI2/PRI2 card
•QPC720 1.5 Mb PRI card
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

ISDN Signaling Link (ISL) hardware 19
•NT5D12 dual-port 1.5 DTI/PRI card
•QPC775 Clock Controller or NTRB53
Equipment required for dedicated mode using leased lines:
•NT6D11(AB/AE/AF) D-Channel (DCH) card (for 2.0 Mb PRI)
•QPC757 D-channel (DCH) for (1.5 Mb PRI)
•NT6D80 Multipurpose Serial Data Link (MSDL) card
•NTBK51 Downloadable D-Channel Daughterboard (DDCH), used as
an option to the NT6D80 MSDL
•modem set in synchronous mode
Equipment required for dedicated mode using a dialup modem:
•NT6D11(AB/AE/AF) D-Channel (DCH) card (for 2.0 Mb PRI)
•QPC757 D-channel (DCH) for (1.5 Mb PRI)
•NT6D80 Multipurpose Serial Data Link (MSDL) card
•NTBK51 Downloadable D-Channel Daughterboard (DDCH), used as
an option to the NT6D80 MSDL
•modem with autodial capability
Note: This configuration is the least reliable due to lockup problems
inherent in Smart Modems from power spikes and noisy lines. To
increase the reliability on this configuration, use a constant power
source when powering the modems. Also, verify that TIE lines meet data
grade specifications. Nortel takes no responsibility for ISL D-Channel
outages due to modem lockup.
•500 set line card
•QPC71 2W TIE, or QPC237 4W TIE E&M
Equipment required for dedicated mode using a DTI/DTI2 trunk:
•NT6D11(AB/AE/AF) D-Channel (DCH) card (for 2.0 Mb PRI)
•QPC757 D-channel (DCH) for (1.5 Mb PRI)
•NT6D80 Multipurpose Serial Data Link (MSDL) card
•NTBK51 Downloadable D-Channel Daughterboard (DDCH), used as
an option to the NT6D80 MSDL
•NT5D97 dual-port DTI2/PRI2 card
•QPC472 1.5 Mb DTI card or NT5D12 dual-port 1.5 DTI/PRI card
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.

20 ISDN Primary Rate Interface equipment overview
•QMT8 Asynchronous Data Module (ADM), QMT11 Asynchronous/Syn-
chronous Interface Module (ASIM) or QMT21 High Speed Data Module
(HSDM)
•Data line card
64 Kbit/s Clear Data Hardware
The QMT21 High Speed Data Module (HSDM) is required in the clear-data
pathway to support the 64Kbit/s clear-data function. One module is required
at each system end of any connection.
D-Channel Handler description
This section provides descriptions of the D-Channel (DCH) cards, the MSDL
card, and the Downloadable D-Channel Daughterboard.
NT6D11 DCH
Power requirements
The power requirements for the NT6D11AB/11AE/AF DCH are:
•+5 volts at 3 amperes
•+12 volts at 75 milliamperes
•-12 volts at 75 milliamperes
DCH/PRI interface
The NT6D11AB/AE/AF DCHs connect to the PRI2 cards by means of a
special RS422 cable, the QCAD328A, which is a special RS422 cable; refer
to "QCAD328" (page 300) of the Cabling chapter for more details.
DCH faceplate
NT6D11AB/AE/AF DCHs have one Light Emitting Diode (LED), to indicate
an active or inactive state, and two external connectors:
•Port J1 is a standard asynchronous port providing an interface for
non-PRI applications.
Note: This connection will not support an Add-on Data Module (ADM)
terminal.
•Port J2 is the D-Channel Interface port.
Figure 2 "NT6D11 DCH faceplate layout" (page 21) shows the faceplate
layout.
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301 02.03 Standard
Release 5.5 7 December 2007
Copyright © 2003-2007, Nortel Networks
.
