Tesano Installation Instructions
ID:

Before Beginning Installation
•Read through the entire instruction thoroughly
•A minimum of 2 persons is required for this assembly. Tables longer than 96” require 3-4 persons.
•These instructions reflect typical assemblies. They may not match your specific configuration.

Required Tools
•Drill Driver
•#2-Phillips Bit
•Laser Level
•¼” Allen Wrench
Hardware 1
Hardware 2
Hardware 3
Hardware 4
Hardware 5
Hardware 6

Tesano Conference

Tesano Conference Exploded
1. Work Surface
2. Top Beams
3. Mending Plate
4. Base
5. Rail Key
6. Wire Management
7. Power Rail
1
4
3
27
6
5

Step 1: Connecting Rails to Bases
•Run glides out of bases before beginning assembly.
•Loosen bolts (hardware #6) in the keys attached to the beam.
•Insert the beams with rail keys attached, into each of the bases with the “THIS SIDE UP” label facing
up and pilot holes facing ground.
•Use labels to attach correct beams to correct bases.

Step 2: Installing Top
•Insert pins (hardware #4) into the holes along the top edge of base end.
•Place top onto beams, sliding one end into the pins of one base.
•Repeat with the base on the opposite end.
•Tighten the cams to bring the two surfaces flush.
•Make sure the ends match labels.

Step 3: Securing Top with Mending Plates
NOTE: Ensure to center sides of top to the bases prior to attaching mending plates. Square the base up to
the top before securing the mending plates.
•Attach mending plate along the center of the metal spacer. Pilot holes should be present.
•Attach smaller mending plates in between the edge of the table and the top wood rails.

Step 4: Securing Top Rails
•With the mending plates secured in place, secure the top beams to the wood rails using hardware #5
long silver screws. The pilot holes in the beam should be facing the ground.
•Using cap screws (hardware #6) shown below, insert into side of rail keys.

Step 4: Securing Top Rails
•Center the top beam between the base and the tighten cap screws ensuring bottom of beams are
flush with on another.
•Secure the top beams to the wood rails using hardware #5 long silver screws. The screws will go
through the slotted openings along the face of the beams.

Step 5: Fastening Aprons
•Locate notch, place in apron toward end of table.
•Place the aprons between the inside of the side rail and the black beam, and fasten them using
supplied silver screws (hardware #2). Screws will go THROUGH the aluminum extrusion.

Step 6: Installing Wire Management
•Attach jumpers to receptacles
•Run the jumpers around the table, in a U-shape design.
•At one end of the table, the plug in-feed or hardware should run
through the leg.
Jumper
Plug-in Infeed
Jumper

Step 7: Installing Wire Management Covers
•Locate the wire management channels.
•Ensuring that the power duplex lines up with the cutout, fasten the wire management channel using
silver screws (hardware #1) and black screws (hardware #3).
•The label will be facing the top.
•The silver screws (hardware #1) must be used on the raised surface, while the black screws
(hardware #3) should be used on the lower surface.

Step 7: Installing Power Rail Units
•The power rail unit will come with the two black brackets which should be inserted first into the rail.
•The silver bolts should be inserted into the bracket before inserting into rail.
•Place power unit over screws.
•Tighten nuts to secure unit to the rail.
