Num'axes Canicalm spray User manual

1
Guide d’utilisation Fr - 3
User’s guide Gb - 11
Manual de instrucciones Es - 19
Gebrauchsanleitung D - 27
Manuale d’uso It - 35

User’s guide Gb - 11
How to obtain the best results
The owner’s involvement during the first use of the product
is a key factor in obtaining the best results.
Do not leave your dog unattended with the collar on until he is used to wearing it and you are satisfied
that it is working correctly.
Closely watch your pet during the first days’ use.
When your dog is barking, let the collar operate without interference. Any interference on your part
could teach your dog that barking is a means to get your attention. As soon as your dog stops barking,
reward your dog (but not excessively) with petting, verbal praise or dry food.
When you first begin to use Canicalm Spray collar, refill the reservoir frequently. It’s very important
that your dog never empties the collar. Otherwise, he/she will understand that he can stop the sprays
by barking during a certain amount of time. Moreover, he will associate barking with reward.
Remember that barking can indicate some behavioural problems. The bark limiter collar will allow you
to resolve problems caused by excessive barking. Before using the collar, have your dog checked by
your veterinarian.
Thank you for choosing the CANICALM Spray bark limiter by NUM’AXES. Before using this product,
carefully read the instructions in this manual, be sure to keep it safe for future reference.
• How to obtain the best results ........................................11
• Package contents ............................................................12
• How the collar works ......................................................12
• Filling the spray reservoir ...............................................12
• Activate the collar ............................................................14
• Deactivate the collar ........................................................14
• Replacing battery ............................................................14
• Fitting the collar ..............................................................14
• Recommendations ......................................................... 15
• Maintenance ....................................................................16
• Troubleshooting ...............................................................16
• Technical specifications ..................................................17
• Guarantee .......................................................................17
• Guarantee conditions ......................................................17
• Spare parts ......................................................................18
• Collection and recycling of collar at the end of its life ..18
Index

Gb - 12
Package contents
- a collar equipped with a nylon strap and a long life battery
- a spray refill (citronella, lavender or odourless)
- this user’s guide
How the Collar works
Filling the spray reservoir
Before turning the collar on, you have to fill the reservoir of your product.
To avoid unexpected triggering while you are filling or refilling the product, the collar should be
imperatively turned off.
Precautions for filling the spray reservoir:
– Do not fill the unit while your dog is wearing the collar.
– Fill the reservoir away from sources of ignition, naked flame or any incandescent material. Do not smoke.
– Direct the spray valve away from your body (especially from your eyes).
– Only use NUM’AXES branded spray refills with your CANICALM Spray collar.
To fill the reservoir:
– Put the unit on a flat and stable surface with the refill valve upright and the spray valve directed away
from your body and your eyes (See Diagram 2).
– Hold the spray can upside down then insert the nozzle in the refill valve.
– Firmly push down on the spray can and hold for 3 seconds, then release.
If spray is escaping while you are filling the reservoir, you are not pressing firmly enough and/or you
are not holding the can in a vertical position (See Diagram 2).
Refill valve
Nylon strap
Microphone
Reservoir
Spraying valve
ON / OFF button
Area where you have
to blow in order to
test the activation of
the collar

Gb - 13
– Wait for a short time, then turn your collar on in order to trigger a spray (see Activate the collar).
- Blow on the hole located close to the serial number label 2 or 3 times in order to ensure the good
operation of the collar.
– In order to completely fill the resevoir, check in the first place that the collar is turned off.
– Turn the spray can upside down and insert the nozzle in the refill valve (spray refill in a vertical
position).
– Firmly push down on the spray can for 10 seconds then release.
There are about 25 sprays in each reservoir.
It is very important to refill the reservoir before the spray reservoir runs dry. Otherwise, your dog
understands that he/she can stop the sprays by barking during a certain amount of time and associates
barking with reward.
Hold the spray refill upside
down and in a vertical position
Spraying valve
Microphone
Refill valve
WARNING
The spraying valve and microphone have
to be directed away from your body
(especially from your eyes).
Diagram 2

Gb - 14
Activate the collar
The battery is already fitted in the collar when you buy it.
- Before turning the collar On, take care to direct the spraying valve away from your body and
particularly from your face because the collar automatically emits a spray when you switch it On.
- Press the red On/Off button so that it does not come out of the plastic case (button inserted approx.
1 mm inside the collar). Use a pointed object such as the point of a pen to sufficiently press the
button.
- The collar will automatically emit a spray (or a “click” sound if the reservoir is empty).
- In order to test the good activation of the collar, blow on the hole located close to the serial number
label (see Diagram 1). A spray is emitted indicating the collar is On (the collar will emit a “click”
sound if the reservoir is empty).
Deactivate the collar
Press the red On/Off button using a pointed object such as the point of a pen.
Replacing battery
The battery supplied in the collar is a SAFT 3,6 Volt Lithium battery.
Battery life:
- approximately 3 years on regular use
- approximately 4 years in stand-by
Caution: The battery can only be replaced by the manufacturer.
For further information, please contact your distributor.
Caution: Do not under any circumstances open the CANICALM SPRAY collar. You could damage
components. Moreover, opening the collar voids your guarantee.
Fitting the collar
Collar adjustment is very important:
- If the nylon strap is too loose, the collar is likely to move and it will not operate properly.
- If the nylon strap is too tight, the dog will have breathing difficulties.
The nylon strap is properly adjusted when you can insert two fingers between the strap and your dog’s
neck.
The collar must be positioned on your dog’s neck with:
- The spray valve and the microphone pointing up toward your dog’s snout (See Diagram 3).
- The refill valve directed downward. Reservoir in contact with your dog’s neck (See Diagram 3).
If you have a long haired dog, make sure that the spray reaches the dog’s snout area. If necessary, trim
the hair on your dog’s neck.

Gb - 15
Do not leave the Canicalm Spray collar on your dog more than 8 hours a day.
Recommendations
- The collar should only be used on dogs over 6 months old.
- Before using the collar, have your dog checked by your veterinarian to ensure he is fit to wear a bark
limiter.
- The collar is weatherproof but not waterproof.
- Do not place or keep the device in places exposed to temperatures exceeding 40°C/ 104°F.
- To avoid unexpected triggering, your dog should not wear a medal, metallic collar, or any other kind
of collar together with the CANICALM Spray collar.
- If you are not using the collar for 15 days or more, empty the reservoir by pressing on the refill valve
with a ballpoint pen.
- Using a mobile phone within 1 meter / 3.3 feet from the collar can occasionally trigger it.
-
Under no circumstances should you open the CANICALM Spray collar. You could damage components.
Moreover, opening the collar voids your guarantee.
- Keep the Canicalm spray collar and refill can out of reach of children.
Spray valve
Refill valve
Diagram 3

Gb - 16
The refill can is a pressurized container. Caution for use:
- Keep the refill can away from direct sunlight and do not expose it to temperatures exceeding 50°C /
122°F.
- Do not pierce or burn the refill can, even after use.
- Do not spray on a naked flame or any incandescent material.
- Keep it away from sources of ignition – No smoking.
- Do not use it or keep it in a confined area.
- Use only as directed.
Maintenance
- To clean the CANICALM Spray collar use a soft cloth moistened with water and a mild detergent. Do
not use solvents or harsh detergents to clean your CANICALM Spray collar. Use simply a soft cloth.
- The nylon strap can be washed with soapy water.
- The spray can make your dog’s hair sticky. Wash your dog’s neck area weekly with a wash cloth and
mild soap then rinse and dry.
Troubleshooting
Before thinking your collar is broken, first read this guide over, then make sure the problem is not
caused by an empty reservoir or an incorrect use.
If the problem persists, contact your distributor or check out on www.numaxes.com.
You can also contact NUM’AXES at +33.2.38.63.03.84 or by Email [e-mail].
Depending on the extent of the malfunction, you may have to return your product for service and repair.
For all repairs, please supply the following:
- the complete product
- the proof of purchase (invoice or sales receipt)
If you omit one of these items, the After Sales Service will have to invoice you for any repair costs
incurred.

Technical specifications
Power SAFT 3,6 Volt Lithium battery
Battery life approximately 3 years on regular use
approximately 4 years in stand-by
Reservoir capacity 25 sprays
Spray can ( 75 ml ) Cosmetic quality alcohol
Citronella, lavender or odourless Natural citronella essential oil.
Natural lavender essential oil.
Each refill can contains approximately 200 sprays (that
is to say that you can refill your collar about 8 times).
Water Resistance weatherproof
Bark detection by microphone
Dimensions 60 x 32 x 32 mm / 2,36 x 1,26 x 1,26 inches
Weight (avec la pile) 42 g / 1.46 ounces
Adjustable collar for necks from 15 to 55 cm / from 6 inches to 22 inches
Operating temperature between + 5°C and + 40°C/ +41°F and +104 °F
Guarantee
NUM’AXES guarantees the product against production defects for 2 years after original purchase.
All postage and packing charges will be the purchaser’s sole responsibility.
Guarantee conditions
1. The guarantee will be valid only if the proof of purchase (invoice or sales receipt), without
cancellation, is submitted to the distributor or to NUM’AXES.
2. This guarantee does not cover the following:
- changing the battery
- changing the nylon strap
- supplying spray refills
- direct or indirect transport risks incurred when sending the article back to the distributor or
NUM’AXES
- damage to the article caused by:
- negligence or incorrect use (ex. bites, breakage, cracking)
- use contrary to the instructions or not envisioned therein
- repairs performed by unauthorized persons
- loss or theft
3. If the product is found to be defective, NUM’AXES will repair or replace it at their discretion.
4. No claim may be advanced against NUM’AXES, particularly in relation to incorrect use or breakdown.
Gb - 17

Gb - 18
5. NUM’AXES reserves the right to modify the characteristics of its products with a view to making
technical improvements or to comply with new regulations.
6. The information contained in this guide may be subject to amendment without prior notice.
7. Photos and drawings are not contractual.
Spare parts
You can purchase spare parts (nylon strap, citronella refills, lavender refills or odourless refills) from
your supplier at any time.
Collecting and recycling your device at the end of its life
The pictogram which appears on your product means that this one can not be thrown with
household refuse.
You have to bring the device to a collection location suitable for treatment, development, recycling of
electronic wastes or bring it back to your distributor.
Recycling helps the environment; by contributing to the preservation of natural resources and
protecting human health.
www.numaxes.com / [e-mail]

www.numaxes.com
Indice B
