Nutone 112 User manual

MODEL • 112

Page 1

WARNING

WARNING –TO REDUCETHE RISK OF FIRE, ELECTRIC SHOCK,

OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:

1. All electrical work must be done in accordance with local and/

or National Electrical Code as applicable. For safety, this prod-

uct must be grounded. If you are unfamiliar with methods of

installing electrical wiring, secure the services of a qualified elec-

trician.

2. Turn off power at service entrance before installing wiring, ser-

vicing, or cleaning this product.

3. Do not install heater upside down or sideways. Heater must be

located in the horizontal position.

4. Do not recess louvered face of the heater more than three inches

from the vertical face of any overhang (cabinet).

5. Do not locate heater behind doors, furniture, etc., where the air

flow to the unit will be restricted.

6. To avoid electrical shock; do not install heater within arm’s length

of tub or shower enclosure.

7. To avoid motor bearing damage and noisy and/or unbalanced

impellers, keep drywall spray, construction dust, etc., off power

unit.

8. Provide this heater with a separate electrical circuit following

directions under “Wire the Heater” section.

9. This product is equipped with a thermostat which may start it

automatically. Turn off power at service entrance before clean-

ing or servicing.

10. This heater includes a visual alarm to warn that parts are get-

ting excessively hot. If the alarm lights are activated, immedi-

ately turn the heater off and inspect for any objects on or adja-

cent to the heater that may cause high temperatures.

11. Please read specification label on product for further informa-

tion and requirements.

KICKSPACE

HEATER

Factory Wired 240/208 V.A.C.

READ AND SAVE THESE INSTRUCTIONS

VOLTS WATTS AMPS BTU/HR

240 1500 6.3 5120

208 1125 5.4 3840

120* 1500 12.5 5120

120* 750 6.3 2560

PLAN THE INSTALLATION

This heater is designed for installation in an enclosed space such

as under a counter or kickspace to provide warm, gentle heat at the

floor level. Reread Safety Notes 3 through 8 for guidelines in plan-

ning the installation.

The Model 112 is factory wired for 240/208 V.A.C. operation. It of-

fers a choice of heat outputs and can be internally connected for

multiple wattages at different voltages shown in the table below.

All ratings are 1-Phase, 60 Hertz.

*See “FIELD CONVERSION TO 120 V.A.C.” section.

INSTALL THE HEATER

1. Mark the intended mounting location in the base plate under

the counter or kickspace, and remove required material to pro-

vide for easy insertion and removal of the heater cabinet.

2. The unit will be secured in place with screws through the side

angle support brackets. Provide adequate material behind side

angle support for secure mounting.

SIDE

ANGLE SUPPORT

BRACKETS

Installer: Leave this manual with the homeowner.

Homeowner: Use and Care information on page 3.

MODEL • 112

Page 2

FIELD CONVERSION TO 120 V.A.C.

If a 120 V.A.C. circuit is to be used, make wiring changes as fol-

lows:

1. Disconnect white wire from heater element terminal “2” and

connect it to terminal “4.” The heater will now operate at 120

V.A.C., 750W, 6.3A.

2. For 120 V.A.C, 1500W, 12.5A operation, add the short red

jumper wire (provided) between terminals “1” and “2”.

3. Remove alarm light wire leads from terminals “1” and “3” of the

high temperature limit. Remove white wire lead from limit ter-

minal “1” and reconnect at limit terminal “3”. Secure wire leads

with wire tie so there is no interference with unit operation.

NOTE: Terminal numbers are marked on the side of the blower

housing, above the heater elements.

WIRE THE UNIT

WARNING: Disconnect power at service entrance before wir-

ing this product.

1. Run electrical power cable to installation location. Provide two

feet of slack to allow heater to be pulled out far enough to re-

move top cover for cleaning or servicing.

NOTE: It is recommended that flexible conduit be used for field

wiring to the unit to protect the wires from sharp objects or hazard-

ous environments.

NOTE: Be sure supply voltage meets the equipment requirement.

Refer to the rating plate, unit wiring diagram and specification table.

2. Remove top cover for access to wiring box at rear of heater.

3. Remove one of the two knockouts and connect power cable to

heater using appropriate connector. Allow at least six inches of

wiring inside of wiring box.

4. Connect black to black, white to white and green (or bare wire)

to ground screw, as shown. Tuck wires down inside the wiring

box.

5. Replace top cover.

WARNING: Do not operate heater without top cover in place.

6. Slide heater into place and secure to mounting surface.

MODEL • 112

Page 3

CHECK OPERATION

1. Turn thermostat counterclockwise to its lowest setting.

2. Turn on power to circuit at service entrance.

3. Turn thermostat clockwise.The heating element and fan should

come on. Set thermostat to desired temperature level. During

proper operation, the heater will cycle on and off periodically.

If heater does not come on:

1. Return the thermostat to lowest setting.

2. Shut off power at service entrance.

3. Remove the top cover. Check for proper line voltage and rein-

spect wiring connections. Reread installation procedure mak-

ing sure all steps were followed.

4. Also check the thermal fuse. It may be open and need to be

replaced. Consult the service parts list for the part number of a

replacement fuse. Follow the procedure described in the last

paragraph of the warranty when ordering replacement parts.

MAINTENANCE

NOTE: Always disconnect power at service entrance before clean-

ing or servicing heater.

The only maintenance required for this heater is to periodically

vacuum the front grille and housing. Simply remove the two side

angle support screws, slide heater out, and remove top cover for

access to the blower housing.

MODEL • 112

Page 4

SERVICE PARTS

99044023A

WARRANTY

BROAN-NUTONE ONE YEAR LIMITED WARRANTY

Broan-NuTone warrants to the original consumer purchaser of its products that such products will be free from defects in materials or workmanship for a period of one year

from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

During this one-year period, Broan-NuTone will, at its option, repair or replace, without charge, any product or part which is found to be defective under normal use and

service.

THIS WARRANTY DOES NOT EXTEND TO FLUORESCENT LAMP STARTERS AND TUBES. This warranty does not cover (a) normal maintenance and service or (b) any

products or parts which have been subject to misuse, negligence, accident, improper maintenance or repair (other than by Broan-NuTone), faulty installation or installation

contrary to recommended installation instructions.

The duration of an implied warranty is limited to the one-year period as specified for the express warranty. Some states do not allow limitation on how long an implied

warranty lasts, so the above limitation may not apply to you.

BROAN-NUTONE’S OBLIGATION TO REPAIR OR REPLACE, AT BROAN-NUTONE’S OPTION, SHALL BE THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY UNDER

THIS WARRANTY. BROAN-NUTONE SHALL NOT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH

PRODUCT USE OR PERFORMANCE. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation may not apply

to you.

This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. This warranty supersedes all prior warranties.

To qualify for warranty service, you must (a) notify Broan-NuTone at the address or telephone number below, (b) give the model number and part identification and (c)

describe the nature of any defect in the product or part. At the time of requesting warranty service, you must present evidence of the original purchase date.

Broan-NuTone LLC

926 West State Street

Hartford, WI 53027

(1-800-637-1453)

KEY PART

NO. NUMBER PART DESCRIPTION

1 99522899 Cover (White)

2 99522400 Cycling Thermal Overload Limit Switch

3 99521763 Thermal Fuse

4 99521765 Motor

5 99020130 Blower Wheel

6 99521760 Motor Plate
