Oce cm2510 Installation and operating manual

cm2510_4010_us_saf.fm -1 ページ ２００６年１１月２７日 月曜日 午後３時１８分

Notice for Users in U.S.A.
NOTE:
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference at his own expense.
Model names (peripheral devices)
9501*
1
, 9502*
1
, 9509*
2
, 9511*
2
, 9503, 9504, 9505, CM2510030, 9506, 9507, CM2510050*
1
, CM4010020*
2
, ZB3500160, CM2510190
*1 Can be installed when using the cm2510.
*2 Can be installed when using the cm4010.
Model Number: cm2510 / cm4010
cm2510 J / cm4010 J
Warranty
While every effort has been made to make this document as accurate and helpful as possible, Océ Imagistics Inc. makes no warranty
of any kind with regard to its content. All information included herein is subject to change without notice. Océ is not responsible for any
loss or damages, direct or indirect, arising from or related to the use of this operation manual.
© Océ 2007. All rights reserved. Reproduction, adaptation or translation without prior written permission is prohibited, except as
allowed under copyright laws.
Each instruction also covers the peripheral devices used with these products.
Caution!
For complete electrical disconnection, pull out the main plug.
The socket-outlet shall be installed near the equipment and shall be easily accessible.
FOR YOUR RECORDS ...
To protect against loss or theft, record and retain for reference the machine's serial number located at the bottom of the back of the
left side of the machine.
Model Number
Serial Number
Date of Purchase
Place of Purchase
Authorized Océ Printer
Service Department Number
WARNING:
FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the
manufacturer could void the user's authority to operate this equipment.
Shielded interface cables must be used with this equipment to maintain compliance with EMC regulations.
cm2510_4010_us_saf.fm 0 ページ ２００７年１月９日 火曜日 午後６時１１分

1
Contents
CAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Laser information . . . . . . . . . . . . . . . . . . . . . . . . . . 3
INSTALLATION REQUIREMENTS . . . . . . . . . . . . . 4
SUPPLIES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Storage of supplies. . . . . . . . . . . . . . . . . . . . . . . . . 5
Supply of spare parts and consumables . . . . . . . . 5
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Machine specifications / copier specifications . . . . 6
Continuous copying speeds . . . . . . . . . . . . . . . . . . 8
Printable sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Ambient environment . . . . . . . . . . . . . . . . . . . . . . . 8
Acoustic noise emission (measurement according to
ISO7779) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Emission concentration (measurement according to
RAL-UZ62: Edition Jan. 2002) . . . . . . . . . . . . . . . . 9
Automatic document feeder specifications. . . . . . . 9
Exit tray unit (right tray) specifications . . . . . . . . . . 9
Stand/1x500 sheet paper drawer specifications. . 10
Stand/2x500 sheet paper drawer specifications. . 10
Large capacity tray specifications . . . . . . . . . . . . 11
Finisher specifications . . . . . . . . . . . . . . . . . . . . . 12
Saddle stitch finisher specifications . . . . . . . . . . . 13
Punch module specifications (for finisher) . . . . . . 14
Punch module specifications (for saddle stitch
finisher). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Printer specifications . . . . . . . . . . . . . . . . . . . . . . 15
Network scanner / Internet Fax specifications . . . 16
Pull scan function (TWAIN) specifications . . . . . . 16
Optional equipment . . . . . . . . . . . . . . . . . . . . . . . 17
TO THE ADMINISTRATOR OF THE MACHINE . . 20
Factory default passwords . . . . . . . . . . . . . . . . . . 20
Forwarding all transmitted and received data to the
administrator (document administration function). . . .20
Trademark acknowledgments . . . . . . . . . . . . . . . 21
Note:
• Considerable care has been taken in preparing this manual. If you have any comments or concerns about the manual, please
contact your dealer or nearest Océ Service Department.
• This product has undergone strict quality control and inspection procedures. In the unlikely event that a defect or other problem is
discovered, please contact your dealer or nearest Océ Service Department.
• Aside from instances provided for by law, Océ is not responsible for failures occurring during the use of the product or its options,
or failures due to incorrect operation of the product and its options, or other failures, or for any damage that occurs due to use of
the product.
Products that have earned the ENERGY STAR®are designed to protect the environment
through superior energy efficiency.
The Environmental Choice Program guidelines are applied to the products only in Canada. The
products that meet the Environmental Choice Program guidelines carry the logo shown to the
left. The products without the logo may not meet the Environmental Choice Program guidelines.
cm2510_4010_us_saf.fm 1 ページ ２００６年１１月２８日 火曜日 午前１１時３１分

2
CAUTIONS
1. Do not touch the transfer belt. Scratches or smudges on the transfer belt will
cause dirty prints.
2. The fusing unit is extremely hot. Exercise care in this area.
3. Do not look directly at the light source. Doing so may damage your eyes.
4. Four adjusters are provided on all optional stand/paper drawer units. These
adjusters should be lowered until they contact the floor.
When moving the machine with the optional stand/paper drawer, be sure to
raise the adjusters. Also, unlock the two casters at the front of the optional
stand/paper drawer. After moving the machine, lower the four adjusters until
they reach the floor and lock the two casters.
5. Do not make any modifications to this machine. Doing so may result in
personal injury or damage to the machine.
6. The machine is heavy. To prevent injury when moving the machine, it is
recommended that it be moved by four or more persons.
7. Do not make copies of anything which is prohibited from copying by law. The
following items are normally prohibited from printing by national law. Other
items may be prohibited by local law.
●Money ●Stamps ●Bonds ●Stocks
●Bank drafts ●Checks ●Passports ●Driver's licenses
8. Do not use a flammable spray to clean the machine. If gas from the spray
comes in contact with hot electrical components or the fusing unit inside the
machine, fire or electrical shock may result.
9. Do not throw toner, a toner container (toner cartridge), or a waste toner box
into a fire. Toner may fly and cause burns.
10. Store toner, toner containers (toner cartridges), and waste toner boxes out of the reach of children.
The machine includes the document filing function, which stores document image data on the machine's hard drive. Stored
documents can be called up and printed or transmitted as needed. If a hard drive failure occurs, it will no longer be possible to call
up the stored document data. To prevent the loss of important documents in the unlikely event of a hard drive failure, keep the
originals of important documents or store the original data elsewhere.
With the exception of instances provided for by law, Océ Imagistics Inc. bears no responsibility for any damages or loss due to the
loss of stored document data.
"BATTERY DISPOSAL"
THIS PRODUCT CONTAINS A LITHIUM PRIMARY MEMORY BACK-UP BATTERY THAT MUST BE DISPOSED OF PROPERLY.
PLEASE CONTACT YOUR LOCAL OCÉ DEALER OR AUTHORIZED SERVICE REPRESENTATIVE FOR ASSISTANCE IN
DISPOSING OF THIS BATTERY.
This product utilizes a CR coin Lithium battery which contains a Perchlorate material. Special handling for this material may apply,
California residents, See www.dtsc.ca.gov/hazardouswaste/perchlorate/
Others, consult local environmental officers.
This product utilizes tin-lead solder, and a fluorescent lamp containing a small amount of mercury.
Disposal of these materials may be regulated due to environmental considerations.
For disposal or recycling information, please contact your local authorities or the Electronics Industries Alliance: www.eia.org
Fusing unit
Adjuster
Lock Release
cm2510_4010_us_saf.fm 2 ページ ２００６年１１月２７日 月曜日 午後３時１８分

3
CAUTIONS
Laser information
Wave length 785 nm +10 nm
-15 nm
Pulse times North America:
23 cpm model: (5.1 µs ±5.1 ns)/7 mm
27 cpm model: (5.1 µs ±5.1 ns)/7 mm
35 cpm model: (3.8 µs ±3.8 ns)/7 mm
45 cpm model (Color): (3.8 µs ±3.8 ns)/7 mm
45 cpm model (B/W): (2.8 µs ±2.8 ns)/7 mm
Output power Max 0.7 mW
At the production line, the output power of the scanner unit is adjusted to 0.30 MILLIWATT PLUS 5% and is maintained constant by
the operation of the Automatic Power Control (APC).
Caution
Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation
exposure.
For North America:
SAFETY PRECAUTIONS
This Digital Equipment is rated Class 1 and complies with 21 CFR 1040.10 and 1040.11 of the CDRH standards. This means that
the equipment does not produce hazardous laser radiation. For your safety, observe the precautions below.
• Do not remove the cabinet, operation panel or any other covers.
• The equipment's exterior covers contain several safety interlock switches. Do not bypass any safety interlock by inserting wedges
or other items into switch slots.
The above label is affixed to the laser
unit inside the machine.
cm2510_4010_us_saf.fm 3 ページ ２００６年１１月２８日 火曜日 午前１１時３２分

4
INSTALLATION REQUIREMENTS
Improper installation may damage this product. Please note the following during initial installation and whenever the
machine is moved.
1. The machine should be installed near an accessible
power outlet for easy connection.
2. Be sure to connect the power cord only to a power
outlet that meets the specified voltage and current
requirements. Also make certain the outlet is properly
grounded.
• For the power supply requirements, see the name
plate at the bottom of the back of the left side of the
machine.
Connect the machine to a power outlet which is not
used for other electric appliances. If a lighting fixture is
connected to the same outlet, the light may flicker.
3. Do not install the machine in areas that are:
• damp, humid, or very dusty
• exposed to direct sunlight
• poorly ventilated
• subject to extreme temperature or humidity
changes, e.g., near an air conditioner or heater.
4. Be sure to allow the required space around the
machine for servicing and proper ventilation.
5. When moving the machine, four persons must firmly
grasp the transport handles on both sides of the
machine.
6. The machine includes a built-in hard drive. Do not
subject the machine to shock or vibration. In
particular, never move the machine while the power is
on.
17-23/32"
(45cm)
11-13/16"
(30cm)
11-13/16"
(30cm)
A small amount of ozone is produced within the printer during operation. The emission level is insufficient to cause any health
hazard.
NOTE:
The present recommended long term exposure limit for ozone is 0.1 ppm (0.2 mg/m3) calculated as an 8 hr. time-weighted average
concentration.
However, since the small amount that is emitted may have an objectionable odor, it is advisable to place the copier in a ventilated
area.
cm2510_4010_us_saf.fm 4 ページ ２００６年１１月２７日 月曜日 午後３時１８分

5
SUPPLIES
Standard supplies for this product that can replaced by the user include paper, toner cartridges, and staple cartridges for
the finisher.
Be sure to use only Océ-specified products for the toner cartridges, finisher staple cartridge, saddle stitch finisher staple
cartridge, and transparency film.
For best copying results, be sure to use only Océ supplies which are designed, engineered, and tested to maximize the
life and performance of Océ products.
Storage of supplies
Proper storage
1. Store the supplies in a location that is:
• clean and dry,
• at a stable temperature,
• not exposed to direct sunlight.
2. Store paper in the wrapper and lying flat.
3. Paper stored in packages standing up or out of the wrapper may curl or become damp, resulting in paper misfeeds.
Storing toner cartridges
Store a new toner cartridge box horizontally. Do not store it standing on end. If stored standing on end, the toner may not
distribute well even after shaking the cartridge vigorously, and will remain inside the cartridge without flowing out.
Staple cartridge
The finisher and saddle stitch finisher require the following staple cartridge:
481-8
Staple cartridge for finisher (approx. 5000 per cartridge x 3 cartridges)
794-5
Staple cartridge for saddle stitch finisher (approx. 5000 per cartridge x 3 cartridges)
Supply of spare parts and consumables
The supply of spare parts for repair of the machine is guaranteed for at least 7 years following the termination of
production. Spare parts are those parts of the machine which may break down within the scope of the ordinary use of
the product, whereas those parts which normally exceed the life of the product are not to be considered as spare parts.
Consumables too, are available for 7 years following the termination of production.
cm2510_4010_us_saf.fm 5 ページ ２００６年１１月２７日 月曜日 午後３時１８分

6
SPECIFICATIONS
Machine specifications / copier specifications
* First copy out time is measured with original on the document glass in full ready condition with fuser at operating temperature and
mirror motor at operating speed, actual time may vary based on environment conditions.
Name Digital Full Color Multifunctional System
cm2510/cm4010
Type Desktop
Photoconductive type OPC drum
Printing method Electrophotographic system (laser)
Developer system Dry-type two-component magnetic brush development
Fusing system Heat rollers
First-copy time*
Color copy time: 6.9 seconds (cm4010)
8.9 seconds (cm2510)
Black and white copy time: 4.1 seconds (cm4010)
6.3 seconds (cm2510)
(Portrait feeding of 8-1/2" x 11" (A4) sheets from 1st paper tray, without auto color selection and auto
color mode.)
Scanning resolution
Document glass
Black and white scanning:600 x 600 dpi, 600 x 300 dpi (factory default
values)
Color scanning: 600 x 600 dpi (factory default values)
Reversing single pass
feeder (automatic
document feeder)
Black and white scanning:600 x 600 dpi, 600 x 300 dpi (factory default
values)
Color scanning: 600 x 600 dpi (factory default values)
Printing resolution 600 x 600 dpi
Scanning gradation 10 bits
Printing gradation Black and white printing: 2 tones (1 bit)
Color printing: 2 tones per color (1 bit) or 16 tones per color (4 bits)
Original sizes / types Max. 11" x 17" (A3) / sheets, bound documents
Copy sizes Maximum: 11" x 17" (A3) Minimum: 5-1/4" x 5-3/4" (A5R)
Print margins Leading edge: 11/64" (4 mm) or less, trailing edge: 1/8" (3 mm) or less, near edge / far edge: total
11/64" (4 mm) or less
Warm-up time 80 seconds or less (cm2510)
240 seconds or less (cm4010)
Copy ratios
Variable: 25% to 400% in increments of 1%, total 376 increments (25% to 200% when the auto
document feeder is used)
Fixed presets: 25%, 50%, 64%, 77%, 100%, 121%, 129%, 200% and 400% for inch sizes;
25%, 50%, 70%, 81%, 86%, 100%, 115%, 122%, 141%, 200% and 400% for AB sizes.
Two reduction ratios and two enlargement ratios can be stored.
Tray 1 / tray 2
Paper sizes: 11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R,
5-1/2" x 8-1/2"R, A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR
Paper weight: Plain paper (16 lbs. to 28 lbs. (60 g/m2to 105 g/m2))
Paper capacity: 500 sheets (21 lbs. (80 g/m2))
Paper types: Océ-recommended plain paper, recycled paper, and colored paper
Automatic paper size detection (cm4010)
When "Auto-Inch" detection is selected:
11" x 17", 8-1/2" x 14", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R
When "Auto-AB" detection is selected:
A3, B4, A4, A4R, B5, B5R, 216 mm x 330 mm (8-1/2" x 13")
cm2510_4010_us_saf.fm 6 ページ ２００６年１１月２７日 月曜日 午後３時１８分

7
SPECIFICATIONS
Machine specifications / copier specifications (Continued)
Bypass tray
Paper sizes: 12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R,
7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R, A3W, A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K,
16KR
Paper weights:
Thin paper (15 lbs. to 16 lbs. (55 g/m2to 59 g/m2)), plain paper (16 lbs. to 28 lbs. (60 g/m2to
105 g/m2)), heavy paper (28 lbs. to 56 lbs. (106 g/m2to 209 g/m2)), envelopes (20 lbs. to 24 lbs.
(75 g/m2to 90 g/m2))
Paper capacity:
Standard paper 100 sheets, envelopes 20 sheets, transparency films 20 sheets, heavy paper 40
sheets, tab paper 20 sheets, gloss paper 20 sheets
Paper types:
Plain paper, recycled paper, colored paper, heavy paper, thin paper, transparency film, envelopes
(Monarch, Com-10, DL, C5)
Automatic paper size detection
When "Auto-Inch" detection is selected:
12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R,
A3, B4, A4, B5
When "Auto-AB" detection is selected:
A3W, A3, B4, A4, A4R, B5, B5R, A5R, 11" x 17", 216 mm x 330 mm (8-1/2" x 13"), 8-1/2" x 11"
Paper size entry: The size can be entered from 5-1/2" to 17" (from 148 mm to 432 mm) (W), from
5-1/2" to 11-5/8" (from 100 mm to 297 mm) (H).
Tab paper: A4 size, tab widths 31/64" to 51/64" (12 mm to 20 mm)
8-1/2" x 11" size, tab widths 1/4" to 51/64" (6.1 mm to 17 mm)
Duplex module
Paper sizes: 11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 5-1/2" x 8-1/2"R, A3,
B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR
Paper weight: Plain paper (16 lbs. to 28 lbs. (60 g/m2to 105 g/m2)) (cm2510)
Plain paper (16 lbs. to 28 lbs. (60 g/m2to 105 g/m2)), heavy paper (28 lbs. to 56 lbs.
(106 g/m2to 209 g/m2)) (cm4010)
Océ-recommended plain paper, recycled paper, and colored paper
Output tray (Center tray)
Output location / method: In machine body / Face-down output
(12" x 18" and A3W paper can be output to right tray, finisher, or saddle stitch finisher)
Output capacity:
500 sheets (using Océ-recommended 8-1/2" x 11" or A4 paper)
(The maximum number of sheets that can be held varies depending on ambient conditions in the
installation location, the type of paper, and the storage conditions of the paper.)
Tray full sensor: Yes
Shifter function: Yes
Required power supply AC 120 V ±10% 60 Hz
Power consumption 1.44 kW
Dimensions
cm2510:
24-13/32" (W) x 26-3/8" (D) x 37-13/32" (H) (620 mm (W) x 670 mm (D) x 950 mm (H))
cm4010:
25-25/64" (W) x 26-3/8" (D) x 37-51/64" (H) (645 mm (W) x 670 mm (D) x 960 mm (H))
Weight cm2510: Approx. 246.8 lbs. (112 kg)
cm4010:
Approx. 271.1 lbs. (123 k g )
Overall dimensions
cm2510: 38-3/16" (W) x 26-3/8" (D) (970mm (W) x 670mm (D))
cm4010: 39-11/64" (W) x 26-3/8" (D) (995mm (W) x 670mm (D))
(when bypass tray is extended)
cm2510_4010_us_saf.fm 7 ページ ２００６年１１月２７日 月曜日 午後３時１８分

8
SPECIFICATIONS
Continuous copying speeds*1
*1 Copy speed during output of the second copy and following copies when performing continuous one-sided copying of the same
page (excluding offset output).
*2 Using plain paper from any tray other than the bypass tray.
*3 When heavy paper is loaded in the bypass tray.
Model cm2510 cm4010
Copy ratio 100% / Reduced / Enlarged
Copy mode Color copying Black and white
copying Color copying Black and white copying
Plain
paper*2
11" x 17", A3, 8K
13 copies/min. 17 copies/min. 19 copies/min.
8-1/2" x 14",
8-1/2" x 13", B4
15 copies/min. 20 copies/min. 21 copies/min.
8-1/2" x 11"R,
7-1/4" x 10-1/2"R,
A4R, B5R, 16KR
18 copies/min. 25 copies/min. 28 copies/min.
5-1/2" x 8-1/2",
A5R
18 copies/min. 25 copies/min. 28 copies/min.
8-1/2" x 11", A4,
B5, 16K
25 copies/min. 35 copies/min. 40 copies/min.
Extra sizes
11 copies/min. 12 copies/min. 15 copies/min. 18 copies/min.
Heavy
paper*3
8-1/2" x 11",
8-1/2" x 5-1/2"R,
A4, B5, A5R, 16K
10 copies/min. 11 copies/min. 14 copies/min. 15 copies/min.
Printable sizes Ambient environment
Paper size Printable size Paper size Printable size
12" x 18"* 279 x 432mm A3W* 297 x 420mm
11" x 17" 275 x 425mm A3 293 x 413mm
8-1/2" x 14" 212 x 349mm B4 253 x 357mm
8-1/2" x 13" 212 x 323mm A4 206 x 290mm
8-1/2" x 11" 212 x 272mm B5 178 x 250mm
5-1/2" x 8-1/2 " 136 x 209mm A5 144 x 203mm
7-1/4" x 10-1/2R" 180 x 260mm 8K 266 x 383mm
16K 191 x 263mm
* When printing on 12" x 18" (A3W) size paper using the PCL or PS printer driver,
the maximum print area is 299 mm x 450 mm.
85%
(Humidity)
(Temperature)
60%
20%
54˚F
(10˚C)
86˚F
(30˚C)
91˚F
(35˚C)
cm2510_4010_us_saf.fm 8 ページ ２００７年１月９日 火曜日 午後６時１１分

9
SPECIFICATIONS
Acoustic noise emission (measurement according to ISO7779)
Emission concentration (measurement according to RAL-UZ62: Edition Jan. 2002)
Automatic document feeder specifications
* Paper weights from 9 lbs. (35 g/m2) to 13 lbs. (49 g/m2) require the use of slow scan mode.
Exit tray unit (right tray) specifications
* The maximum number of sheets that can be held varies depending on ambient conditions in the installation location, the type of
paper, and the storage conditions of the paper.
Sound power level LwA
Model cm2510 cm4010
Printing mode
(continuous printing)
Color: 6.3 B
Black and white: 6.3 B
Color: 6.8 B
Black and white: 6.8 B
Standby mode 5.5B 5.5B
Ozone 0.02 mg/m3or less
Dust 0.075 mg/m3or less
Styrene 0.07 mg/m3or less
Model cm2510 cm4010
Original sizes
11" x 17" to 5-1/2" x 8-1/2", A3 to A5, long paper
(max. width 11-45/64" (297 mm) x max. length 31-31/64" (800 mm), scanning in mono 2 mode of
one side only is possible in fax and image scan modes)
Original weight
One-sided 9 lbs. to 34 lbs. (35 g /m
2
to 128 g /m
2
)*
Two-sided 13 lbs. to 28 lbs. (50
g /m
2
to 105 g /m
2
)
One-sided 9 lbs. to 34 lbs. (35
g /m
2
to 128 g /m
2
)*
Two-sided 13 lbs. to 34 lbs. (50
g /m
2
to 128 g /m
2
)
Capacity 100 sheets (21 lbs. (80 g/m2)) Maximum stack
height of 1/2" (13 mm)
150 sheets (21 lbs. (80 g/m2)) Maximum stack
height of 3/4" (19.5 mm)
Power supply Supplied from the machine
Model CM2510010 (cm2510) / CM4010010 (cm4010)
Output method Face-down output
Output capacity* 100 sheets (using Océ-recommended 8-1/2" x 11" or A4 paper)
Dimensions
When tray is folded up:
11-3/8" (W) x 15-61/64" (D) x 2-3/64" (H) (289 mm (W) x 405 mm (D) x 52 mm (H))
When tray is extended:
16-1/2" (W) x 15-61/64" (D) x 2-3/64" (H) (419 mm (W) x 405 mm (D) x 52 mm (H))
Weight Approx. 2 lbs. (0.93 kg)
cm2510_4010_us_saf.fm 9 ページ ２００６年１１月２７日 月曜日 午後３時１８分

10
SPECIFICATIONS
Stand/1x500 sheet paper drawer specifications
Stand/2x500 sheet paper drawer specifications
Model 9501 (cm2510) 9509 (cm4010)
Paper sizes 11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, A3, B4, A4, A4R,
B5, B5R, 8K, 16K, 16KR
Paper weight Plain paper (16 lbs. to 28 lbs. (60 g/m2to 105 g/m2))
Paper capacity 500 sheets (21 lbs. (80 g/m2)) x 1 tray
Paper types Océ-recommended plain paper, recycled paper, and colored paper
Automatic paper size
detection
When "Auto-Inch" detection is selected:
11" x 17", 8-1/2" x 14", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R
When "Auto-AB" detection is selected:
A3, B4, A4, A4R, B5, B5R, 216 mm x 330 mm (8-1/2" x 13")
Power supply Supplied from the machine
Dimensions 28-11/32" (W) x 26-3/8" (D) x 11-15/16" (H) (720 mm (W) x 670 mm (D) x 303 mm (H))
(including adjuster)
Weight Approx. 44.1 lbs. (20 kg) Approx. 45.2 lbs. (20.5 kg)
Model 9502 (cm2510) 9511 (cm4010)
Paper sizes 11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, A3, B4, A4, A4R,
B5, B5R, 8K, 16K, 16KR
Paper weight Plain paper (16 lbs. to 28 lbs. (60 g/m2to 105 g/m2))
Paper capacity 500 sheets (21 lbs. (80 g/m2)) x 2 trays
Paper types Océ-recommended plain paper, recycled paper, and colored paper
Automatic paper size
detection
When "Auto-Inch" detection is selected:
11" x 17", 8-1/2" x 14", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R
When "Auto-AB" detection is selected:
A3, B4, A4, A4R, B5, B5R, 216 mm x 330 mm (8-1/2" x 13")
Power supply Supplied from the machine
Dimensions 28-11/32" (W) x 26-3/8" (D) x 11-15/16" (H) (720 mm (W) x 670 mm (D) x 303 mm (H))
(including adjuster)
Weight Approx. 51.8 lbs. (23.5 kg) Approx. 52.9 lbs. (24 kg)
cm2510_4010_us_saf.fm 10 ページ ２００６年１１月２７日 月曜日 午後３時１８分

11
SPECIFICATIONS
Large capacity tray specifications*
* Stand/1x500 sheet paper drawer (9501/9509) or stand/2x500 sheet paper drawer (9502/9511) is required.
Model 9503
Paper sizes 8-1/2" x 11", A4 (paper size change must be performed by a service technician)
Paper weight Plain paper (16 lbs. to 28 lbs. (60 g/m2to 105 g/m2))
Paper capacity 3500 sheets (21 lbs. (80 g/m2))
Paper types Océ-recommended plain paper, recycled paper and colored paper
Power supply Supplied from the machine
Dimensions 14-9/16" (W) x 21-21/32" (D) x 20-15/32" (H) (370 mm (W) x 550 mm (D) x 520 mm (H))
Weight Approx. 63.9 lbs. (29 kg)
cm2510_4010_us_saf.fm 11 ページ ２００６年１１月２７日 月曜日 午後３時１８分

12
SPECIFICATIONS
Finisher specifications
*1 The maximum number of sheets that can be held varies depending on ambient conditions in the installation location, the type of
paper, and the storage conditions of the paper.
*2 The maximum number of sheets for stapling assumes a paper weight of 24 lbs. (90 g/m2) and includes two cover sheets of 28 lbs.
to 56 lbs. (106 g/m2to 209 g/m2).
Model 9504
Paper sizes 12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R,
5-1/2" x 8-1/2"R, A3W, A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR
Paper weight
Thin paper (15 lbs. to 16 lbs. (55 g /m
2
to 59 g /m
2
)) Plain paper (16 lbs. to 28 lbs. (60 g /m
2
to 105 g /m
2
))
Heavy paper (28 lbs. to 56 lbs. (106 g /m
2
to 209 g /m
2
))
Modes Non-staple, staple
Allowed paper sizes for
offset
11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, A3, B4, A4, A4R, B5, 8K, 16K
Offset distance 1-3/16" (30 mm)
Tray capacity*1
Non-stapling:
500 sheets (8-1/2" x 11", 8-1/2" x 11"R,
7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R, A4, A4R, B5,
B5R, A5R, 16K, 16KR)
250 sheets (12" x 18", 11" x 17", 8-1/2" x 14",
8-1/2" x 13", A3W, A3, B4, 8K)
Stapling*2:
30 sets or 500 sheets (8-1/2" x 11",
8-1/2" x 11"R, A4, A4R, B5, 16K, 16KR)
30 sets or 250 sheets (11" x 17", 8-1/2" x 14",
8-1/2" x 13", A3, B4, 8K)
Dimensions
When tray is folded up:
17-21/64" (W) x 23-27/64" (D) x 8-5/64" (H) (440 mm (W) x 595 mm (D) x 205 mm (H))
When tray is extended:
25-3/16" (W) x 23-27/64" (D) x 8-5/64" (H) (640 mm (W) x 595 mm (D) x 205 mm(H))
Weight Approx. 28.7 lbs. (13 kg)
Stapler section
Allowed paper sizes for
stapling
11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, A3, B4, A4, A4R, B5, 8K, 16K, 16KR
(Three stapling positions: one staple at bottom left corner, one staple at top left corner, and two
staples.)
Maximum number of
sheets for stapling*2
50 sheets (8-1/2" x 11", 8-1/2" x 11"R, A4, A4R, B5, 16K, 16KR)
30 sheets (11" x 17", 8-1/2" x 14", 8-1/2" x 13", A3, B4, 8K)
(30 sheets when the sheets are the same width but different lengths.)
cm2510_4010_us_saf.fm 12 ページ ２００６年１１月２７日 月曜日 午後３時１８分

13
SPECIFICATIONS
Saddle stitch finisher specifications*1
*1 Paper pass unit (9506) and stand/1x500 sheet paper drawer (9501/9509) or stand/2x500 sheet paper drawer (9502/9511) are
required.
*2 The maximum number of sheets that can be held varies depending on ambient conditions in the installation location, the type of
paper, and the storage conditions of the paper.
*3 The maximum number of sheets for stapling assumes a paper weight of 24 lbs. (90 g/m2) and includes two cover sheets of 28 lbs.
to 56 lbs. (106 g/m2to 209 g/m2).
Model 9505
Paper sizes 12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R,
5-1/2" x 8-1/2"R, A3W, A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR
Paper weight Thin paper (15 lbs. to 16 lbs. (55 g/m2to 59 g/m2)) Plain paper (16 lbs. to 28 lbs. (60 g/m2to
105 g/m2)) Heavy paper (28 lbs. to 56 lbs. (106 g/m2to 209 g/m2))
Modes Non-staple, staple
Allowed paper sizes for
offset
11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, A3, A4, A4R, B4,
B5, B5R, 8K, 16K, 16KR
Offset distance 25/32" (20 mm)
Tray capacity*2
Non-stapling:
1000 sheets (8-1/2" x 11", 8-1/2" x 11"R,
7-1/4" x 10-1/2"R, A4, A4R, B5, B5R, 16K, 16KR)
500 sheets (12" x 18", 11" x 17", 8-1/2" x 14",
8-1/2" x 13", 5-1/2" x 8-1/2"R, A3W, A3, B4, A5R,
8K)
Stapling*3:
50 sets (one staple at top left corner) or 1000
sheets (8-1/2" x 11", A4, B5)
30 sets or 1000 sheets (8-1/2" x 11",
8-1/2" x 11"R, A4, A4R, B5, B5R, 16K, 16KR)
30 sets or 500 sheets (11" x 17", 8-1/2" x 14",
8-1/2" x 13", A3, B4, 8K)
Dimensions
When tray is folded up:
21-27/32" (W) x 24-1/64" (D) x 39-49/64" (H) (555 mm (W) x 610 mm (D) x 1010 mm (H))
When tray is extended:
26-11/64" (W) x 24-1/64" (D) x 41-21/64" (H) (665 mm (W) x 610 mm (D) x 1050 mm (H))
Weight Approx. 101.4 lbs. (46 kg)
Stapler section
Allowed paper sizes for
stapling
11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, A3, B4, A4, A4R, B5, B5R, 8K, 16K,
16KR
(Three stapling positions: one staple at bottom left corner, one staple at top left corner, and two staples.)
Maximum number of
sheets for stapling*3
30 sheets (8-1/2" x 11", 8-1/2" x 11"R, A4, A4R, B5, B5R, 16K, 16KR)
25 sheets (11" x 17", 8-1/2" x 14", 8-1/2" x 13", A3, B4, 8K)
(25 sheets when the sheets are the same width but different lengths.)
Saddle unit
Stapling method Fold in half and staple in two places on centerline
Folding position Fold at centerline (can be adjusted with [Saddle Stitch Position Adjust] in the System Settings)
Allowed paper sizes for
saddle stitch stapling
11" x 17", 8-1/2" x 11"R, A3, B4, A4R, 8K,16KR
Allowed paper weights
for saddle stitch stapling
15 lbs. to 56 lbs. (55 g/m2to 209 g/m2)
Number sheets for saddle
stitch stapling / Number
of sets
Maximum: 10 sheets (21 lbs. (80 g/m2) x 9 sheets + 56 lbs. (209 g/m2) x 1 sheet) / 10 sets (6 to 10
sheets), 20 sets (1 to 5 sheets)
cm2510_4010_us_saf.fm 13 ページ ２００６年１１月２７日 月曜日 午後３時１８分

14
SPECIFICATIONS
Punch module specifications (for finisher)
Punch module specifications (for saddle stitch finisher)
Model 9507
Hole punching 2 holes or 3 holes
Allowed paper sizes for
punching
2 holes:
8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11"R
3 holes:
11" x 17", 8-1/2" x 11", A3, A4
Punchable paper weights
15 lbs. to 56 lbs. (55 g/m2to 209 g/m2)
Model 9508
Hole punching 2 holes or 3 holes
Allowed paper sizes for
punching
2 holes:
8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11"R
3 holes:
11" x 17", 8-1/2" x 11", A3, A4
Punchable paper weights
15 lbs. to 56 lbs. (55 g/m2to 209 g/m2)
Note:
Special media such as transparency film and label sheets cannot be stapled or punched.
cm2510_4010_us_saf.fm 14 ページ ２００６年１１月２７日 月曜日 午後３時１８分

15
SPECIFICATIONS
Printer specifications
*1 When the PS3 expansion kit (CM2510020) is installed and the machine is used as a PostScript printer.
*2 Barcode font kit (ZB3500160) is required.
Type Built-in
Continuous printing speed
Same as continuous copying speed (When printing same document continuously on 8-1/2" x 11"
(A4) plain paper in non-offset mode, excluding processing time.)
Printing resolution 600 x 600 dpi / 1200 x 600 dpi*1(black and white printing, rotating output not performed)
Printer driver type PCL5c, PCL6, PostScript 3 compatible*1
Supported protocols TCP/IP, IPX/SPX, NetBEUI, EtherTalk
Fonts PCL5c, PCL6 80 European fonts, 28 barcode fonts*2, 1 bitmap font
PostScript 3 compatible*1136 European fonts
Interface port LAN connectivity: 10Base-T / 100Base-TX
USB (type A): Supports USB 2.0 (Full speed) USB (type B): Supports USB 2.0 (Hi speed)
Memory Standard system memory: 640 MB
Print area Entire page excluding margin of 11/64" (4.2 mm) at each edge. The actual print area may vary
depending on the printer driver and the software application.
cm2510_4010_us_saf.fm 15 ページ ２００６年１１月２７日 月曜日 午後３時１８分

16
SPECIFICATIONS
Network scanner / Internet Fax*1specifications
*1 Internet fax expansion kit (CM2510040) is required.
*2 Total number of all destinations (Scan to E-mail, Scan to FTP, Scan to Desktop, Scan to Network folder, Internet Fax, Fax, and
Group)
Pull scan function (TWAIN) specifications
Type Color scanner
Scanning resolution (dpi)
100 x 100, 200 x 200, 300 x 300, 400 x 400, 600 x 600
Internet Fax: 200 x 100, 200 x 200, 200 x 400, 400 x 400, 600 x 600 (200 x 100, 200 x 200 when file
type is TIFF-S) Halftone can be selected for resolutions other than 200 x 100 dpi.
Scanning speed
cm2510:
Color (8-1/2" x 11" / A4) One-sided: 35 pages/min. (200 x 200 dpi),
Two-sided: 15 pages/min. (200 x 200 dpi)
Black and white (8-1/2" x 11" / A4) One-sided: 48 pages/min. (200 x 200 dpi),
Two-sided: 15 pages/min. (200 x 200 dpi)
cm4010:
Color (8-1/2" x 11" / A4) One-sided: 35 pages/min. (200 x 200 dpi),
Two-sided: 35 pages/min. (200 x 200 dpi)
Black and white (8-1/2" x 11" / A4) One-sided: 60 pages/min. (200 x 200 dpi),
Two-sided: 60 pages/min. (200 x 200 dpi)
Interface port LAN connectivity: 10Base-T / 100Base-TX
Supported protocols TCP/IP
File formats
Color
(including grayscale)
File types: TIFF, JPEG, PDF, Encrypted PDF
Compression ratio: High / Medium / Low
Black and white File types: TIFF, PDF, Encrypted PDF
Compression modes: None / Medium (G3) / High (G4)
Internet Fax
(black and white only)
File types: TIFF-FX (TIFF-F, TIFF-S)
Compression modes: Medium (G3) / High (G4)
Remarks
Number of one-touch keys for
storing destinations*2
Maximum number of keys: 999
Number of destinations that can be
stored in a group (1 key)*2
Maximum number of destinations in one group (1 key): 500
Supported protocol TCP/IP
Color modes Full Color, Grayscale, Mono Diffusion, Mono 2 gradation
Resolution settings
75 dpi, 100 dpi, 150 dpi, 200 dpi, 300 dpi, 400 dpi, 600 dpi
(The resolution can be specified by entering a numerical value from 50 to 9600 dpi. However, when
a high resolution is specified, it is necessary to reduce the scanning area.)
Scanning area Maximum: 11" x 17" (A3)
cm2510_4010_us_saf.fm 16 ページ ２００６年１１月２７日 月曜日 午後３時１８分

17
SPECIFICATIONS
Optional equipment
Yes:Can be installed.
cm2510 cm4010
Automatic docment feeder Standard
Exit tray unit Yes
Stand/1x500 sheet paper drawer Yes
Stand/2x500 sheet paper drawer Yes
Large capacity tray Yes
Finisher Yes
Saddle stitch finisher Yes
Punch module Yes
Printer function Standard (PCL), Yes (PS)
Application integration module Yes
Network scanner function Standard
Internet fax function Yes
Pull scan function (TWAIN) Standard
Facsimile function Yes
cm2510_4010_us_saf.fm 17 ページ ２００６年１１月２７日 月曜日 午後３時１８分

18
cm2510_4010_us_saf.fm 18 ページ ２００６年１１月２７日 月曜日 午後３時１８分
