Oce cm6520 User manual
Océ
cm6520
Box Operations
User’s Guide
Printing for
Professionals
cm6520 x-1
Introduction
Introduction
Thank you for choosing this machine.
This User’s Guide contains details on the operations required to use the User Box functions of the cm6520,
precautions on their use, and basic troubleshooting procedures. In order to ensure that this machine is used
correctly and efficiently, carefully read this User’s Guide before using the machine.
If software (such as Job Spooler, HDDTWAIN or Box Operator) other than that described in this User’s Guide
has been installed, data saved in a user box can be used from a computer on the network. Since the operation
differs for each software, refer to the manual for the corresponding software for details.
In addition, for details on the operation of Web Connection, which can be used to operate this machine over
a network, refer to the User’s Guide [Web Connection Operations].
Views of the actual equipment may be slightly different from the illustrations used in this manual.
Energy Star®
As an ENERGY STAR®Partner, we have determined that this machine meets the ENERGY STAR®Guidelines
for energy efficiency.
What is an ENERGY STAR® product?
An ENERGY STAR®product has a special feature that allows it to automatically switch to a "low-power
mode" after a period of inactivity. An ENERGY STAR®product uses energy more efficiently, saves you money
