OEM Tools 24685 Service manual

WARNING
The following safety information is provided as a guideline to help you operate your Cordless Power Ratchet under the
safest possible conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or safe handling
instructions are not known or not followed. The following safety instructions are to provide the user with the information
necessary for safe use and operation. Please read and retain these instructions for the continued safe use of your Power
Ratchet. Failure to follow instructions listed below may result in serious injury. In addition, make sure that anyone who uses
the equipment understands and follows these safety instructions as well.
Explanation of Safety Signal Words
WARNING:Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION:Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION:Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may
result in property damage.
NOTES:Provide clarity and helpful information.
Thank you very much for choosing an OEMTOOLS®Product!
For future reference, please register your new tool at www.oem-tools.com and complete the owner’s record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this
product before you begin using it. This product is designed for certain applications only. OEMTOOLS®cannot be responsible
for issues arising from modification. We strongly recommend that this product is not modified and/or used for any application
other than that for which it was designed. If you have any questions relative to a particular application, DO NOT use the
product until you have first contacted customer service to determine if it can or should be performed on the product.
WARNING:This product can expose you to chemicals, including lead, which are known to the State of California to
cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Operating Instructions and Parts Manual 24685
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself
and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in
personal injury and/or damage to product or property. Please retain instructions for future reference.
1
5/20
2020 OEMTOOLS®
12V LITHIUM-ION 3/8" SQUARE DRIVE
CORDLESS POWER RATCHET
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
UNPACKING
After unpacking unit, inspect carefully for any damage
that may have occurred during transit. Check for loose,
missing, or damaged parts. If any damage is observed, a
shipping damage claim must be filed with the carrier. DO
NOT use the OEMTOOLS®12V Lithium-ion 3/8" Square
Drive Cordless Power Ratchet if broken, cracked or
damaged parts (including labels) are noted. Any power tool
that appears damaged in any way, operates abnormally,
or is missing parts should be removed from service
immediately. If you suspect that the Power Ratchet was
subjected to shock load (a load that was dropped suddenly,
unexpectedly, etc.), immediately discontinue use until it has
been checked by a factory authorized service center.

2
Operating Instructions and Parts Manual 24685
5/20
2020 OEMTOOLS®
12V LITHIUM-ION 3/8" SQUARE DRIVE
CORDLESS POWER RATCHET
WARNING:Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result
in electric shock, fire, and/or serious injury. Save all
warnings and instructions for future reference.
WORK AREA SAFETY
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. DO NOT operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gas, or dust. Power tools create sparks which
may ignite the dust or fumes.
3. Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
1. Power tool plugs must match the outlet. Never modify
the plug in any way. DO NOT use any adapter plugs
with earthed (grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric shock.
2. Avoid body contact with earthed or grounded surfaces such
as pipes, radiators, ranges, and refrigerators. There is an
increased risk of electric shock if your body is earthed or
grounded.
3. DO NOT expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
4. DO NOT abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges, or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
5. When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of a ground fault circuit interrupter
(GFCI) reduces the risk of electric shock.
PERSONAL SAFETY
1. Stay alert, watch what you are doing, and use common
sense when operating a power tool. DO NOT use a
power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious
personal injury.
2. Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal
injuries.
3. Prevent unintentional starting. Ensure the switch is in
the OFF position before connecting to power source
and/or battery pack, picking up or carrying the tool. It is
dangerous to carry power tools with your finger on the
power switch or plug a power tool into a power outlet
while the power switch is in the ON position.
4. Remove any adjusting key or wrench before turning
the power tool ON. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
5. DO NOT overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
6. Dress properly. DO NOT wear loose clothing or jewelry.
Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewelry or long hair can be caught
in moving parts.
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
POWER TOOL SAFETY
1. DO NOT force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
2. DO NOT use the power tool if the switch does not turn it ON
and OFF. Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/or the
battery pack from the power tool before making any
adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
4. Store idle power tools out of the reach of children.
Power tools are dangerous in the hands of untrained
users. DO NOT allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
5. Maintain power tools. Check for misalignment or binding
of moving parts, breakage of parts and any other
condition that may affect the power tool’s operation. If
damaged, the power tool should be repaired before use.
Many accidents are caused by poorly maintained power
tools.
6. Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are easier to control
and less likely to bind.
7. Use the power tool, accessories and tool bits, etc. in
accordance with these instructions, taking into account
the working conditions and the work to be performed.
Use of the power tool for operations different from those
intended could result in a hazardous situation.
8. Hold power tools by insulated gripping surfaces when
performing an operation where the cutting tool may
contact hidden wiring or its own cord. Contact with a
“live” wire will make exposed metal parts of the tool “live”
and shock the operator.
BATTERY TOOL USE AND CARE
1. Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
2. Use power tools only with specifically designated battery
packs. Use of any other battery packs may create a risk of
injury and fire.
3. When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.

3
Operating Instructions and Parts Manual 24685
5/20
2020 OEMTOOLS®
12V LITHIUM-ION 3/8" SQUARE DRIVE
CORDLESS POWER RATCHET
4. Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
SERVICE
Have your power tool serviced by a qualified repair
person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
SPECIFIC SAFETY INSTRUCTIONS
WARNING:Know your cordless ratchet. DO NOT plug
in the charger or install the battery in the tool until you
read and understand this Instruction Manual. Learn the
tool’s applications and limitations, as well as the specific
potential hazards related to this tool. This will reduce the
risk of electric shock, fire, or serious injury.
WARNING:Always wear eye protection. Any power
tool can throw foreign objects into your eyes and cause
permanent eye damage. ALWAYS wear safety goggles
(not glasses) that comply with ANSI safety standard
Z87.1.
WARNING:To avoid fire or toxic reaction, never use
gasoline, naphtha, and acetone, paint thinner or similar
highly volatile solvents to clean the tool.
1. Use only accessories that are recommended for
this cordless ratchet. Follow the instructions that
accompany the accessories. The use of improper
accessories may result in injury to the operator or
damage to the tool.
2. If any part is missing or damaged, DO NOT plug the tool into
the power source or install any accessory until the missing or
damaged part is replaced.
3. Avoid awkward hand positions where a sudden slip
could cause your hand to move into the path of the
tool.
4. To avoid injury from accidental starting, always remove
the battery from the tool before installing or removing
an accessory.
5. It is recommended that impact sockets and
accessories are used with this tool. Never use
accessories that are not ANSI compliant.
6. Always check sockets and accessories for damage
or excessive wear. Worn accessories may cause an
unsafe working environment.
7. Never use this product in place of a torque wrench.
8. Keep the handle and body clean and free of oil and
grease. Always use a clean dry cloth when cleaning.
DO NOT use solvents, brake fluid, gasoline, or other
petroleum products to clean the tool. They will damage
the tool.
9. When wearing gloves, they must be tight fitting and slip
resistant. Leather gloves offer the best protection.
10. Always use two hands when operating this tool. Use
one hand on the handle and the other on the front of
the tool body.
11. Never place your hand so it is touching the socket or
accessory when the tool is turned ON.
12. Be ready for components to shift when removing any
fastener. The speed of the fastener removal could
cause unexpected shifting of the components.
13. DO NOT disassemble this tool. Take it to a qualified
professional when service or repair is required.
Incorrect reassembly may result in electric shock or fire.
14. Always charge the battery pack indoors in a well-
ventilated area. The charger must never be subjected
to wet conditions.
15. This tool vibrates. Repeated or long-term use can
cause temporary or permanent injury in hands, wrists,
arms, and shoulders. If there is any concern, always
reach out to a medical professional prior to use.
PURPOSE
The OEMTOOLS®12V Lithium-ion 3/8" Square Drive
Cordless Power Ratchet is used for tightening or
loosening nuts and bolts, automotive repair, body shop
maintenance, and other applications.
PRODUCT SPECIFICATIONS
Drive 3/8" Square Drive
Speed (No Load) 230 RPM
Max Powered Torque 35 Ft/Lb. (47 N•m)
Max Manual Torque 96 Ft/Lb. (130 N•m)
Battery 12V / 2.0 Ah Li-ion
Weight 1.9 Lbs.
Charge Time 5-6 Hrs. (7 Hrs. Full Charge)
CONTENTS
(1) Power Ratchet, (1) 12V / 2.0 Ah Li-ion Battery,
(1) Charger, (1) Blow Mold Storage Case
INSTRUCTION
1. Install the correct socket or accessory to the tool. Make
sure the accessory is fully engaged and not damaged.
Impact rated sockets and adapters are recommended.
2. Use the direction lever on the back of the ratchet head to set
the rotational direction desired.
3. Insert the fully charged battery into the handle of the
tool. Ensure the battery is fully engaged; there will be a
slight “click”.
4. Place the socket onto the fastener to be removed/
installed.
5. Slide the lock switch UP, to unlock the ratchet.
NOTE: Always check the vehicle maintenance manual for
torque requirements. This tool is not a torque wrench and will
overtighten low torque fasteners.
6. Hold the tool with both hands and squeeze the trigger.
NOTE: When tightening fasteners, DO NOT let the tool lock
out for more than 2-3 seconds. This can cause damage to the
fastener and/or tool.
7. Remove the tool from the fastener. Slide the lock
switch DOWN to lock the ratchet.

4
Operating Instructions and Parts Manual 24685
5/20
2020 OEMTOOLS®
12V LITHIUM-ION 3/8" SQUARE DRIVE
CORDLESS POWER RATCHET
Green
Light
Red
Light
Battery on
the Charger Charging Status
ON OFF NO Charger connected to the power supply
ON ON YES Battery charging
ON OFF YES Battery fully charged
Red Light ON Red and Yellow
Light ON
Red, Yellow, and
Green Light ON
< 1/3 Battery 2/3 Battery Full Battery Charge
MAINTENANCE
DO NOT attempt maintenance on this tool. Please call
OEMTOOLS®customer service at 1-866-458-2472 for
assistance if there is any issue with the tool.
DISPOSAL
At the end of the useful life of the tool, always dispose
of in accordance with federal, state and local and
regulations.
BATTERY DISPOSAL
Some countries have regulations concerning battery
disposal. Follow all applicable regulations. Return
used batteries to a collection location for recycling.
Call 800-822-8837 or visit www.call2recycle.org to find
a collection location.
POWER SOURCE CONNECTION POWER
REQUIREMENTS
This product is designed to operate on a properly
grounded 120 volt, 60Hz, single-phase alternating
current (AC) power source fused with a time delayed
fuse or circuit breaker. It is recommended that a qualified
electrician verify the ACTUAL VOLTAGE at the receptacle
into which the product will be plugged and confirm that
the receptacle is properly fused and grounded.
DO NOT OPERATE THIS PRODUCT if the ACTUAL
power source voltage is less than 105 Volts AC or greater
than 132 Volts AC. Contact a qualified electrician if this
problem exists. Improper performance and/or damage
to the product will result if operated on inadequate or
excessive power. DO NOT abuse cord. Never use the
cord to carry the tool or unplug the tool from a power
outlet. Keep cord away from heat, sharp edges, or
moving parts. Replace damaged cords immediately.
Damaged cords increase the risk of electric shock.
CHARGING THE BATTERY PACK
1. Place the discharged battery in a dry location near a
110-120V 60 Hz electrical outlet.
2. Slide the battery charging cap onto the battery. Slide
the charging cap as far as it will go onto the battery.
3. Plug the charger into the 110-120V/60 Hz wall
receptacle.
BATTERY CHARGE INDICATOR LIGHTS
BATTERY INDICATOR LIGHTS
WARNING:DO NOT charge batteries when the work
area or the battery temperature is at or below 32°F (0°C)
or above 113°F (45°C).
1. The green indicator light will turn ON indicating the
charger is “live.”
2. The green and red indicator lights will turn ON when the
charging cap is properly installed onto the battery.
3. If the indicator lights do not turn on, check to make sure
the charging cap is slid fully onto the battery and the
electrical outlet is working properly.
4. The green indicator light will remain ON and the red
indicator light will turn OFF when the battery is fully
charged.
5. The battery should be left on the charger for up to
6 hours or until the green indicator light turns ON to
ensure it is fully charged.
NOTE: It is normal for the battery charger to hum and be
warm to the touch during operation.
NOTE: If the battery pack does not charge properly, check
to make sure the electrical outlet is “live.”

5
Operating Instructions and Parts Manual 24685
5/20
2020 OEMTOOLS®
12V LITHIUM-ION 3/8" SQUARE DRIVE
CORDLESS POWER RATCHET
PRODUCT LAYOUT
Figure Description
A Ratchet Head
B 3/8" Square Drive
C Rotation Direction Lever
D LED Light
E Lock Switch
F Battery Level Indicator
G Trigger
H Battery
I Battery Release
J Charger (Not Depicted)
PARTS LIST
A
C
B
DEG
H
IF

6
Operating Instructions and Parts Manual 24685
5/20
2020 OEMTOOLS®
12V LITHIUM-ION 3/8" SQUARE DRIVE
CORDLESS POWER RATCHET
Figure Description Qty.
1Ratchet Head Assembly 1
2Planetary Gear Arm 1
3Planetary Gears 3
4Ring Gear 1
5Washer 1
6Fastener with Elastic Washer 2
7Motor Flange 1
8Central Drive Gear 1
9Motor 1
10 Power Switch 1
11 Terminal Plate 1
12 Connection Terminal 1
13 Discharge Terminal 1
Figure Description Qty.
14 Battery Pack 1
15 LED Board for Charge Indicator
and LED 1
16 Charge Indicator Cover 1
17 Trigger 1
18 Lock Switch Wire 1
19 Lock Switch 1
20 Housing 2
21 Housing Fasteners 2
22 Housing Fasteners 4
23 Housing Fasteners 2
24 Trigger Spring 1
25 Wire Insulating Shrink Tubing 1

7
Operating Instructions and Parts Manual 24685
5/20
2020 OEMTOOLS®
12V LITHIUM-ION 3/8" SQUARE DRIVE
CORDLESS POWER RATCHET
3580 E. Raines Road, Suite 3, Memphis, TN 38118
Tel: [phone]
www.oem-tools.com
CONTACT US
NOTES:

8
Operating Instructions and Parts Manual 24685
5/20
2020 OEMTOOLS®
12V LITHIUM-ION 3/8" SQUARE DRIVE
CORDLESS POWER RATCHET
OEMTOOLS®ONE YEAR WARRANTY
For up to one year from the original purchase of this OEMTOOLS®product, if you find any defect in material or
workmanship (through normal usage) return it to the place of purchase or to OEMTOOLS®for repair or replacement
at our discretion. In order to obtain this service, send your tool and proof of purchase (transportation pre-paid) to
OEMTOOLS®Q.A. Dept., 3850 Raines Road #3, Memphis, TN 38118. We will not be responsible for lost or damaged
goods during transportation; please insure your package. If our inspection verifies the defect, we will either repair or
replace the product, or we may elect to refund the purchase price if we cannot readily and quickly provide you with a
replacement. We will return repaired products at our expense, but if we determine there is no defect, or that the defect
resulted from causes not within the scope of our warranty, then you must bear the cost of returning the product.
OEMTOOLS®does not provide warranty for products labeled other than OEM®or OEMTOOLS®. OEMTOOLS®will
not provide any warranty for products subjected to abnormal use. Abnormal use includes (but is not limited to) abuse,
accident, alteration, neglect, and unauthorized or unreasonable use or repairs. This warranty does not cover bits,
blades, files, batteries, or calibration. We recommend that you maintain your tools and sharpen or replace blades, bits,
files, and batteries as necessary. OEMTOOLS®reserves the right to make any changes in construction or design at any
time without any obligation in incorporating such changes to tools or equipment previously sold.
OEMTOOLS®makes every effort to ensure that its products meet high quality and durability standards, and warrants
to the original purchaser that this product is free from defects in materials and workmanship for the period of one
year from the date of purchase. This warranty does not apply to damage due directly or indirectly to misuse, abuse,
negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear
and tear or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or
consequential damages arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you. THIS WARRANTY
IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may also have other rights,
which vary from state to state.
Don’t forget to register your new OEMTOOLS®product at www.oem-tools.com.
