OEM Tools 27311 Service manual

UNPACKING
After unpacking unit, inspect carefully for any damage that
may have occurred during transit. Check for loose, missing, or
damaged parts. If any damage is observed, a shipping damage
claim must be filed with carrier. DO NOT use the OEMTOOLS®
Power Steering and Brake Air Bleed Adapter Kit if broken, bent,
cracked or damaged parts (including labels) are noted. Any Power
Steering and Brake Air Bleed Adapter Kit that appears damaged
in any way, operates abnormally or is missing parts should
be removed from service immediately. If you suspect that the
Power Steering and Brake Air Bleed Adapter Kit was subjected
to shock load (a load that was dropped suddenly, unexpectedly,
etc.) immediately discontinue use until it has been checked by a
factory authorized service center.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself
and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in
personal injury and/or damage to product or property. Please retain instructions for future reference.
Operating Instructions and Parts Manual 27311
11/16
2016 OEMTOOLS®
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
POWER STEERING AND BRAKE
AIR BLEED ADAPTER KIT
Thank you very much for choosing an OEMTOOLS®Product!
For future reference, please register your new tool at www.oem-tools.com and complete the owner’s record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product
before you begin using it. This product is designed for certain applications only. OEMTOOLS®cannot be responsible for issues arising
from modification. We strongly recommend this product is not modified and/or used for any application other than that for which it was
designed. If you have any questions relative to a particular application, DO NOT use the product until you have first contacted customer
service to determine if it can or should be performed on the product.
WARNING: Pursuant to California Proposition 65, this product contains chemicals known to the state of California to cause
cancer and birth defects or other reproductive harm. Wash hands after handling.
The following safety information is provided as a guideline to help you operate your Power Steering and Brake Air Bleed Adapter Kit under the
safest possible conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or safe handling instructions are not
known or not followed. The following safety instructions are to provide the user with the information necessary for safe use and operation. Please
read and retain these instructions for the continued safe use of your tool. Failure to follow instructions listed below may result in serious injury. In
addition, make certain that anyone who uses the equipment understands and follows these safety instructions as well.
WARNING
Explanation of Safety Signal Words
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION: Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may
result in property damage.
NOTES: Provide clarity and helpful information.

2
Operating Instructions and Parts Manual 27311
POWER STEERING AND BRAKE
AIR BLEED ADAPTER KIT
11/16
2016 OEMTOOLS®
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your tool. Read this manual carefully. Learn the tool’s
applications and limitations, as well as, potential hazards
specific to it.
2. Keep work area clean and well lit. Cluttered or dark work areas
invite accidents.
3. Keep children away. All children should be kept away from
the work area. Never let a child handle a tool without strict
adult supervision.
4. Do not operate this tool if under the influence of alcohol or
drugs. Read warning labels on prescriptions to determine if your
judgment or reflexes are impaired while taking drugs. If there is
any doubt, do not attempt to operate.
5. Use safety equipment. Eye protection should be worn at all times
when operating this tool. Use ANSI approved safety glasses.
Everyday eyeglasses are NOT safety glasses. Dust mask, non-
skid safety shoes, hard hat or hearing protection should be used
in appropriate conditions.
6. Wear proper apparel. Loose clothing, gloves, neck-ties, rings,
bracelets or other jewelry may present a potential hazard when
operating this tool. Keep all apparel clear of the tool.
7. Don’t overreach. Keep proper footing and balance at all times
when operating this tool.
8. Check for damage. Check your tool regularly. If part of the tool is
damaged it should be carefully inspected to make sure that it can
perform its intended function correctly. If in doubt, the part should
be repaired. Refer all servicing to a qualified technician. Consult
your dealer for advice.
9. Keep away from flammables. Do not attempt to operate this tool
near flammable materials or combustibles. Failure to comply may
cause serious injury or death.
10. Store idle tools out of the reach of children and untrained persons.
Tools may be dangerous in the hands of untrained users.
11. Maintain tools with care.
12. Keep tools dry and clean.
13. Properly maintained tools are less likely to bind and are easier
to control. Do not use a damaged tool. Tag damaged tools
“Do not use” until repaired.
14. Check for misalignment or binding of moving parts, breakage of
parts, and any other condition that may affect the tool’s operation.
15. If damaged, have the tool serviced before using. Many accidents
are caused by poorly maintained tools.
16. Use only accessories that are recommended by the manufacturer
for your model. Accessories that may be suitable for one tool may
become hazardous when used on another tool.
17. Tool service must be performed only by qualified repair personnel.
Service or maintenance performed by unqualified personnel
could result in a risk of injury.
18. When servicing a tool, use only identical replacement parts. Use
of unauthorized parts or failure to follow maintenance instructions
may create a risk of injury.
19. Maintain a safe working environment. Keep the work area well lit.
Make sure there is adequate surrounding workspace. Keep the
work area free of obstructions, grease, oil, trash, and other debris.
Do not use this product in a damp or wet location.
20. Maintain labels and nameplates on this product. These carry
important information. If unreadable or missing, contact
OEMTOOLS®for a replacement.
21. Keep the handle dry, clean, and free from brake fluid, oil
and grease.
22. Before use, read and understand all warnings, safety precautions,
and instructions as outlined in the vehicle manufacturer’s service
manual. It is beyond the scope of this manual to properly describe
the correct procedure and test data for each vehicle.
23. Always perform vehicle service in a properly ventilated area.
Never run an engine without proper ventilation for its exhaust.
Stop work and take necessary steps to improve ventilation in the
work area if you develop momentary eye, nose, or throat irritation
as this indicates inadequate ventilation.
24. Engine parts that are in motion and unexpected movement of
a vehicle can injure or kill. When working near moving engine
parts, wear snug fit clothing and keep hands and fingers away
from moving parts. Keep hoses and tools clear of moving parts.
Always stay clear of moving engine parts. Hoses and tools can be
thrown through the air if not kept clear of moving engine parts.
The unexpected movement of a vehicle can injure or kill. When
working on vehicles always set the parking brake or chock
the wheels.
25. Be alert for hot engine parts to avoid accidental burns.
26. If you drove your car recently, fluids could be very hot. Allow at
least 2 hours before you handle any fluids. Oil and Coolant burns
are very dangerous.
27. Avoid accidental fire and/or explosion. Do not smoke near engine
fuel and battery components.
28. The warnings, precautions, and instructions discussed in this
manual cannot cover all possible conditions and situations that
may occur. The operator must understand that common sense
and caution are factors which cannot be built into this product,
but must be supplied by the operator.
29. For safety purposes and the prevention of damage to expensive
components it is advised that the user have an understanding of
basic automotive repair and a working knowledge of automotive
systems.
30. We believe the information contained herein to be reliable.
However, general technical information is given by us without
charge and the user shall employ such information at his own
discretion and risk. We assume no responsibility for results or
damages incurred from the use of such information in whole
or in part. Always refer to specific instructions and technical
information supplied by vehicle manufacturer.

3
Operating Instructions and Parts Manual 27311
POWER STEERING AND BRAKE
AIR BLEED ADAPTER KIT
11/16
2016 OEMTOOLS®
31. The manufacturer declines any and all responsibility for damage
to vehicles or components if said damage is the result of unskillful
handling by the operator or of failure to observe the basic safety
rules set forth in the instruction manual.
32. Used oil, antifreeze, brake fluid and transmission fluid contains
chemical compounds that can be harmful to humans and other
animals. When managed properly, used oil may again be of
beneficial use. Used oil may be blended and recycled as a heating
or industrial fuel and also may be re-refined and made into new
lubricants. Persons who perform maintenance on their own
vehicles are responsible for managing the used fluids in a manner
that is protective of human health and the environment and to
follow all local laws and regulations concerning their disposal.
DISPOSAL
At the end of the useful life of the OEMTOOLS®Power Steering
and Brake Air Bleed Adapter Kit, dispose of the components
according to all state, federal and local regulations.
PURPOSE
When coupled with a hand vacuum pump, these adapters allow
user to help remove trapped air in Power Steering and Brake
System components and lines.
PRODUCT SPECIFICATIONS
Reservoir Capacity: 4 oz.
POWER STEERING VACUUM BLEED PROCEDURE
1. Check and fill the pump reservoir.
2. Attach the 3-1⁄2" Clear Hose to the bottom of the Fluid
Reservoir Cap.
3. Attach the Fluid Reservoir Cap to the Fluid Reservoir.
4. Using the 1-1/2" Clear Hose, connect Fluid Reservoir Cap to
user supplied Hand Vacuum Pump.
NOTE: It is important to connect the Vacuum Pump to the Fluid
Reservoir Cap port that is NOT connected to the dip tube port on
the bottom the Fluid Reservoir Cap.
5. Determine which Rubber Stopper best fits your Power
Steering Pump Reservoir. Insert the Rubber Stopper tightly
into the Pump Reservoir fill neck.
6. Using the 24" Clear Hose, connect Fluid Reservoir assembly to
the Rubber Stopper.
WARNING
Make sure hose and pump are clear of all belts and other moving
engine parts before starting engine.
NOTE: When applying vacuum a small amount of fluid may collect
in the Fluid Reservoir. Be sure to monitor Fluid Reservoir and do
not allow fluid to completely fill the Reservoir.
NOTE: DO NOT allow fluid to be drawn into the Hand Vacuum
Pump. Damage to the Hand Vacuum Pump will occur.
NOTE: Be sure to hold the Vacuum Pump and Fluid Reservoir in
a vertical position. Otherwise fluid may bypass the Reservoir and
damage the Hand Vacuum Pump.
7. Apply 15" Hg. vacuum to the Power Steering Pump Reservoir
with the engine idling. Cycle the steering wheel from lock-
to-lock every 30 seconds for approximately five minutes. Do
not hold the steering wheel on stops while cycling. Be sure
to monitor the Vacuum Pump Gauge and maintain adequate
vacuum as the air purges.
8. Release the vacuum and remove the Rubber Stopper from
the Power Steering Pump Reservoir. Add additional fluid if
necessary and reinstall the Power Steering Pump Reservoir
Cap.
9. Restart the engine, cycle steering wheel and check for fluid
leaks.
NOTE: In severe cases of aeration, it may be necessary to repeat
this procedure several times.
BRAKE BLEEDING PROCEDURE
1. Assemble the components as above, attaching the Brake
Bleeder Adapter that best fits your bleeder screw.
2. Ensure the Master Cylinder is full of clean brake fluid.
NOTE: It is important to closely monitor the brake fluid level in
the master cylinder when bleeding brakes. If the brake master
cylinder reservoir is completely drained, you run the risk of
introducing additional air into the system.
3. Connect the Brake Bleeder Adapter to the bleeder screw
farthest from the master cylinder. On most vehicles this will be
the right rear.
4. Open bleeder screw and pump the Hand Vacuum Pump 10 to
15 times.
NOTE: DO NOT allow fluid to be drawn into the Hand Vacuum
Pump. Damage to the Hand Vacuum Pump will occur.
NOTE: Be sure to hold the Vacuum Pump and Fluid Reservoir in
a vertical position. Otherwise fluid may bypass the Reservoir and
damage the Hand Vacuum Pump.
5. After filling the Reservoir with about 2" of fluid, close the
bleeder screw and refill the master cylinder.
6. Drain the old fluid from the Reservoir.
7. Repeat the process until you see clean fluid with no bubbles
passing through the hose.
8. Repeat the entire process on each bleeder screw working
your way closer to the master cylinder each time.

4
Operating Instructions and Parts Manual 27311
POWER STEERING AND BRAKE
AIR BLEED ADAPTER KIT
11/16
2016 OEMTOOLS®
Parts List Parts Diagram
Figure Description Quantity
A 4 Oz. Fluid Reservoir 1
B 1-1/2" Clear Hose 1
C 3-1/2" Clear Hose 1
D 24" Clear Hose 1
E Fluid Reservoir Cap 1
F Small Rubber Stopper 1
G Large Rubber Stopper 1
HBrake Fluid Adapters 3
Note: Not all components of the Power Steering and Brake Air Bleed
Adapter Kit are replacement items, but are illustrated as a convenient
reference for location and position in the assembly sequence.
The manufacturer and/or its distributor have provided the parts list
and assembly diagram in this manual as a reference tool only. Neither
the manufacturer nor its distributor makes any representation or
warranty of any kind to the buyer that he or she is qualified to make
any repairs to the product, or that he or she is qualified to replace any
parts of the product. In fact, the manufacturer and/or its distributor
expressly states that all repairs and parts replacements should be
undertaken by certified and licensed technicians, and not by the
buyer. The buyer assumes all risk and liability arising out of his or her
repairs to the original product or replacement parts thereto, or arising
out of his or her installation of replacement parts thereto.
CONTACT US
3580 E. Raines Road, Suite 3, Memphis, TN 38118
Tel: [phone]
www.oem-tools.com
OEMTOOLS®ONE YEAR WARRANTY
If for up to one year from the date of purchase of this OEMTOOLS®product you find any defect in material or workmanship, through normal
usage, return it to the place of purchase, or to OEMTOOLS®for repair or replacement at our discretion. In order to obtain this service, send
your tool and proof of purchase, transportation pre-paid, to OEMTOOLS®Q.A. Dept., 3580 E. Raines Road #3, Memphis, TN 38118. We will not
be responsible for lost or damaged goods during transportation; please insure your package. If our inspection verifies the defect, we will either
repair or replace the product at our election, or we may elect to refund the purchase price if we cannot readily and quickly provide you with a
replacement. We will return repaired products at our expense, but if we determine there is no defect, or that the defect resulted from causes not
within the scope of our warranty, then you must bear the cost of returning the product.
OEMTOOLS®does not provide warranty for products labeled other than OEM®or OEMTOOLS®. OEMTOOLS®will not provide any warranty
for products subjected to abnormal use. Abnormal use includes, but is not limited to, abuse, accident, alteration, neglect, and unauthorized or
unreasonable use or repairs. This warranty does not cover bits, blades, files, batteries, or calibration. We recommend that you maintain your tools
and sharpen or replace blades, bits, files, and batteries as necessary. OEMTOOLS®reserves the right to makes any changes in construction or
design at any time without any obligation in incorporating such changes to tools or equipment previously sold.
OEMTOOLS®makes every effort to ensure that its products meet high quality and durability standards, and warrants to the original
purchaser that this product is free from defects in materials and workmanship for the period of one year from the date of purchase. This
warranty does not apply to damage due directly or indirectly to misuse, abuse, negligence or accidents, repairs or alterations outside our
facilities, criminal activity, improper installation, normal wear and tear or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may
also have other rights, which vary from state to state.
Don’t forget to register your new OEMTOOLS®product at www.oem-tools.com.
A
F
H
D
C
G
B
E
