oGrow OG03AL86-BKE User manual

OGrow Walk-in 6' x 8'
LAWN AND GARDEN
GREENHOUSE
With Heavy Duty Aluminium Frame
MODELS#
MANUAL VERSION # 2
OG03AL86-BKE
OGAL-866

Thank you for purchasing the OGROW™ greenhouse
Follow the assembly and safety instructions in this manual.
If you have any questions, please contact our Customer Service Department
Let's
Grow
Together!
Parts List.........................................
Side Walls.......................................
Back Wall........................................
Front Wall.......................................
Door Frame...................................
Roof and Full Structure.............
The Door.........................................
The Vents........................................
The Panels......................................
3-4
8
10
12
14
15
17
19
21
•
•
•
•
•
•
•
•
•
PAGE 2

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
PART# PART NAME PART
IMAGE QTY
4
1
1
1
1
1
1
1
1
6
6
1
4
1
1
1
Corner Beam
Front Right Roof Beam
Front Left Roof Beam
Rear Right Roof Beam
Rear Left Roof Beam
Right Doorway Support
Left Doorway Support
Rear Support Pole- Left
Rear Support Pole- Right
Side Support Pole
Roof Support Pole
Top Doorway Beam
Corner Bracket
Door Rail
Vent Support Bar
Rear Floor Bar
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
PART# PART NAME PART
IMAGE QTY
1
2
1
1
1
1
6
2
1
2
1
2
1
2
1
2
Front Floor Bar
Vent Stopper
Vertical Door Rail Support
Left Door Support
Rear Horizontal Support
Diagonal Support
Front Horizontal Support
Top Door Bar
Center Door Bar
Bottom Door Bar
Vent Side Bar
Door Slider
Front Diagonal Support
Vent Top Bar
Side Floor Bar
(Including Rollers)
PARTS LIST
PAGE 3
Right Door Support
20

PAGE 4
(See page 21)
PARTS LIST
32
33
34
39
40
41
42
43
44
PART# PART NAME PART
IMAGE QTY.
1
2
97
16
6
142
8
4
1
Top Roof Bar
Side Ceiling Plate
Bolt
Door Screw
Vent Screw
Panel Clip
Beam End Cap
Gutter End Cap
Long Door Support Bolt
45
47
48
49
50
51
52
A-I
PART# PART NAME PART
1
2
1
98
1
1
1
23
Door Frame Spacer
Spanner Wrench
Vent Brace
Nut
Vent Bottom Bar
Rail End Cap- Right
Rail End Cap- Left
Polycarbonate Panel
QTY.

NOTICE:
Read the entire IMPORTANT SAFETY INFORMATION section
at the beginning of this document – including all text under subheadings
– before set up or use of this product.
PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
KEEP THEM IN A SAFE PLACE WHERE YOU CAN REFER TO THEM AS NEEDED.
The warnings, precautions, and instructions discussed in this manual cannot cover all possible
conditions and situations that may occur. The user must understand that common sense and
caution are factors which cannot be built into this product, but must be supplied by the user.
Assembly/Installation Precautions
1. Assemble only according to these instructions. Improper assembly can create hazards.
2. Wear ANSI-approved safety goggles and heavy-duty work gloves during assembly. We recommend
that two people together assemble the greenhouse for a smooth and efficient assembly.
3. This unit contains pieces with sharp edges. The machined edges of the aluminium parts and the
ends of the panel clips may be sharp. Handle all parts carefully.
4. Keep assembly area clean and well lit.
5. Keep bystanders out of the area during assembly.
6. Do not assemble when tired or when under the influence of alcohol, drugs or medication.
8. Build the Greenhouse on a flat and level surface. A concrete foundation is recommended for a
high-quality installation.
9. WARNING: The brass bushings inside the Rollers of this product contain lead, a chemical known
to the State of California to cause birth defects (or other reproductive harm). (California Health &
Safety Code § 25249.5, et seq.)
IMPORTANT SAFETY INFORMATION
Use/Service Precautions
1. This product is not a toy. Do not allow children to play in or climb on this product. Although this
greenhouse does include protective covers, there are still some exposed sharp edges. In addi-
tion, protective covers may fall off over time. Children must be supervised if allowed near the
greenhouse.
2. SNOW/DEBRIS ACCUMULATION HAZARD. The heavy weight of accumulated snow or other debris
can cause parts of this greenhouse to buckle suddenly. Do not allow debris to accumulate on
top of the greenhouse. If snowfall is expected, place additional supports (not provided) under-
neath the Crown (32). NEVER enter a greenhouse with accumulated debris on top.
3. Use as intended only. The product capabilities only apply to a properly and completely assembled
product.
4. Inspect periodically; replace damaged parts immediately and do not enter greenhouse if parts
are loose or damaged.
!
PAGE 5
