OHAUS TD52 User manual

TD52 Indicator
Li-ion Battery Option
Instruction Manual
www. .com [e-mail]1.800.561.8187 www. .com [e-mail]1.800.561.8187

EN-1
1. INTRODUCTION
Please read this manual completely before installation and operation.
CAUTION:
READ ALL SAFETY WARNINGS BEFORE INSTALLING, MAKING
CONNECTIONS, OR SERVICING. FAILURE TO COMPLY WITH THESE
WARNINGS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY
DAMAGE. RETAIN ALL INSTRUCTIONS FOR FUTURE REFERENCE.
1.1 Kit Contents
Battery with attached
battery cover.
2. INSTALLATION
2.1 Safety Precautions
For safe and dependable operation of this equipment, please comply with all safety
precautions mentioned in this manual.
Disconnect equipment from mains power supply before installation.
www. .com [e-mail]1.800.561.8187 www. .com [e-mail]1.800.561.8187

EN-2
2.2 Installation procedure
Follow the steps below. Refer to the figures when performing these steps.
For TD52P:
1. Separate the indicator from the base by disconnecting the load cell cable from the male
connector at the back of the Indicator. Remove the interface option cover.
2. Connect the 7-pin Li-ion Battery Pack power cable to the main board battery connector
as shown.
Cable
Battery Connector
Arrow
Load cell cable male connector
Interface option cover
www. .com [e-mail]1.800.561.8187 www. .com [e-mail]1.800.561.8187

EN-3
3. Place the Li-ion Battery Pack so Slots 1 on the bottom right edge of the Battery Pack
align with the Rib on the bottom of the Indicator Option Area. Slide the Battery Pack to
the right (in the direction of the arrow) until the Slots engage with the Rib.
4. Twist the Li-ion Battery Pack cable a half turn and connect the 7 Pin connector from
the Indicator to the Battery Pack. Secure the Battery Pack with with one screw at the
location marked Boss Screw 9.
5. Put the interface option cover back on the terminal.
Li-ion Battery Pack 7 pin
connector
Screw
Arrow
Rib
Boss post 9
Slot 1
www. .com [e-mail]1.800.561.8187 www. .com [e-mail]1.800.561.8187

EN-4
For TD52XW:
1. Remove the interface option cover. Release the 6 screws with sealed washers.
2. Rotate the rear housing forward away from the front housing as shown.
Screw
Load cell cable male connector
www. .com [e-mail]1.800.561.8187 www. .com [e-mail]1.800.561.8187

EN-5
3. Connect the 7-pin Li-ion Battery Pack power cable to the main board battery connector
as shown.
4. Place the Li-ion Battery Pack so Slot 1 on the bottom right edge of the Battery Pack
align with the Rib on the bottom of the Indicator Option Area. Slide the Battery Pack to
the right (in the direction of the arrow) until the Slots engage with the Rib.
Cable
Battery connector
Slots 1
Arrow
Rib
Boss post 9
www. .com [e-mail]1.800.561.8187 www. .com [e-mail]1.800.561.8187

EN-6
5. Twist the Li-ion Battery Pack cable a half turn and connect the 7 Pin connector from
the Indicator to the Battery Pack. Secure the Battery Pack with with one screw at the
location marked Boss Screw 9.
Connect the cable to Li battery packing 7 pin connectors.
6. Put the rear housing back on the front housing. Re-install the 6 screws with sealed
washers.
For TD52XW withreversed rear cover:
1. Remove the 6 sealing screws to open the rear housing. Remove the M25 hole plug as
shown.
7 Pin Connector
Screw
Screw
www. .com [e-mail]1.800.561.8187 www. .com [e-mail]1.800.561.8187

EN-7
2. Take the rear housing down from the front housing as shown.
3. Connect the cable to the main board battery connector 3.
Cable
Battery connector 3
www. .com [e-mail]1.800.561.8187 www. .com [e-mail]1.800.561.8187

EN-8
4. Install the Li battery packing. Push it along the arrow. (Note: slot 2 match with the rib of
the red part).
5. Secure it with one screw (Note: Boss Post is 10). Connect the cable to Li battery
packing 7 pin connectors.
6. Put the rear housing back on the front housing. Re-install the 6 screws. Fasten the 6
screws with sealed washer (Torque is 1.8N*m± 0.5).
Slot 2
Rib
Boss post 10
7 Pin connector
screw
www. .com [e-mail]1.800.561.8187 www. .com [e-mail]1.800.561.8187

EN-9
3. BATTERY OPERATION
3.1 Battery Icon
During battery operation, the battery icon indicates the battery charge level remaining.
Battery 5 - 25 % remaining
Battery 25 - 50 % remaining
Battery 50 - 75 % remaining
Battery 75 - 100 % remaining
The battery icon is located above the weighing unit on the indicator display, as can be seen
in the image below.
When battery level is below 5% the indicator will shut down automatically.
It takes about 9 hours to fully charge the battery.
4. BATTERY SPECIFICATIONS
Battery Type:
Lithium-Ion, 2500mAh, 7.4V
Battery Operating Time:
21 hours* with backlight off
Battery Charging Time:
9 hours
Operating Temperature Range:
-20 °C ~ 60 °C (-4 °F ~ 140 °F)
Charging Temperature Range:
0°C ~ 45°C (32°F ~ 113 °F)
Note:
* The number of hours the balance can run on the battery depends on many factors.
Backlight, and Interface Options will all reduce the hours before a recharge is needed. For
optimum battery life, turn these features off.
Battery icon
www. .com [e-mail]1.800.561.8187 www. .com [e-mail]1.800.561.8187

EN-10
WARNING:
Stop charging the battery if charging is not completed within the
specified time.
Stop using the battery if the battery becomes abnormally hot, or if there
is an oder, discoloration or deformation.
Stop using the battery if abnormal conditions are detected during use,
charging or storage.
5. COMPLIANCE
Mark
Standard
This product complies with the applicable harmonized standards of EU
Directives 2011/65/EU (RoHS), 2014/30/EU (EMC). The EU Declaration of
FCC Note
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at their own expense.
Industry Canada Note
This Class A digital apparatus complies with Canadian ICES-003.
Disposal
In conformance with the European Directive 2012/19/EU on Waste Electrical
and Electronic Equipment (WEEE) this device may not be disposed of in
domestic waste. This also applies to countries outside the EU, per t
heir
specific requirements.
Please dispose of this product in accordance with local regulations at the
collecting point specified for electrical and electronic equipment. If you have
any questions, please contact the responsible authority or the distribut
or
from which you purchased this device.
Should this device be passed on to other parties (for private or professional
use), the content of this regulation must also be related.
Thank you for your contribution to environmental protection.
