Ohaus ES Series Bench Scale
INSTRUCTION MANUAL
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

3
Ohaus Corporation,
We, Ohaus Corporation, declare under our sole responsibility that the models listed below are in
conformity with the directives and standards mentioned.
Models: ES Series Bench Scales
Year in which the CE Mark was first Attached: 2001
Marking EC Directive (including applicable Standard
amendments)
73/23/EC EN609 0
Electrical equipment for use within Safety of information technology equipment
voltage limits
89/336/EC EN61326
Electromagnetic Compatibility Electrical equipment measurement, control and
laboratory use.
FCC NOTE: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 1 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL
INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS
EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY ENERGY AND, IF NOT
INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE
HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN A
RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL INTERFERENCE IN WHICH CASE THE USER
WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS A LIMITS FOR RADIO NOISE
EMISSIONS FROM DIGITAL APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING
EQUIPMENT STANDARD ENTITLED DIGITAL APPARATUS, ICES-003 OF THE DEPARTMENT
OF COMMUNICATIONS CANADA.
CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE BRUITS RADIOELECTRIQUES
APPLICABLES AUX APPAREILS NUMERIQUES DE CLASSE A PRESCRITES DANS LA NORME
SUR LE MATERIEL BROUILLEUR: APPAREILS NUMERIQUES, NMB-003 EDICTEE PAR LE
MINISTRE DES COMMUNICATIONS.
Unauthorized changes or modi ications to this equipment are not permitted.
Before plugging in the ES Series Bench Scale, make sure that the line voltage of the
power adapter and plug match.
ISO 9001 Registration or Ohaus Corporation. Ohaus Corporation, USA, was examined and
evaluated in 1994 by the Bureau Veritas Quality International, BVQI, and was awarded ISO 9001
registration. This certifies that Ohaus Corporation, USA, has a quality system that conforms with
the international standards for quality management and quality assurance (ISO 9000 series).
Repeat audits are carried out by BVQI at intervals to check that the quality system is operated in
the proper manner.
DECLARATION OF CONFORMITY
Ted Xia
President
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Ohaus ES Series Bench Scale
INSTRUCTION MANUAL
Models: ES6R, ES30R, ES50R, ES50L, ES100L, ES200L
 The contents of this manual applies to all models of the ES Series
Bench Scale.
 Calibration weights are not provided with the ES Series Bench
Scale.
 For best results, use the product within the specified optimum
operating temperature range.
 For best accuracy, perform your mass measurements in a clean
environment, free of electrostatic and magnetic fields, dust and dirt,
moisture, vibration and air currents.
 Use your ES Series Bench Scale with care, gently loading items to
be weighed on the center of the platform. Avoiding rough treat-
ment will aid in extending the life of your ES Series Bench Scale.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

6
Introduction
This manual covers operation and troubleshooting for the Ohaus
ES Series Bench Scale, models ES6R, ES30R, ES50R, ES50L, ES100L
and ES200L.
Unpacking
ES Series Bench Scale is shipped with the following components:
 Scale Base
 Indicator
 Power Adapter
 Mounting Bracket and Screws
 This Instruction Manual
 Warranty Card
 Plastic Insert
Leveling Scale Plat orm
Model ES 0L, ES100L and ES200L are equipped with adjustable
leveling feet. Adjust the four leveling feet under the platform to level it.
Power Options
AC Adapter Operation
 The 9 Volt output AC adapter (included with the ES Series
Bench Scale) with positive female plug shall be used.
 Connect the AC Adapter to the power input jack on the side of
the scale.
 Plug the AC Adapter into a properly grounded wall outlet.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

7
Battery Installation
 Remove the battery cover on the bottom of the indicator and
place six AA size alkaline batteries into the compartment as
indicated. Re-insert the battery cover.
 Batteries are not included.
Wall / Base Mount
 A Wall / base mounting bracket and screws are provided.
 When the indicator is fastened to the front of the base, make
sure to install the plastic insert underneath the indicator.
Plastic Insert
Operation & Product Features
Power Up Test: When the scale is turned on, all display
segments will appear for approximately 3 seconds before
resetting to zero or disappearing and 0 being displayed.
Stable Reading Indication: On the display, a down arrow will
appear in the lower left corner indicating that the weight
reading is stable. During weighing, this down indicator
disappears and will reappear once a stable reading has been
reached.
Weight Unit Indication: On the display, one of the four right
facing arrows on the right side will appear indicating the
weight unit selected: kg, lb, oz or lb:oz. (kg, lb or oz only for
ES200L)
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

8
Overload: If the applied load exceeds the capacity of the
scale, an E will appear on the display and the load should
be removed immediately. The scale will return to normal
operation.
Negative Value: When a load is removed from the scale, any
zeroed value will be displayed as a negative number. To
return to normal operation, the zeroed value can be cancelled
by pressing On/Off/Zero.
Zero Function: Values can progressively be added to a
sample. By pressing the On/Off/Zero key, the scale display
returns to zero. After adding additional mass, press On/Off/
Zero to zero the scale again. Additional mass may be added
up to the capacity of the scale. While removing the sample
from the scale, a total gross weight of the sample will be
displayed as a negative value. Zero the scale again before
subsequent usage.
Low Battery Indication: The display will show Lo when the
batteries are weak and need to be replaced.
Auto Shut-O : To extend battery life, the scale will automati-
cally turn off after approximately five minutes if no key press or
active weighing is occurring. This feature is only active with
battery operation.
Two Button Keypad
On/O /Zero: Pressing this key turns on the scale. The same
key operates the zero feature when the scale is ON. A long
press of three seconds will turn the scale off.
Units/Cal: Press this key briefly to change the weighing unit.
The following weight units may be selected: kilogram (kg),
pound (lb), ounce (oz), or pound:ounce (lb:oz), (kg, lb, or
oz only for ES200L). Pressing and holding this key longer will
start the calibration process.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

9
Calibration
For best results, calibrate the scale at regular intervals. This is espe-
cially important if the scale is in use for prolonged periods.
1. Allow the scale to warm up and stabilize for two
minutes before commencing the calibration
procedure.
2. Press and hold the Units/Cal key until CAL
flashes on the display.
3. Press the On/Off/Zero key to capture the scale
zero. The platform should be empty and the
display shows -C-
4. After the zero is captured, the display will show
xxx. The value xxx is the span calibration
weight.
. Place the calibration weight on the platform and
press On/Off/Zero key. The display will again
show -C-.
6. After span capture, the display will return to the
normal weighing mode.
NOTE: If CAL E appears on the display, a calibration
error has occurred and the process should be re-
peated. The message CAL E will appear if the
calibration steps are not followed in the correct order
or if an incorrect calibration weight was applied.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

10
Speci ications
ES6R ES30R ES50R
Capacity x Readability 6.000 x 0.002 kg 30.00 x 0.01 kg 0.00 x 0.02 kg
13.22 x 0.00 lb 66.10 x 0.0 lb 110.20 x 0.0 lb
211.6 x 0.1 oz 1,0 8.0 x 0. oz 1,763 x 1 oz
13 lb:3 oz x 1 oz 66 lb:2oz x 1 oz 110 lb:3 oz x 1 oz
Linearity ±0.002kg ±0.01kg ±0.02kg
Weighing Units kg, lb, oz, lb:oz
Calibration Auto calibration from keypad, 100% capacity weight required
Stabilization Time 3 seconds
Tare Range To capacity by subtraction
Maximum Overload 1 0% of capacity
Overload Indication [ E ]
Underload Indication Negative value
Auto Shut-off minutes no activity (battery operation only)
Optimum Operating Temperature 41° to 9 ° F / ° to 3 ° C
Platform Size 12.4 L x 11 W / 31.6cm L x 28cm W
Indicator Size 9.8 L x .  W x 2.7 H / 2 cm L x 14cm W x 7cm H
Power Requirements 6 AA Alkaline batteries
Net Weight 6 lb / 2.7 kg
ES50L ES100L ES200L
Capacity x Readability 0.00 x 0.02 kg 100.00 x 0.0 kg 200.00 x 0.1 kg
110.20 x 0.0 lb 220.4 x 0.1 lb 440.8 x 0.2lb
1,763 x 1 oz 3, 26 x 2 oz 7,0 0 x oz
110 lb:3 oz x 1 oz 220 lb:6oz x 2 oz N/A
Linearity ±0.02kg ±0.0 kg ±0.1kg
Weighing Units kg, lb, oz, lb:oz kg, lb, oz
Calibration Auto calibration from Auto calibration from keypad, 0% capacity
keypad, 100% capacity weight required
weight required
Stabilization Time 3 seconds
Tare Range To capacity by subtraction
Maximum Overload 1 0% of capacity
Overload Indication [ E ]
Underload Indication Negative value
Auto Shut-off minutes no activity (battery operation only)
Optimum Operating Temperature 41° to 9 ° F / ° to 3 ° C
Platform Size 20.  L x 1 .7 W / 2cm L x 40cm W
Indicator Size 9.8 L x .  W x 2.7 H / 2 cm L x 14cm W x 7cm H
Power Requirements 6 AA Alkaline batteries
Net Weight 30 lb / 13.6 kg
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

11
Troubleshooting
SYMPTOM PROBABLE CAUSE REMEDY
Unit will not turn ON. Power adapter not Check the power
plugged in or battery adapter.
low. Change batteries.
Incorrect weight reading. Scale was not re-zeroed. Press On/Off/Zero with no
weight on the platform.
Scale was not properly Recalibrate.
calibrated.
LIMITED WARRANTY
Ohaus ES Series Bench Scales are warranted against defects in materi-
als and workmanship for a period of 12 months from the date of
delivery. During the warranty period, Ohaus will repair, or, at its option,
replace any component(s) that prove to be defective at no charge,
provided that the product is returned, freight prepaid, to Ohaus.
This warranty does not apply if the product has been damaged by
accident or misuse, exposed to radioactive or corrosive materials, has
foreign material penetrating to the inside of the product, or as a result of
service or modification by other than Ohaus. In lieu of a properly
returned warranty registration card, the warranty period shall begin on
the date of shipment to the authorized dealer. No other express or
implied warranty is given by Ohaus Corporation. Ohaus Corporation
shall not be liable for any consequential damages.
As warranty legislation differs from state to state and country to country,
please contact Ohaus or your local Ohaus dealer for further details.
With offices worldwide.
Ohaus Corporation 2002, all rights reserved. P/N 71139461A
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]
