PAGE PRINTERS
OKIPAGE® 20 Series
The advanced
20 PPM printers
for medium
to large
workgroups.

Raise workgroup
productivity to
a higher level with
the OKIPAGE 20
Series Printers
from OKIDATA.
HIGHER SPEED AND ADVANCED FEATURES FOR GREATER PRODUCTIVITY.

The OKIPAGE 20 Series Workgroup Printers are built to
handle the rigorous demands of growing network printing
environments. For medium to large workgroups, the
OKIPAGE 20 Series offers a variety of features
designed to increase productivity. From the state-
of-the-art OkiLAN®network interface
with OkiVIEW®management software –
to two-sided duplex printing (standard on
the 20 DX and 20 DXn – optional on the 20), and
the 20’s large paper capacity, these printers perform.
The OKIPAGE 20 Series offers several models
configured out-of-the-box for duplex or network
applications, making it easy to get the right printer for
your network needs, now and in the future.
Designed to connect to a multitude of network
environments, and compatible with most operating
systems, OKIPAGE 20 Series Printers can be
configured for peer-to-peer workgroups,
individual users, or several network
servers. Their unsurpassed performance
in a variety of network applications
makes the OKIPAGE 20 Series the
printers of choice for workgroups serious
about productivity.
UNIX
Novell
20
OKIPAGE
20
OKIPAGE
20
OKIPAGE
20
OKIPAGE
Peer-to-Peer Networking
Networking with
an NT System
Client/Server Networking
DESIGNED TO FIT YOUR BUSINESS...
TODAY AND TOMORROW

KIDATA’s OKIPAGE 20
Series Printers are the
durable, high-speed network
printers designed to power up your
workgroup’s productivity. They’re
perfect for medium to large workgroups
that need higher speed and greater
throughput for shared/network environ-
ments. With the OKIPAGE 20 you get
faster print speed, advanced perfor-
mance features, network efficiency
and outstanding reliability that comes
from OKIDATA’s legendary tank tough
printhead technology – ensuring that
your OKIPAGE 20 will be on the job
– keeping you productive long after
other competitive printers have quit.
ADVANCED FEATURES ENHANCE
WORKFLOW AND CUT COSTS
The OKIPAGE 20 Printers are packed
with advanced perfor-
mance features and
smart, time-saving
options that speed
your group’s workflow
and make you more
efficient. Engineered
with greater print speed
and an exceptional
duty cycle for higher
volumes, the OKIPAGE 20 Series
Printers are rugged and built to run
long and fast. Business correspondence,
proposals, spreadsheets and complex
graphics print quickly and smoothly
with superlative resolution on a wide
variety of business media including
overhead transparencies, envelopes,
card and label stock. The 20 Series
gives you maximum paper handling
for excellent productivity. During
unattended print runs, especially in
shared environments, the OKIPAGE
20’s huge paper capacity keeps your
jobs rolling. Automatic tray linking
reduces reloading
intervention by sup-
porting up to three
separate “whole ream”
paper sources. Two
optional 530-sheet
paper trays and a multi-
purpose feeder option
create a total of five
paper sources to let you
construct practically any combination
of stocks you need in a document:
letterhead in the first tray; standard
sheets in the second; invoices in the
third; and envelopes in the multi-
purpose feeder, or practically any other
way you want to do it. It’s a smart way
to boost your productivity.
OKIPAGE 20 configured with
optional 2nd tray mechanism.
Standard Tray: 530 sheets
Manual Feed: 100 sheets
2nd Tray: 530 sheets
Paper capacity shown: 1160 sheets
Network Interface Card –
a productivity enhancing option.
O
•Fast 20 pages-per-minute speed
•True 600 dpi and 600 x 1200
dpi graphics
•Long-running 50,000 pages/month
duty cycle
•Outstanding connectivity to most
popular network environments:
Novell Netware®, NT®, Unix®, OS/2®
•Supports Windows®NT 4.0/3.51,
Windows 95 and 3.1x operating systems –
and Macintosh®via PostScriptTM option
•Duplex printing – prints both sides of a
sheet (standard on OKIPAGE 20DX and
20DXn – optional on OKIPAGE 20)
•Optional flash memory for forms,
barcodes, graphics and more
•4MB RAM standard – upgradable
to 68MB
OKIPAGE® 20

DOUBLE UP ON EFFICIENCY
WITH DUPLEXING
The OKIPAGE 20’s optional duplexer
enhances your speed and efficiency even
more by enabling you to print both
sides of a sheet – saving time, cost
and natural resources. That translates
directly to your bottom line – reducing
your cost per copy and lowering total
cost of ownership. Even for smaller
workgroups the savings add up quickly.
MEMORY THAT SAVES TIME
AND MONEY
The OKIPAGE 20 can simplify
practically any job – making short work
of even complex, memory-intensive
projects. If you need additional memory,
just plug it in – and with flash memory
options you can store and print forms,
signatures, special fonts – even barcodes
can be accessed instantly during print-
ing. It’s a tremendous savings in time
and cost that can practically eliminate
the need for pre-printed forms.
ITWORKS THE WAY YOU DO
The OKIPAGE 20 Series network
functionality works to your advantage.
Easy-to-install network cards make
it a snap to add users, and the 20 is
versatile and flexible enough
to accommodate a wide
variety of network
configurations. It works the
way you do – optimizing your particular
workgroup’s style and flow, giving each
user uninterrupted access to the print-
er. The OKIPAGE 20 Printers support
all major operating systems and are
compatible with most custom and
off-the-shelf software – so you’ll look
good in any environment. If you want
Adobe®PostScriptTM Level 2, it’s an
easy snap-in upgrade as well.
BETTER SUPPORT ALSO
MEANS HIGHER PRODUCTIVITY
OKIPAGE 20 Series Printers are
engineered to give you years of depend-
able high-quality printing even under
the most punishing multi-user condi-
tions. Built into your OKIPAGE 20 is
OKIDATA’s legendary reliability with
a 5-Year Limited Printhead Warranty.
And wrapped around the entire printer
is a 1-Year On-site Limited Warranty
to keep your business up and
running. And OKIDATA goes
even further, with toll-free
customer technical support
24 hours-a-day/7 days-a-
week…because we know your
business depends on your printer.
THE CLEAR CHOICE
Speed, efficiency, ease of use, warranty
and support...they all add up to make
the OKIPAGE 20 Series Workgroup
Printers the clear choice for your high-
productivity network.
OKIPAGE 20DXn configured with
standard duplexer and optional
second and third tray mechanisms
and multi-feeder.
Standard Tray: 530 sheets
Manual Feed: 100 sheets
Multi-Feed: 100 sheets
2nd Tray: 530 sheets
3rd Tray: 530 sheets
Paper capacity shown: 1790 sheets
OKIPAGE® 20DXn
Fonts
Flash memory lets you store and print
forms, unique bar codes and signatures.

OKIPAGE 20 DX FEATURES SAME AS STANDARD
OKIPAGE 20 WITH DUPLEX PAPER MECHANISM.
OKIPAGE 20 DXn HAS BOTH DUPLEX
MECHANISM AND ETHERNET NETWORK ADAPTER
CARD AS CONFIGURED.
PERFORMANCE
PRINT SPEED:20 PAGES PER MINUTE
PRINT RESOLUTION:600 DPI WITH 600 X1200
GRAPHICS
ENDURANCE: 50,000 PAGES PER MONTH
RESIDENT MEMORY: 4 MB STANDARD RAM;
68 MB MAXIMUM RAM
COMPATIBILITY:HP®LASERJET®4000 SERIES
EMULATION (PCL®6 COMPATIBLE); IBM®PRO-
PRINTER III XL AND EPSON FX (9-PIN COMPATIBLE)
MICROPROCESSOR/SPEED (MHZ): MIPS
R3000/40
INTERFACING
INTERFACES:BI-DIRECTIONAL PARALLEL PORT,
IEEE-1284 COMPLIANT; INTERNAL SERIAL
INTERFACE RS232-C.
PAPER HANDLING
STANDARD PAPER INPUT:530-SHEET
LETTER/LEGAL/UNIVERSAL TRAY
MANUAL FEED INPUT:100 MULTI-SHEETS;
10 ENVELOPES; MAILING LABEL STOCK;
OVERHEAD TRANSPARENCIES
STANDARD PAPER OUTPUT:
250 SHEETS, FACE DOWN
ALTERNATE PAPER OUTPUT:
100 SHEETS, FACE UP
PAPER WEIGHT:16-28 LB MAIN TRAY;
16-36 LB MULTI-MANUAL FEED;
16-28 LB 2ND/3RD TRAY; DUPLEX 16-24 LB
RESIDENT FONTS
SCALABLE FONTS: 35 PCL SCALABLE FONTS;
10 TRUETYPE SCALABLE FONTS
BITMAP FONTS: 4 FONTS (LINE PRINTER,
USPS POSTNETTM BARCODE, OCR-A, OCR-B)
ENVIRONMENTAL
SIZE (WXDXH): 14.4” X18.2” X13.0”
(366MMX462MMX331MM)
WEIGHT:42 LB (19.0 KG)
POWER: 120 VAC 50/60 HZ, 230 VAC
50/60 HZ
WARRANTY
1-YEAR LIMITED ON-SITE WARRANTY ON PARTS
AND LABOR
5-YEAR LIMITED LED PRINTHEAD WARRANTY
RELIABILITY
TONER CARTRIDGE LIFE:5,000 PAGES
(5% DENSITY)
IMAGE DRUM LIFE:30,000 PAGES
(CONTINUOUS PRINTING)
OPTIONS AND ACCESSORIES
MEMORY UPGRADE:4, 8, 16 MB SIMMSUSING
STANDARD 72-PIN MEMORY MODULES OR FLASH
MEMORY SIMM
NETWORK INTERFACE CARDS:OkiLAN® 510e
ETHERNET®NETWORK ADAPTER CARD; OkiLAN®
NETWORK UTILITY SOFTWARE ALSO INCLUDED
PAPER TRAYS:530-SHEET LEGAL/UNIVERSAL
2ND/3RD TRAY MECHANISM (16-28 LB);
100-SHEET/50-ENVELOPE POWER FEEDER.
ORDERING INFORMATION
OKIPAGE 20 PRINTER:
120V (ENGLISH)62413201
220V (MULTI-LINGUAL)62413202
120V (MULTI-LINGUAL)62413203
OKIPAGE 20 DX PRINTER:
WITH DUPLEX MECHANISM:
120V (ENGLISH)62413204
220V (MULTI-LINGUAL)62413205
120V (MULTI-LINGUAL)62413206
OKIPAGE 20 DXn PRINTER:
12 MB RAM, POSTSCRIPTTM, WITH DUPLEX
MECHANISM AND ETHERNET NIC I/F:
120V (ENGLISH)62413207
220V (MULTI-LINGUAL)62413208
120V (MULTI-LINGUAL)62413209
MEMORY/UPGRADE:
4 MB SIMM 70028801
PAPER TRAYS:
2ND AND 3RD PAPER TRAY MECHANISM
(530-SHEET) 40346401
MULTI-PURPOSE FEEDER 40352801
DUPLEX FEEDER 70033301
SUPPLIES:
TONER “TYPE 7 SERIES”40468801
IMAGE DRUM CARTRIDGE
“TYPE 7 SERIES”40468701
IEEE-1284 BI-DIRECTIONAL
PARALLEL I/F CABLE 70000803
INTERFACE CARDS:
ADOBE®POSTSCRIPT
LEVEL 2 SIMM KIT 70032701
OKILAN 510e ETHERNET NETWORK
ADAPTER CARD 70032801
FLASH MEMORY SIMM 4 MB 70032601
FLASH MEMORY SIMM 8 MB 70033201
Specifications are subject to change without notice. OKIDATA, OKIPAGE, OkiVIEW,
OkiLAN Reg. T.M., OKI Electric Industry Company, Ltd.; PCL Reg. T.M. Hewlett
Packard Company; Epson Reg. T.M. Seiko Epson Corp.; Proprinter, OS/2 Reg.
T.M. International Business Machines Corp.; TrueType Reg. T.M. Apple Computer,
Inc.; Ethernet Reg. T.M. Digital Equipment Corp.; Adobe Reg. T.M., PostScript
T.M. Adobe Systems Inc.; Novell, Netware, Unix Reg. T.M. Novell Corp.; Energy
Star T.M. U.S. EPA.
© 1998 OKIDATA, Division of OKI America, Inc.
Printed in the U.S.A. MS-9861/0198
As an Energy Star Partner,
OKIDATA has determined
that this product meets
the Energy Star guidelines
for efficiency.
